PROGRAMMING GUIDE AIR Control
1. AIR Control. (Control Remote)
The remote control has the following parts:
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PARTS INDICATION
0 TFT display
1Days of the week (1 to 7) / Heating or
water heating function selection
2Submit data
3Lower temperature
4 OFF - ECO - COMFORT - Start prog.
5Anti-frost
6MANUAL/AUTO
7Erase programme
8Lock
9 Back time
10 Adjust time
11 On/Off
12 Increase temperature
13 Receive data
14 Forward time

2
2. PROGRAMMING STEP BY STEP
1. Turn on the remote by pressing . When the remote
is switched on will appear this imagen on the TFT display
screen to select between room heating and water heating:
»Press 1 on the keyboard to programme
heating (radiators or towel rails).
»Press 2 on the keyboard to programme
water heaters.
NUMBER INDICATION
1Times set
2Days of the week (1 to 7)
3Time
4Temperature
5Lock keypad
6Manual/Automatic mode
7Confort/Economic/Anti-frost mode
1
23
4
5
6 7
TFT display
1
SELECT
2

3
PROGRAMMING GUIDE AIR Control
2. Before starting, please make sure that the time and
date are correct, and the remote control is in Automatic
function (indicated by the icon on the screen).
3. By pressing .You will see Sel1, Sel2, Sel3,... the
screen and the 7 days of the week will blink. Select
the days you want to programme by pressing their
corresponding keys from 1 to 7 ( ):
»Selected days will stop blinking.
»Unselected days will keep blinking on the screen.
You can freely select one, all, or a selection of days to
programme.
If you have to cancel the selection of any day, simply
press its key, and it will blink again indicating that it has
been deselected.
4. Pressing you will access the dotted strip
( ) that represents the hour by hour programme.
You will see 0h, 1h, 2h,... on the screen and the first
symbol ( ) will blink. By pressing or you can move
through the hours.
5. You can select one of the modes ECO, COMFORT
or OFF for each hour you want to programme, following
the next sequence (only one mode per hour is possible):
»By pressing once: ECO Mode (you will see and
a flashing , you can change the temperature by
pressing or ).
»By pressing again: COMFORT Mode (you will see
and a flashing , you can change the temperature
by pressing or ).
»Pressing one more time: OFF (no temperature
appears on the screen, and a dot will appear
bouncing up and down).
PLEASE NOTE: If you change a mode temperature, it
changes it for all the hours with this mode set.

The range of temperatures of the ECO and COMFORT
modes are different, depending on the type of
programming you chose when turning on the remote
control (heating or water heating):
Heating Selected
Icon Mode Range of temperatures
COMFORT 20.0ºC – 30.0ºC
ECO 15.0ºC – 19.5ºC
ANTI-FROST 8.0ºC
Water heating selected
Icon Mode Range of temperatures
COMFORT 55.0ºC – 72.0ºC
ECO 40.0ºC – 54.5ºC
ANTI-FROST 8ºC
Once you have chosen the desired mode and
temperature for the current hour, move to the next
you want to programme using or . Repeat the
previous sequence as many times as hours you wish to
programme.
6. If you want to activate the ANTI-FROST Mode in the
hours you set as OFF, press (you will see and 8.0º
on the screen). To deactivate it, press .
7. Press or wait 1 minute without pressing any key to
exit the programming mode.
8. Send the programming to the desired radiator, towel
rail or water heater by pressing at a maximum range
of 2 m.
Remember this is only a quick programming guide. Please refer to the
full manual for more detailed information about the AIR Control remote.
Thank you.
