Rocket espresso Re a2 User manual

_____________________________________________________________________________________________

User Instructions Rocket RE A and RE S

Espresso Machines

RE A: 2 – 3 – 4 brewing heads

RE S: 2 – 3 – 4 brewing heads

From serial # C1507…..

_____________________________________________________________________________________________

Index Page

General data 3

Introduction 4

Important safeguards 5

Installation 7

Technical data 8

Installation diagram 9

Description of external components RE A series (automatic portion control) 10

Description of external components RE S (semi-automatic portion control) 11

Start-up 12

Operation RE A series with automatic portion control 13

 Brewing espresso 13

 Dispensing hot water 14

Operation RE S series with semi-automatic portion control 15

 Brewing espresso 15

 Dispensing hot water 16

Dispensing steam to froth or heat up liquids 16

Turning off the machine 17

Proper care and maintenance 18

Disassembling / dismantling of the machine 20

Programming automatic coffee portions 21

Programming hot water portions 22

Programming by the authorized technician 23

Declaration of CE conformity 27

Information for the authorized service technician:

RE A: Electrical diagram

28

(2 Gr. + 3 Gr. machines)

RE A: Hydraulic circuit

30

_____________________________________________________________________________________________

General data

Rocket Espresso Limited

Via Curiel 13

20060 Liscate (Milano)

Italy

Phone +39 02 9535 1334

Email info@rocket-espresso.com

Web www.rocket-professionale.com

Rocket RE series espresso machines

Rocket Espresso RE A2 2 brewing groups with automatic portion control

Rocket Espresso RE A3 3 brewing groups with automatic portion control

Rocket Espresso RE A4 4 brewing groups with automatic portion control

Rocket Espresso RE S2 2 brewing groups with semi-automatic portion control

Rocket Espresso RE S3 3 brewing groups with semi-automatic portion control

Rocket Espresso RE S4 4 brewing groups with semi-automatic portion control

The machines come with:

 User instructions

 1 one cup filter handle

 1 one cup metal filter basket

 1 blind filter basket (for cleaning/rinsing of brewing group)

 1 bottomless filter holder

Two group machines only:

 2 two cup filter handles with 2 two cup metal filter baskets

Three group machines only:

 3 two cup filter handles with 3 two cup metal filter baskets

Four group machines only:

 4 two cup filter handles with 4 two cup metal filter baskets

_____________________________________________________________________________________________

Introduction

Please read this user manual carefully since it provides important information on the

correct installation, use and maintenance of your coffee machine.

The user should be fully conversant with safety operating procedures contained in the

manual and should follow the instructions and advice provided with.

The information contained in this manual is necessary for the safe installation and

operation of your coffee machine.

It should be retained in a safe place for future reference. Copies are available from

your local dealer.

The user must respect the safety regulations at the point of installation. The user

must check the surrounding areas to ensure safe and hygienic use is guaranteed.

The information contained in this manual relating to installation and operation is not a

substitute for safety instructions and technical data affixed to the machine and/or its

packaging.

The manual provides information that is current at the time of publication. The

information is subject to amendment or alteration without notice.

Installation should only be carried out by technicians and service providers authorised

by Rocket Espresso Ltd.

To ensure maximum performance efficiency, it is essential that technical service and

maintenance is carried out exclusively by Rocket Espresso Ltd. authorised technicians.

Rocket Espresso Ltd. accepts no liability for injury and damage to person, persons or

property caused by incorrect installation, misuse, and user negligence, neglect of the

machine or any other circumstances beyond its control.

All spare parts fitted to the machine must be original Rocket Espresso Ltd.

components.

It is the responsibility of the user to notify the manufacturer of any defects or

damages, which may affect the safety of the original installation or future safe

operation of the machine.

The machine component’s manufacturers are responsible for the parts supplied by

them. The customer is responsible for the personal use of the equipment.

It is the responsibility of the user to ensure that the location of the machine is

hygienic, and that its continued safe operation can be guaranteed.

