Roland VE-7000 User manual

Owner’s Manual
Before using this unit, carefully read the sections entitled: “USING THE UNIT
SAFELY” and “IMPORTANT NOTES” (Owner’s Manual p. 2, 3; p. 5). These
sections provide important information concerning the proper operation of the
unit. Additionally, in order to feel assured that you have gained a good grasp of
every feature provided by your new unit, Owner’s Manual should be read in its
entirety. The manual should be saved and kept on hand as a convenient reference.
CH EDIT CONTROLLER
VE-7000
Copyright © 2000 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of ROLAND CORPORATION.
Roland Website: http://www.roland.co.jp/

2
USING THE UNIT SAFELY
USING THE UNIT SAFELY
• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.
• Do not open (or modify in any way) the unit or its
AC adaptor.
• Do not attempt to repair the unit, or replace parts
within it (except when this manual provides
specific instructions directing you to do so). Refer
all servicing to your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the "Information" page.
..........................................................................................................
• Never use or store the unit in places that are:
• Subject to temperature extremes (e.g., direct
sunlight in an enclosed vehicle, near a heating
duct, on top of heat-generating equipment); or
are
• Damp (e.g., baths, washrooms, on wet floors);
or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
..........................................................................................................
• Make sure you always have the unit placed so it is
level and sure to remain stable. Never place it on
stands that could wobble, or on inclined surfaces.
..........................................................................................................
• Be sure to use only the AC adaptor supplied with
the unit. Also, make sure the line voltage at the
installation matches the input voltage specified on
the AC adaptor’s body. Other AC adaptors may
use a different polarity, or be designed for a
different voltage, so their use could result in
damage, malfunction, or electric shock.
..........................................................................................................
• Do not excessively twist or bend the power cord,
nor place heavy objects on it. Doing so can
damage the cord, producing severed elements and
short circuits. Damaged cords are fire and shock
hazards!
..........................................................................................................
• Do not allow any objects (e.g., flammable material,
coins, pins); or liquids of any kind (water, soft
drinks, etc.) to penetrate the unit.
• Immediately turn the power off, remove the AC
adaptor from the outlet, and request servicing by
your retailer, the nearest Roland Service Center, or
an authorized Roland distributor, as listed on the
"Information" page when:
• The AC adaptor, the power-supply cord, or the
plug has been damaged; or
• Objects have fallen into, or liquid has been
spilled onto the unit; or
• The unit has been exposed to rain (or otherwise
has become wet); or
• The unit does not appear to operate normally or
exhibits a marked change in performance.
..........................................................................................................
• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for the
safe operation of the unit.
..........................................................................................................
• Protect the unit from strong impact.
(Do not drop it!)
..........................................................................................................
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ●symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.

3
USING THE UNIT SAFELY
•Do not force the unit’s power-supply cord to share
an outlet with an unreasonable number of other
devices. Be especially careful when using
extension cords—the total power used by all
devices you have connected to the extension
cord’s outlet must never exceed the power rating
(watts/amperes) for the extension cord. Excessive
loads can cause the insulation on the cord to heat
up and eventually melt through.
..........................................................................................................
•Before using the unit in a foreign country, consult
with your retailer, the nearest Roland Service
Center, or an authorized Roland distributor, as
listed on the "Information" page.
..........................................................................................................
•The unit and the AC adaptor should be located so
their location or position does not interfere with
their proper ventilation.
..........................................................................................................
•Always grasp only the plug on the AC adaptor
cord when plugging into, or unplugging from, an
outlet or this unit.
..........................................................................................................
•Whenever the unit is to remain unused for an
extended period of time, disconnect the AC
adaptor.
..........................................................................................................
•Try to prevent cords and cables from becoming
entangled. Also, all cords and cables should be
placed so they are out of the reach of children.
..........................................................................................................
•Never climb on top of, nor place heavy objects on
the unit.
•Never handle the AC adaptor or its plugs with
wet hands when plugging into, or unplugging
from, an outlet or this unit.
..........................................................................................................
•Before moving the unit, disconnect the AC
adaptor and all cords coming from external
devices.
..........................................................................................................
•Before cleaning the unit, turn off the power and
unplug the AC adaptor from the outlet (p. 5).
•Whenever you suspect the possibility of lightning
in your area, disconnect the AC adaptor from the
outlet.
..........................................................................................................

