Roadmaster ENZO 8 User manual

PRODUCT CODE
MS03093
USER MANUAL
SERIAL NUMBER

CONTENTS
2
1. PREFACE AND INTRODUCTION 3
2. SAFETY NOTICE 4
»2.1 Before driving
»2.2 While driving
»2.3 Labelling
3. PARTS INTRODUCTION 9
»Parts description
4. OPERATION 10
»4.1 Control panel
»4.2 How to operate your scooter
5. BATTERY CHARGING AND CARE 15
»5.1 Charging the battery
»5.2 Battery
6. INSPECTION AND MAINTENANCE 18
»6.1 Inspection
»6.2 Regular checking record
»6.3 Battery, fuse and tire
»6.4 Storage
»6.5 Moving about
7. TROUBLE SHOOTING AND SPECIFICATION 21
8. WARRANTY 22

3
Please carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could
result in harm, injury or trac accidents. For maximum safety while using the vehicle please read
this owner’s manual.
Our scooters have been designed and manufactured to provide a comfortable and secure yet
aordable solution for some mobility requirements.
1. PREFACE AND INTRODUCTION
»This owner’s manual includes operation instructions for every aspect of the vehicle, assembly
instructions, and instructions for how to deal with possible accidents.
»The symbols used in this manual are explained below. Read especially the notes marked with
these symbols:
»This manual includes a copy of repair and maintenance record chart and warranty
information. Please keep it in a safe place or with the scooter.
»If someone else uses the scooter, please make sure that you provide them with the
instruction manual for his or her consideration.
»As designs change some illustrations and pictures in the manual may not correspond to the
vehicle that you purchased. We reserve the right to make design modications.
Warning Improper usage could result in serious injury or death.
Attention Improper usage could lead to injury and/or damage to your scooter.
Suggestion Follow these instructions to keep your vehicle in a good operating order.
SUGGESTION
To maximise your batteries eciency and service life, please fully recharge your new
battery before rst use.

2. SAFETY NOTICE
4
2.1 BEFORE DRIVING
The user needs to be familiar with the usage and operation of this vehicle before driving. Therefore,
please always keep the following safety notices in mind.
The same trac rules apply to the use of this vehicle as apply to pedestrians
For your safety, please therefore follow the rules that apply to pedestrians.
»Ride on the pavement, single carriage roads, or pedestrian areas only. Never ride on
motorways or dual carriageways.
»Please do not drive your scooter after consuming alcohol or when you are tired.
»Please be careful when driving your scooter in low light. It has not been designed for use at
night.
»The scooter may be used on single carriage roads in the 8mph (12.8kp/h) switch speed
mode.
Practice operating your vehicle
Before using the scooter in busy or potentially dangerous areas, familiarise yourself with the
operation of your scooter. Please practise in a wide and open area like a park. In order to avoid
accidents with your scooter while driving, please bear in mind driving motions, such as accelerating,
stopping, turning, reversing, and driving up-and down ramps.
»Please turn the speed dial to value 3 for your initial practice.
»Be sure someone accompanies you for safety when driving on the roads for the rst time.
»Only use higher speed settings when you are condent that you can easily operate and
control your scooter.
Do not use this vehicle to carry or haul goods
»As only the maximum weight can be carried please refer to MAX USER WEIGHT on page 19.
»Maximum loading weight for basket is 3 kg.
Tyres
Correct air pressure in the tyres is essential for optimal steering and stability of the scooter.
»Check air pressure every two weeks. Inate to the proper air pressure (30-35 psi).
»Maximum tyre pressure is 50 psi.
The scooter is only to be used by one person at a time
Do not carry passengers on your scooter (including children)