_____________________________________________________________________________________________

Important safeguards

1. Read all instructions.

2. This machine has been designed for the sole purpose of producing coffee, hot

water and steam for hot beverages.

All other uses are outside of the scope of this machine and, therefore, dangerous

and hazardous.

3. The machine has been designed from safe, accessible, durable components and

materials and manufactured to the highest standards for use only in professional

environment.

4. The machine should only be operated in accordance with instructions contained

in this manual and verbal instructions and training provided by an authorised

Rocket Espresso Ltd. dealer.

5. The machine must be operated by responsible adult persons who know the use

of the equipment and should not be used by children, minors or untrained

persons.

6. Close supervision is necessary when any appliance is used by or near children.

7. Do not touch hot surfaces. Use handle or knobs. Coffee brewing groups, metal

pipes, spouts, steam and hot water valves and wands, metal part of filter holders

are hot and will cause burns.

8. Never hold your hands under the brewing group, the filter handle, and the steam

and hot water wands. Hot drinks, hot steam and hot water are dispensed.

9. The machine should not be operated with temperatures lower than 6 °C and

hotter than 36 °C.

10. Do not use outdoors.

11. The machine should not be exposed to elements such as sunlight, rain, snow,

extreme temperatures etc.

12. Do not use aerosol sprays near the machine.

13. Do not place heavy objects or climb on top of the coffee machine.

14. Do not place on or near a hot gas or electric burner. Do not allow liquids to get

inside the coffee machine.

15. Allow the machine to cool before putting on or taking off parts

16. To protect against electric shock do not immerse machine, cord and plugs in

water or other liquid and do never let machine’s internal parts get in touch with

liquids.

17. Ensure that the machine is installed with a proper earth/ground in accordance to

local safety practises, codes and legislation.

18. Prevent the power cable from being stretched, or pulled tight.

19. Never use the machine with wet hands and / or with bare feet.

20. Never operate the machine without water.

_____________________________________________________________________________________________

21. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts.

22. Do not let cord hang over edge of table or counter, or touch hot surfaces.

23. Do not place on or near a hot gas or electric burner or in a heated oven.

24. Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

25. Before carrying out any maintenance operations turn the machine to “OFF”,

disconnect it from the mains and allow cooling.

26. Do not operate any appliance with a damaged cord, plugs, or after the appliance

malfunctions or has been damaged in any manner. Return appliance to the

nearest authorized service facility for examination, repair, or adjustment.

27. Accessory attachments are not recommended by the appliance manufacturer as

they may may cause injuries.

28. Do not use appliance for other than intended use.

29. Before any cleaning or maintenance the machine should be disconnected from

the electric supply.

30. When cleaning the machine never use caustic or abrasive cleaning chemicals.

31. To ensure efficient and correct operation it is essential to follow the

manufacturer’s instructions concerning the periodic maintenance carried out by

the authorized service technician.

32. When the machine is not being used for long periods of time, the hydraulic

systems should be drained completely and the machine stored in a temperature

above freezing (0°C or 32°F). This will prevent the hydraulic system from

freezing which could damage internal pipes and boiler.

33. The machine must be switched off whenever it is left unattended. The

connection to the water mains must be closed.

34. This appliance can be used by children aged from 8 years and above and persons

with reduced physical sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of

the appliance in a safe way and understand the hazards involved. Children shall

not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

35. Save these instructions.

_____________________________________________________________________________________________

Installation

The espresso machine Rocket RE series is to be installed to comply with the applicable

federal, state or local plumbing codes having jurisdiction exclusively by authorised

technical service.

All machines are designed to ensure maximum possible user safety. It is, however, an

important responsibility of the user to observe the following safety codes to further

enhance safe installation and operation.

1. Always ensure that hazardous packing items such as plastic bags, Styrofoam,

nails, etc. are properly disposed of to prevent accidental injury to children or

other persons.

