Rockford Fosgate RFX-8130 Installation and operating manual

®®
Installation Reference Sheet
Páginas de Referencia para la Instalación
Schéma d’Installation
Installations Beiblatt
Istruzioni di Installation
RFX-8130

GENERAL
•ISO Mountable – 178mm x 50.4mm (trim ring removed)
•SMART-On (Sequentially Managed Accessory Remote
Turn-On) Separate turn-on leads for amplifiers and signal processors
that protect speakers and electronics from damaging transients
•Any Button Wake-Up
•Clock
•Cell Phone Mute
•Switchable Loudness – Enables bass response to be boosted at
low listening levels
•IR Remote Compatible w/ Pulse – Ability to operate
functions via remote control as well as trigger external devices (amp
racks, neon lights, etc.)
•Dimmable Dual Color Illumination – Green or Amber color
•Internal Amplifier – 4-channel speaker outputs
•Smart Power Antenna Output
PREAMP
•Low Source Impedance – Enables multiple amplifiers to be
driven without signal loss
FEATURES
•5-ch Pre-Out w/Adjustable Sub Level – Front/Rear/Sub
(80Hz Mono) RCA
•Source Tone Memory – Enables separate Bass and Treble
memory for different formats
•External Audio Input – Allows the source unit to play an
additional audio source (VCR, video game, etc.)
TUNER
•Gen 3.2 w/patented Digital Automatic Alignment
•MIR (Multipath Interference Rejection) – Improves audio
performance when radio reception is poor
•World Wide Tuner – America/Europe/Aust/Saudi
•24 Station Presets – 6AM/18FM Presets
•Auto Store – Auto programming of all 24 presets
COMPACT DISC
•5.0 Hologram laser w/multi-damping
•Dual 1 Bit D/A Converters w/8x Oversampling
•Digital Servo Control w/Auto Focus – Adjusts to CD
manufacturing tolerances for accurate tracking
SPECIFICATIONS
FM TUNER
Frequency Response ................................. 30Hz – 15kHz
Usable Sensitivity..........................................20dB @ 1uV
Alternate Ch. Selectivity ........................................... 90dB
Adjacent Ch. Selectivity ........................................... 50dB
50dB Quieting Sensitivity........................................ 18dBf
Signal-to-Noise Ratio ............................................... 72dB
Channel Separation ...................................≥25dB @ 1kHz
Capture Ratio ................................................ 2.6 @ 45dBf
CD PLAYER
Usable Discs ..................................................... 5” and 3”
Frequency Response ...................... 20Hz – 20kHz (±2dB)
Signal-to-Noise Ratio ............................................. >90dB
Channel Separation .................................................. 86dB
Dynamic Range ..................................................... 100dB
AM TUNER
Sensitivity.......................... 31dBf max. @ 10dB sensitivity
–6dB Bandwidth ....................... 5kHz min. – 12kHz max.