5
2. SAFETY NOTICE
2.2 WHILE DRIVING
Please carry out daily inspections. Refer to the section entitled INSPECTION AND MAINTENANCE.
Do not move your body out of the vehicle while moving
»Such action may cause you to lose balance and risk injury from falling.
»Pay attention that your clothes do not tangle in the wheels.
Do not use your vehicle under the circumstances below.
»On roads with heavy trac or roads that are muddy, gravelly, bumpy, narrow, snowed over,
icy, or canal towpaths not guarded by any fence or hedge. Keep away from places where you
might get the wheels stuck.
»Do not drive at night or when it is raining, snowing, misty, or windy.
»Do not drive your vehicle in an “S” pattern or make erratic turnings.
»Do not take the scooter onto escalators.
»UNDER NO CIRCUMSTANCES SHOULD THE SCOOTER BE USED AS A SEAT IN A MOTOR
VEHICLE (E.G. CARS, BUSES, TRAINS, ETC).
About Mobile Phones and other electrical equipment
»Do not use a mobile phone or other wireless communication device while driving.
»Always switch o the scooter and remove the ignition key before using a mobile phone.
»Do not charge the mobile phone or any other electrical devices from your scooter’s battery.
Ramps, inclines and drops
»Do not drive onto steep ramps greater than the specied gradient. Refer to the section
entitled CLIMBING ANGLE.
»Always use a low speed setting when ascending or descending a gradient.
»Do not drive on roads with large drops or potholes.
»Please slow down when driving on roads with inclines.
»Do not make sudden turns when driving on gravel roads or ramps.
»Always lean forward when climbing a steep gradient.
Automatic Power Shut Down
In order to avoid accidental battery run down, your scooter is equipped with an automatic power
shut down facility. If the scooter is switched on, after remaining undisturbed for a period of thirty
minutes it will automatically turn o. Should this occur, simply switch your scooter o and back on
and it will be ready to use once again.

2. SAFETY NOTICE
6
STARTING AND DRIVING
»Make sure the seat is installed properly.
»Make sure the tiller has been secured properly.
»Fold down the armrests so you can rest your arms on them.
»Turn the power switch to ON. If necessary, turn on the headlights.
»Check battery indicator to see whether there is enough power for your journey. If you have any
doubt about the remaining power, please recharge the batteries before departure.
»Set the speed dial to a position you feel safe and comfortable with.
»Check the forward/reverse speed lever works correctly.
»Make sure the electromagnetic brake works correctly.
»Make sure it is safe around you before you drive on the street. Engage the 8mph (12.8kp/h)
switch if you are driving on the pavement.
WARNING
»Do not set in the freewheel mode when driving on a gradient.
»Always re-engage the anti-freewheel device before use. Failure to do so may result in
injury.
»To protect your safety, the power will automatically cut o and electromagnetic brake
system will activate while you are driving down a steep gradient. This will limit the speed
to a safe level. Turn the power on again to re-start your scooter.
»Maximum User Weight Limit - Refer to section entitled MAX. USER WEIGHT. Overloading
the weight limit may lead to damage of your scooter or cause it to malfunction and will
endanger your safety. The warranty does not cover this type of damage.
ATTENTION
»Do not push both RH & LH sides of the speed control lever simultaneously. This might
leave you unable to control your scooter.
»Do not turn the power switch to OFF while driving as this will lead to an emergency stop
and possible risk of accident and injury.
»Do not set to the highest speeds while driving indoors.
»Do not adjust the speed dial while driving, a sudden change in speed may cause danger
to you and others, and may cause damage to your scooter.
»Do not place magnetic devices near the area of the operation handle as this could aect
the safe operation of your scooter.
»Do be careful while driving in heavy trac or crowded areas.
»While reversing the vehicle, beware of people or objects behind you.

7
2. SAFETY NOTICE
DRIVING ON THE PAVEMENT
»Ensure the 8mph (12.8kp/h) limit switch is set to the slowest setting when using the scooter
on the pavement.
»This will limit the scooter to a maximum speed of 8mph (12.8kp/h).
»The limit switch can be set to the fastest setting for use on the road or on private ground.
STOPPING
»Release the speed control lever completely. The vehicle will naturally brake and stop.
»Turn the power switch to (OFF). Then pull out the key.