2. If there is evidence of defect or damage to the machine an authorised Rocket

Espresso Ltd. dealer or technician should be notified immediately so that

remedial action can be taken.

3. This machine is safe only when it has been correctly connected to an efficient

earthing/grounding system. This should conform to local safety standards and

legislation in force at the time of installation.

4. Installation of any Rocket Espresso Ltd. product should only be undertaken by

duly authorised, properly trained and qualified personnel

5. Protect the user by fitting a circuit breaker to electric supply feeding the

machine.

6. A residual current device (RCD) having a rated residual operating current not

exceeding 30mA must be installed.

7. The machines with electrical input over 16 A, must be connected to a net with

impedance = or < than 0,37 Ω.

8. Dangerous or improper electrical connections are extremely hazardous and

should never occur.

9. Always check the integrity of the component content of the machine. Never fit

defective or damaged spare parts. Always request replacement spare parts from

Rocket Espresso Ltd.

10. Before connecting the machine to electric supply, always check that capacity and

power rating at least equals the power requirement of the machine.

11. The machine has to operate with clean soft drinking water. Never attempt to run

the machine with water that is harder than 7°F. The manufacturer recommends

use of an in line filter.

12. Check the efficiency of the machine’s water drain. Drain tray is located under the

drip tray

13. This equipment must be installed on a flat, level and stable surface. The

minimum height of this surface is 1025 mm

14. Handle the machine with care.

_____________________________________________________________________________________________

Technical data

Voltage Please refer to the technical data plate on the

machine

Wattage Please refer to the technical data plate on the

machine

Temperature The machine should not be operated with

temperatures under 6°C and over 36 °C.

Water The machine must be operated with soft,

clean drinking water. If the local water supply

has a high mineral content use a water

softener. A build up of mineral deposit may

restrict the flow of water within the hydraulic

systems causing damage to the machine and

risking personal injury. Rocket Espresso

recommends installation of an in line filter.

Water pressure from the mains Maximum water inlet pressure is 6 Bar

(0,6 MPa – 600 KPa). Please install a pressure

reducing valve if water pressure from the

mains is higher.

The minimum water pressure is 1.5 Bar

(0.15MPa-1500 KPa)

Hydraulic connections Water inlet 3/8” gas

Machine ventilation Please make sure that there is an open area

of at least 100 mm on each side and

behind the machine to allow adequate

ventilation

Boiler capacity 14,5 litre 2 group

23 litre 3 group

28 litre 4 group

Dimensions (for high drip tray version)

Width Depth Height

2 group 780 mm - 30.70 in 583 mm – 22.95 in. 535 mm – 21.06 in.

3 group 1.000 mm- 39.37 in 583 mm – 22.95 in. 535 mm – 21.06 in.

4 group 1.220 mm – 48.03 in 583 mm – 22.95 in. 535 mm – 21.06 in.

_____________________________________________________________________________________________

Installation diagram

Pos. 2 group machine 3 group machine

A 780 mm 30.70 in. 1000 mm 39.37in.

B 583 mm 22.95 in. 583 mm 22.95 in.

C 535 mm 21.06 in. 535 mm 21.06 in.

D 55 mm 2.17 in. 55 mm 2.17 in.

E 1.025 mm 40.35 in. 1.025 mm 40.35 in.

F 263 mm 10.35 in. 373 mm 14.69 in.

G 50 mm 1.97 in. 160 mm 6.30 in.

H 110 mm 4.33 in. 80 mm 3.15 in.

L 150 mm 5.90 in. 150 mm 5.90 in.

M 290 mm 11.42 in. 290 mm 11.42 in.

N 115 mm 4.53 in. 115 mm 4.53 in.

O 100 mm 3.94 in. 100 mm 3.94 in.

