Road Armor Stealth 611 Series Configuration guide

Page ( 1 of 3 )
INSTALL INSTRUCTIONS
Stealth Front Bumper
Product : 611XXX
Applicaon : 2011-2016 Ford Super Duty

2011-2016 Ford Super Duty (V.20161219) Page ( 2 of 3 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
SAFETY FIRST!
 FOLLOW ALL INSTRUCTIONS, YOUR SAFETY AND THE SAFETY OF OTHERS IS MOST IMPORTANT.
 WEAR APPROPRIATE EYE PROTECTION AND EXERCISE CAUTION WHEN DRILLING / CUTTING
REQUIRED TOOLS RECOMMENDED TOOLS
INCLUDED HARDWARE
I WARNING
Read the instrucons completely before beginning installaon. Before ghtening bolts,
drilling or cung where required, check to make sure there are no obstrucons such as
brake, fuel or electrical lines which may be damaged. Also keep in mind this is an aer-
market product and MAY require minor shimming and/or trimming, reaming, etc. for
proper t. Road Armor is not responsible for any damages to vehicle.
 IMPORTANT NOTICE
 Be sure to inspect and test t your product to ensure proper tment before having it coated, painted, bed
lined, etc.
 Road Armor will not be responsible for the cost of coang your unit if any problems with t or nish are not
noted and addressed beforehand.
SAE & METRIC Socket set and wrenches Adjustable Table Cart / Table/Pallet Li or Hoist
Screw drivers, pry tool, pick tool, pliers Impact driver
(14) 1/2” x 1.5” Grade 8 Bolt Plates
(14) 1/2” Washers
(14) 1/2” Lock Washers
(14) 1/2” Hex Nuts
(4) Keeper Washers
(1) Winch and Logo Kit
(6) 7/16” Bolts (6) 7/16” Washers
(6) 7/16” Lock Washers
(2) Triple Nut Plates
(1) 1/4” Bolt and Lock Nut (608 Applicaon Only)

2011-2016 Ford Super Duty (V.20161219) Page ( 3 of 3 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
x2
23
4 5
1
1Unplug bumper wiring harness from the body harness
2Remove (4) 13mm bolts each side of outer bumper support gussets
3Remove under-run guards from both frame rails (18mm bolts)
4Remove bolts from front by each tow hook to remove bumper
5Remove factory tow hooks both sides using 15mm socket
6
7
x3
8
6Fit up Road Armor bracket and bolt on using
four single bolt tabs per bracket as shown
7Place one of the triple nut plates on top of
bracket and bolt down as shown. Do not
fully ghten.
8Insert one bolt tap through the bumper slot poinng outward and ax
using the retainer clip. This is best achieved using a deep socket to press
the retainer down over the threads.
9Line up the bumper with the bracket inserng retained bolt through the
bracket slot. Then install washer, lock washer, and nut but do not fully
ghten.
10 Now install the remaining bolt tabs in the same fashion.
11 Once centered and sased with tment ghten everything down.
Bumper will have up, down, in, out and some rotaonal adjustment .
FINISHED