2. SAFETY NOTICE
8
2.3 LABELLING
Please carefully read all labels on the scooter before driving it. For your future reference, do not
remove them.
WARNING
»Do not operate the scooter unless the handle bar is
in a lock position.
»Do not lean against or pull forward on the handle
bar while mounting or dismounting from the
scooter. Serious harm or injury can occur.
The manufacturer disclaims all responsibility for any
personal injury or property damage which may occur as
a result of improper use of its products.
»Never lift the scooter up by the front or rear shroud
WARNING
Radio waves may aect scooter control.
Radio wave sources, such as radio stations, amateur radio (HAM) transmitters, two-way
radios, and cellular phones, can aect powered motorised scooters. Following the warning
listed below should reduce the chance of unintended brake release or powered scooter
movement which could result in serious injury.
1. Do not turn ON hand-held personal communication devices, such as citizens band (CB)
radios and cellular phones, while the powered scooter is turned ON.
2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them.
3. If unintended movement or brake release occurs, turn the powered scooter OFF as
soon as it is safe.
4. Be aware that adding accessories or components, or modifying the powered scooter,
may make it more susceptible to interference from radio wave sources. (Note: There is
no easy way to evaluate their eect on powered scooter.)
5. Report all incidents of unintended movement or brake release to the powered scooter
manufacturer, and note whether there is a radio wave source nearby.

3. PARTS INTRODUCTION
9
01 Control Panel
02 Rear Mirror
03 Indicator Lamp
04 Charger Socket Cover
05 Basket
06 Tiller
07 Tiller Adjust Lever
08 Head Lamp
09 Seat
10 Seat Rotation Lever
11 Hand Brake Lever
12 Side Reector
13 Rear Lamp
14 Freewheel Lever
15 Anti-tip Wheel
16 Width Adjustable Armrests Knob
17 Height Adjustable Armrests Knob

4. OPERATION
10
4.1 CONTROL PANEL
»Put the ON/OFF key switch on.
»The battery level indicator shows the current level of your batteries
»Now turn the speed control to the desired driving speed.
»Pull the drive lever with your ngers toward the handle bars (right lever for forward
movement, left lever for backward movement).
»To sound the horn, press the horn button.
»To put on the front and back lights, press the lights button (7).
»To put on the emergency ashers, press button (6).
»To put on the indicator lights, press the desired button (8-9)
(left = left indicator, right = right indicator).

4. OPERATION
11
4.2 HOW TO OPERATE YOUR SCOOTER
Turn the key to power ON or OFF
»(ON) : Power is turned on
»(OFF) : Power is turned o
SPEED DIAL
Turn this dial to determine the speed range of the scooter. Turn the dial anti-clockwise to go slower
and clockwise to go faster.
FORWARD, REVERSE, AND BRAKING
»Push the speed control lever forwards with your right thumb and the vehicle will move forward.
»Push the speed control lever forwards with your left thumb and the vehicle will move backward.
»The horn will beep when the vehicle is in reverse.
»Release the speed control lever freely while either going forward or reverse, and the electromagnetic
brake in the motor will be activated, and the vehicle will stop.
INDICATOR LAMP SWITCH
»The light will ash and buzzer will make a beeping sound when turning the switch to the left or
right.
»Return the switch back to the middle. The indicator will be cancelled.
HORN BUTTON
Press the horn button to sound the horn. Release the button to stop the horn.
TEMPERATURE SENSOR
The Temperature Sensor is built in to the control panel. Temperature given is for reference only.