4
Contents
USING THE UNIT SAFELY......................................................................2
Contents ..................................................................................................4
IMPORTANT NOTES ...............................................................................5
Main features...........................................................................................6
Names of Things and What They Do.....................................................7
Front panel...................................................................................................................................................7
Rear panel....................................................................................................................................................9
Before you begin...................................................................................10
Update the VM Console ..........................................................................................................................10
Make connections.................................................................................14
Placing the VE-7000 on the VM Console...............................................................................................14
Turning on the power ...........................................................................15
Basic operation (connected to the VM Console)..................................................................................15
Convenient functions to remember ....................................................19
Operations in the channel edit pages
(connected to the VM Console) ..........................................................20
Using the joystick to control surround
(connected to the VM Console) ..........................................................21
Preparations for surround panning.......................................................................................................21
Using the joystick to control surround panning..................................................................................22
Troubleshooting....................................................................................23
MIDI Implementation.............................................................................24
1. THRU'ed data .......................................................................................................................................24
2. Control data transmission...................................................................................................................24
3. Control data transmission address map ...........................................................................................25
4. Control data transmission data..........................................................................................................26
MIDI Implementation Chart ..................................................................27
Specifications........................................................................................28
MEMO.....................................................................................................29
Information ............................................................................................30

5
-
IMPORTANT NOTES
In addition to the items listed under “USING THE UNIT
SAFELY” on page 2, please read and observe the
following:
Power Supply
•Do not use this unit on the same power circuit with any
device that will generate line noise (such as an electric
motor or variable lighting system).
•The AC adaptor will begin to generate heat after long
hours of consecutive use. This is normal, and is not a
cause for concern.
•Before connecting this unit to other devices, turn off the
power to all units. This will help prevent malfunctions
and/or damage to speakers or other devices.
Placement
•This device may interfere with radio and television
reception. Do not use this device in the vicinity of such
receivers.
•To avoid possible breakdown, do not use the unit in a wet
area, such as an area exposed to rain or other moisture.
Maintenance
•For everyday cleaning wipe the unit with a soft, dry cloth
or one that has been slightly dampened with water. To
remove stubborn dirt, use a cloth impregnated with a
mild, non-abrasive detergent. Afterwards, be sure to wipe
the unit thoroughly with a soft, dry cloth.
•Never use benzine, thinners, alcohol or solvents of any
kind, to avoid the possibility of discoloration and/or
deformation.
Additional Precautions
•Use a reasonable amount of care when using the unit’s
buttons, sliders, or other controls; and when using its jacks
and connectors. Rough handling can lead to malfunctions.
•When connecting / disconnecting all cables, grasp the
connector itself—never pull on the cable. This way you
will avoid causing shorts, or damage to the cable’s
internal elements.
•To avoid disturbing your neighbors, try to keep the unit’s
volume at reasonable levels (especially when it is late at
night).
•When you need to transport the unit, package it in the box
(including padding) that it came in, if possible. Otherwise,
you will need to use equivalent packaging materials.

6
Main features
The VE-7000 is a channel edit controller that enables a revolutionary leap in
efficiency when operating the channel parameters of a VM-C7200/C7100
V-series mixing console (subsequently referred to as the VM Console)
connected via MIDI.
The VE-7000 has the following features.
•Analog-feel operating panel for realtime control
29 rotary encoders and 25 buttons are arranged in a space-saving
configuration.
Main parameters such as “GAIN,”“DYNAMICS,”“EQ,”and “SEND”of
the desired input channel can be controlled simultaneously in analog-like
operation.
•Joystick
A joystick can be used for surround panning.
•Compact
The VE-7000 can be easily placed in a vacant area of the VM-C7200
(console) and held in place with a rubber magnet.
•Easy connection
A single MIDI cable is all you need for basic connection.

