Roland SPD-6 User manual

Setup Example
PD-9
PD-120
KD-80
KD-7
CY-12R/C
KD-80
KD-7
Setup Example
2.2 m
Stereo 1/4" 2 x 1/4"
PD-9
PD-120
CY-12R/C
Roland Corporation U.S.
5100 S.Eastern Avenue P.O. BOX 910921
Los Angeles, CA 90091-0921
Phone: [phone] Fax: [phone]
Visit us online at www.RolandUS.com
All specifications and appearances are subject to change without notice.
All trademarks are the property of their respective companies.
Printed in Japan Apr. ’03 RAM-3689 C-4 PBL-UPR-N
SPD-S SAMPLING PAD
SPD-20 TOTAL PERCUSSION PAD
SPD-6 PERCUSSION PAD
HPD-15 HANDSONIC
Options
A Monitor Built for Electronic Percussion.
The PM-1 is the perfect monitoring system for Roland’s
SPD-Series and HPD-15 HandSonic. Precisely tuned for
the needs of acoustic and electronic percussionists, the
PM-1’s 60-watt amplifier and 2-way speaker system
sound great on stage or at home. And monitoring is easy,
thanks to a smart angled design that even
accommodates drum stands.
Controls Connectors
*Requires APC-33 Clamp Set.
Extension pads for the SPD-S, SPD-20,
and HPD-15, allowing users to trigger
additional sounds using high-quality
"mesh" or rubber drum heads. PD-120 and
PD-100 pads available in red or purple.
KD-120 kick available in
red or purple. Dynamic crash, ride and hi-hat
cymbals designed to faithfully re-
create acoustic cymbal dimensions,
movements and inertia.
Affordable dual-trigger crash/ride cymbal with natural
"swinging" motion and super-accurate triggering.
*Beater and connection cable included.
*Kick drum pedal not included and
shown only for photography purposes.
*Trigger: 2 (head, rim)
Slant-type stand designed for hand
percussion products like the HPD-15
and SPD-6.
PDS-15 can be slanted
to improve HPD-15's
playability.
An affordable way to play and trigger MIDI modules
and samplers from an acoustic drum set, or expand
the capabilities of an electronic set.
Heavy-duty mounting clamp for use with
the SPD-S/20/6 and the HPD-15.
Personal Monitor Amplifier
PM-1
V-Pads™
PD-120/100/80R/80
V-Kicks
KD-120/80
V-Cymbals™
CY-12R/C, CY-14C,
CY-15R, CY-12H
Dual-Trigger Cymbal Pad
CY-6
Kick Trigger
RT-7K
Trigger MIDI Converter
TMC-6
Snare Trigger
RT-5S
Tom Trigger
RT-3T
Kick Trigger Unit
KD-7
Dual-Trigger Pads
PD-9/7
Single-Trigger Pad
PD-6
Pad Stand
PDS-15
Hi-Hat Control Pedal
FD-7
Pedal Switch
DP-2
Connection Cable
PCS-31
Expression Pedal
EV-5
Stereo Headphone
RH-50
Footswitch
FS-5U
All Purpose Clamp
APC-33
Pads
Pad Stand
Others
Kick Triggers
Acoustic Drum Triggers
Trigger MIDI Converter
Cymbals
Visit us online at www.Roland.com All specifications and appearances are subject to change.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan Apr. '03 RAM-3688 BGE-2 PBL-UPR-N

Follow these simple steps to record and play a sound.
