ROEQ Spring Kit User manual

ROBOTIC EQUIPMENT
Spring Kit User Guide
How to install the ROEQ spring kit
2020–10–06

Spring Kit User Guide
Revision: 1.0
Publicly available
1 Introduction
This is the guide on, how to install the ROEQ spring kit to a MiR100 or MiR200. The robot used as illustration in
this guide is a MiR200 MKV. The spring kit, will lift up the bogey-arm of the robot, and then add extra gravitational
force on the traction wheel.
2 Required tools
•Strong cable ties
•TX20 Screwdriver
•TX30 Screwdriver
•Hex key 4 mm
•Woodblock or similar to place under robot
Figure 1: Spring kit layed on the ground. The kit consist of a left and right part.
3 How to
p. 2 of 7
Section 3 How to

Spring Kit User Guide
Revision: 1.0
Publicly available
Step Instruction and Illustration
1. •Remove the Top Module from the MiR robot
•Lift top cover from robot
Figure 2: Cover lifted from robot
2. •In robots with ESD-wire, unplug it before fully removing top cover
Figure 3: Disconnected ESD-wire
p. 3 of 7
Section 3 How to

Spring Kit User Guide
Revision: 1.0
Publicly available
3. •Locate and remove the all the TX20 screws holding the side covers.
•Disconnect the four connectors for LED strips on the side cover. The connectors are placed in each
corner.
•Remove both sides from the robot.
Figure 4: A: TX20 holding cover. B: Connector for LED strip.
4. •Lift the front of the robot.
•Place a woodblock or similar under the front wheels of the robot.
Figure 5: Two woodblocks placed under the front of the robot, lifting the bogey-arm.
p. 4 of 7
Section 3 How to

Spring Kit User Guide
Revision: 1.0
Publicly available
5. •Start at one side of the robot, take brackets and spring for that side.
•Remove the bolts and spring.
•Add the lower bracket to the bogey-arm. See Figure 6
Figure 6: The lower bracket mounted on the left side of the robot.
6. •Mount the spring to the lower bracket with the fitting bolt.
•Add the upper brackets on the top frame.
•Add the nut to the brackets to keep them in place.
Figure 7: Spring added to lower bracket and upper brackets added to frame
p. 5 of 7
Section 3 How to

Spring Kit User Guide
Revision: 1.0
Publicly available
7. •Pull out the spring to place a cable tie in the spring
•Secure the cable tie around the top frame and tighten it to pull the spring up the to nut
Figure 8: Cable tie in position to pull the spring the last bit
8. •Add the bolt to top frame and fasten it to the nut.
•Cut and remove the cable tie.
•Repeat step 5 to 8 for the other side.
Figure 9: Spring mounted to bracket on top frame.
p. 6 of 7
Section 3 How to

Spring Kit User Guide
Revision: 1.0
Publicly available
9. •Mount the side covers to the robot again.
•Connect the connectors to the LED strips again.
•To protect the wires close to the springs, secure them with tape or similar (See Figure 10)
•Put the top shell on the robot again, remember the ESD wire.
•Mount the ROEQ Top Module, and the robot is ready to use again
Figure 10: Electrical tape used to protect the wires from the LED strips.