7
Names of Things and What They Do
Front panel
The front panel is divided into the areas shown below.
fig.area
1
PREAMP AREA
Control the parameters of the channel edit PREAMP page.
2
DELAY/DYN AREA
Control the parameters of the channel edit DELAY/DN page.
3
FLEX BUS AREA
Control the parameters of the channel edit FLEX BUS page.
4
EQ AREA
Control the parameters of the channel edit EQ BAND
(or EQ GAIN) page.
2
34
6
7
8
9
1
5

8
Names of Things and What They Do
5
MAIN/CUE AREA
Control the parameters of the channel edit MAIN/CUE page.
6
SURROUND AREA
Control the parameters of the channel edit SURROUND page.
7
CH VIEW AREA
Access the CH VIEW page and switch screens.
8
[SHIFT] button
Used when executing SHIFT functions.
9
POWER/MIDI Indicator
This will light when the power is on. This will blink when
MIDI messages are received at the MIDI IN connector.

9
Names of Things and What They Do
Rear panel
fig.rear
1
MIDI connectors (MIDI IN/OUT)
These connectors are used to connect MIDI devices.
MIDI OUT is normally connected to the MIDI IN connector of the device
being controlled by the VE-7000, such as the VM Console.
MIDI messages received at MIDI IN will be output (“thru'ed”) without
change from MIDI OUT. Use this when you wish to send MIDI messages
such as MTC (MIDI Time Code) from an external MIDI device to the VM
Console.
2
POWER
This turns the power of the VE-7000 on/off.
3
AC Adapter Jack (DC IN)
Connecttheincluded“PSB-1U”ACadapterto this jack. Never use any other
AC adapter.
4
Cable Hook
Hook the cable of the “PSB-1U”AC adapter around this hook to prevent
accidental disconnection.
fig.CordHook.e
1
2
34
To prevent malfunction
and/or damage to speakers
or other devices, always
turn down the volume, and
turn off the power on all
devices before making any
connections.
To prevent the inadvertent
disruption of power to
your unit (should the plug
b
e pulled out accidentally),
and to avoid applying
undue stress to the AC
adaptor jack, anchor the
power cord using the cord
hook, as shown in the
illustration.
Cord Hook
The cord of
the supplied AC Adaptor
To the Power Outlet

10
Before you begin
Update the VM Console
In order to connect the VE-7000 to a V-mixing console and use it as a
controller, the VM Console must be using system version 1.520 or higher
and VM processor must be using unit1 (and 2) version 1.500.
Use the following procedure to check the version of your VM Console.
Then, if necessary, perform the update as described in the following section
“Updating the VM Console system version.”
The “VM-7000 update card”required for the update is included with the
VE-7000.
Basic work flow
Check the version ➝ save your data ➝ perform the update ➝ check the version
➝ restore your data
Update procedure
Check the version
1
Turn on the power of the VM Console and processor as usual.
2
Hold down [on Display], and press MEMORY/RECALL area
[9].
3
The current version will be displayed. Verify that unit1 (and 2)
in “System Version:”is 1.500 or higher.
4
When you press any button on the panel, the previous display
will reappear.
5
Turn off the power of the VM System.
Notes when updating
The update procedure will erase all data from the project, library, and
system user areas, and will return the unit to the factory settings.
Before you perform the update, save any important data, and restore the
data after the update is completed.
Take the procedure of
Update B if the current
“System Version”is under
1.500.

11
Before you begin
Save your data
1
Insert the data memory card (2--16 MB) that you normally use.
2
Turn on the power of the console.
3
Hold down [SHIFT] and press [STORE (UNDO/REDO)].
4
Press [F4 (OK]. The project will be stored.
Perform the update - Update A
(in case that unit 1(and 2) in “System Version”
is 1.500 and higher)
1
Insert the supplied update memory card.
2
Turn on the power of the console. The display will indicate
“Welcome to SSFDC program update,”and the update will
begin automatically.
3
When the update is completed, the system will start up
automatically.
4
Remove the update memory card and keep it in a safe place.
Perform the update - Update B
(in case that unit 1(and 2) in “System Version”
is under 1.500)
1
Insert the supplied update memory card.
2
Hold down [PROJECT] and [F5], and turn on the power of the
console.
Take the procedure of
Update B if the current
“System Version”is under
1.500.
When the console has
already newest system
program, the system does
not begin update.
Never turn off the power or
remove the memory card
while the update is taking
place. Doing so will
damage the internal system
program, making it
impossible to start up
correctly.
Take the procedure of
Update A if the current
“System Version”is 1.500
and higher.

