Rockville TITAN 15 User manual

7
2
LEVEL LEVEL BT
LEVEL
-10dB – MIC
PWR SIGNAL CLIP
CH 2 THRU
MIX OUT
+4dB – LINE
OUTDOOR
SPEECH
MIC/LINE 1
INPUT
MIC/LINE 2
INPUT
THRU/MIX
AC IN AC OUT
FUSE POWER
220V110V
100100
INDOOR
NORMAL
PAIRING
TWS LINK
100
Bluetooth
1
5
7
To connect any Bluetooth capable device, follow the steps listed below.
1. Make sure the TITAN 15 unit's power switch is in the ON position.
2. Turn on the Bluetooth feature on your device and ensure that it is discoverable.
3. Press the PAIRING button for 3 seconds to activate Bluetooth pairing mode. The PAIR-
ING LED will ash slowly.
4. Press the PAIRING button for 1 second. The PAIRING LED will ash quickly.
5. Go to your device's Bluetooth interface and select "TITAN 15" from the list of availa-
ble devices. If pairing is successful, the PAIRING LED will stop ashing and remain lit.
6. Use the BT LEVEL control to adjust the volume of input from the paired Bluetooth device.
7. To end the Bluetooth connection, follow your device's procedure for disconnecting
from a paired device.
Select
3
4
3 SECONDS
1 SECOND
6

8
3
4
21
5
7
12
13
10
6
11
8
9

9
1. CH1/CH2 Input Level Controls: used to control the volume of the Mic/Line inputs.
When the THRU/MIX switch is set to MIX OUT, they control the mix output.
2. BT Level Control: adjusts the volume of Bluetooth input.
3. EQ Control: EQ settings are designed around the purpose of tuning the speaker for the
environment in which you are using it. They are variations of the Normal speaker set
ting with a few minor variations to boost certain frequencies:
Normal - “at” speaker setting which will suit most normal listening environments.
Indoor - subtle low-mid frequency and high-mid boost frequency.
Outdoor - subtle high frequency boost.
Speech - subtle high-pass frequency and mid frequency boost.
4. Bluetooth Pairing and TWS Link Buttons: these buttons will allow for usage of the
Bluetooth and TWS functions. For detailed directions on how to use either one of these
functions, please refer to pages 6 and 7 of this manual.
5. Line/Mic Switch: this switch corresponds to the Mic/Line inputs. When connecting a
microphone, make sure that the specic Line/Mic button is in the "down" position.
When connecting a line level device, make sure that the specic button is in the "up"
position.
6. Power LED indicator: will illuminate when the unit is receiving power.
Signal LED indicator: will illuminate when the unit is receiving a signal from the CH1,
CH2, or Bluetooth inputs.
Clip LED indicator: will illuminate when there is a power overload. It indicates that
limiting has taken place in order to protect and avoid damage to the amplier or
speaker. Continuously overdriving the system will cause distortion and may cause
damage to the amplier and or the speaker.
7. Combo XLR & ¼˝ ports: accept XLR type connectors and balanced/unba-
lanced ¼˝ TRS/TS plugs. When you use an unbalanced ¼˝ TS plug, the line input
automatically turns the ring into ground.
8. THRU/MIX out XLR port: For detailed directions on how to use this port, please refer
to page 5 of this manual.
9. CH2 THRU/MIX Switch: used to determine the signal output of the THRU/MIX port.
Please to page 5 of this manual for further details.
10. 250V/6.3A User Serviceable Fuse
11. AC In/AC Out Power Connectors: Input and output PowerCON connectors. The
power output can be used to power and additonal speaker or amplier that accepts
PowerCON connectors.
12. Voltage selector switch
13. Power switch
Functions

