ROBERTO FIORE Cabinets To Go WC0930 User manual

ASSEMBLY INSTRUCTIONS
These assembly instructions are only applicable for all Wall Cabinet 1-Door
ITEM No.:WC0930--WC2130 WC0936--WC2136
Page 1

►Items Quantity
Item Description Qty
Doors 1
B
Back Panel 1
C Side Panels Left & Right
2
D Top & Bottom Panels
2
E Shelves 2
F 1
Hardware Box
Hinges 2pcs, Bumpers 2pcs, 2/3" Flat Head Screws 4pcs, 2/3" Round Head Coarse Thread Screws 8pcs, Cam Locks Male & Female 14pcs, Wooden Dowels 12pcs, Shelf Pins 8pcs
► Required tools:
Page 2
►General Instructions:
Tools Required: Phillips Screwdriver Optional Tools: Electric Drill Optional Tools: Rubber Mallet
► Hardware Box:
a b e
Qty 14
f
Qty 12
cd
Qty 2 Q ty 2 Qty 4Qty 8
ThankyouforpurchasingaCabinetsToGoproduct.Youarenowtheproudownerofahighqualityproductdesigned
tofacethetestofdaily useandguaranteeingyourenjoymentformanyyearstocome.
Carefullyreadtheinstructionsbeforestartingtheinstallation.
Duringassembly,pleasefollowallgenerallyacceptedsafetyprocedures.
FailuretoadheretothefollowinginstructionswillinvalidatethewarrantyandCabinetsToGowilldeclineany responsibilityforany
damagescaused.Anyinstallationwhichdoesnotcorrespondtotheinstructionsmayresultin defects,malfunctioningparts,significant
damageand/orinjury.
Beforetheassemblybegins,checkthatallappropriateandrequiredplumbingandelectricalconnectionsexist.
Beforedrilling,makeabsolutelysurethattherearenopipes(gas,water,electricity,heating,etc.)atthedrilling location.CabinetsToGowill
notbeheldresponsibleforfailuretofollowtheseinstructions.
PRIOR TO ASSEMBLY, PLEASE MAKE SURE YOU HAVE ONE FACE FRAME BOX AND ONE CARCASS BOX, WHICH HAVE ALL THE PARTS IN THE
QUANTITIES MENTIONED BELOW. IF YOU ARE MISSING ANY PARTS, PLEASE STOP AND CONTACT CUSTOMER CARE IMMEDIATELY AT 1-800-
CABINET.
The materials listing above are for the largest unit in this instruction set. Smaller units may require less hardware and materials;
therefore, your item may contain a smaller number of each.
A
C
D
B
E
A
g
Qty 8
C
D
E

Page 3
►Instructions:
1.Unpack box & identify pieces on Page 2. Place
side panel (C) onto a soft work surface.
(Figure 1)
2.Install Hinge base plates (a) onto side panel into
designated holes using screws (d).
(Figure 2)
3.Install metal male cam locks (e) into designated
holes on side panel (C) and bottom panel (D). Use
screwdriver to tighten. Install the wooden dowels
(f) into designated holes. (Figure 3)
4.Install the Top & Bottom panels (D) onto back
panel (B). (Figure 3)
5.Install Top, Bottom, & Back Panels (D,B) onto the
right side panel (C). (Figure 3)
6.Install locking lugs (e) into designated holes, and
then lock them with a screwdriver. (Figure 4)
7.Install side panel (C) onto the assembled panels
using the same methods above. (Figure 5)
Figure 1
SoftSurface
Hard Surface
C
C
Figure 2 Base Plate
Figure 3
Figure 4
Figure 5
a
Qty 2
d
Qty 8
e
Qty 14
f
Qty 12

5.
6.
7.
8.Install hinges onto door into designated holes using screws provided.
Page 4
c
Qty 4
b
Q ty 2
a
► Maintenance
For daily cleaning, use a dry cloth and a soft liquid cleaner.
Never use ab
rasive cleaners containing acetone, chlorine or strong bleach. Also, do not use tools as scrapers,
metallic brushes, and other products which can scratch or tarnish surfaces.
Under
no circumstances should you use chrome cleaner on chrome-plated or brass trim, hinges, handles, sockets etc.
Good ventilation is essential for maintaining the quali ty and look of this furniture.
Warranty and Customer Care Information
For the most up to date warranty information for your product, please visit our website - www.cabinetstogo.com to get
the specific details. If you have any questions with warranties or to make a claim, please contact Customer Care by email
- [email protected] or call 1-800-CABINET.
g
Qty 8
Install door onto cabinet sides though pre-marked screw holes.
Install the shelves (E) by using shelf pins (g) in the locations you choose.
Install the bumpers (b) onto the door corners opposite of the hinges.
