Road Angel Halo User manual
User Guide
02
ROAD ANGEL Group Ltd has made every eort to ensure that all the information
contained in this manual is accurate and reliable. However, the information is
subject to change without notice.
ROAD ANGEL Group Ltd assumes no responsibility for any damage or injury
resulting from the use of this product.
Under no circumstances should ROAD ANGEL products be operated by the driver
whilst the vehicle is in motion.
No part of this publication may be copied, distributed, transmitted or transcribed
without the permission of ROAD ANGEL GROUP Ltd.
UV/solar reective screens block GPS signals from entering the vehicle and may aect
the operation of your ROAD ANGEL Halo. Heated screens can also aect GPS signal
strength.
Copyright 2015 ROAD ANGEL GROUP Ltd. All rights reserved.
DISCLAIMER & COPYRIGHT
03
WARRANTY & REGISTRATION
Your ROAD ANGEL Halo is guaranteed for one year from the date of purchase from
all manufacturing defects that occur with normal use. If your unit fails to perform as
specied in this user guide, please visit:
www.roadangelgroup.com or call 01327 855586.
Your device is supplied with a 12 month warranty starting from the date of purchase.
To activate this please log on and register your unit for free at www.roadangelgroup.com.
Activation of the warranty and/or continued use of this product by you, will constitute
full acceptance of the Disclaimer and Copyright notice and the terms there under.
If this product is installed in a vehicle that is used by people other than yourself, you
accept and agree without reservation that it is your obligation to notify other vehicle
users as to the safe working usage of this product.
ROAD ANGEL and Halo are trademarks or registered trademarks of ROAD ANGEL
GROUP Ltd.
Product Disposal Instructions
The symbol shown here and on the product means that it is classed as Electrical
or Electronic Equipment and should not be disposed with other household or
commercial waste at the end of its working life.
The Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) has
been put in place to recycle products using best available recovery and recycling
techniques to minimise the impact on the environment, treat any hazardous substances
and avoid the increasing landll.
For more information please contact your local authority or the retailer where the
product was purchased.
This product has been designed to comply with international directives on
the Restriction of Hazardous Substances (RoHS) and has been designed and
type-tested to comply with EU requirements and carries a CE mark.
ENVIRONMENTAL & COMPLIANCE
04
SAFETY PRECAUTIONS
• Do not disassemble or modify this product
• Only use this product with the power cables supplied
• Avoid small objects and liquids from entering the product
• Do not leave this product in direct sunlight for prolonged periods of time or exposed
to excessively high temperatures
• Ensure that this product does not obstruct your view of the road
05
THANK YOU FOR CHOOSING ROAD ANGEL HALO
06
With‘crash for cash’ scams on the increase and payouts worth £400m a year, it’s never
been more important to record your journeys on the road and be prepared for any
incidents that may occur along the way. Crash for cash claims add on average £14 to
each of our premiums, but if you’re unlucky enough to be personally victimised,
not only is your health at risk but your insurance premium could rise by up to 30%.
ROAD ANGEL Halo is specically designed to ght back against fraudulent claims as
a simple, discreet accident camera suitable for use in any vehicle. Halo continuously
records and saves footage as you drive, and in the event of an accident uses G-Force
sensors to capture the footage in an event le. This footage is then saved separately
and can later be used as evidence in a claim.
07
With built-in GPS technology and Google Maps, Halo is able to pin-point where
your vehicle was and the GPS speed it was travelling at the time of an accident*.
The optional sound recording feature also means, if switched o, you can retain your
privacy as you drive. Both cameras allow for clear, reliable footage with viewing
angles of 150°, a HD resolution of 1280p x 720p in the forward facing camera and
640p x 480p in the rear.
* UV/solar reective screens block GPS signals from entering the vehicle and may aect
the operation of your ROAD ANGEL Halo. Heated screens can also aect GPS signal
strength.