4. OPERATION
12
LIGHT BUTTON
»Push the light button to switch the front and rear lights on.
»Push the button again to turn the lights o
BATTERY INDICATOR
»The remaining power indicated by the battery indicator will vary by the actual driving time
incurred and how you drive.
»Repeated starting, stopping or climbing of gradients will consume the power more quickly.
BRAKING
»Electro-magnetic brake: Release the speed control lever completely, and the electromagnetic
brake will be activated automatically, bringing the scooter to a stop.
SUGGESTION
»You should recharge the batteries after each time the vehicle is used to ensure
maximum range. The batteries should be charged up at least once a week even if
the scooter is not used.
»After charging or replacing a new battery, drive the vehicle for 2-3 minutes to make
sure the battery capacity is sucient.
»In wintertime, the battery may respond more slowly and the battery range may be
reduced.
»When driving on a gradient, the battery indicator light might move up and down.
This is a normal phenomenon so please do not worry.
»Even if the battery is used properly, it is natural for the battery’s capacity to reduce
with time, which results in reduced battery range compared to a brand new battery.
Therefore, when you nd the battery’s range is about only 50% of the range when
the batteries were new, it is time to replace the batteries. Please see your dealer
for replacement batteries. If you continue to use the old battery when it should be
replaced, it could lead to a rapid decline in performance.
»The battery range will be reduced when driving frequently on a slope or rough
terrain, as this leads to greater consumption of power.
»The batteries have a six-month warranty covering manufacturing defects. This
warranty does not cover faults due to incorrect battery recharging.
WARNING
When on a gradient NEVER switch the vehicle to the freewheel mode. The
electromagnetic brakes will not be applied. This may result in injury.
BATTERY INDICATOR

4. OPERATION
13
SEAT
»The seat can be turned to 45 degrees or 90 degrees.
»Pull the seat adjustment lever forward and swivel seat.
»Release the lever, then continue swivelling the seat until it locks in position.
HOW TO ADJUST THE ARMREST WIDTH
Loosen the knobs at the back of the seat frame rstly, then adjust the
armrest width by sliding the armrest. Once satised with the width,
tighten the knob.
HOW TO RE-POSITION THE SEAT
The seat can be adjusted backwards and forwards for a comfortable
driving position. To slide the seat, pull the lever at the front the seat
and reposition as required.
HOW TO SET TO FREEWHEEL MODE
»Engaged mode: push the lever forward. The scooter can now
be driven by motor power.
»Freewheel Mode: Pull the lever back. The scooter can be
moved manually.
TILLER ADJUSTMENT
The tiller can be adjusted to several positions as you feel comfortable.
»Push (or pull) the lever to adjust the tiller to positions you want.
»Once the right position is set, release the lever to secure the tiller.
ATTENTION
»Return the seat to the forward position before driving.
»Ensure the limit switch is set to the slowest setting when using the scooter on the
pavement.
PUSH
PUSH
PULL
PULL

4. OPERATION
14
MANUAL BRAKE
As well as an electromagnetic brake, squeeze the
brake lever to apply the brake and then release
the lever to release the brake. The manual brake
tightness can be adjusted by the brake cable
adjuster near the left-hand side wheel.
MAIN CIRCUIT BREAKER (RESET BUTTON)
When the voltage in your scooter’s batteries
becomes low or the scooter is heavily strained
because of excessive loads or steep inclines,
the main circuit breaker may trip to protect the
motor and electronics from damage.

