Rocket Espresso MACINATORE SUPER FAUSTO User manual

USER MANUAL

Congratulations on purchasing the SUPER FAUSTO grinder by
Conti Valerio for Rocket Espresso
ROCKET ESPRESSO - WARRANTYAND REGISTRATION
Warranty is with the dealer from whom you purchased the
machine.
To register your purchase with Rocket Espresso, please go to
www.rocket-espresso.com/register.html and enter the following
details:
• Name:
• Country:
• Place of purchase:
• Serial number of the machine:
• Email address:

Pg 03
CONTENTS
• SAFETY INSTRUCTIONS 04
• PRESERVATION OF THE MANUAL 06
• REMOVING MACHINE FROM PACKAGING 06
• GENERAL INFORMATION 07
• SUPER FAUSTO TECHNICAL DATA 09
• OTHER INFORMATION 10
• APPLIANCE DESCRIPTION 11
• SETTING UPYOUR SUPER FAUSTO 13
• LOCKING THE CONTAINER 14
• INTRODUCTION 15
• INSTRUCTIONS FOR USE 16
• GRIND SETTING 17
• APPLIANCE SETTING 18
• SWITCHING ON YOUR SUPER FAUSTO 19
• STANDBY MODE 19
• DOSE DISPENSING AND SETTING DISPLAY 20
• FUNCTION BLOCK 21
• TECHNICAL MENU 22
• COUNTERS 22
• BRIGHTNESS 23
• DISPLAY COLOUR 24
• FACTORY RESET 25
• FIRMWARE INFORMATION 26
• CLEANING AND MAINTENANCE 27

Pg 04
SAFETY INSTRUCTIONS
The design of this machine has taken into account all reasonable
user safety precautions. Nevertheless particular conditions of
installations and handling may create unforeseen situations
beyond the installers control.
1. Check to see that the data on the rating plate corresponds
to that of the main electrical supply to which the machine will
be attached.
2. The installation and repair must conform to local electrical
safety codes and regulations.
3. This machine is only safe when it has been correctly
connected to an efficient earthing/grounding system.
4. We do not recommend the use of multiple adapters and
extension cords.
5. Do not use this machine if there is damage to its cord, plug or
if any part of the machine malfunctions. Return the machine
to the nearest authorised service facility for examinations,
repair o adjustment.
6. The machine has been designed for the sole use of grinding
roasted coffee beans. Any other use must be considered
improper and therefore dangerous. The manufacturer
shall not be held responsible for any damaged caused by
inappropriate use.
7. These appliances are intended to be used for commercial
applications, for example in kitchens of restaurants,
canteens, hospitals and in commercial enterprises such
as bakeries, butcheries, etc., but not for continuous mass
production of food.
8. To protect against electric shocks when using any electrical
appliance including your Super Fausto Grinder:
a. Do not immerse the machine itself, cord and plugs
in water or other liquid and do not let the machine’s

Pg 05
internal parts get in contact with liquid.
b. Prevent the power cable from being stretched or pulled
tight.
c. Do not use the machine with wet hands.
d. Do not allow children or untrained persons to use the
machine.
e. Do not operate the machine when bare foot.
f. Always unplug the machine from the power supply
before performing any cleaning and or maintenance
operations.
g. Do not use water jets, non-suitable detergents or a
steam cleaner for cleaning.
h. Do not leave the machine switched on when not in use.
i. Do not obstruct the ventilation and or heat dissipation
openings and or slits not introduce water or any other
liquid into same.
j. Always switch off the appliance before removing
blockages from the pouring lip.
k. Never insert spoons, forks or other utensils into the
dispensing funnel.
l. Should a foreign body stop the motor, switch the
machine off immediately and contact an authorised
dealer and or service centre.
m. Do not expose the machine to atmospheric agents (sun,
rain, etc).
9. The machine is not designed for use in extreme temperature.
Operate within a -5°c to +30°c range.
10. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the

