ROBINHOOD RBCA171BUB User manual

Installation and Operating Instructions Issue: 1
Description: ROBINHOOD BEVERAGE CENTRE 171 CANBLACK
Model Number: RBCA171BUB
Model RBCA171BUB
*Actual unit may vary from model pictured above.

Contents
Congratulations!
Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read
through the whole user manual which provides important safety instructions and description of the product and the
proper use of its functions.
To avoid the ever-present risks involved with using an electrical appliance it is vital that the appliance is installed
correctly and that you read the safety instructions carefully to avoid misuse and hazards. It is important that you
retain these instructions and your proof of purchase along with any other important documents about this product
for future reference.
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without
notice.
Content
Important Safety Instructions...............................................................................................................................1
Installation Instructions........................................................................................................................................2
Operating Instructions..........................................................................................................................................4
Troubleshooting ...................................................................................................................................................7
Cleaning and Maintenance...................................................................................................................................8
Warranty Certificate (New Zealand).....................................................................................................................9
Disposal Information
•Most of the packing materials are recyclable. Please dispose of these materials through your local recycling
depot or by placing them in appropriate collection containers.
•If you wish to discard this product, please contact your local authorities and ask for the correct method of
disposal.

1
Important Safety Instructions
Read the assembly instruction section and safety precautions of this booklet carefully before removing
the contents of this carton.
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience or knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety. Young
children should be supervised to ensure that they do not play with the appliance.
2. In certain circumstances electrical appliances may be a safety hazard.
3. Do not place heavy objects on top of this appliance.
4. The appliance is not intended to be operated by means of an external timer or separate remote-
control system.
5. Electrical connection must be made as per local wiring rules and regulations. Do not disconnect the
appliance with wet hands and do not disconnect the power cord with extreme force. Do not coil the
cord while in use but keep any excess cord to the back of the appliance. Take care that the power
socket is accessible.
6. The appliance should be unplugged when not in use and before any maintenance is carried out on
the appliance.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its Authorized Service
Centre or a similarly qualified person in order to avoid a hazard.
8. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
9. WARNING: Keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of
obstruction.
10. WARNING: Do not damage the refrigerant circuit.
11. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance.
12. WARNING: When positioning the appliance, ensure the power cord is not trapped or damaged.
13. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of
the appliance.
14. Do not store explosive substances such as aerosol cans with flammable propellant in this appliance.
15. Do not modify this appliance.
16. This appliance must be correctly installed, strictly in accordance with the manufacturer’s
instructions. Please see the specific section of this booklet that refers to installation.
17. When disposing of this appliance, please do so according to local regulations as it contains
flammable gas & refrigerant.
18. The refrigerant isobutene (R600a) contained within the refrigerant circuit of the appliance is a
natural gas with a high level of environmental compatibility. It is nevertheless flammable.
19. During transportation, installation and servicing of the appliance ensure that none of the
components of the refrigerant circuit are damaged.
20. Avoid open flames and sources of ignition.
21. Thoroughly ventilate the room in which the appliance is situated.
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION
BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS
NEAR THIS APPLIANCE
This appliance is intended to be used in household and similar applications such as:
Staff kitchen areas in shops, offices and other working environments; Farm houses and by clients in
hotels, motels and other residential type environments; Bed & breakfast type environments; Catering
and similar non‐retail applications.
Symbol Meaning:
WARNING: Risk of fire / flammable materials

2
Installation Instructions
Unpacking the Appliance
•Remove the external & internal packaging.
•When unpacking the appliance please check for any damage. If damage is found, do not connect
to the power source and contact the Authorized Service Provider.
•Before connecting the appliance to the power source, let it stand upright for approximately 4
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation. Remove any protective film from the outer surface.
•Clean the interior surface with lukewarm water using a soft cloth.
Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct
sunlight, etc. Do not put the appliance in wet or frozen areas. Ensure that air can circulate freely around
the back of the appliance.
Warning: It must be possible to disconnect the appliance from the mains power supply; the plug must
therefore be easily accessible after the installation. The appliance is designed to cabinet installed or
freestanding.
Cabinet Installation

3
Installation Instructions
Electrical Connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your
domestic power supply. The appliance must be earthed. The power supply cable plug is provided with a
contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a
separate earth in compliance with current regulations, consulting a qualified electrician.
Appliance Overview
Note: Depending on the actual model you purchased, some models may have recessed handles
instead of external handles.