-Phrase-
001 Moon Drs
002 Moon Bas
003-004 Moon Gt x 2
005 Moon Vo
006 JzStpDrs
007 JzStpBas
008 JzStpChd
009 JzStpPad
010 JzStpMel
011 2step Bt
012-013 JnglBt x 2
014 Xylo Bkg
015 SynthBkg
016 Org Bkg
017 HipHpBkg
018 Didgerdo
019 BongoPtn
020 CongaPtn
021 ShakrPtn
022 TablaPtn
023-025 16BtPtn x 3
026-028 16BtFil x 3
029 16BtEnd
030 16BtSnr
031 16BtCrK
-S.E.-
032-033 AirDrft x 2
034 SuperLow
035 RevoDown
036 SwepNoiz
037 VerbyHit
038 RevLASER
039 WhtPulse
040 Sperks
041 SldWhstl
042 NoiseTap
043 Dolphin
044 Scratch
045 Hi-Q
046 Spd-S
047 Welcome
048 ComeOn!
049 UGotGrv
050 Yeaaah
051 Haaaay
052 BasSlide
-Percussion-
053-054 WndChim x 2
055 PinChime
056-057 BelTree x 2
058-059 Crotale x 2
060-061 Triang x 2
062-063 AccCym x 2
064-065 CupChim x 2
066 Gong
067 Tamtam
068-070 Block x 3
071-072 Claves x 2
073 Cricket
074 FlexMtl
075 MtlCrash
076 Ratchet
077 Vibraslp
078-081 Tmbrn x 4
082-083 Cowbell x 2
084-085 CowbJam x 2
086 CowbBngo
087 CowbMmbo
088-089 Agogo x 2
090 SlighBel
091-092 AnklBed x 2
093 Shaker
094 ShakeEgg
095 Maracas
096-097 Cabasa x 2
098-100 Bongo x 3
101-103 Conga x 3
104-105 Cajon x 2
106-108 Timble x 3
109-112 SpokTom x 4
113-116 OctTom x 4
-Drums-
117-125 clubSnr x 9
126 808Snr
127 909Snr
128 110Snr
129 eSnr
130-132 AcuSnr x 3
133-135 Xstick x 3
136 808Claps
137 909Claps
138 110Claps
139-140 HndClap x 2
141 FingSnap
142-146 clubKik x 5
147-148 808Kik x 2
149 909Kik
150 110Kik
151-152 AcuKik x 2
153-156 clubHH x 4
157-158 808HH x 2
159-160 909HH x 2
161-162 110HH x 2
163-165 AcuHH x 3
166 110 Cym
167-169 Splash x 3
170-172 Crash x 3
173 China 16
174-175 Ride x 2
176-178 808Tom x 3
179-181 AcuTom x 3
CompactFlash (approx.)
Internal
(approx.)
16MB 32MB 64MB 128MB 256MB 512MB
LONG
STANDARD
FINE
12 min.
6 min.
3 min.
12 min.
6 min.
3 min.
24 min.
12 min.
6 min.
48 min.
24 min.
12 min.
96 min.min.
48 min.min.
24 min.min.
193 min.
96 min.
48 min.
386 min.
193 min.
96 min.
1 REVERB+GATE (Reverb+Gate)
2 DLYEDREVERB (Delayed Reverb)
3 STEREODELAY (Stereo Delay)
4 SYNC-DELAY (Sync Delay)
5 TAPE-ECHO (Tape Echo)
6 CHORUS
7 PHASER
8 FLANGER
9 STEPFLANGER (Step Flanger)
10 TREMOLO/PAN
11 SIMPLE-COMP (Compressor)
12 COMP-ENHANC (Compressor+Enhancer)
13 2BAND-COMP (2Band Compressor)
14 4BAND-PEQ (4Band Parametric Equalizer)
15 FILTER
16 ISOLATOR
17 WAH
18 OVERDRIVE
19 DISTORTION
20 LO-FI (Lo-Fi Processor)
21 RADIOTUNING (Radio Tuning)
22 RINGMODULAT (Ring Modulator)
23 PITCHSHIFT (Pitch Shifter)
24 PITCHBENDER (Pitch Bender)
25 OCTAVE
26 VOICETRANS (Voice Transformer)
27 CENTRCANCEL (Center Canceler)
28 SYNTH-PERC (Synthesizer Percussion)
29 SHORTLOOPER (Short Looper)
30 SLICER
SAMPLING PAD
1 REVERB+GATE (Reverb+Gate)
2 DLYEDREVERB (Delayed Reverb)
3 STEREODELAY (Stereo Delay)
4 SYNC-DELAY (Sync Delay)
5 TAPE-ECHO (Tape Echo)
6 CHORUS
7 PHASER
8 FLANGER
9 STEPFLANGER (Step Flanger)
10 TREMOLO/PAN
11 SIMPLE-COMP (Compressor)
12 COMP-ENHANC (Compressor+Enhancer)
13 2BAND-COMP (2Band Compressor)
14 4BAND-PEQ (4Band Parametric Equalizer)
15 FILTER
16 ISOLATOR
17 WAH
18 OVERDRIVE
19 DISTORTION
20 LO-FI (Lo-Fi Processor)
21 RADIOTUNING (Radio Tuning)
22 RINGMODULAT (Ring Modulator)
23 PITCHSHIFT (Pitch Shifter)
24 PITCHBENDER (Pitch Bender)
25 OCTAVE
26 VOICETRANS (Voice Transformer)
27 CENTRCANCEL (Center Canceler)
28 SYNTH-PERC (Synthesizer Percussion)
29 SHORTLOOPER (Short Looper)
30 SLICER
CompactFlash (approx.)
Internal
(approx.)