Pg 06
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
11. Do not allow children to play with this equipment at any time.
12. The user must respect the general safety regulations in force
in the country in the machine is being used as well as the
rules of common sense and shall be responsible for ensuring
periodic maintenance is performed.
13. The owner is responsible for checking the machine is
installed in tolerable environmental conditions such as to not
create a health or safety hazard for those using the machine.
14. Should you decide to no longer use this type of appliance,
we recommend that you make it inoperative: unplug the
appliance from the mains socket and cut off the power cord.
15. In the case of machine breakdown or malfunction switch the
machine off and do not tamper with it.
PRESERVATION OF THE MANUAL
This manual must be available at all times to users and /or the
persons performing maintenance on the machine. They must be
informed of how to use the machine correctly and residual risk.
Ensure it is preserved in a clean dry place so that the contents
are not damaged. Do not remove, tear out or rewrite any part
of the manual for any reason. In case of loss or for further
information please contact Rocket Espresso or Conti Valerio.
REMOVING MACHINE FROM PACKAGING
1. Ensure that there are no signs of damage to the machine by
checking the external cladding of the packaging.
2. Check the machine for signs of damage once the packaging

Pg 07
has been carefully removed.
3. Keep the packaging ( boxes, foam, plastic bags) well away
from the reach of children.
4. If there is evidence of defect or damage to the machine, the
authorised dealer from whom you purchased the machine
should be notified immediately so that remedial action can
be taken.
5. This symbol on the appliance or package means that the
appliance must not be considered as normal
household refuse, but that it must be
delivered to an appropriate collection centre
for the recycling of electric and electronic
appliances.
Make sure the appliance is disposed of correctly. For further
information about how to recycle this product contact your
local council or refuse disposal service.
GENERAL INFORMATION
This user manual is an essential part of the safe operation of your
Super Fausto Grinder, therefore it is important that you read the
enclosed warnings and precautions carefully. The information
contained in this manual must not be construed as substituting
the safety prescriptions and the technical data regarding the
installation and operation carried on the machine itself and
packaging materials.
The manufacturer reserve the right to make modifications to this
manual with no obligation to update previous versions except
in exceptional cases. Particularly information concerning the
safety during installation, operation and cleaning. This manual
reflects the current state of machine technology and shall not be
considered obsolete when updated at a later date on the basis of

Pg 08
acquired experience.
Please keep this manual in a safe place where it can be made
available to all users. Rocket Espresso can not be held liable
for any damage to people or property resulting from failure to
respect the instructions concerning safety, installations and
maintenance contained in this manual. For repairs contact
only an authorised service centre and request use of original
and spare parts. This manual must be preserved with care:
the manufacturer (Conti Valerio) declines all responsibility for
damages to persons or things or to the machine itself from
improper use or from use other than those outlined in safety
precautions and maintenance.

Pg 09
DESCRIPTION
VOLTAGE (V) 110 220 240 220
FREQUENCY (Hz) 60 50 50 60
10 A 900 W 900 W 900 W
250 250 250 250
1700 1400 1400 1400
4,0 4,0 4,0 4,0
10,5 10,5 10,5 10,5
480 480 480 480
175 175 175 175
285 285 285 285
POWER CONSUMPTION
MOTOR POWER (W)*
RPM
PRODUCTIVITY (g/s)
WEIGHT WHEN EMPTY (Kg)
HEIGHT (mm)
WIDTH (mm)
DEPTH (mm)
*The value given is for the actual revolutions of the burrs Activation times:
Ton: 30 sec. - Toff: 900 sec.
SUPER FAUSTO TECHNICAL DATA

Pg 10
MANUFACTURER
CONTI VALERIO S.R.L.
Via Luigi Longo, 39/41
50019 SESTO FIORENTINO
Firenze
Italy
For Rocket Espresso
COFFEE GRINDER MODEL
RS75E
OTHER INFORMATION

Pg 11
APPLIANCE DESCRIPTION
1. Touchscreen Display
2. Container cover
3. Coffee bean container
4. Coffee bean container opening/closing tab
5. Grinding adjusting knob
6. Dispensing funnel
7. Filter holder fork
8. Power ON switch
04.00 S
1

Pg 12
6
7
8
4
2
3
5

Pg 13
SETTING UPYOUR SUPER FAUSTO
MACHINE UNLOCK
Before starting the grinder operation, unscrew and remove the
white lock screw under the machine (turn anti-clockwise).
1