4
Operating Instructions
Start Operation
1. Cleaning the compartment
Before power on, clean inside of the appliance and check the drainage pipe in good connection.
(For details, please refer to the “Maintenance and cleaning”)
2. Position the appliance
Before power on, level the appliance on the firm & dry floor for at least 30 minutes.
3. Power on
The appliance will operate and go to its default temperature after 1 hour, otherwise you should
check the power connection.
Control Panel
All keys would be invalid in lock mode. Please unlock first.
ON/OFF
Press the button and hold 3 seconds for power on or standby mode.
Light
Press the button, turn on or turn off the LED lights inside. In stand-by mode, the key is
invalid.
UP
Press the button once, LED Display in regular flash showing current set temperature.
Continue pressing to adjust set temperature, each increment is 1℃. Flashing temperature
being set will stop after 5 seconds of no further adjustment and this temperature will save.
LED display return to show actual temperature inside.
Down
Press the key once, LED Display in regular flash showing current set temperature. Continue
pressing to adjust set temperature, one press reduce 1℃. Regular flash quit after 5 seconds
detecting no press and new set temperature save. LED display return to show actual
temperature inside.

5
Operating Instructions
Child Lock (Combination key）
Lock - Press both keys at the same time for 3 seconds to lock.
Unlock - Press both keys at the same time for 3 seconds to unlock.
Fahrenheit/Celsius display interchange
Switch temperature unit between Fahrenheit and Celsius by pressing both keys at the
same time for 3 seconds.
Attention
1. The cooling temperature could be set from 0℃-10℃.
2. Alarm sound: when a system malfunction occurs and alarm sounds, press any key on the
control panel to cancel the alarm sound.
3. Temperature sensor failure:
If a temperature sensor failures occur, error code displays. E1 for open circuit; E2 for short
circuit.
When the defrost sensor failure occur, error code displays: E3 for open circuit; E4 for short circuit.

6
Operating Instructions
Beverage storage
•The appliance provides sufficient independent shelves to allow your collection of wine to mature
quietly and peacefully.
•3 chromed wire shelves loading capacity: 171 cans. (Standard can with Φ66x123 mm)
Loading capacity will vary in terms of different way of cans arrangement or different can sizes.
•Each shelf can pull out partly to store cans easily.
•Open the door wide enough before pulling out shelves.
•If the beverage cooler is not in use for long periods of time, it is recommended to power it off,
clean it carefully, and open the door for ventilation.

7
Troubleshooting
The appliance makes lots
of noise?
Please adjust the front foot, keep the appliance leveling.
Please keep the appliance a bit space from walls.
Liquid flowing sound inside
the cabinet?
It is normal because of the refrigerant working inside.
The appliance does not
start?
Make sure the appliance is connected to the power properly.
Make sure switch on the power.
The compressor re-starts after 5 minutes for a power cut.
Compressor runs
continuously?
If no cold is being produced, call the after-sale service.
Door does not seal tightly? After long time use, the door seal might get stiff & distorted partially.
1. Heat the door seal with hot-wind blower or hot towel.
2. The door seal get softened and close the door.
The appliance does not
cool sufficiently?
Please adjust temperature setting.
Keep the appliance away from sunlight or heat.
Please do not open the door frequently.
Unpleasant smells inside
cabinet?
A little bit plastic smell for newly-buy appliance is normal and will
disappear after a short time.
Clean the compartment and ventilate it for a few hours.
Condensate on the glass
door?
Please do not open the door frequently or for a long time.
Please do not set the temperature too low.
High ambient temperature and humidity would cause condensate.
The light is not working? Check the power supply first.
Call the retailer’s after-sale service if the light is broken.