1 Shut off valve water mains

(not included to delivery)

2 Pressure reducing valve

(not included to delivery)

3 Water softener

(not included to delivery)

4 Drain

(not included to delivery)

5 Safety switch

(not included to delivery)

_____________________________________________________________________________________________

Description of external components RE A series

(automatic portion control)

Fig. 1

1 Machine’s on/off switch. Position “0” = off; position “1” = on

2 Steam wand. Caution: can become hot and cause burns.

3 Steam handle

4 Cups tray. Do never pour any liquid on this tray! It will filter inside the

equipment and can cause electrical shocks and serious injuries.

5 Key pad

6 Hot water wand. Caution: can become hot and cause burns

7 Pump pressure gauge. Pump pressure should be around 9 Bar.

8 Boiler pressure gauge. Boiler pressure should be around 0,9 Bar

9 Drip tray

10 Filter handle. Caution: can become hot and cause burns

11 Coffee brewing head (“group”). Caution: can become hot and cause

burns

12 Display

13 Control lamp “machine on” (when lightening)

14 Sight glass boiler water level control

_____________________________________________________________________________________________

Description of external components RE S series

(semi-automatic portion control)

Fig. 1B

1 Machine’s on/off switch. Position “0” = off; position “1” = on

2 Steam wand. Caution: can become hot and cause burns.

3 Steam handle

4 Cups tray. Do never pour any liquid on this tray! It will filter inside the

equipment and can cause electrical shocks and serious injuries.

5 Coffee dispensing start / stop button

6 Hot water wand. Caution: can become hot and cause burns

7 Pump pressure gauge. Pump pressure should be around 9 Bar.

8 Boiler pressure gauge. Boiler pressure should be around 0,9 Bar

9 Drip tray

10 Filter handle. Caution: can become hot and cause burns

11 Coffee brewing head (“group”). Caution: can become hot and cause burns

12 Hot water valve handle. Caution: can become hot and cause burns

13 Control lamp “machine on” (when lightening)

14 Sight glass boiler water level control

_____________________________________________________________________________________________

Start up

We assume the machine has been properly installed.

Open the water tap and switch on the main electrical switch (not included to delivery).

Turn the on/off switch (Fig. 1 or Fig. 1B – Pos. 1) from position 0 to position 1.

Wait till the boiler pressure has reached the working pressure (0.9 bar approx). You

can check it on the gauge (Fig. 1 or Fig. 1B – Pos. 8).

Open the steam handle (Fig. 1 or Fig. 1B – Pos. 3) for some seconds and then close it.

This operation avoids milk resuction into the boiler. Wait till the working pressure has

been reached again .

Your machine is now ready to work.

Operation of Rocket Espresso RE A series (automatic portion control)

Fig. 2 Touchpad

A B C D E F

_____________________________________________________________________________________________

Brewing espresso (with automatic portion control)

Preparing ONE cup of espresso

1. Use one cup filter handle (with 1 spout)

2. Position the metal one cup filter basket firmly inside the filter handle

3. Pour one portion (app. 6, 5-7 g) of ground espresso coffee into the filter basket

4. Tamp the ground coffee gently using the tamper supplied with the machine

5. Tighten the filter handle (Fig. 1-10) firmly into the brewing group (Fig. 1-11).

6. Put one cup under the filter handle spout.

7. Press the portion key for one cup dispensing (Fig. 2, B or D). Hot coffee flows into

the cup from the filter handle’s coffee spout.

8. When the programmed quantity of coffee (i.e. 25 cc/ 1 oz. for a typical espresso)

has been dispensed the machine will stop automatically (automatic portion control).

9. Remove the filter handle (Fig.1-10) from the machine and empty used coffee

grounds.

Preparing TWO cups of espresso

1. Use two cup filter handle (with 2 spouts)

2. Position the metal two cup filter basket firmly inside the filter handle

3. Pour two portions (app. 12 – 14 g) of ground espresso coffee into the filter basket

4. Tamp the ground coffee gently using the tamper supplied with the machine

5. Tighten the filter handle (Fig. 1-10) firmly into the brewing group (Fig. 1-11)

6. Put one cup under each of the filter handle spouts.

7. Press the portion key for two cup dispensing (Fig. 2, C or E). Hot coffee flows into

the cups from the filter handle’s coffee spouts.

