Rockville DMX-WTR User manual

OWNER’S MANUAL
2.4GHZ WIRELESS DJ DMX LIGHTING TRANSMITTER
or RECEIVER
DMX-WTR (Transmitter)
DMX-WRE (Receiver)

Please read the owner’s manual carefully for proper use of your DMX-
WTR or DMX-WRE wireless DMX modules. Should you need technical
assistance please call our technical help line at 1-646-758-0144,
Monday through Friday, 9am to 5pm EST.
• For indoor use only. Do not expose units to moisture.
• Only use the included power adapters. Do not use the adapters if the
cord is damaged in any way. Do not break off the ground prong as this
increases the risk of electric shock.
• Working temperature range is -4° – 113° F (-20° – 45° C), 10% – 90%
relative humidity.
• Make sure there are no obstructions between the transmitter and the
receiver(s).
IMPORTANT SAFETY INSTRUCTIONS
NO USER SERVICEABLE PARTS INSIDE.
WE RECOMMEND TAKING THE UNIT TO A
QUALIFIED SERVICE TECHNICIAN FOR ANY
REPAIRS.

1. XLR 3 pin male connector
2. 5 volt power input
3. ID key LED indicator
4. ID key
5. Antenna
1. XLR 3 pin female connector
2. 5 volt power input
3. ID key
4. Antenna/ID key LED indicator
Functions
DMX-WTR transmitter
DMX-WRE receiver
1 2
1 2
3 4
3
4
5

1. Power up the DMX-WRE unit(s) first by connecting the power supply.
2. Now power up the DMX-WTR unit by connecting the power supply.
3. Connect the DMX-WTR to the DMX source. If using a fixture with
a built-in transmitter, turn it on at this time.
3. Connect the DMX-WRE unit(s) to the desired fixture(s).
4. Press the ID key on the DMX-WTR to indicate the ID setting. Press
again to set the ID. To change the ID value, press the key button
until the desired value is found. To set the ID for the DMX-WRE,
follow the procedure above. Please note that the ID needs to match
on both the DMX-WTR and DMX-WRE. If your fixture has a built
in transmitter and you are only using a DMX-WRE unit, it’s ID
should match the fixture’s ID. When the units are used in the
future, they will remember the previously used ID.
ID Code and Corresponding LED Indicator Color:
1. RED
2. GREEN
3. RED + GREEN
4. BLUE
5. RED + BLUE
6. GREEN + BLUE
7. RED + GREEN + BLUE
5. The DMX-WTR will automatically look for and choose an interfer-
ence free channel which it will also assign to the DMX-WRE. If
there is over 10% interference, the DMX-WTR will switch to another
channel and set the DMX-WRE to that same channel. If the whole
frequency is occupied, the DMX-WTR will switch to frequency
hopping mode.
6. The LED on the DMX-WTR will blink RED slowly until communication is
established with the receiver. The status LED on the DMX-WRE unit(s)
will flash GREEN slowly until communication is established.
Operation

Features and Specifications
• Built in 650mAH rechargeable battery
• Battery Power: working time: 9 Hours (Only takes 2 hours to fully charge)
• You can also use the item while its plugged in and charging
• Daisy Chain multiple lights together and use one receiver for all the
lights that are linked together. This setup requires one transmitter
and one receiver.
• You can connect one transmitter to your DMX controller and then
one receiver to each light, and then each light will have its own
channels on the controller so they can all be controlled
independently (can be done with up to 7 lights/groups)
• Makes it easy to set up all your lights without a ton of wires everywhere
• Controls are extremely reliable and work without any delay
• The product uses 2.4Ghz frequency band
• Efficient GFSK modulation with 126 channel high-speed frequency
hopping (FHSS). Hops 1100 times per second for interference free
operation.
• Tri-color LED displays status and parameters
• One-touch operation
• 7 Selectable groups of lights can be controlled independently
• You can connect up to 25 receivers to each transmitter
• Requires you to hold the button to change linking – this ensures
no accidental un-linking happens
• System Information CPU: 32-bit ARM Core
• Distance: 1968 feet (600 meters)
• Modulation: GFSK Maximum transmit power: 23dBm
• Receiver sensitivity: -94dBm
• Unit dimensions: 4.7˝ long and antenna is 3.5˝ tall
• Weight: 0.4 lbs

Troubleshooting
PROBLEM
No power 1. Make sure the power adapter is properly plugged in at the wall
and to the unit.
2. Make sure the power adapter is not damaged.
SOLUTION
Units not
responding to
DMX
1. Check that the DMX-WTR and DMX-WRE(s) are powered on.
2. Check that the receiver and transmitter ID keys match.
3. Check that the transmitter is connected to the DMX OUT port of
the controller and that the receiver is connected to the DMX IN port
of the fixture.
Applications
• Stage lighting
• Up lighting (wall washing)
• DJ lighting
• Clubs/Bars
• Party halls
• Theatrical performances
• Stadium lights

Responsible party name: Rockville
Address: 600 Bayview Ave.
Entrance A
Inwood, NY 11096
Hereby declares that the products DMX-WTR Transmitter and DMX-
WRE Receiver comply with FCC rules as mentioned in the following
paragraph:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION
COMPLIANCE INFORMATION

© 2018 ROCKVILLE // Features and specifications are subject
to change and or improvement without notice.
RockvilleAudio.com
This manual suits for next models
1