8
Cleaning and Maintenance
Always ensure that the power supply is switched off prior to conducting any maintenance or cleaning of
the appliance.
Cleaning the Appliance
•Disconnect the appliance before cleaning.
•Clean the appliance with soft cloth or sponge by water.
•Do not use organic solvents, alkaline detergent, boiling water, washing powder or acid liquid
etc.
•Do not flush the compartment of the appliance.
•Clean regularly surfaces that can come in contact with accessible drainage systems.
Note: Do not clean the appliance with alkaline detergent, organic solvents, brushes, boiling water.
Power cut
Most power cuts could be resolved within a short time. To protect your wines during a power cut,
avoid opening the door as much as possible. During very long power cuts, take the necessary
measures to protect your wine.
Out of service for long time
Remove all bottles from the appliance, switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
If the appliance is disconnected or if there is a power cut, you must wait at least five
minutes before re-starting.
Moving the appliance
Cut off the power supply and unplug the appliance.
Remove all bottles from the appliance.
When moving the appliance, do not lean the appliance over 45°.

9
Warranty Certificate (New Zealand)
Terms and Conditions
The following conditions apply in respect of the warranty given in this certificate:
1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and
faulty materials, under normal use and subject to the exclusions in this certificate, for a period of:
•Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic
use.
•Uniduct – 12 months from date of original purchase for domestic use.
•Ironing centre – 12 months from date of original purchase for domestic use.
•Sinks sets– 5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6
months on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for
domestic use.
•Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original
purchase for domestic use.
“Original purchase”, when used in this certificate, means purchase by the customer directly from Monaco or one of its approved
suppliers.
2. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part
which we at our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This
warranty is subject to terms and conditions set out in this certificate.
3. The warranty only applies within New Zealand.
4. The customer must produce the original invoice or other purchase documentation as proof of the original purchase date.
Warranty exclusions
1. The warranty does not apply where, in Monaco’s opinion:
•The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or
serviced by an unauthorised person.
•The product was not installed in accordance with our instructions.
•The product was purchased overseas or was not designed for use in New Zealand. The product was not used, cleaned
or cared for in accordance with our instructions.
•The product was used outdoors.
2. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or
are due to:
•Exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;
Using inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish,
bleach, mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
•Heat damage, including from washing the product at high temperatures;
•Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the
product surface or excessive weight being placed on the product;
•Structural or support changes in or affecting the building or the application where the product has been installed;
•Failure to clean or maintain the product as recommended; or any other causes specified in the product information as
being excluded from this warranty.
3. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are
not covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of
the product that were not brought to your supplier’s attention at the time you inspected the product.
4. Costs incurred on installation or removal of a product, or any reinstallation of a product, or any associated costs, are not
covered by this warranty.
5. Monaco will not be liable for consequential or indirect loss or damage whatsoever and however arising out of or in
connection with the supply, performance or removal of the product, including (but not limited to) loss of profit, loss of
revenue, loss of contract, loss of goodwill or increased cost of workings, even if due to the negligence of Monaco or any of
its approved suppliers, employees or agents.
6. Charcoal filters and light bulbs are not covered by this warranty
7. This warranty and the statements contained in this certificate or other documents given to you do not exclude, restrict or
modify the application of any term implied into this warranty by statute, provided that (to the extent any statutory
provision permits Monaco to limit its liability for a breach of an implied condition or warranty) Monaco’s liability for such
breach is limited to the payment of the cost of replacing the product, repairing the product or acquiring an equivalent
product.
8. Subject to clause 5, our obligations under this warranty are limited to those set out in this certificate, and this warranty is
expressly instead of all other warranties, express or implied, including any implied warranty of merchantability or fitness
for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage in trade to
the contrary.
Terms and conditions are subject to change.
Monaco Corporation Ltd
Telephone: [phone]
Email: [e-mail]
www.robinhood.co.nz