5. BATTERY CHARGING AND CARE
15
5.1 CHARGING THE BATTERY
Follow the procedure below step by step:
»Turn the power switch to OFF.
»Connect the charger’s power cord into the power outlet.
»Open the charging socket cap on the scooter’s tiller. Then connect the
charger’s round plug to the charging socket.
»Turn on the switch on the charger.
»Both the charger’s red and orange LEDs will be lit when beginning
charging. The charging duration is about 6 hours. To ensure
optimum performance a 10-hour charge is recommended. We do not
recommend charging for more than 24 consecutive hours.
»Both the charger’s LEDs will be lit during the charging process. The
orange LED will turn green when charging is complete.
»Turn o the charger; disconnect the power cord and the round plug
from charger socket on the scooter.
NOTE: The immovable function will be activated while your scooter is in charging status.
WARNING
»The fan inside the charger will be activated accordingly when you turn on the
charger. If the fan does not work when connected to the charger or the green light
is not showing, DO NOT use this charger. It may lead to overheating of the charger
and cause a re as a result.
»There is a red LED present on the charger to illustrate operation. If this LED does not
illuminate, the charger is defective. Please contact your dealer.
ATTENTION
»While gripping or folding the handle bar, beware of nger or hands caught in the
handle area.
»While returning the battery pack to the battery pack cavity on the shroud, beware of
trapping ngers or hands.
»A ap on the end of battery pack can be opened to place your bag (not over 3kg in
weight).
WARNING
»Keep away from ammable objects while charging as it may lead to re or explosion
of battery.
»Do not smoke while charging as the battery may release hydrogen gas. Always
charge your battery in a well-ventilated space.
»Never connect or disconnect the plug or cord with wet hands while charging. Do not
connect or disconnect the plug or cord when they are wet, it may lead to electric shock.

5 BATTERY CHARGING AND CARE
16
ATTENTION
Please follow the rules below to avoid accidents while charging.
»Please use the supplied charger only, and recharge the battery to its full capacity
every time. You may damage the battery and scooter if you use a charger which is
not to the correct specication.
»Please charge in a well-ventilated space where it is not directly exposed to the
sunlight. Do not charge in surroundings where it is humid or under rainfall and
morning dews.
»Do not charge in temperatures less than -10°C or higher than +50°C as the charger
may not work well and the batteries may become damaged.
SUGGESTION
How to maximise battery eciency and service life
»Fully recharge your new battery before rst use.
»Be sure to charge the battery fully every time. The battery life will be seriously
shortened or decayed if the battery is repeatedly used without being fully charged.
»Always complete the charging until the orange LED light turns green. NEVER stop
charging before it is complete.
»Keep your batteries fully charged whenever possible.
»If you do not use your scooter for a long time, it should be charged at least every
week to keep the battery in a fully usable condition.
»The ambient temperature will aect charging time. Charging time will be longer in
the winter.
»After charging, do not leave the charger socket plugged in to the scooter, as this will
cause a power drain on the scooter and temporarily reduce its range.
5.2 BATTERY
»Do not expose the battery to temperatures below 10°C or above 50°C when charging or storing
the vehicle. This will damage the batteries and shorten their life.
»These batteries are maintenance-free and there is no need to rell with water.
»You are required to recharge the batteries on a regular basis. Even if the scooter is stood idle, you
should charge the batteries at least once a week.
»The batteries carry a six-month manufacturer’s warranty. This warranty only covers issues
relating to manufacturing faults, and not faults relating to failure to recharge the batteries as
instructed above.

5. BATTERY CHARGING AND CARE
17
SUGGESTIONS
»Make sure the terminals are installed properly and put the cover back on.
»Do not use the battery to charge telecom equipment or other items.
»Battery eciency will vary with outside conditions; the driving distances will be
shorter in the winter. If the vehicle is not used for a long time, please charge the
battery at least every week.
»Replace both batteries together.
CHARGER REPLACEMENT
»Follow procedure 1 and 2 above.
»Make a note of how the wire and socket are situated in the battery pack before you move the
charger’s wire and socket.
»Unplug the socket to remove the charger, then replace a new one.
»Situate the wire, socket and LED on the battery pack as they were originally.
CLEANING THE BATTERY
If the batteries are contaminated by water, battery acid, dust or other substances, they will discharge
quickly. The batteries supplied with the scooter are sealed and as such are maintenance free with no
risk of battery leakage. Please follow the steps below to clean the battery.
»Turn the scooter power switch to OFF.
»Remove the seat and dust cover.
»Remove the shroud and unplug the terminal of the tail light and signal lights.
»Use a clean cloth to wipe o the soiled area.
»Take out the battery.
»Clean the battery with a clean cloth. If the terminal is covered by white powder, please wipe it
clean using warm water.
WARNING
»The wiring system and charger are well situated in battery pack while assembled
in plant. Do not attempt to re-locate the wiring system by yourself. The improper
layout of wiring system may result in the wires being pinched by battery box, which
could cause the electronic system to fail.
»Be sure the battery wires are connected to their right battery terminal.
SUGGESTIONS
»If necessary, ask for help from your dealer for advice about maintaining and
replacing the battery.