GENERAL
Operating Voltage ............................... +10.5 to +16V DC
Continuous Power Output ........................... 7.5 x 4 Watts
Dynamic Power Output ................................13 x 4 Watts
Pre-Out Voltage (vol. max.) ................................ 2.4 Vrms
Preamp Output Impedance ....................................... 50Ω
Equalization ....................................... Bass ±8dB @ 60Hz
Treble ±10dB @ 10kHz
Sub-Out .......................................... 12dB/octave @ 80Hz
Chassis Dimensions ........................... 7"W x 63⁄8"D x 2"H
(178mm x 162mm x 50.4mm)
Nosepiece Dimensions ................... 71⁄16"W x 7⁄8"D x 2"H
(179.7mm x 22.2mm x 50.4mm)
Weight ................................................... 3.54 lbs. (1606g)
IR REMOTE
Dimensions ............................... 29⁄16” W x 33⁄4” L x 3⁄4” H
(6.51cm x 9.53cm x 1.9cm)
®®
AM / FM ST / CD Player / CD Changer Controller
Detachable Faceplate w/IR Remote
RFX-8130 Specification
Reference
Sheet
RFX-8130
®®
AUD SEL
6
RDMRPTSCAN PAUSED.SCN DIM
43 521
P.SCN LOUDDSPL
CLOCK ILLUM
PWR
AUTO
VOL TUNE
COMPACT
DIGITAL AUDIO
Specifications subject to change without notice
®
1-6
+
–
®

RFX-8130 AM / FM ST / CD Player / CD Changer Controller
Detachable Faceplate w/IR Remote
Antenna
Subwoofer (–)
Subwoofer (+)
3
4
5
6
7
8
9
10
1
2
(Looking into the Radio
Connector)
Front Right (–)
Front Right (+)
Front Left (–)
Front Left (+)
Rear Right (–)
Rear Right (+)
Rear Left (–)
Rear Left (+)
10
9
8
7
6
5
4
3
2
1
RCA Harness
CD Changer/Ex Audio DIN
(Looking into the Changer DIN)
4321
8765
12 11 10 9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
Right Signal (+)
Audio Common (–)
Left Signal (+)
Shield (Barrel)
Ground
N/C
N/C
N/C
N/C
Battery (+12V)
E&C Data
N/C
N/C
Power Harness
(Looking into the Radio Connector)
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Turn-On “B”
Turn-On “A”
Turn-On “C“
Audio Mute
External Audio
Rear (L–)
Rear (R–)
Front (L–)
Front (R–)
Chassis Ground
(Blue/White)
(Lt. Blue)
(Blue/Red)
(Brown)
(Green/White)
(Green/Black)
(Purple/Black)
(White/Black)
(Gray/Black)
(Black)
N/C
Dimmer Out
Dimmer In
Ignition +12V
N/C
Pwr. Antenna
Rear (L+)
Rear (R+)
Front (L+)
Front (R+)
Battery +12V
(Orange/White)
(Orange)
(Red)
(Dk. Blue)
(Green)
(Purple)
(White)
(Gray)
(Yellow)
Minimum & Maximum
Mounting Angle
20°
20°
Antenna
Input
1-6
+
–
White
White/Black
Gray
Gray/Black
Green
Green/Black
Purple
Purple/Black
Orange/White
Orange
Green/White
Brown
Yellow
Red
Lt. Blue
Dimmer In (+12V to activate) (Input)
4 Speaker System
2 Speaker System
IR Remote
RFX-1110
Press “Diamond R”
Button to Pulse
Turn on “C”
Turn-On “C” (300mA Max) (Output)
(Pulsed 500ms)
Turn-On “B” (300mA Max) (Output)
(.5 sec DELAY ON – FAST OFF)
Turn-On “A” (2.0 Amp Max) (Output)
(FAST ON – .5 sec DELAY OFF)
Battery +12V (Input)
Ignition (switched +12V) (Input)
Chassis Ground (Input)
Battery Replacement
(2) CR2032
+
–
+
–
+
–
+
–
Blue/Red
Blue/White
Power Antenna (300mA Max) (Output)
Dk. Blue
10A Fuse
Black
Turn-On “B” = Amplifier(s)
Turn-On “A” = Signal Processor(s)