10
Specifications
Features
• Rockville TITAN 15 15˝ Active/Powered 2,000 Watts DJ/PA Speaker System
• 500-Watt True RMS/1,000 Watts Program Power/2000 Watts Peak
• High-power long-throw 15˝ woofer with 3˝ OFC copper voice coil and an 80 Oz magnet
• Frequency Response: 35Hz – 20KHz
• Maximum SPL @1w/1m: 130dB peak/124dB continuous
• Sound dispersion at 10dB: H100° x V60°
• Sensitivity: 98dB
• Crossover: 1800Hz
• State-of-the-art 1.34˝ titanium-diaphragm compression driver for crystal-clear
high-frequency reproduction
• Compact and light-weight system delivers distortion-free sound even at max volume
• Green amplier technology turns over 90% of electricity into usable sound
• Class D amplier technology offers high-power transparent sonic performance
• Built-in limiter fully protects the speaker from distortion at any volume level and also
protects the amplier from ever getting damaged
• Our custom engineered limiter allows the speaker to play at crazy high volumes while
limiting the frequencies that sound bad
• 4 DSP Sound Modes/Preset EQ settings (normal, indoor, outdoor, and speech) to ac-
commodate different listening environments and applications
• Built-in reliable Pro Bluetooth with 100-foot range and no distortion
• TWS (True Wireless Stereo) technology allows you to link 2 speakers wirelessly in stereo
• Custom tooled aluminum amplier heatsink stays cool and looks nice
• A/C power output allows you to power an additional speaker or amplier, etc.
• 2-Channel mixer built-in with ultra-low noise Mic/Line inputs via XLR & ¼˝ combo
jacks with volume control
• Balanced line output via XLR for linking additional speaker systems or for adding a
subwoofer
• Clip/limit LED indicator makes it easy to set your levels
• Power and signal LED indicators
• Stand mounting with 35-mm pole socket
• Ergonomically shaped handle for easy carrying and setup
• A full-grilled front cabinet perfectly protects speaker alevelst road damage
• Enclosure is made of rugged drop-tested, high-grade polypropylene construction
• The cabinet has a built-in handle and wheels for easy transporting
• 110/220 volt switchable power supply with external user serviceable fuse
• Dimensions of speaker: 17.9˝ x 14.3˝ x 28.3˝ (L x W x H)
• Weight of speaker: 48 lbs

11
Troubleshooting
PROBLEM
No sound/
distorted sound
No power
Poor Mic sound
Mic feedback
Buzzing sound
1. Make sure the unit is plugged in and the power switch is in the
ON position.
2. Check that the power cable is plugged in tightly to the unit.
3. Check and replace the fuse if necessary.
4. If people or equipment tend to step on and roll over or stretch
your power cable it can get damaged. Always try a second cable
to test for shorts in original cable. Dispose of damaged power
cables immediately.
1. Make sure you are using the XLR part of the Mic/Line ports.
2. If using wireless mics connect them into the Line input of your mixer.
Point the mics away from the speaker. Make sure the mics be-
hind of the speaker, not in front of it.
Make sure you are using a proper cable. For ¼˝ cables, there are
3 types: instrument, TS (unbalanced), and TRS (balanced). The
TITAN 15 accepts both TS and TRS ¼˝ cables. Check the require-
ments of the connected gear and make sure you are using the
appropriate cable.
1. Check that all appropriate cables are plugged in correctly.
2. Check the Levels settings. Refer to the "Setting Level Con-
trols" section on page 4 of this manual for instructions on how to
properly adjust the input level controls.
3. Be sure your microphone is on and plugged into the correct input.
4. If using a mixing console, make sure fader and balance are set
to center positions and levels are increased. Make sure the mixer
is plugged into the correct input.
6. If channel or BT levels settings are maxed out, turn down the
appropriate one as you may be overdriving the unit.
7. Check volume and level settings on all input sources.
SOLUTION
Bluetooth/TWS
pairing fails
1. Check to see that both devices are turned on and that your
Bluetooth device is discoverable.
2. Turn both devices off and then on alevel.
3. Make sure you've selected the proper source.
4. Make sure that the Bluetooth device is within 5 feet of the unit.
5. Move both devices away from other Bluetooth devices, micro-
waves, wireless routers, and other electronics.
6. Make sure that the unit is not paired to a previously paired
device or to another speaker.
Please refer to pages 6 and 7 for Bluetooth and TWS pairing
procedures.

12

13
Responsible party name: Rockville
Address: 600 Bayview Ave,
Entrance A,
Inwood, NY 11096
Hereby declares that the product(s) TITAN 15 pro audio speaker complies with FCC rules
as mentioned in the following paragraph:
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection alevelst harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION

14

15

© 2019 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
RockvilleAudio.com