Halo Features..................................................................................................................10
Package Contents.........................................................................................................12
01. Before you start
Product registration.....................................................................................................14
Preparing for use ..........................................................................................................14
Anatomy of Halo ...........................................................................................................15
Camera installation .....................................................................................................16
02. Using Halo
Start-up sequence........................................................................................................19
Micro SD card.................................................................................................................19
Real time recording......................................................................................................20
Manual recording .........................................................................................................21
Event recording.............................................................................................................22
CONTENTS
08
Parking mode recording ............................................................................................23
Micro SD card removal................................................................................................25
Power removal...............................................................................................................25
03. Using Halo Player
Installing Halo Player...................................................................................................29
Halo Player operation..................................................................................................30
Halo device setup.........................................................................................................33
04. Other Information
Control button overview ...........................................................................................35
LED guide ........................................................................................................................36
Voice / audible alert guide .......................................................................................37
09
HD resolution, high quality video recording
Front camera includes CMOS imaging sensor allowing high quality HD (1280 x 720)
recording at 20 fps
Rear camera allows (640 x 480) recording at 10fps
Wide angle
150° horizontal wide angle camera lens
Built-in high sensitivity microphone
Voice recording along with video recording
Optional privacy button
Multiple recording modes
Real time recording, Event recording, Manual recording, Motion sensor recording
(enabled when in Parking mode, Parking mode only available when used with Halo
hardwire kit)
Built-in 3 axis acceleration sensor
Detects external impact using 3 axis sensor and activates Event recording
HALO FEATURES
10
Built-in back-up battery
In the event of an incident, the Road Angel Halo will use its small internal battery to
continue the event le recording*
Built-in GPS
Video recording with accurate location, date and time
Instructive User Interface
Provides LED indications, sound eects, and voice prompts
PC Application
Allowing product conguration and video playback
* Please note: If power is removed the length of the clip recorded will be determined by battery charge at the time
of event.
HALO FEATURES
11
Halo Front Camera
USB Stick Containing
User Manual and Halo
Player Software
Quick-Start Guide Rear Camera
(With Connection Lead) 10 x Adhesive Wire Clips
In-Car Power Cable 16GB Micro SD Card USB Micro SD Card Reader
PACKAGE CONTENTS
12
Product registration
Preparing for use
Anatomy of Halo
Camera installation
1
BEFORE YOU START
13
BEFORE YOU START
Product Registration
Before operating Halo please visit our website at www.roadangelgroup.com to register
your product and activate your 12 month warranty.
Preparing for use
Remember to check the camera position and angle before operation.
Video quality may degrade with severe backlight, at night or when
you enter dark environments such as tunnels, car parks etc.
Excessive window tinting may aect the quality and colour balance
of video.
Ensure that your windscreen is clean (inside and out) for the best
possible video quality.
14
15
1. Power connector
2. Micro SD card slot
3. Control button
4. Camera lens
5. Mounting bracket
6. LED indicator
7. Microphone
8. Rear camera port
Anatomy of Halo
1
8
6
3
5
4
7
2
Camera Installation
1. Inserting the memory card
Insert the supplied Micro SD card into the slot as per the
illustration on the right, being careful to insert it the correct
way around. Inserting the Micro SD card will automatically
format the card for use with Halo.
2. Installing Halo in your vehicle
It is recommended that Halo is mounted in an elevated
position in your vehicle, with a location between the rear
view mirror and the windscreen being particularly eective.
Halo is axed to the windscreen using the sticky pad
supplied. Simply remove the backing material and apply
pressure to ensure a secure x.
16
BEFORE YOU START
17
3. Powering Halo
Using the power lead supplied, plug Halo into your vehicle’s
cigarette lighter socket. A red LED will illuminate and an
audible alarm will sound. The red LED will then change to
blue, signifying that Halo has commenced recording.
4. Camera angle and cable management
Pay particular attention to the angle of the camera to
ensure that it has an unobstructed line of sight and is angled
correctly to cover the widest possible viewing area.
Use the self-adhesive wire retention clips supplied to
channel any visible cables away from your eld of view
and to maintain a tidy interior. Alternatively cables can be
hidden in the vehicle by a professional installer.
USING HALO
18
Start-up sequence
Micro SD card
Real time recording
Manual recording
Event recording
Parking mode recording
Micro SD card removal
Power removal
2
19
Start-Up Sequence
Apply power to Halo, a red LED will illuminate and an audible alarm will sound to denote that
Halo is powering up. The red LED will then change to blue, signifying that Halo has
commenced Real time Recording mode.
Micro SD Card
If no SD card is detected, Halo will alternate between RED and BLUE LED illumination.
A voice alert will instruct you to insert a Micro SD Card.
ALTERNATING BETWEEN RED and BLUE LEDs: No Micro SD Card in device
BLUE: RecordingRED: Powering Up
USING HALO
Real time recording:
Halo begins real time recording automatically on power up,
this is indicated with a BLUE LED.
During real time recording:
Pressing the Control Button once turns the microphone on/o.
Pressing the Control Button twice activates Manual Recording mode.
Pressing and holding the Control Button formats the Micro SD card.
In Real time recording mode Halo will continue to save individual les
(each 60 seconds in length) and starts to overwrite the oldest les when
the folder on the SD card reaches the set storage allotment.
BLUE: Recording