Pg 14
LOCKING THE CONTAINER
Before starting the appliance it is necessary to fit the coffeebean
container (3) and fit the portafilter holder fork (7).
• Insert the bean container (3) into its seat positioning so that
the hole lines up.
• Tighten the lock screw (9).
• Place the portafilter holder fork (7) onto the machine and
fasten with provided screws. There is a little flexibility with
height.
7
3
9

Pg 15
INTRODUCTION
It is necessary to set up the appliance before operating by
determining the correct grind required to create a perfect
extraction.
An espresso grind is a very fine grind yet still granular.
Coffee loses its flavour rapidly once ground and therefore only
grind as much as is needed for the espresso you are about to
prepare.
Temperature, humidity and wearing of the grinder burrs all effect
the accuracy of the grind setting, therefore each morning you
may find you need to “dial in” your grinder (make the grind setting
coarser or finer). This will be the difference between good coffee
and great coffee.
Ensure that your dosing and tamping is consistent.
Good extraction is characterised by a 5 - 10 second delay, before
any coffee will pour. Heavy droplets will appear and develop into
a thick, straight and even pour. The colour will be dark brown or
hazelnut, preferably with a reddish reflection.
The pour should be stopped before colour lightens and the pour
begins to curl in.
If the flow is too fast (another sign will be a pale crema and white
streaks) then adjust your grind and make it finer - rotate the
adjusting knob clockwise.
If the flow is too slow the grind is to fine. Adjust the grind and
make is coarser - rotate the adjusting knob anticlockwise.
Correct grind equals correct extractions equals correct flavour.

Pg 16
INSTRUCTIONS FOR USE
Plug in the machine and close the push tab at the bottom of the
bean container.
Fill the bean container with coffee beans.
Press the power on button (8) that must light up.
Pull the tab (4) out a little to permit the passage of the beans.
Place the portafilter onto the fork (7) underneath the dispensing
funnel.
Select the single (10), double (12) or triple (11) dose.
Dispensing/grinding stops once the preset time has elapsed or
if you want stop the grinding sooner press the key (10), (12) or (11)
again.
7
8
4

Pg 17
GRIND SETTING
Set the grinder by means of the adjusting knob (5) by rotating
it clockwise to make powder finer or anticlockwise to make it
coarser.
To start, grind some coffee off into portafilter and make a coffee.
This will give you the initial understanding of what the setting is
like in relation to the coffee.
Change the setting when the grinder is operating 1 - 2 notches
at a time. The difference between the notches will relate to 3 - 5
seconds in extraction time.
5

Pg 18
APPLIANCE SETTING
10. Key for single coffee dose
11. Key for triple coffee dose
12. Key for double coffee dose
13. Key for continuous dispensing mode
14. Key to access the menu
15. Padlock (locked/unlocked programming)
16. Decreasing key
17. Increasing key
18. Selected dose time display
04.00 S
10
11
13
14 15
12
16
18
17

Pg 19
SWITCHING ON YOUR SUPER FAUSTO
When switching the appliance on for the first time, it is configured
in the mode set by the factory and it will maintain the last mode
previous to switch off.
When switching the appliance on, the screen will display the “R”
graphic, pressing it displays the main screen.
STANDBY MODE
After 2 minutes of inactivity, the display goes into standby mode
and appears the “R” graphic. To exit standby mode, press the “R”
graphic, the main screen will reappear on the display.

Pg 20
DOSE DISPENSING AND SETTING
DISPLAY
• Place the portafilter on the filter hold fork.
• Press the dose key.
• The key will illuminate and the coffee will be ground and
dispensed into the portafilter.
• Once grinding has been completed, the zero returns to set
value.
• The grind time can be increased by pressing the (17) key or
decreased by pressing the (16) key.
CONTINUOUS DISPENSING MODE ACTIVATION
If you press the (13) key the continuous mode is activated.
The dispensing will continue until the release of the button.
By pressing one of the keys (10), (11) or (12) you return to the
automatic mode of dose selection.
04.00 S
10
11
13
12
16 17