®®
Dimmer Out (External Control) (Output)
Front (L+) (Speaker Output)
Front (L–) (Speaker Output)
Front (R+) (Speaker Output)
Front (R–) (Speaker Output)
Rear (L+) (Speaker Output)
Rear (L–) (Speaker Output)
Rear (R+) (Speaker Output)
Rear (R–) (Speaker Output)
R
E
D
Sub Output Red (Mono)
G
R
E
E
N
G
R
A
Y
Front Output Red (Right)
Rear Output White (Left)
Rear Output Red (Right)
Front Output White (Left)
Audio Mute (GND to activate) (Input)
External Audio (GND to activate) (Input)
®
RESET
Instrument Panel Thickness Tabs to Bend
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Left Side View Right Side ViewTop View
Installation
Reference
Sheet
G G C
CCB F A D E E D AF B C
FA-1608-A
FA-1612-A

RFX-8130 AM/FM ST/Reproductor de CD’s/Controlador de Cargador de CD’s
Frontal Extraible con Mando a Distáncia
Instrument Panel Thickness Tabs to Bend
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Left Side View Right Side ViewTop View
Páginas de Referencia
para la Instalación
G G C
CCB F A D E E D AF B C
Subwoofer (–)
Subwoofer (+)
1
2
10
9
8
7
6
5
4
3
2
1
4321
8765
12 11 10 9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
22 21 20 19 18 17 16 15 14 13 12
1110987654321
20°
20°
Audio Externo (GND para ser activado)
(Entrada)
Sistema de 4
altavoces
+
–
+
–
+
–
+
–
Alimentación de la Antena
(Máx 300mA (Salida)
®®
R
O
J
O
Salida Subwoofer Rojo (Mono)
V
E
R
D
E
G
R
I
S
Antena
Ángulos Máximo y
Mínimo para montaje
Entrada de
Antena
(Mirando hacia el
Conector de la Radio)
Derecha Frontal (–)
Derecha Frontal (+)
Conector RCA
Salida Frontal Rojo (Derecha)
Izquierda Frontal (–)
Izquierda Frontal (+)
Salida Frontal Blanco (Izquierda)
Mando a distancia
por Infrarrojos
RFX-1110
Pulse el botón R
Diamante para el
encendido “C”
Cambio de batería
(2) CR2032
1-6
+
–
®
Salida Posterior Blanco (Izquierda)
Salida Posterior Rojo (Derecha)
Derecha Posterior (–)
Derecha Posterior (+)
Izquierda Posterior (–)
Izquierda Posterior (+)
Azul Oscuro
Blanco
Blanco/Negro
Gris
Gris/Negro
Verde
Verde/Negro
Violeta
Violeta/Blanco
Naranja/Blanco
Naranja
Verde/Blanco
Marrón
Amarillo
Rojo
Azul Claro
Azul/Rojo
Azul/Blanco
Negro
Encendido “B” = Amplificadore(s)
Encendido “A” = Procesador de Señal
3
4
5
6
7
8
9
10
Salida de Dimmer (Control Externo) (Salida)
Silenciador de Audio
(GND para ser activado)
(Entrada)
Encendido “C” (300mA Máx) (Salida)
(Pulsado 500ms)
Encendido “B” (300mA Máx) (Salida)
(Delay de 0.5 segundos conectado apagado Rápido)
Encendido “A” (2.0 Amp Máx) (Salida)
(Encendido Rápido Delay de 0.5 segundos desconcectado)
Batería +12V (Entrada)
Ignition (switched +12V) (Entrada)
Toma de tierra del Chasis (Entrada)
Fusible de
10 Amperios
Salida para el altavoz frontal (R–)
Salida para el altavoz posterior (R–)
Salida para el altavoz posterior (R+)
Salida para el altavoz posterior (L–)
Salida para el altavoz posterior (L+)
Salida para el altavoz frontal (R+)
Salida para el altavoz frontal (L–)
Salida para el altavoz frontal (L+)
Entrada de Dimmer (+12V para ser activado)
(Entrada)
Conector de Alimentación