12
Before you begin
3
Release the buttons when “ ∗∗∗∗ ”is indicated in the display.
4
Turn off the power of the VM system when “VM-7000
updated. Reboot Please”is indicated in the display.
5
Remove the update memory card and keep it in a safe place.
Check the version
1
Take the procedure specified in “Check the version”(p. 10) in
order to check the current version.
2
The current version will be displayed. Verify that “System
Version”is 1.520 and higher and unit1 (and 2) in “System
Version”is 1.500 and higher.
3
When you press any button on the panel, the previous display
will reappear.
Restore your data
1
Insert the memory card (2--16 MB) that you used to save your
data.
2
Press [PROJECT].
3
Choose “SELECT.”
4
Use the V1 knob (SELECT NUMBER) to select the project that
you stored.
5
Press [SELECT].
6
Press [F5 (OK)]. The project will be loaded.
Never turn off the power or
remove the memory card
while the update is taking
place. Doing so will
damage the internal system
program, making it
impossible to start up
correctly.

13
Before you begin
7
Hold down [SHIFT] and press [PROJECT]. The SYSTEM
MENU will appear.
8
Select “MEMORY CARD.”
9
Select the “LIBRARY”page.
10
In LOAD/SAVE TARGET, turn EQ, DELAY, CHANNEL,
EFFECTS, and EZ ROUTING TEMPLATE all ON (highlighted
in black).
11
In COMMAND, press [LOAD (F5)].
12
Press [OK (F5)]. All libraries will be loaded.
This completes the update procedure.
If you are using two consoles, perform the update procedure for the second
console in the same way.

14
Make connections
Connect the necessary devices as shown in the following diagram.
fig.connect
Use a MIDI cable to connect the VE-7000's MIDI OUT to the MIDI IN of the
device (e.g., VM Console) that you wish to control from the VE-7000.
If you wish to use the VE-7000 to control another device, such as an
additional VM Console, connect the device to the MIDI IN of the VE-7000.
MIDI messages that are input to the VE-7000's MIDI IN will be re-
transmitted without change from MIDI OUT, and sent to the MIDI IN of the
VM Console or other device being controlled by the VE-7000.
Placing the VE-7000 on the VM Console
If you are using the VE-7000 with a “VM-C7200”VM Console, place it at the
left of the display area. The rubber magnet on the bottom of the unit will
hold it in place.
Since you will need to view the display area of the VM Console (or other
device) being controlled as you operate the VE-7000, we recommend that
you place it as close to the display area as possible.
VE-7000 VM-C7200
MIDI OUT
MIDI IN
MIDI OUT
MIDI IN
INPUT SENS
MASTER
PHONESMIXER MODE
HD Recorder
To prevent malfunction
and/or damage to speakers
or other devices, always
turn down the volume, and
turn off the power on all
devices before making any
connections.

15
Turning on the power
1
Turn on the power of the peripherals.
2
Turn on the POWER of VE-7000. Make sure that the POWER/
MIDI indicator lights.
Basic operation
(connected to the VM Console)
Screens in which the VE-7000 can be operated
Operations on the VE-7000 will be valid when the display of the VM
Console is in the following states.
Wheneither [INPUT CH1-24], [MULTIIN CH1-24], or [FLEXBUS MASTER 1-12]
is selected and the channel edit screen is displayed.
fig.chedit2
This unit is equipped with
a protection circuit. A brief
interval (a few seconds)
after power up is required
before the unit will operate
normally.
What is the channel edit screen?
This is a screen where the parameters of the desired channel are edited.
Access it by pressing [CH EDIT] on the VM Console. The title area in the
upper left of the display will indicate “CH EDIT.”
J
oystick operations will be
valid only when the
channel edit
“SURROUND”page is
accessed.