16MB 32MB 64MB 128MB 256MB 512MB
LONG
STANDARD
FINE
12 min.
6 min.
3 min.
12 min.
6 min.
3 min.
24 min.
12 min.
6 min.
48 min.
24 min.
12 min.
96 min.
48 min.
24 min.
193 min.
96 min.
48 min.
386 min.
193 min.
96 min.
-Phrase-
001 Moon Drs
002 Moon Bas
003-004 Moon Gt x 2
005 Moon Vo
006 JzStpDrs
007 JzStpBas
008 JzStpChd
009 JzStpPad
010 JzStpMel
011 2step Bt
012-013 JnglBt x 2
014 Xylo Bkg
015 SynthBkg
016 Org Bkg
017 HipHpBkg
018 Didgerdo
019 BongoPtn
020 CongaPtn
021 ShakrPtn
022 TablaPtn
023-025 16BtPtn x 3
026-028 16BtFil x 3
029 16BtEnd
030 16BtSnr
031 16BtCrK
-S.E.-
032-033 AirDrft x 2
034 SuperLow
035 RevoDown
036 SwepNoiz
037 VerbyHit
038 RevLASER
039 WhtPulse
040 Sperks
041 SldWhstl
042 NoiseTap
043 Dolphin
044 Scratch
045 Hi-Q
046 Spd-S
047 Welcome
048 ComeOn!
049 UGotGrv
050 Yeaaah
051 Haaaay
052 BasSlide
-Percussion-
053-054 WndChim x 2
055 PinChime
056-057 BelTree x 2
058-059 Crotale x 2
060-061 Triang x 2
062-063 AccCym x 2
064-065 CupChim x 2
066 Gong
067 Tamtam
068-070 Block x 3
071-072 Claves x 2
073 Cricket
074 FlexMtl
075 MtlCrash
076 Ratchet
077 Vibraslp
078-081 Tmbrn x 4
082-083 Cowbell x 2
084-085 CowbJam x 2
086 CowbBngo
087 CowbMmbo
088-089 Agogo x 2
090 SlighBel
091-092 AnklBed x 2
093 Shaker
094 ShakeEgg
095 Maracas
096-097 Cabasa x 2
098-100 Bongo x 3
101-103 Conga x 3
104-105 Cajon x 2
106-108 Timble x 3
109-112 SpokTom x 4
113-116 OctTom x 4
-Drums-
117-125 clubSnr x 9
126 808Snr
127 909Snr
128 110Snr
129 eSnr
130-132 AcuSnr x 3
133-135 Xstick x 3
136 808Claps
137 909Claps
138 110Claps
139-140 HndClap x 2
141 FingSnap
142-146 clubKik x 5
147-148 808Kik x 2
149 909Kik
150 110Kik
151-152 AcuKik x 2
153-156 clubHH x 4
157-158 808HH x 2
159-160 909HH x 2
161-162 110HH x 2
163-165 AcuHH x 3
166 110 Cym
167-169 Splash x 3
170-172 Crash x 3
173 China 16
174-175 Ride x 2
176-178 808Tom x 3
179-181 AcuTom x 3
Add Sampling to Any Percussion Setup!
The SPD-S Sampling Pad is a simple and
affordable way to tap into the power of
sampling. Six pads and three edge triggers
allow drummers to trigger CD-quality samples
and create phrase loops complete with
pro-quality effects.
Integrates easily with your kit
Choose from pre-loaded or
sampled sounds
Powerful sound creation tools
Expandable and customizable
A great alternative to acoustic triggers and a rack
sampler, the SPD-S lets you play up to eight sounds
using six durable rubber pads and three superb-feeling
edge triggers. There are no complicated settings to make.
Just record a sound, assign it to a pad and go. Up to 12
minutes of sampling is provided in Long mode, along
with CD-quality sampling and easy editing including
Truncate and Trigger Mode functions.
With room for 399 User waveforms, the SPD-S can store
plenty of samples. Better still, there are also 181 ready-to-
play waveforms pre-loaded into User memory. These
sounds are unique to the SPD-S and include a variety of
acoustic and electronic drums, percussion, sound effects
and phrase loops that can be combined with user samples
to create the ultimate drum kit. A sampling CD is also
included, making it easy to expand the onboard sounds.
With 30 multi-effects algorithms and a unique ambience
effect, the SPD-S offers endless sound-sculpting tools.
Just add an effect and resample the output for quick and
easy triggering! Using the Phrase Maker function, you can
create custom phrase loops by resampling a pattern being
triggered from the pads. And tweaking a sound or effect
during performance is easy—just twist the front-panel
knobs or use an optional expression pedal.