8. When the programmed quantity of coffee (i.e. 25 cc/ 1 oz. for a typical espresso)

has been dispensed the machine will stop automatically (automatic portion control).

9. Remove the filter handle (Fig.1-10) from the machine and empty used coffee

grounds.

_____________________________________________________________________________________________

B. Semi-automatic brewing of espresso

Key Fig. 2- A (“P”) has to be used for semi-automatic dispensing of espresso. Press

this key to begin espresso dispensing and press again to stop the supply.

For all other procedure please see above.

Dispensing of hot water

1. Position the end nozzle of the hot water wand (Fig. 1-6) inside a suitable

pitcher used for food only.

2. Press the hot water key (Fig. 2-F).

3. Hot water will be dispensed into the pitcher.

4. When the programmed quantity of hot water has been reached, the

dispensing will stop automatically. The dispensing can be stopped

manually anytime pressing again the hot water key.

_____________________________________________________________________________________________

Operation of Rocket Espresso RE S series (semi-automatic portion control)

Preparing ONE cup of espresso

1. Use one cup filter handle (with 1 spout)

2. Position the metal one cup filter basket firmly inside the filter handle

3. Pour one portion (app. 6,5-7 g) of ground espresso coffee into the filter basket

4. Tamp the ground coffee gently using the tamper supplied with the machine

5. Tighten the filter handle (Fig. 1B-10) firmly into the brewing group (Fig. 1B-11).

6. Put one cup under the filter handle spout.

7. Press the coffee dispensing key (1B-5). Hot coffee flows into the cup from the filter

handle’s coffee spout.

8. When the requested quantity of coffee (i.e. 25 cc/ 1 oz. for a typical espresso)

has been dispensed, push the coffee dispensing key again to stop dispensing.

9. Remove the filter handle (Fig.1B-10) from the machine and empty used coffee

grounds.

Preparing TWO cups of espresso

1. Use two cup filter handle (with 2 spouts)

2. Position the metal two cup filter basket firmly inside the filter handle

3. Pour two portions (app. 12 – 14 g) of ground espresso coffee into the filter basket

4. Tamp the ground coffee gently using the tamper supplied with the machine

5. Tighten the filter handle (Fig. 1B-10) firmly into the brewing group (Fig. 1B-11)

6. Put one cup under each of the filter handle spouts.

7. Press the coffee dispensing key ( Fig. 1B-5). Hot coffee flows into the cups from

the filter handle’s coffee spouts.

8. When the requested quantity of coffee (i.e. 25 cc/ 1 oz. for a typical espresso)

has been dispensed, push the coffee dispensing key again to stop dispensing.

9. Remove the filter handle (Fig. 1B-10) from the machine and empty used coffee

grounds.

_____________________________________________________________________________________________

Dispensing of hot water

1 Position the end nozzle of the hot water wand (Fig. 1B-6) inside a suitable

pitcher used for food only.

2 Open the hot water valve ( Fig. 1B-12).

3 Hot water will be dispensed into the pitcher.

4 When the requested quantity of hot water has been dispensed, close the hot

water valve again.

_____________________________________________________________________________________________

Dispensing steam to froth or heat up liquids

1. Fill a suitable ideally stainless steel pitcher (used for food only) with an

insulated grip with the liquid to be heated up or frothed.

2. Position the steam nozzle of the steam wand (Fig. 1 or Fig. 1B – Pos. 2) just

below the surface of the liquid inside the liquid in the recipient.

To avoid personal injury always ensure that the end nozzle of the steam

wand (Fig. 1 or Fig. 1B – Pos. 2) is below the surface of the liquid to be

steamed.

3. Turn on steam valve (Fig. 1 or Fig. 1B – Pos. 3).

4. Heat up or froth the liquid inside the pitcher. Pay attention to hot sprays!

They may cause injuries.