6. INSPECTION AND MAINTENANCE
18
6.1 INSPECTION
»Clean the scooter with a damp cloth and dust down approximately once a week to preserve the
appearance of the scooter.
»Adjust the tiller height and return to the original position and swivel the seat once a week to
ensure the parts adjust and remove smoothly and easily when required.
»Check for signs of wear and tear on the tires and the upholstery on a regular basis.
»For optimum performance and to increase the lifespan of your scooter, it is recommended that
you have your scooter serviced once a year.
6.2 REGULAR CHECKING RECORD
To make sure your scooter is correctly serviced, take it to your dealer for regular maintenance checks.
This should be at intervals of six months after the rst inspection after one month. Your dealer may
charge a fee for this service.
YEAR 1 2 3 4 YEAR 1 2 3 4
Service Dates Service Dates
Controller Upholstery
On/o switch Seat
Controller Lever Back
Braking Armrests
Recharge point Electrics
Batteries Connections
condition
Levels Lights
Connections Test run
Discharge test Forwards
Wheels and Tyres Reverse
Wear Emergency stop
Pressure Left turn
Bearings Right turn
Wheel nuts Slope test
Motors Over obstacles
Wiring List Items repaired
Noise
Connections
Brake
Brushes
Chassis
Condition
Steering

6 INSPECTION AND MAINTENANCE
19
6.3 BATTERY, FUSE AND TYRE
BATTERY
Refer to the section entitled BATTERY on page 15.
FUSE
If the battery charger is turned on and no LEDs are lit, check the fuse.
TYRES
The condition of the tyres depends on how you drive and use your scooter.
»Please check the tread depth regularly. Replace the tyres when the tread depth is less than 0.5
mm.
SUGGESTION
Ask for help from your scooter dealer to inspect or replace the fuse, since the tiller
shroud has to be removed rst before you can replace the fuse.
ATTENTION
»When tread depth is below 0.5mm it can easily lead to vehicle slippage, making
braking
distances longer. Replace the tyres as early as possible when they do not
have insucient
tread depth.
»The tyre pressure should be kept at about 26 PSI (approx. 1.8KG/cm) for the best
ride and handling.
ATTENTION
When conducting maintenance of your vehicle, please turn the power switch to OFF and
remove the charger cords.

6. INSPECTION AND MAINTENANCE
20
6.4 STORAGE
Make sure the vehicle is stored under the following circumstances:
»Make sure the seat is set in the Forward position.
»Make sure the Power switch is turned to OFF.
6.5 MOVING THE SCOOTER
»Turn the power switch OFF before moving.
»Lift the scooter by the chassis, and not by the bumpers. Lifting the scooter by the bumper could
cause damage or injury.
»For your safety, always ask for help if required. You will need 2 or 3 persons when moving or
lifting the vehicle.
SUGGESTIONS
»Please store the scooter in a location where it is away from the direct sunlight, rain,
or dew. When storing for a long time, please charge the battery to full power and
then disconnect the battery terminal.
SUGGESTIONS
»Do not splash water directly on your scooter to wash it. This could lead to
malfunction of the system electrics.
»Do not use petrol, solvents or vaporising solution as these may deform or damage
the shrouds.
»Do not use wax.