The SPD-S has a stereo input and can accommodate up to
two trigger units for playing a drum pad in either a head or
head/rim configuration. And with MIDI In and Out, it makes
a great controller and module as well. Drummers will also
appreciate being able to assign two waveforms per pad
and switch them via velocity or footswitch. The pads and
the optional footswitch also make for an easy way to stop
sounds, switch Patches and turn effects On or Off.
MULTI-EFFECTS SAMPLING MODE/TIME
Convenient CompactFlash storage
PRE-LOADED SOUNDS
The SPD-S works with readily available
CompactFlash media—making it easy to
expand the onboard sampling time, store
custom sounds, and
even import or
export .WAV/AIFF
files using your
Mac or PC.
*Please contact your authorized Roland dealer regarding compatibility of CompactFlash media.
Connect the source to the Input
jack and set the Mic/Line switch
accordingly.
Press PATCH to enter Patch mode
and use the [-]/[+] buttons to select
the destination.
Press SAMPLE and strike the
pad where you want the
sample to go.
Press SAMPLE and strike the
pad where you want the
sample to go.
Press START/STOP and start the
source. The SPD-S automatically
begins sampling when the input
exceeds the threshold. Press
START/STOP again when finished.
• Pads Built-in Pads: 9 • Maximum Polyphony 8 voices • Sampling Mode
Fine/Standard/Long • Sampling Frequency 44.1 kHz • Input Level Line : -10 dBu, Mic: -50
dBu • Input Impedance 10 k ohms (LINE/MIC) • Output Level Output: -10 dBu • Output
Impedance Output: 1 k ohms Headphones: 47 ohms * 0 dBu = 0.775 Vrms • Memory
Patches: 128 Waves (User): 399 (Pre-loaded Sound 181), Card: 500 • Maximum Sampling
Time 12 min. approx. (Internal Memory, Long Mode) • Effects Multi-Effects (30 Type) +
Ambience (System) • Display 16 characters, 1 line (backlit LCD) • Connectors Output Jacks
(L/Mono, R, 1/4 inch phone type), Input Jacks (L/Mono, R, 1/4 inch phone type) *LINE/MIC
selectable, Headphones Jack (Stereo 1/4 inch phone type), Trigger Input Jack (1/4 inch TRS
phone type), Expression Pedal Jack (1/4 inch TRS phone type), MIDI Connectors (IN, OUT),
Footswitch Jack (1/4 inch TRS phone type), CompactFlash Card Slot • Power Supply DC 9 V
AC Adaptor • Current Draw1,000 mA • Dimensions 342 (W) x 282 (D) x 83 (H) mm / 13-1/2
(W) x 11-1/8 (D) x 3-5/16 (H) inches • Weight 2.1 kg / 4 lbs 11 oz (excluding AC Adaptor) •
Accessories Owner's Manual, AC Adaptor (ACI-120C/ACI-230C/ACB-230E/ACB-240A),
Sampling CD, Slit Tape, Screws: 2, Hexagon Wrench
REAR VIEW
SPECIFICATIONS
* The SPD-S's CompactFlash file system is developed by Kyoto Software Research, Inc.
Fugue ©1999-2003 Kyoto Software Research, Inc. All rights reserved.
Sampling is easy! Follow these simple steps to record and play a sound.

