Rockler GRP2325 1 User manual

Review full instructions prior to use for important safety information.
Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
Mini Ball Bearing Drawer Slide Instructions
Effective October 2020
2BP0918
GENERAL SAFETY WARNINGS
This product is designed only for specific applications as defined in the instructions and should not be modified or used for any
manner not described in these instructions. Use only recommended accessories. Before using the Mini Ball Bearing Drawer Slide:
READ, UNDERSTAND and FOLLOW ALL INSTRUCTIONS AND SAFETY WARNINGS. KEEP THESE INSTRUCTIONS READILY
AVAILABLE FOR FUTURE REFERENCE.
>Always confirm that you are using the most recent version of
the Instructions and safety warnings for your product (see the
Instructions link on the product page at Rockler.com).
>Before using another tool with this product, always read,
understand and follow the instructions and safety warnings
in the owner’s manual for that tool. If you do not have the
owner’s manual, obtain one from the tool’s manufacturer
before using it with this product.
>Before using any chemical with this product, always read,
understand and follow all safety warnings and guidelines in
the manufacturer’s Safety Data Sheet (SDS; formerly called
“MSDS”), especially regarding:
• How to safely use the chemical, including potential hazards
and recommended first aid measures;
• Personal safety equipment required to safely use the
chemical (e.g. gloves, eye protection, mask/respirator, etc.);
• Proper and safe handling, storage and disposal of
the chemical.
>Before using this product, review and verify that all tools to be
used with it have safety equipment installed and are in proper
working order as defined by the tool’s owner’s manual.
>Do not use this product until you have read and are
confident you understand:
• Installing Slides (p. 3);
• Mounting Options (p. 4).
>The user assumes all risk and responsibility for the proper and
safe use of this product and for ensuring product suitability for
the intended application.
>It is the sole responsibility of the purchaser of this product to
ensure that any anyone you allow to use this product reads
and complies with all instructions and safety precautions
outlined in this manual prior to use.
>Follow all standard shop safety practices, including:
• Keep children and bystanders away from the tool
operating area;
• Do NOT use power tools in explosive environments, or in
the presence of flammable liquids, fumes or dust;
• TURN OFF AND UNPLUG all power tools BEFORE
making any adjustments or changing accessories;
• Remain alert and use good judgment. Do not use this
product if you are in any way impaired by medications,
alcohol, drugs or fatigue;
• Keep your work area well lit and clean;
• Dress appropriately. Secure loose clothing, remove all
jewelry and tie up long hair before using this product;
• ALWAYS wear safety glasses, hearing protection
and respiratory protection that complies with
NIOSH/OSHA/ANSI safety standards;
• Use dust collection tools and dust face masks to
reduce exposure to dust;
• Use safety equipment such as featherboards, push
sticks and push blocks, etc., when appropriate;
• Maintain proper footing at all times and do not overreach;
• Do NOT force woodworking tools.
>These warnings and instructions do NOT represent the total
of all information available regarding tool safety, use and
technique. Always seek out opportunities to learn more
and improve your skills and knowledge.
Drilling, sawing, sanding or machining wood
products can expose you to wood dust, a substance known
ot the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for
personal protection. For more information go to
www.P65Warnings.ca.gov/wood.
Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury
or property damage.
Notice indicates important or helpful information and/or user tips.
3
Drawer width should be 1/4" less than the width of the cabinet
opening to allow a 1/8" reveal (gap) on either side. Recommended
drawer side thickness is 1/2".
Installing Slides
1. Establish the slide mounting location on the drawer sides.
Make sure that the centerline will be far enough above the
drawer bottom to allow clearance for drilling for and installing
the mounting screw.
2. Cut an 11/16" wide x 1/4" deep groove in each drawer
side, centered on the centerlines.
3. On each side of the cabinet, mark a centerline that will align
with the center of the grooves in the drawer sides. Position
the slides as desired front to back, with the narrower cabinet
member against the cabinet side. Mark pilot hole locations
for the mounting screws.
4. Remove the slides, drill stopped pilot holes and use the
provided #6 x 1/2" pan-head screws to attach the slides
to the cabinet sides.
5. Extend the slides’ wider drawer members and fit the drawer
onto the slides. Position the drawer members front to back
as desired and use the front tapped hole in each to mark the
locations for the provided M4 x 10mm truss-head screws
that will secure the drawer to the slides. See page 4 for
Mounting Options.
6. Remove the drawer and drill 1/8" diameter through holes
at the marked locations.
7. Fit the drawer back on the slides and, from inside the drawer,
thread the M4 x 10mm truss-head screws through the drawer
sides and into the tapped holes in the slides’ drawer members.
Check alignment and positioning and tighten the screws.
Side view
1/4"
1/4"
11/16"
Cabinet
Optional Stop
Drawer
4Distributed by Rockler Companies, Inc.
4365 Willow Dr. Medina, MN 55340
30804 30811
Rev 10/20
1-800-279-4441
www.rockler.com
Check Rockler.com for updates. If you have further questions, please
contact our Technical Support Department at 1-800-260-9663
or support@rockler.com
Mounting Options
A. An optional stop is included in the packaging. This will
allow you to stop runout when pushing in the drawer.
Simply snap the optional stop onto the back end of the
cabinet member of the slide and push the slide member
in past the tabs in the drawer member. Fig. 1.
B. The slide can be mounted several ways to allow more
access to smaller drawers. By placing the cabinet and
drawer members in varying locations on the project you
can change the access from one-half the length of the
drawer to just over three-quarters. Fig. 2.
Fig. 1
Fig. 2
Option A - “Closed Position”
Option B - “Closed Position”
Option A - “Open Position”
Option B - “Open Position”
Cabinet
Cabinet
Cabinet
Cabinet
Drawer
Drawer
Drawer
Drawer
Cabinet member
Cabinet member
Cabinet member
Cabinet member
Drawer member
Drawer member
Drawer member
Drawer member
Mounting Option B requires deeper
cabinets then length of the slide.