(Mirando hacia el Conector de la Radio)
Cambiador de CD's
(Mirando hacia el Cambiador de CD's)
Señal Derechal (+)
Común Audio (–)
Señal Izquierda (+)
Blindaje (Protección)
Tierra
N/C
N/C
N/C
N/C
Battería (+12V)
Datos E/C
N/C
N/C
Sistema de 2
altavoces
1
2
3
4
5
6
7
8
9
10
11
N/C
Encendido “B”
Encendido “A”
Encendido “C“
Silenciador de Audio
Audio Externo
Posterior (L–)
Posterior (R–)
Frontal (L–)
Frontal (R–)
Toma de tierra del chasis
(Azul/Blanco)
(Azul Claro)
(Azul/Rojo)
(Marrón)
(Verde/Blanco)
(Verde/Negro)
(Viloeta/Negro)
(Blanco/Negro)
(Gris/Negro)
(Negro)
N/C
Salida de Dimmer
Entrada de Dimmer
Alimentación +12V
N/C
Alimentación de la Antena
Posterior (L+)
Posterior (R+)
Frontal (L+)
Frontal (R+)
Batería +12V
(Naranja/Blanco)
(Naranja)
(Rojo)
(Azul Oscuro)
(Verde)
(Violeta)
(Blanco)
(Gris)
(Amarillo)
12
13
14
15
16
17
18
19
20
21
22
RESET
FA-1608-A
FA-1612-A

RFX-8130 OM / FM ST / Lecteur CD / Commande Changeur CD
Face détachable avec télécommande IR
Epaisseur du tableau de bord Languettes à plier
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Vue de gauche Vue de droiteVue du haut
Schéma
d’Installation
G G C
CC B F A D E E D AF B C
Antenna
Subwoofer (–)
Subwoofer (+)
3
4
5
6
7
8
9
10
1
2
10
9
8
7
6
5
4
3
2
1
Cablage RCA
4321
8765
12 11 10 9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
20°
20°
Fiche
Antenne
Audio Externe (commande négative) (Entrée)
+
–
+
–
+
–
+
–
Antenne Electrique (300mA Max)
®®
R
O
U
G
E
Sortie Sub rouge (Mono)
V
E
R
T
G
R
I
S
Orange/Blanc
Orange
Blanc
Blanc/Noir
Gris
Gris/Noir
Vert
Vert/Noir
Violet
Violet/Noir
Vert/Blanc
Brun
Jaune
Rouge
Bleu clair
Bleu/Rouge
Bleu/Blanc
Bleu foncé
Noir
Dimmer (Contrôle Externe) (Sortie)
Commande “C” (300mA Max) (Sortie)
(Impulsion 500mA)
Commande “B” (300mA Max) (Sortie)
(Délai d'allumage 0,5s – coupure rapide)
Commande “A” (2,0A Max) (Sortie)
(Allumage rapide – Délai de coupure 0,5s)
Batterie +12V (Entrée)
+15 Allumage (Entrée)
Masse Chassis (Entrée)
Fusible 10A
Avant (G+) (Sortie HP)
Avant (G–) (Sortie HP)
Avant (D+) (Sortie HP)
Avant (D–) (Sortie HP)
Arrière (G+) (Sortie HP)
Arrière (G–) (Sortie HP)
Arrière (D+) (Sortie HP)
Arrière (D–) (Sortie HP)
Atténuateur audio (mute) – commande
négative (Entrée)
Dimmer (+12V pour activer) (Entrée)
Commande “B” = Amplificateur(s)
Commande “A” = Processeur(s) de signal
Télécommande IR
RFX-1110
Appuyer sur le bouton
rouge “Losange R” pour
activer la commande “C.”
Batterie de
remplacement
(2) CR2032
1-6
+
–
®
Arrière droite (–)
Arrière droite (+)
(Vue sur le connecteur de la radio)
Avant droite (–)
Avant droite (+)
Avant gauche (–)
Avant gauche (+)
Arrière gauche (–)
Arrière gauche (+)
N/C
Commande “B”
Commande “A”
Commande “C“
Atténuateur audio
Audio Externe
Arrière (G–)
Arrière (D–)
Avant (G–)
Avant (D–)
Masse chassis
(Bleu/Blanc)
(Bleu clair)
(Bleu/Rouge)
(Brun)
(Vert/Blanc)
(Vert/Noir)
(Violet/Noir)
(Blanc/Noir)
(Gris/Noir)
(Noir)
(Orange/Blanc)
(Orange)
(Rouge)
(Bleu foncé)
(Vert)
(Violet)
(Blanc)
(Gris)
(Jaune)
N/C
Entrée Dimmer
Sortie Dimmer
Allumage +12V
N/C
Antenne Electr.
