Robotics Technologies EZ720p User manual

EZ720p
AHD MOBILE DVR
User Manual

AHD MOBILE DVR User Manual EZ720p
Table of Contents
Chapter 1 Overview.......................................................................................... 3
Chapter 2 Quick setup....................................................................................... 3
2.6 Vehicle Information setup....................................................................................................... 5
2.7 Disk Management................................................................................................................. 6
2.8 WiFi Setup........................................................................................................................... 6
2. Server Setup........................................................................................................................ 6
2.10 Net State........................................................................................................................... 7
Chapter 3 ystem Menu.................................................................................... 7
3.2 Video playback.................................................................................................................... 8
3.3 Video backup........................................................................................................................ 8
3.5 Date Time Setup.................................................................................................................
3.6 Vehicle information.......................................................................................................... 10
3.7 Preview setup................................................................................................................. 10
3.8 On/Off Setting................................................................................................................. 11
3. System information.......................................................................................................... 11
3.11 Server Setup................................................................................................................. 12
3.12 WiFi Setup.................................................................................................................... 12
3.13 Network State................................................................................................................. 14
3.15 Mode setup.................................................................................................................... 15
3.16 Main Stream................................................................................................................. 15
3.17 Sub Stream.................................................................................................................... 16
3.18 Recording OSD.............................................................................................................. 17
3.1 Image setup................................................................................................................. 17
3.20 Storage setup................................................................................................................. 17
3.22 User Management.......................................................................................................... 18
3.23 Restore........................................................................................................................... 1
3.24 Logout........................................................................................................................... 1
3.25 UART setting................................................................................................................. 20
3.26 UART-TTS........................................................................................................................ 20
3.26 UART-Serial Net.............................................................................................................. 20
3.27 Rear Camera Setup....................................................................................................... 21
3.2 Log inquiry.................................................................................................................... 22
3.30 Disk Management.......................................................................................................... 22
3.31 Import/Export................................................................................................................. 23
3.32 System Upgrading.......................................................................................................... 23
3.34 Input Alarm.................................................................................................................... 25
3.35 Video Loss.................................................................................................................... 26
3.36 Fatigue Driving Alarm.................................................................................................... 26
3.37 Over Speed Alarm.......................................................................................................... 27
3.38 Disk Error........................................................................................................................ 27
Chapter 4 Installation Best Practices............................................................ 28
2

AHD MOBILE DVR User Manual EZ720p
Chapter 1 Overview
EZ720p is a DVR designed for Analog HD vehicle monitoring. With a built-in high
performance image processor and advanced H.264 video compression technology, it
provides AHD video recording, storage and playback. It is WiFi capable (optional) for
remote monitoring, analysis and management. It features a smart power management
system, which can recognize the power level automatically. When the battery’s voltage is
lower than the safe operating value, the EZ720p will shutdown automatically and maintain
an ultra-low standby power consumption.
Chapter 2 Quick setup
2.1 EZ720p Installation
Please refer to “AHD MOBILE DVR Hardware User Manual (EZ720p)” for the SD card
installation and cable connections.
2.2 User Login
Use the remote control, or right-click the mouse to display the login screen. Please enter
your User Name, and Password, then click “OK” to enter the menu. (The default User
Name is admin, without a Password):
3

AHD MOBILE DVR User Manual EZ720p
Select Menu to start setup:
The ystem Menu is the starting point for setup and control:
2.3 et up the ystem time
Time SYNC: Date and Time can be synchronized with GPS/BD
2.4 et up cameras
Please set up your cameras’ Signal Type, Valid/Invalid. The DVR works with both AHD and
general cameras. If you use AHD cameras, please select the first Type; if you use general
cameras, please select the third Type, if you use both of general and AHD cameras, please
select the second Type.
4

AHD MOBILE DVR User Manual EZ720p
PS: If your cameras don’t display an image on the monitor, please check this setup.
2.5 Wizard
This Wizard will help you to quickly set up a EZ720p connected with the server. If your
DVR is without the WiFi option, you can ignore the step 1/4 and begin with step 2/4.
2.6 Vehicle Information setup
The EZ720p uses “EZ720p ID” to connect with a server, so please input the correct
EZ720p ID which was registered on the server for your EZ720p. The user can modify the
Vehicle Name and Plate Number according to their requirement. The Plate Number is the
vehicle’s plate number, and it will be displayed in the video.
5

AHD MOBILE DVR User Manual EZ720p
2.7 Disk Management
SD cards need to be formatted in the EZ720p when using them for the first time. If the
SD card was not detected by the EZ720p, please check the SD card latch to make sure it
is locked.
2.8 WiFi etup
The EZ720p can store a maximum 6 WiFi ESSID (Access Points). It will search, match,
connect, and switch automatically. Click the corresponding blank to start WiFi setup. Next,
click “Search” to see the available WiFi Access Points in your area. Select one, enter its
password, then save.
2.9 erver etup
IP (or Domain) is your server’s IP (or Domain), the Port should match your server setup.
6