16
Turning on the power
Operations in the CH VIEW screen
You can edit the various parameters in the channel edit CH VIEW page.
Accessing the CH VIEW page
1
Press SECTION [INPUT] (or [MULTI IN] or [FLEX BUS MASTER]).
2
Press [CH EDIT] for the channel that you wish to edit. The unit
will be in channel edit mode.
3
Use [PAGE UP][PAGE DOWN] to select VIEW.
fig.chedit2
In this state, you can use the knobs and buttons of the VE-7000 to edit the
following parameters.
PREAMP AREA
GAIN Preamp gain
øPHASE Preamp phase reversal

17
Turning on the power
DELAY/DYN AREA
DIRECT/THRESHOLD Direct sound level for DELAY
Threshold level for DYN
DELAY LEVEL/RATIO Delay sound level for DELAY
Ratio for DYN
FEEDBACK/ATTACK Feedback level for DELAY
Attack time for DYN
DELAY TIME/RELEASE Delay time for DELAY
Release time for DYN
ON/OFF ON/OFF for delay or dynamics
FLEX BUS AREA
1--12 Send levels to the corresponding flex buses
ON/OFF ON/OFF setting for sends to each flex bus
EQ AREA
HI
GAIN HI gain
FREQ HI frequency
HI-MID
GAIN HI-MID gain
FREQ HI-MID frequency
Q HI-MID Q
LO-MID
GAIN LO-MID gain
FREQ LO-MID frequency
Q LO-MID Q
LO
GAIN LO gain
FREQ LO frequency
EQ ON/OFF ON/OFF for entire EQ
MAIN/CUE AREA
PAN MAIN pan
ON/OFF MAIN send ON/OFF
At the same time, you can
use V1--V6, [F1]--[F6] and
cursor [UP][DOWN] on the
VM Console to operate the
unit conventionally.

18
Turning on the power
CH VIEW area functions
In the CH VIEW area you can access the CH VIEW page and switch between
CH VIEW screens.
Accessing the CH VIEW page
When you press [CH EDIT] on the VM Console to access channel editing,
there may be times when a page other than CH VIEW is displayed.
Insuch cases, you can presstheCH VIEW area [EDIT]toimmediately access
the [CH VIEW] page.
Switching the CH VIEW screen
VM Console version 1.520 provides a special CH VIEW screen for the
VE-7000 in addition to the existing CH VIEW page.
When the CH VIEW page is displayed, you can press the CH VIEW area
[EDIT] to switch the existing CH VIEW screen to the special VE-7000 screen.
Press it once again to return to the previous CH VIEW screen.
fig.ve-7000chedit
In this screen, the various knobs and buttons are in one-to-one
correspondence with the operating panel of the VE-7000, making operation
easy to understand.
In this screen, conventional
operation using the V1--V6,
[F1]--[F6] and cursor
[UP][DOWN] of the
VM Console is not possible.

19
Convenient functions to remember
By holding down the [SHIFT] button of the VE-7000 and pressing the
following buttons, you can use the following convenient functions.
FLEX BUS AREA
•[SHIFT]+[EDIT] (Set ALL to 0dB)
Set the send levels to each FLEX BUS 1--12 to 100 (unity level).
•[SHIFT]+[ON/OFF]
Set the send level to FLEX BUS to 100 (unity level).
EQ AREA
•[SHIFT]+[EDIT] (RESET)
Return the EQ gain to a flat state.
MAIN/CUE AREA
•[SHIFT]+[ON/OFF](CH LINK)
The selected channels will be channel-linked.
If they are already channel-linked, channel link will be defeated.
•[SHIFT]+[EDIT] (Set CENTER)
The pan value will be set to the center.
ALL AREAS
•[SHIFT]+knobs
Skip values to change the setting rapidly.

20
Operations in the channel edit pages
(connected to the VM Console)
By pressing [EDIT] in the various areas, you can access the pages
corresponding to each area.
Press PRE AMP area [EDIT]. --> PREAMP page
Press DELAY/DYN area [EDIT]. --> DELAY/DN page
Press FLEX BUS area [EDIT]. --> FLEX BUS page
Press EQ area [EDIT]. --> EQ BAND page
Press MAIN/CUE area [EDIT]. --> MAIN/CUE page
Press SURROUND area [EDIT]. --> SURROUND page
In each page, you can use
the knobs and buttons of
the VE-7000 to edit in
conjunction with the
V1--V6, [F1]--[F6] and
cursor [UP][DOWN] of the
VM Console itself.
If you operate the
controllers of another area,
the [CH VIEW] page will
appear.