Arrière (G+)
Arrière (D+)
Avant (G+)
Avant (D+)
Batterie +12V
(Vue sur le connecteur
de la radio)
Sortie Arriére gauche blanc
Sortie avant gauche blanc
Sortie avant droite rouge
Sortie Arriére droite rouge
Angle de montage
maximum et minimum
DIN Changeur CD
(Vue sur le DIN Changeur)
Signal positif droite (+)
Commun négatif signal (–)
Signal positif gauche (+)
Blindage
Masse
N/C
N/C
N/C
N/C
Batterie +12V
Données E&C
N/C
N/C
Cablage HP/Alimentation
Installation 4 HP
Installation 2 HP
RESET
FA-1608-A
FA-1612-A

RFX-8130 AM / FM ST / CD Spieler / CD Wechsler-Steuerungsgerät
Abnehmbares Bedienteil/IR Fernbedienung
Dicke des Instrumenten-Panels KlammeRN zu biegen
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Linke
Seitenansicht Rechte
Seitenansicht
Draufsicht
Installations
Beiblatt
G G C
CC B F A D E E D AF B C
Antenne
Subwoofer (–)
Subwoofer (+)
3
4
5
6
7
8
9
10
1
2
(Blick in den Radio Anschluβ)
Vorne rechts (–)
Vorne links (+)
Hinten rechts (–)
Hinten links (+)
10
9
8
7
6
5
4
3
2
1
RCA Adapter
CD Wechsler/Ex Audio DIN
(Blick in den CD Anschluβ)
4321
8765
12 11 10 9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
Rechtes Signal (+)
Audio gesamt (–)
Linkes Signal (+)
Abschirmung
Masse
N/C
N/C
N/C
N/C
Batterie +12V
E&C Daten
N/C
N/C
Strom Stecker
(Blick in den Radio Anschluβ)
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Einschaltstrom “B”
Einschaltstrom “A”
Einschaltstrom “C“
Stummschaltung
Extern Audio
Hinten (L–)
Hinten (R–)
Vorne (L–)
Vorne (R–)
Karosserie Masse
(Blau/Weiβ)
(Hellblau)
(Blau/Rot)
(Braun)
(Grün/Weiβ)
(Grün/Schwarz)
(Violett/Schwarz)
(Weiβ/Schwarz)
(Grau/Schwarz)
(Schwarz)
N/C
Dimmer Ausgang
Dimmer In
Ignition +12V
N/C
Motor Antenne
Hinten (L+)
Hinten (R+)
Vorne (L+)
Vorne (R+)
Batterie +12V
(Orange/ Weiβ)
(Orange)
(Rot)
(Dunkelblau)
(Grün)
(Violett)
(
Weiβ) )
(Grau)
(Gelb)
Minimaler & Maximaler
Einbauwinkel
20°
20°
Antenneneigang
Weiβ
Weiβ/Schwarz
Grau
Grau/Schwarz
Grün
Grün/Schwarz
Violett
Violett/Schwarz
Orange/Weiβ
Orange
Grün/Weiβ
Braun
Gelb
Rot
Hellblau
Stummschaltung (GND zum aktivieren)
(Eingang)
4 Lautsprecher System
2 Lautsprecher
System
IR Fernbedienung
RFX-1110
Drücke “Diamond R”
Taste, um auf “C”
Einschaltimpuls zu geben
Einschaltstrom “C” (300mA Max)(Ausgang)
(Pulsed 500ms)
Einschaltstrom “B” (300mA Max)(Ausgang)
(.5 sec Einschaltverzögerung-Schnelles Ausschalten)
Batterie +12V (Eingang)
Zündung (schaltbar +12V) (Eingang)
Karosserie Masse (Eingang)
Ersatzbatterien
(2) CR2032
+
–
+
–
+
–
+
–
Blau/Rot
Blau/Weiβ
Motor Antenne (300mA Max) (Ausgang)
Dunkelblau
10A Sicherung
Schwarz
Einschaltstrom “B” = Verstärker(s)
Einschaltstrom “A” = Signal Prozessor(s)
®®
Dimmer Ausgang (Externe Kontrolle) (Ausgang)
Vorne (L+) (Lautsprecherausgang)
Vorne (L–) (Lautsprecherausgang)
Vorne (R+) (Lautsprecherausgang)
