ROA G102 The Crunch User manual

In Out
Gain
High
Low
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
1
1
2
3
6
5
4
7
8
9
Controls
1. Mounting holes
2. External switch jack socket
3. Input jack socket
4. Output jack socket
5. LED, red when effect turned-on
6. Bypass mode switch
7. Low cut/boost knob
8. High cut/boost knob
9. Gain knob controls the level of
gain of the effect
Description
-High gain opamp Boost/Fuzz with Baxandall Filter
-Sound ranges from mildly Fuzzy to raunchy crunch
Installation
The G102 The Crunch is designed to be used in the G100
Modular Effect System.
1. Unplug the Base Unit power cord
2. Locate an empty slot
3. Plug the 4-pin socket into an available connector on
the BusBoard
4. Place the module in the base unit and secure with two
M3x8mm bolts
G102 The Crunch
Turning the Effect On/Off
The effect has a relay based true-bypass. The effect can
be turned-on by toggling the Bypass-mode switch to the
right. In this mode the effect is always on. Toggle the
switch to the left to use an external control, like a foot
control, to remotely turn-on and turn-offthe effect. The
external switch control must be of the ‘make’ type. In
either case the red led lights up when the effect is
enabled.
Usage
Run a cable from the guitar to the In jack socket.
Run a cable from the Out jack socket to the amplifier.
Start with all controls at 12 o’clock
Turn-on the effect
Rotate the Volume knob clockwise to increase the output
level and counterclockwise to decrease it
Rotate the Gain knob clockwise to increase the level of
overdrive and counterclockwise to decrease it.
Rotate the Low knob clockwise to boost bass tones up to
+12dB. Turn it counterclockwise to decrease bass tones
up to -12dB.
Rotate the High knob clockwise to boost high tones up to
+12dB. Turn it counterclockwise to decrease high tones
up to -12dB.

Examples
Dark Rythm
In Out
GainHighLow
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
Power Lead
In Out
Gain
High
Low
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
Crazy Fuzz
In Out
GainHigh
Low
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
__________
In Out
GainHighLow
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
__________
In Out
GainHigh
Low
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
__________
In Out
GainHigh
Low
The Crunch
G102
11.2
11.2 11.2
7.1
7.1
7.1
ROAROA
G102
Feel The Sound
G102 The Crunch