AHD MOBILE DVR User Manual EZ720p
2.10 Net tate
Net State: You can check the state of the network connection of your EZ720p here.
Server: Online, it means that the EZ720p connected to the server.
Chapter 3 ystem Menu
3.1 Video Playback
The EZ720p supports one channel video playback, Select “Playback” in the System menu,
then you will get the video searching interface, please search the video according to your
requirement.
7

AHD MOBILE DVR User Manual EZ720p
Note: The system will only show the latest 4,000 video file clips.
3.2 Video playback
Double click the video file in the video Search result Interface to playback the video.
3.3 Video backup
Select the video files in the video search results interface and use your U disk or SD card to
backup the videos. (The EZ720p supports USB time-delay detecting, you can insert the
USB disk after you have set up and clicked the “Backup” button.)
3.4 Basic etup
The basic setup includes the very basic setup items such as Date/Time, Vehicle
Information, and Preview Etc.:
8

AHD MOBILE DVR User Manual EZ720p
3.5 Date Time etup
Time synchronization: The system's date and time can be synchronized with GPS/BD.
9

AHD MOBILE DVR User Manual EZ720p
3.6 Vehicle information
EZ720p ID: This is the ID used to connect your EZ720p with the server. It should be the
same ID which you registered your EZ720p on the server.
3.7 Preview setup
Here you can setup the information which you want to overlay on the Preview image
(please note this is not overlaid on the recording image)
10

AHD MOBILE DVR User Manual EZ720p
3.8 On/Off etting
PS: The EZ720p’s power cable should be connected as per the Hardware User Manual,
otherwise, the On/Off setting will not work.
3.9 ystem information
System information includes: EZ720p Model, Serial Number, Hardware & Firmware version
etc.
3.10 Network setup
Network setup: This interface is used to set up the parameters which are required to
connect the EZ720p to a server.
11

AHD MOBILE DVR User Manual EZ720p
3.11 erver etup
IP/Domain is the IP or domain of your EZ720p’s server.
3.12 WiFi etup
The EZ720p can save maximum 6 WiFi ESSID (Access Points). It will search, match,
connect, and switch automatically. Click the corresponding blank to start WiFi setup. Next,
click “Search” to see the available WiFi access points in your area. Select one, enter the
password, then save it.
12

AHD MOBILE DVR User Manual EZ720p
You can enter the ESSID of the WiFi AP manually, but you can also click “Search” to search
the available WiFi ESSIDs in your area.
13

AHD MOBILE DVR User Manual EZ720p
3.13 Network tate
You can check the state of the network connection of your EZ720p here.
14

AHD MOBILE DVR User Manual EZ720p
3.14 Recording etup
Recording setup includes Mode, Main Stream, Sub Stream, Recording OSD, Image,
Storage.
3.15 CameraMode setup
Please set up your cameras’ Signal Type, Valid/Invalid. The DVR works with both AHD and
general cameras. If you use AHD cameras, please select the first Type, if you use general
cameras, please select the third Type, if you use both of general and AHD cameras, please
15

AHD MOBILE DVR User Manual EZ720p
select the second Type.
3.16 Main tream
Main Stream is stored in local disk. This interface shows the current Main Stream setting
and the corresponding storage size, you can click any line to set up the corresponding
parameters.
PS: If Bit Rate is greater, the corresponding channel’s storage size will be greater.
3.17 ub tream
Sub Stream is used for network transmission and backup on the local disk.
16

AHD MOBILE DVR User Manual EZ720p
3.18 Recording O D
Recording OSD is used to overlay the following information to video recording.
3.19 Image setup
Image setup is used to adjust to camera’s image effect, please set up it carefully.
17

AHD MOBILE DVR User Manual EZ720p
3.20 torage setup
The EZ720p supports dual storage. Both of the Main Stream and Sub Stream can be
stored on the local disk, but each disk can only store one type of stream.
18

AHD MOBILE DVR User Manual EZ720p
3.21 Advanced setup
3.22 User Management
You can add, modify, delete users, and modify the login user name and privileges
3.23 Restore
Restore the default system setup parameters. System will reboot when restore finished.
See the following:
19

AHD MOBILE DVR User Manual EZ720p
There are 3 restore modes:
Normal Info: Restore all info except Vehicle info.
Vehicle Info: Restore vehicle info only.
All: Restore all info.
3.24 Logout
Logout will exit the menu automatically if there has been no activity in the set time range,
and return to operation.
3.25 UART setting
The EZ720p has 1 RS232 Interface.
3.26 UART-TT
Select UART 0 to enter the UART setting interface.
20