Vorne (R–) (Lautsprecherausgang)
Hinten (L+) (Lautsprecherausgang)
Hinten (L–) (Lautsprecherausgang)
Hinten (R+) (Lautsprecherausgang)
Hinten (R–) (Lautsprecherausgang)
R
O
T
G
R
Ü
N
G
R
A
U
Subwoofer Ausgang Rot (Mono)
Ausgang Vorne rot (rechts)
Ausgang Vorne weiβ(links)
Ausgang Hinten weiβ(links)
Ausgang Hinten rot (rechts)
Hinten rechts (–)
Hinten links (+)
Vorne rechts (–)
Vorne links (+)
1-6
+
–
®
Dimmer In (+12V zum aktivieren) (Eingang)
Audio (GND zum activieren) (Eingang)
Einschaltstrom “A” (2.0 Amp Max) (Ausgang)
(Schnelles Einschalten – .5 sec Ausschaltverzögerung)
RESET
FA-1608-A
FA-1612-A

RFX-8130
Spessore del pannello Alette da piegare
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Istruzinoni di
Installazione
G G C
CC B F A D E E D AF B C
Antenna
Subwoofer (–)
Subwoofer (+)
3
4
5
6
7
8
9
10
1
2
10
9
8
7
6
5
4
3
2
1
CD Changer/DIN Audio Est
(Vista del DIN del changer)
4321
8765
12 11 10 9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
E&C Data
N/C
N/C
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
20°
20°
Sistema con 4
altoparlanti
+
–
+
–
+
–
+
–
®®
R
O
S
S
O
Sub Uscito Rosso (Mono)
V
E
R
D
E
G
R
I
G
I
O
Ingresso Dimmer (+12V per attivare) (Ingresso)
Uscita Dimmer (Controllo esterno) (Uscita)
Bianco
Bianco/Nero
Grigio
Grigio/Nero
Verde
Verde/Nero
Viola
Viola/Nero
Anteriori (L+) (Uscita altoparlanti)
Posteriori (L+) (Uscita altoparlanti)
Anteriori (L–) (Uscita altoparlanti)
Anteriori (R+) (Uscita altoparlanti)
Anteriori (R–) (Uscita altoparlanti)
Posteriori (L–) (Uscita altoparlanti)
Posteriori (R+) (Uscita altoparlanti)
Posteriori (R–) (Uscita altoparlanti)
Arancione/Bianco
Arancione
Verde/Bianco
Consenso “B” = Amplificatore
Consenso “A” = Processore di Signale
Non impiegato
+12V batteria
(Ingresso)
Ignition (switched +12V) (ingresso)
Massa del telaio (ingresso)
Fusibile 10A
Non impiegato
Consenso “C” (300mA Max) (Uscita)
(Impulsi 500ms)
Consenso “B” (300mA Max) (Uscita)
(0,5 sec accensione ritardo – spegnimento immediato)
Consenso “A” (2.0 Amp Max) (Uscita)
(accensione immediata, ritardo 0,5 sec spegnimento)
Audio Mute (Massa per attivare) (ingresso)
Marrone
Giallo
Rosso
Azzurro
Blu/Rosso
Blu/Bianco
Blu scuro
Nero
Premere il tasto
“DIAMOND R” per
il consenso “C”
Sostituzione batteria
(2) CR2032
Telecomando
infrarossi
RFX-1110
1-6
+
–
®
Connettore RCA
(Guardando il
connettore della radio)
N/C
Consenso “B”
Consenso “A”
Consenso “C“
Audio Mute
Esterno Audio
Posteriori (L–)
Posteriori (R–)
Anteriori (L–)
Anteriori (R–)
Massa del telaio
(Blu/Bianco)
(Azzurro)
(Blu/Rosso)
(Marrone)
(Verde/Bianco)
(Verde/Nero)
(Viola/Nero)
(Bianco/Nero)
(Grigio/Nero)
(Nero)
N/C
Dimmer Out
Dimmer In
+12V sotto chiave
N/C
Antenna elettrica
Posteriori (L+)
Posteriori (R+)
Anteriori (L+)
Anteriori (R+)
+12V batteria
(Arancione/Bianco)