5. When you’re done, close the steam valve (Fig. 1 or 1B - 3).

6. Clean the steam wand (Fig. 1 or 1B - 2) and the steam wand’s end nozzle

carefully with a non abrasive damp cloth after each single use without

touching it directly with any part of the body to avoid injury or damage due

to the hot surface of steam wand end nozzle. Caution: Hot surface.

Example: Steaming milk

1. Use a clean, cold pitcher and fill 1/3 with cold, fresh milk.

If milk has previously been steamed and stored in the refrigerator, we

suggest adding some fresh milk in order to achieve optimum foam. Milk

should be stored at a temperature around 4-5°C (app. 40°F).

2. Insert steam wand’s (Fig. 1 or 1B - 2) nozzle into the centre milk just below

the surface of the milk.

3. Open steam valve (Fig. 1 or 1B - 3) rapidly.

4. Steam will come out of the nozzle and froth the milk. The milk volume will

increase rapidly. Please lift the pitcher progressively to make sure that

the steam nozzle is always right below the surface of the milk.

5. When enough foam is achieved, submerge nozzle (going sidewise) and keep

it in that position finishing heating milk until the pitcher is too warm to

touch.

Please remember that milk should never be steamed over app. 76°C

(168°F). Milk steamed to over this temperature is scalded.

6. Close steam valve (Fig. 1 or 1B - 3) rapidly, then remove milk pitcher from

steam wand.

7. Wipe the steam wand (Fig. 1 or 1B - 2) immediately after using with a non

abrasive clean damp towel without touching the steam wand (Fig. 1 or

Fig. 1B – Pos. 2) directly with any part of the body to avoid injury or

damage due to the hot surface of steam wand end nozzle. Use a towel

that is designated for the steam wand only. Do not cross contaminate

kitchen towels by using the same towel for cleaning the steam wand

and i.e. kitchen tops.

Do not let the milk bake onto the steam wand. Clogged wands and steam

valves can be expensive to repair or to replace.

_____________________________________________________________________________________________

8. Burp your steam wand (Fig. 1 or Fig. 1B – Pos. 2) immediately after using

opening and closing immediately after the steam valve (Fig. 1 or Fig. 1B –

Pos. 3). Caution: Hot steam will come out of steam wand (Fig. 1or Fig.

1B – Pos. 2).

9. Finish espresso drinks with correct portions of milk and foam.

10. Clean steam pitcher and store for next drink.

Turning off the machine

Turn the main switch (Fig.1-1 or 1B - 1) to position 0.

The machine must be disconnected from the mains (switch off external main switch)

whenever it is left unattended. The connection to the water mains must be closed.

Proper care and maintenance

Simple, routine care of your espresso machine is your best defence against poor

quality shots, as well as preventing breakdowns or, even worse, personal injuries.

After each use:

 Wipe the steam wand (Fig. 1 or Fig. 1B – Pos. 2) immediately after using with a

non abrasive clean damp towel without touching it directly with any part of the

body to avoid injury or damage due to the hot surface of steam wand end

nozzle.

 Do not let the milk bake onto the steam wand.

 Clogged wands and steam valves can be expensive to repair or to replace.

 Burp your steam wand (Fig. 1 or Fig. 1B – Pos. 2) immediately after using

opening and closing immediately after the steam valve (Fig. 1 or Fig. 1B –

Pos. 3).

Caution: Hot steam will come out of steam wand (Fig. 1 or Fig. 1B – Pos. 2).

Burping the wand will remove the milk residue from the inside of the nozzle.

 Knock used coffee grounds from filter holder and rinse. Re-use or store in

brewing head (group) to keep the filter holder warm. (Please remember to take

out filter holders when machine is not operating for some hours (i.e. at night).

Throughout the day:

Wipe the screens inside your group head with a damp clean towel to remove excess

grounds. Caution: hot metal surfaces!

