Road Armor STEALTH 5203R0B Configuration guide

INSTALL INSTRUCTIONS
STEALTH Rear Full-Width Winch Bumper
Product : 5203R0B
Applicaon : 2020 JEEP GLADIATOR JT

2018 Jeep Wrangler JL Rear Bumper Page ( 2 of 4 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
SAFETY FIRST!
• FOLLOW ALL INSTRUCTIONS, YOUR SAFETY AND THE SAFETY OF OTHERS IS MOST IMPORTANT.
• WEAR APPROPRIATE EYE PROTECTION AND EXERCISE CAUTION WHEN DRILLING / CUTTING
REQUIRED TOOLS
INCLUDED HARDWARE
I WARNING
Read the instrucons completely before beginning installaon. Before ghtening bolts,
drilling or cung where required, check to make sure there are no obstrucons such as
brake, fuel or electrical lines which may be damaged. Also keep in mind this is an aer-
market product and MAY require minor shimming and/or trimming, reaming, etc. for
proper t. Road Armor is not responsible for any damages to vehicle.
 IMPORTANT NOTICE
• Be sure to inspect and test t your product to ensure proper tment before having it coated, painted, bed
lined, etc.
• Road Armor will not be responsible for the cost of coang your unit if any problems with t or nish are not
noted and addressed beforehand.
Metric and SAE Socket Sets and Wrenches Screw Driver
(6) 1/2” x 2” Bolt Tabs (2) License Plate Lights & #8 Hardware
(4) 1/2” x 1.5” Bolt Tabs (1) Stain Steel Road Armor Logo Leers and Hardware
(6) 1/2” Keeper Washers (4) 1 1/16” Sensor Plug
(10) 1/2” Grade 8 Washers (4) 1 1/16” Sensor Grommet
(10) 1/2” Hex Nut
(10) 1/2” Grade 8 Lock Washers
(2) 1/4” License Plate Screws
(2) 1/4” License Plate Nylon Nuts
(4) 1/4” Washers
(2) 1/4” Lock Nut

2018 Jeep Wrangler JL Rear Bumper Page ( 3 of 4 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
1Disconnect the rear bumper harness, release the clips holding the bumper end of the harness to the Jeep. Connector is
located inside the driver side hitch of the Jeep. Remove hitch harness and plug from bumper.
2Using a 16mm socket, remove license plate and 2 bolts securing the center of bumper to hitch.
3Using a 16mm socket, remove 2 bolts securing the bumper outer mounng brackets to the rear hitch from ea. side.
4Pull o factory bumper and set aside.
5Remove factory recovery hook using 21mm socket; 2 bolts on the top, through the hitch.
2
3
3
NOTE
5
6If equipped, disassemble rear bumper, carefully remove all sensors and harnesses. **Note sensor locaon**
IF INSTALLING REAR WINCH—CONTINUE WITH install STEP 5 Below - TECH Tips on Last Page STOP
1Install Road Armor Logo with included #10 Stainless Buon Head Bolts and Keps Nuts.
2Install both 3x2 (SRM SURFACE MOUNT) lights, as this is easier now than aer Road Armor bumper has been installed.
3Install hitch pin plate with included #10 Stainless Buon Head Bolts and Keps Nuts
4Install both license plate lights using #8 hardware, as this is easier now than aer Road Armor bumper has been installed.
NOTE If installing winch do so at this me: Install 8000lbs Winch on to winch plate.(License Plate Relocaon Bracket: LPF360B)
**DISASSEMBLY COMPLETE**
STOP

2018 Jeep Wrangler JL Rear Bumper Page ( 4 of 4 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
5If equipped: Insert 4 kit grommets into bumper holes followed by all sensors and harness. **Original sensor locaon**
6Install 6 - 2” bolt tabs through bumper using the included keeper washers. Use a 3/4” deep socket to push the washers
over the threads.
7Install both bumper brackets onto outside of hitch as shown below. Use 2 - 1 1.5” bolt tabs to secure each bracket to
hitch using a washer, lock washer and nut over each bolt.
8Install new Road Armor bumper by starng a washer, lock washer and nut over each bolt. Once all nuts are nger ght,
check tment and ghten them all down. Check that all the bracket bolts are fully ght as well.
9Reconnect bumper all wiring harness and ensure all wiring is secured. (Wire license plate light to factory harness.)
75
6
FINISHED!
8
9

2018 Jeep Wrangler JL Rear Bumper Page ( 5 of 4 )
www.ROADARMOR.com
INSTALL INSTRUCTIONS
**Installaon Tips - STEALTH Winch Rear Bumper**
1When installing “hawse” Fairlead, use 2 - 3/8” bolts (supplied with winch) to install fairlead onto winch mounng plate.
2If installing “roller” fairlead, use bumper as templet to drill out 3/8” holes shown below with blue arrows (allows the
boom two winch bolts to bolt through the fairlead bracket and into the winch.) (Longer winch bolts will be needed.)
3Install winch by placing winch onto mounng plate (lever on passenger side); use 4 - winch bolts through plate to install
winch onto bumper. (Green Arrows) (longer bolts may need to be purchased depending on what mounng bolts were
supplied with the winch.) (License Plate Relocaon Bracket Available for Purchase: LPF360B)
1
2
3