(Arancione)
(Rosso)
(Blu Scuro)
(Verde)
(Viola)
(Bianco)
(Grigio)
(Giallo)
(Guardando il connettore della radio)
Connettore di alimentazione
Signale destro (+)
Comune audio (–)
Signal sinistro (+)
Schermo
Massa
N/C
N/C
N/C
N/C
+12V batteria
Angolo minimo e
massimo di installazione
Ingresso
Antenna
Uscita Anteriori Bianco (sinistro)
Uscita Anteriori Rosso (destro)
Uscita Posteriori Bianco (sinistro)
Uscita Posteriori Rosso (destro)
Anteriori (R–)
Anteriori (R+)
Anteriori (L–)
Anteriori (L+)
Posteriori (R–)
Posteriori (R+)
Posteriori (L–)
Posteriori (L+)
Sistema con 2
altoparlanti
RESET
AM / FM ST / CD Player / CD Changer Controller
Frontalino Estraibile
Vista da sinistra Vista da destraVista dall’alto
FA-1608-A
FA-1612-A

Sintonizzatore a copertura mondiale
Le bande di frequenza del sintonizzatore possono
essere programmate per adeguarsi ai diversi sistemi
dei paesi (Giappone escluso).
1.Tenere premuto DSPL per 2 secondi
2.Premere il tasto Onda Sinusoidale (Tuner)
3.PremerepiúvolteSELperselezionaretraAMERI-
CAS, EUR/AUST e SAUDI
Nota: per l'Italia selezionare EUR/AUST
Weltweiter Tuner
Das Frequenzband des Tuners kann programmiert
werden,uminden verschiedenen Ländern einwandfrei
zu funktionieren (ausgenommen Japan).
1.Drücken und halten Sie DSPL für zwei Sekunden
2.Drücken Sie SINE WAVE (Tuner)
3.Drücken Sie SEL, um zwischen AMERICAS, EUR/
AUST und SAUDI umzuschalten
Rockford Fosgate
Rockford Corporation
546 South Rockford Drive
Tempe, Arizona 85281 U.S.A.
In U.S.A., [phone]
In Europe, Fax [phone]
In Japan, Fax [phone]
MAN-1606-A
3/97
DEUTSCH ITALIANO
Sintonizador Standard Mundial
La banda de frecuencias del sintonizador puede ser
programdaparasercompatibleconlosdiferentescódigos
de los países (excepto Japón)
1.Mantenga pulsado el botón DSPL durante dos
segundos
2.Pulse el botón con la onda senoidal (Radio)
3.Pulse SEL para cambiar secuencialmente entre
AMERICAS,EUROPA/AUSTRALIAyARABIASAUDI
ESPAÑOL
World Wide Tuner
The frequency band on the tuner can be programmed
toconform withdifferent country codes (except Japan)
1.Press and hold DSPL for two seconds
2. Press SINE WAVE (Tuner)
3. Press SEL to cycle through AMERICAS, EUR/
AUST and SAUDI
ENGLISH
FRANÇAIS
World Wide Tuner
La bande de fréquence peut être programmé pour
convenir au codes des différent pays (excepté le Japon).
1.Enfoncez et tenez DSPL enfoncé durant deux
secondes
2. Enfoncez SINE WAVE (Tuner)
3. Enfoncez SEL pour parcourir AMERICAS, EUR/
AUST et SAUDI
MADE IN MEXICO
Designed and Engineered in the USA
by Delco Electronics and Rockford Fosgate
This product was assembled by Delco Electronics at Deltronicos de Matamoros,
Mexico. Due to the global nature of their manufacturing facilities and the electronics
parts industry in general, some parts may be manufactured in other countries.