_____________________________________________________________________________________________

Before shutting down the machine after work:

For the following operations the machine has to be on:

Scrubbing the inner side of the brewing head (where the filter holder is tightened in):

With a small hard brush, give the inside of the group a good scrub. Caution: hot metal

parts! Do not touch! When done depress with RE A series machines key Fig. 2-A (“P”)

and with RE S series machines key Fig. 1B to dispense some hot water. Depress these

keys again after five seconds to stop water dispensing.

Back flushing (“rinsing”) of the group: The group should be back flushed at least once

a day (typically after work) with a specific food quality cleaning product for espresso

coffee machines. This operation is done individually with every group. Start

proceeding as follows:

Replace the filter basket inside the filter holder with the blind filter basket (the one

without holes). Now put the specific food quality cleaning product for espresso coffee

machines into the blind filter basket (quantity of cleaning product according to

manufacturer’s instructions; typically half a coffee spoon of product)). Now tighten the

filter holder into the group. From now on please follow the dedicated procedures for

RE A and RE S machines.

With RE A machines (automatic portion control) please use the built-in

semiautomatic back flushing program: Select the group you wish to back flush. Now,

operating with the selected group, keep key Fig. 2-A depressed while depressing key

Fig. 2-B. The leds of both keys start flashing. When the back flushing cycle is finished,

these keys stop flashing. Remove the filter holder from the group and depress key Fig.

2-A again. Dispense hot water for another 10/15 seconds and depress this key again

to stop. The operation for this group is done. Please note that while the back flushing

program is running on one group, you can operate with the other ones.

With RE S machines please proceed as follows: Depress key Fig. 1B – 5 and switch

it off after 15 seconds. Repeat this procedure about 5 times. When done remove the

filter holder, depress key B1-5 and dispense hot water for about 15 seconds. The

depress key B1-5 again to stop dispensing.

After backflushing the water being dispensed should be clean and fresh.

If needed, please repeat the back flushing again with water only to make sure the

detergent residues are washed away.

For the following operations the machine has to be switched off, unplugged

and completely cooled down:

Clean showers, group gaskets and group flange with a clean brush (to be used only

for this purpose).

Cleaning the filter holder and the metal filter baskets:

With a small screw driver or teaspoon, flick out the filter basket from the handle.

Once you have the filter basket out, clean both the filter basket and the internal

surface of the handle with a pot scourer until both surfaces are clean from the dark

coffee oils.

_____________________________________________________________________________________________

Should the oils in the handle have built up to excessive amounts, it may be necessary

to soak the handle and the metal filter basket in hot water with a cap full of special

detergent product for espresso machines for 30 minutes or so and then rinse

thoroughly in fresh water.

Wash metal filter baskets and filter handle in warm water adding a special detergent

product or espresso machines following the instruction’s of the specific product. It has

to be food quality and for this specific use with coffee machines.

Clean the drip tray (Fig. 1 or Fig. 1B – Pos. 9) and grid with a non abrasive damp

cloth.

Clean drain tray (located under the drip tray) with a clean damp cloth and a clean

brush.

Wipe down surface of machine with non-abrasive clean cloth. Do never use aggressive

cleaners or scouring powders! This operation has to be done when necessary.

How to disassemble/dismantle the machine

The machine has to be disassembled and dismantled by an authorized technician

according to local law and jurisdiction.

1. Clean filter holders, baskets and brewing head (“group”).

2. Switch off and let machine completely cool down to ambient temperature.

3. Remove the drip tray (Fig. 1 or Fig. 1B – Pos. 9)

4. Open the boiler drain valve (located under the drip tray). The boiler water will

flow into the machine’s drain tray.

5. When done, close the boiler drain valve.

6. Position the drip tray (Fig. 1 or Fig. 1 B – Pos. 9).

7. Store the machine in a safe, dry and clean place.

Rocket Espresso RE A2 User manual

Popular Coffee Maker manuals by other brands
