Installation & Operation
Serial Number: Date of Purchase:
R1L 10" 12"
Single R1L-1X10 R1L-1X12
Dual R1L-2X10 R1L-2X12
R1L – LOADED ENCLOSURES
SVC - SINGLE VOICE COIL SUBWOOFERS
INSTALLATION – ENGLISH
CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.
Run the speaker cable from the amp. When routing the speaker cable from the amplifier, avoid running it close to any sources of high current
(wiring harnesses).The positive (+) speaker output from the amp connects to the red terminal of the enclosure, and the negative (-) connects to the
black terminal.
INSTALACIÓN – ESPAÑOL
PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio
y/o posibles lesiones.
Recorrido del Cable de Altavoz Desde el Amplificador. Al llevar el cable de altavoz desde el amplificador, evite que pase cerca de cualquier
fuente de alto corriente (cables de alimentacion). El terminal positive (+) de las salida de rojo, y el terminal negativo (-) al terminal negro.
INSTALLATION – FRANÇAIS
MISE EN GARDE : avant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de
blessures, d’incendie ou de dommages à l'appareil.
Branchement du câble du haut-parleur de l’amplificateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de l’approcher d’une source
de courant important. La sortie positive de l’ampli se branche sur le terminal rouge du caisson, et le négatif se branche sur le terminal noir.
EINBAU– DEUTSCH
VORSICHT:Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu
vermeiden.
Anschluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel
kreuzt, um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherkabels kommt in die rote Klemme des Terminals, die Negativ-Leitung in die
schwarze Klemme des Terminals.
INSTALLAZIONE – ITALIANO
ATTENZIONE: Prima dell’installazione,scollegate il terminale negativo (-) della batteria per evitare danni all’unità,
pericoli d’incendio e/o potenziali lesioni personali.
Far correre il cavo dell’altoparlante all’amplificatore. Quando fate correre il cavo dell’altoparlante all’amplificatore non
fatelo passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto. Il segnale positivo dell’altoparlante (+) in uscita dall’amplificatore á col-
legato al terminale rosso del diffusore, e il negativo (-) al terminale nero.
Strip 5/8"
(16mm)
From
Amplifier
From
Amplifier
16 AWG
-to-
12 AWG
R1L-1X10 / R1L-1X12
Amplifier 4Ω Mono
Amplificador 4Ω Mono
Amplificateur de 4Ω Mono
Amplifier 4Ω Mono
Amplificatore 4Ω Mono
Black
Negro
Noir
Schwarz
Nero
Red
Rojo
Rouge
Rot
Rosso
R1L-2X10 / R1L-2X12
Amplifier 2Ω Mono
Amplificador 2Ω Mono
Amplificateur de 2Ω Mono
Amplifier 2Ω Mono
Amplificatore 2Ω Mono
FEATURES
SPECIFICATIONS
Enclosure Features
• High Current Binding Posts
• Constructed with 5/8" MDF
•Covered with High Density Carpet
Specifications subject to change without notice
R1L-1X10 Single 10" SVC
Nominal Impedance (Ohms) 4 Ω
Replacement Woofer R1S410
Power Handling (Watts) 150 RMS / 300 Max
Overall Dimensions (HxWxD) 12.0” x 15.825” x 12.25”
(30.5cm x 40.1cm x 31.1cm)
R1L-2X10 Dual 10" SVC
Nominal Impedance (Ohms) 2 Ω
Replacement Woofer R1S410 (wired internally)
Power Handling (Watts) 300 RMS / 600 Max
Overall Dimensions (HxWxD) 12.0” x 30.0” x 12.25”
(30.5cm x 76.2cm x 31.1cm)
R1L-1X12 Single 12" SVC
Nominal Impedance (Ohms) 4 Ω
Replacement Woofer R1S412
Power Handling (Watts) 150 RMS / 300 Max
Overall Dimensions (HxWxD) 14.0” x 17.5” x 12.25”
(35.6cm x 44.5cm x 31.1cm)
R1L-2X12 Dual 12" SVC
Nominal Impedance (Ohms) 2Ω
Replacement Woofer R1S412 (wired internally)
Power Handling (Watts) 300 RMS / 600 Max
Overall Dimensions (HxWxD) 14.0” x 33.75” x 12.25”
(35.6cm x 85.7cm x 31.1cm)
Speaker Features
• Parabolic polypropylene cone.
• 12 AWG compression terminals.
• 18 gauge stamped steel frame.
• Optimized for sealed enclosures.
12/2008 B.M.
12/2008 E.R.
1230-55704-01 Printed in China
Rockford Fosgate
Rockford Corporation
600 South Rockford Drive
Tempe, Arizona 85281 U.S.A.
In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899
www.rockfordfosgate.com
LIMITED WARRANTY INFORMATION
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
Speakers – 1Year. Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate Dealers in the
United States of America or its possessions. Product purchased by consumers from an Authorized Rockford Fosgate Dealer in
another country are covered only by that country’s Distributor and not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an Authorized Rockford Fosgate Dealer
in the United States. In order to receive service, the purchaser must provide Rockford with a copy of the receipt stating the
customer name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be
equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, water, theft, shipping
2.Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4.Any product which has had the serial number defaced, altered, or removed
5. Subsequent damage to other components
6.Any product purchased outside the U.S.
7.Any product not purchased from an Authorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of the
express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this limitation
may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection with the sale of the
product.
How to Obtain Service
Contact the Authorized Rockford Fosgate Dealer you purchased this product from.
If you need further assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for details.
2009 Rockford Corporation.All rights reserved.
Rockford Fosgate, the Rockford Fosgate logo, and the PRIME logo are either
registered trademarks or trademarks of Rockford Corporation.
