INSTALL INSTRUCTIONS
Spartan Rear Bumper
Product : 4102XR
Applicaon : 2010 — 2018 Ram 2500, 3500

2010—2018 Ram 2500, 3500 (V.20180413) Page ( 2 of 12 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
SAFETY FIRST!
• FOLLOW ALL INSTRUCTIONS, YOUR SAFETY AND THE SAFETY OF OTHERS IS MOST IMPORTANT.
• WEAR APPROPRIATE EYE PROTECTION AND EXERCISE CAUTION WHEN DRILLING / CUTTING
REQUIRED TOOLS
INCLUDED HARDWARE
I WARNING
Read the instrucons completely before beginning installaon. Before ghtening bolts,
drilling or cung where required, check to make sure there are no obstrucons such as
brake, fuel or electrical lines which may be damaged. Also keep in mind this is an aer-
market product and MAY require minor shimming and/or trimming, reaming, etc. for
proper t. Road Armor is not responsible for any damages to vehicle.
 IMPORTANT NOTICE
• Be sure to inspect and test t your product to ensure proper tment before having it coated, painted, bed
lined, etc.
• Road Armor will not be responsible for the cost of coang your unit if any problems with t or nish are not
noted and addressed beforehand.
Metric & Standard Socket Set Pick/Screw Driver (for sensor removal)
61/2"-13 x 1-1/2" Grade 8 Yellow Zinc Finish
16 1/2" x 1.062" OD Thru-Hardened Yellow Zinc
10 1/2" Yellow Zinc Finish High Alloy Medium
10 1/2"-13 Yellow Zinc Finish Grade 8 Finished
81/4"-20 x 3/4" ASTM F879 Hex Drive Grade 18
81/4"-20 Zinc Finish Steel with External Tooth
2License Plate Light
4#8-32 x 3/4" ASTM F879 Hex Drive Grade 18-8
Stainless Steel Flat Socket Cap
4#8-32 Zinc Finish Steel with External Tooth
41 1/8" Dome Plug
4#10-24 x 3/4" ASTM F879 Hex Drive Grade 18-
4#10-24 Zinc Finish Steel with External Tooth
41.5" Single Bolt Tab (ZINC)
4M6 x 16mm Phillips Hex Washer Head Tap
41/4" (14) Screw Size License Plate Nut White

2010—2018 Ram 2500, 3500 (V.20180413) Page ( 3 of 12 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
NOTE: Bumper will be removed
during this step. Be prepared to
hold bumper in place and remove
once bolt plates are removed.
1Disconnect wire harness from license plate lights. Repeat this step for the other side of the
bumper.
2Disconnect wire harness from trailer wire plug. Once the wire harness is disconnected, push in the
clips on both sides of the plug and remove plug from bumper.
3Using a 15mm socket remove the two bolts that hold the bumper mounts to frame. Repeat step
for other side of bumper.
4Using a 15mm socket remove the two bolts which are located where the license plate mounts to
bumper. Once they are removed the bumper can be removed from truck.

2010—2018 Ram 2500, 3500 (V.20180413) Page ( 4 of 12 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
5Install factory sensors (if equipped), trailer pin, aermarket light, and license plate lights.
6Install the bolt on bracket onto the bumper assembly using the (3) 1/2” bolt tabs per side. Tighten
enough to allow for adjustability.
7Insert (2) 1/2” bolt tabs per side into the frame brackets and secure in place with the 1/2” retaining
nuts.
8Place bumper onto truck and aach the 1/2” hardware (at washer, split lock washer, and nut) to the
frame brackets.
9Adjust le/right rst and ghten frame brackets. Then adjust up/down and in/out and ghten the 3
1/2” bolts per side.
10 Wire in aermarket license plate lights into factory harness and reaach wiring harness to truck.
Make sure to secure any loose wiring.
Driver’s Side
