Rockwell Automation Allen-Bradley PowerFlex 4-Class HIM User manual

Quick Reference
Original Instructions
PowerFlex 4-Class HIM (DSI)
Catalog Numbers 22-HIM-A3, 22-HIM-C2S
I
Introduction
This Quick Reference provides display descriptions, key descriptions, information about the menu navigation tabs, and a parameter list for the
PowerFlex® 4-Class HIM (DSI) Human Interface Modules (HIM).
Topic Page
Introduction 1
Summary of Changes 2
Display Descriptions 2
Key Descriptions 3
Menu Navigation Tabs 3
Parameter List 4
Additional Resources 7
SelEsc
Esc
7 8 9
4 5 6
1 2 3
.0 +/-
Sel
Jog
Alt
Param #
View Lang Remove
DSI
Esc Sel
ALT
LANG
DISP
Jog
|
DSI
REMOVE
Esc Sel
ALT
LANG DISP
Jog
|
DSI
22-HIM-A3 — IP20 (NEMA Type 1) 22-HIM-C2S — IP66 (NEMA Type 4X/12)

2Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021
PowerFlex 4-Class HIM (DSI) Quick Reference
Summary of Changes
This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all
changes.
Display Descriptions
Topic Page
Removed parameter 24; modified parameter 23. 5
Display
1 Status Line: Direction |Operating Status |Drive Status |Auto/Manual Mode |Parameters Locked/Unlocked
2
Process Display screen:
Output Frequency
User Display Line 1 (HIM Parameter 04)
User Display Line 2 (HIM Parameter 05)
3 Programming screen
4MenuNavigationTabs
5 Large Format User Display screen:
SEL
DIAG DSEL MEM
Changed Params
Linear List
Parameters
Groups
PARAM
Hz
A
V
F Stopped Auto
Hz
F At Reference Auto
Output Freq
4
5
1
2
3
Esc
7 8 9
4 5 6
1 2 3
.0+/-
Sel
Jog
Alt
Param #
View Lang Remove
DSI
Hz
A
V
F Stopped Auto

Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021 3
PowerFlex 4-Class HIM (DSI) Quick Reference
Key Descriptions
Menu Navigation Tabs
Keys Description
Exit a menu, cancel a change to a parameter value, or acknowledge a fault/alarm.
Select a digit, select a bit, or select a menu tab.
Scroll through options, increase a value, or toggle a bit.
Scroll through options, decrease a value, or toggle a bit.
Enter a menu, enter edit mode in a parameter screen, or save a change to a parameter value.
plus…
Toggle between the Process Display and Large Format Display.
Select an available language for text displayed on HIM screens.
Allow the HIM to be disconnected without causing a fault condition.
Enable direct parameter number entry.
Start the drive.
Stop the drive or clear a fault.
Change direction.
Jog the drive.
Type parameter numbers and values.
Increase or decrease the speed Reference to the drive after these keys are enabled by setting drive parameter 38 [Speed Reference] as follows:
When the HIM is the DSI Master, set parameter 38 to ‘5’ (Comm Port).
When the HIM is the DSI Slave, set parameter 38 to ‘1’ (Internal Freq).
To view the HIM’s active device type status (Master or Slave), see HIM Parameter 10 [M/S Status].
Tabs Description
DIAG The Diagnostics tab is used to display faults, the device (drive or peripheral) status, and device version.
PARAM The Parameters tab is used to edit parameters. Parameters can be displayed in groups, in a linear list, or only those changed from their defaults.
DSEL The Device Select tab is used to select the device (drive or peripheral) that the HIM is to access.
MEM The Memory Storage tab is used for HIM Copycat (uploading/downloading configurations to the HIM EEPROM).
HIM The HIM Setup tab is used to access HIM parameters, view the HIM version, and to edit the Reference text when a user-defined Reference is used.
Esc
Sel
Alt
Sel
View
Lan
Remove
+/-
Param #
Jog
...
0
9
.
+/-

4Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021
PowerFlex 4-Class HIM (DSI) Quick Reference
Parameter List
Parameter
No. Name and Description Details
01 [Startup Display]
Selects the display screen shown when the HIM is powered up.
Default: 0 = Main Menu
Values: 0 = Main Menu
1 = Process Disp
2 = Large Disp
3 = Startup Param
Type: Read/Write
02 [Startup Param]
Selects a desired drive parameter to be displayed if Parameter 01 [Startup Display] is set to ‘3’ (Startup Param).
Default: 1
Minimum: 1
Maximum: 65535
Type: Read/Write
03 Reserved
04 [User Disp Line 1]
Selects a desired drive parameter to be displayed on User Display Line 1 of the Process Display screen.
For example, setting to ‘3’ selects PowerFlex 4-Class drive Parameter 3 [Output Current] to be displayed.
Default: 3
Minimum: 1
Maximum: 65535
Type: Read/Write
05 [User Disp Line 2]
Selects a desired drive parameter to be displayed on User Display Line 2 of the Process Display screen.
For example, setting to ‘5’ selects PowerFlex 4-Class drive Parameter 5 [DC Bus Voltage] to be displayed.
Default: 5
Minimum: 1
Maximum: 65535
Type: Read/Write
06 [Large Disp Param]
Selects a desired drive parameter to be displayed on the Large Format User Display screen.
For example, setting to ‘1’ selects PowerFlex 4-Class drive Parameter 1 [Output Freq] to be displayed. Setting to ‘0’ enables
the Scaled Reference to be displayed.
Default: 1
Minimum: 0
Maximum: 65535
Type: Read/Write
07 [LCD Contrast]
Sets the HIM LCD contrast level.
Default: 50%
Minimum: 0%
Maximum: 100%
Type: Read/Write
08 [Reset HIM]
1 (Reset):Resets the HIM.
2 (Set Defaults):Resets HIM parameters to factory settings.
This parameter returns to a value of ‘0’ (Ready) after the reset function is complete.
Default: 0 = Ready
Values: 0 = Ready
1 = Reset
2 = Set Defaults
Type: Read/Write
09 [Device Type]
Selects the HIM device type. When set to ‘0’ (Auto), the HIM is automatically configured as either a DSI Master or Slave
depending on the presence of other peripheral devices.
Default: 0 = Auto
Values: 0 = Auto
1 = Slave
2 = Master
Type: Read/Write
10 [M/S Status]
Displays the HIM active device type.
Default: –
Values: 1 = Slave
2 = Master
Type: Read-only
11 [HIM Ref Preset]
0 (Zero Start):HIM Reference is always ‘0.0’ at power on.
1 (Host Output):HIM will assume the Host’s output feedback (bumpless transfer) and preset its Reference when the
Reference is configured to be received on the RS-485 port. This can be verified by viewing Diagnostics/Device Status/
Remote Freq Ref = 1.
2 (Last HIM Ref):HIM will store the HIM Reference in EEPROM each time it is changed. HIM Reference is restored at power on.
Default: 0 = Zero Start
Values: 0 = Zero Start
1 = Host Output
2 = Last HIM Ref
Type: Read/Write
12 [Ref Scaling]
Enables or disables scaling the Reference to a user-defined value. When Parameter 12 [Ref Scaling] is set to ‘1’
(Enabled), use HIM Parameters 13…22 to scale the Reference.
Default: 0 = Disabled
Values: 0 = Disabled
1 = Enabled
Type: Read/Write
13 [Ref Max Value]
Sets the user-defined value to be displayed when the drive is running at 60 Hz.
Default: 600
Minimum: 100
Maximum: 65535
Type: Read/Write

Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021 5
PowerFlex 4-Class HIM (DSI) Quick Reference
14 [Ref Dec Position]
Sets the number of digits to be displayed to the right of the decimal point for the Reference.
Default: 1
Minimum: 0
Maximum: 3
Type: Read/Write
15
16
17
18
19
20
21
22
[Ref Units Char 1]
[Ref Units Char 2]
[Ref Units Char 3]
[Ref Units Char 4]
[Ref Units Char 5]
[Ref Units Char 6]
[Ref Units Char 7]
[Ref Units Char 8]
Selects up to 8 characters (from the ISO 8859-1 character set) to use for the Reference units on the Process Display.
Parameters 15…22 can also be configured using the ‘Edit Ref Text’ selection in the HIM Setup tab.
Default: 72(‘H’)
Default: 122(‘z’)
Default: 32(blank - no character)
Default: 32(blank - no character)
Default: 32(blank - no character)
Default: 32(blank - no character)
Default: 32(blank - no character)
Default: 32(blank - no character)
Minimum: 32
Maximum: 255
Type: Read/Write
23 [AUTO MAN Switch]
Switch the display of AUTO and MAN.
Default: 0 = Switch
Values: 0 = Switch
1 = Not Switch
Type: Read/Write
New settings to HIM parameters are implemented immediately. Resetting the HIM is not required for new values to take effect.
Parameter
No. Name and Description Details

6Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021
PowerFlex 4-Class HIM (DSI) Quick Reference
Notes:

Rockwell Automation Publication 22HIM-QR001G-EN-P - August 2021 7
PowerFlex 4-Class HIM (DSI) Quick Reference
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at rok.auto/literature.
Resource Description
PowerFlex 4M User Manual, publication 22F-UM001 Provides basic information needed to install, start-up, and troubleshoot the PowerFlex 4M
Adjustable Frequency AC Drive.
PowerFlex 4M Adjustable Frequency AC Drives Technical Data, publication 22F-TD001 Provides detailed technical data, specifications, and ratings for the PowerFlex 4M
Adjustable Frequency AC Drive
System Security Design Guidelines Reference Manual, SECURE-RM001
Provides guidance on how to conduct security assessments, implement Rockwell
Automation products in a secure system, harden the control system, manage user access,
and dispose of equipment.
Industrial Components Preventive Maintenance, Enclosures, and Contact Ratings
Specifications, publication IC-TD002
Provides a quick reference tool for Allen-Bradley industrial automation controls and
assemblies.
Safety Guidelines for the Application, Installation, and Maintenance of Solid-state
Control, publication SGI-1.1
Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides
general guidelines for the application, installation, and maintenance of solid-state control
in the form of individual devices or packaged assemblies incorporating solid-state
components.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications. Provides declarations of conformity, certificates, and other certification details.

Publication 22HIM-QR001G-EN-P - August 2021
Supersedes Publication 22HIM-QR001F-EN-P - September 2009 Copyright © 2021 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Rockwell Automation Support
Use these resources to access support information.
Documentation Feedback
Your comments help us serve your documentation needs better. If you have any suggestions on how to improve our content, complete the
form at rok.auto/docfeedback.
Technical Support Center Find help with how-to videos, FAQs, chat, user forums, and product notification updates. rok.auto/support
Knowledgebase Access Knowledgebase articles. rok.auto/knowledgebase
Local Technical Support Phone Numbers Locate the telephone number for your country. rok.auto/phonesupport
Literature Library Find installation instructions, manuals, brochures, and technical data publications. rok.auto/literature
Product Compatibility and Download Center
(PCDC) Download firmware, associated files (such as AOP, EDS, and DTM), and access product release
notes. rok.auto/pcdc
Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec.
Allen-Bradley, expanding human possibility, PowerFlex, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Otomasyon Ticaret A.Ş. Kar Plaza İş Merkezi E Blok Kat:6 34752, İçerenköy, İstanbul, Tel: +90 (216) 5698400 EEE Yönetmeliğine Uygundur