Bass Drum (Kick)
b01-b03 Dry Kick x 3
b04 Meat Kick
b05 Pillow Kick
b21-b22 Reverb Kick x 2
b23-b25 Mondo Kick x 3
b26-b27 Solid Kick x 2
b39-b44 TR-808 Kick x 6
b45-b48 TR-909 Kick x 4
b49 TR-606 Distortion Kick
b50 CR-78 Kick
Snare Drum
S01-S03 Piccolo Snare x 3
S04-S06 Beech Snare x 3
S07-S09 Acoustic Snare x 3
S10-S12 Steel Snare x 3
S13-S15 Loose Snare x 3
S16-S21 Medium Snare x 6
S22-S26 Concert Snare x 5
S27 Roll Snare
S39-S45 Brush Snare x 7
S46 Rock Snare
S47 Rocker Snare
S70-S71 Jungle Snare x 2
S72-S73 Electronic Snare x 2
S74-S75 TR-808 Snare x 2
S76 TR-909 Snare
S77 TR-707 Snare
S78 TR-606 Snare
S79 CR-78 Snare
S80-S86 Cross Stick x 7
Tom-Tom
t01-t04 Big Tom x 4
t05-t08 Studio Tom x 4
t09-t12 Jazz Tom x 4
t27-t28 Room Tom x 2
t29-t30 Acoustic Tom x 2
t38 TR-808 Tom
t39-t40 TR-909 Tom x 2
Hi-Hat Cymbal
h01-h05 Pop Hi-Hat x 5
h06-h10 Real Hi-Hat x 5
h11-h12 Brush Hi-Hat x 2
h26-h29 TR-808 Hi-Hat x 4
h30-h31 TR-909 Hi-Hat x 2
h32-h33 CR-78 Hi-Hat x 2
Hi-Hat Cymbal for pedal control
H01-H02 Pop Hi-Hat x 2
H17 Hand Cymbal Hi-Hat
Crash/Ride Cymbal
C01-C04 Crash Cymbal x 4
C05-C07 Chinese Cymbal x 3
C15-C20 Ride Cymbal x 6
C21-C26 Sizzle Ride Cymbal x 6
C35 TR-808 Cymbal
C36 TR-606 Cymbal
Latin Percussion (Cuban, Brazilian)
L01-L05 Bongo x 5
L06-L13 Conga x 8
L14-L18 Cowbell x 5
L19-L20 Claves x 2
L21-L22 Guiro x 2
L23 Maracas
L24-L26 Shaker x 3
L27-L28 Tambourine x 2
L29-L32 Timbale x 4
L33 Vibra Slap
L34-L38 Agogo x 5
L39 Cabasa
L40-L45 Cuica x 6
L46-L52 Pandeiro x 7
L53-L57 Surdo x 5
L58-L61 Tamborim x 4
L62-L65 Samba Whistle x 4
L66 Cax ix i
L67-L70 Berimbau x 4
L71-L74 Caix a x 4
L75 Rain Stick
L76 Samba Bateria
L77 Samba Loop (*2)
L78 Shaker Loop (*2)
Indian Percussion
i01 Sarna Bell
i02-i06 Baya x 5
i07-i14 Tabla x 8
i15-i20 Pot Drum x 6
i21-i24 Dholak x 4
i25-i27 Madal x 3
i28 Khole
i29-i32 Dhol x 4
i33 Tabla Baya Loop (*2)
African/Middle
Eastern/Australian/Other Percussion
[Africa]
F01 Shekere
F02-F06 Djembe x 5
F07-F09 Talking Drum x 3
F10-F13 Afro Drum x 4
F14 Metal Castanets
[Middle East]
F15 Bell Tree
F16-F17 Sagat x 2
F18-F20 Darbuka x 3
F21-F22 Doira x 2
F23-F27 Doholla x 5
F28-F31 Rek x 4
F32 Bendir
F33 Dawul
[Australia]
F34 Clapstick
F35 Boomerang
[Others]
F36 Bloom Bell
[Africa]
F37 Afro Loop (*2)
Japanese/Korean/Chinese/
Southeast Asian Percussion
[Japan]
J01 Biwa
J02 Atarigane
J03 Hyoshigi
J04 Ohkawa
J05-J07 Tsuzumi x 3
J08-J09 Shime Taiko x 2
J10-J11 Matsuri Taiko x 2
J12-J14 Taiko x 3
J15 Matsuri
J16 Yyoo Dude
[Korea]
J17-J18 Buk x 2
J19 Jang-Gu
J20-J22 Jing x 3
J23-J25 Gengari x 3
[China]
J26-J28 Ban Gu x 3
J29-J30 Gu x 2
J31-J32 Tang Gu x 2
J33-J34 Hu Yin Luo x 2
J35 Nao Bo
J36 x iao Bo
J37-J38 Tam-Tam x 2
J39-J42 Gong x 4
[Southeast Asian]
J43 Finger Cymbal
J44 Rama Cymbal
J45-J46 ChenchenChenchen x 2
J47-J48 Bali Cymbal x 2
J49 Thai Gong
J50-J51 Jaws Harp x 2
Orchestral Percussion
o01 Sleigh BellSleigh Bell
o02 Tree Chimes
o03-o04 Triangle x 2
o05-o06 CastanetsCastanets x 2
o07 Wood Blockood Block
o08 Slapstick
o09-o10 Concert Bass Drum x 2
o11-o14 Timpani x 4
o15 Church BellChurch Bell
o16-o18 Percussion Hit x 3
o19-o24 Orchestra HitOrchestra Hit x 6
Melodic Percussion/Melodic
InstrumentsInstruments
M01 Glockenspiel
M02 Vibraphone
M03 x ylophone
M04-M05 Marimba x 2x 2
M06 Bass MarimbaBass Marimba
M07 Celesta
M08-M09 Tubular Bells x 2
[Central America]
M10-M11 Steel Drum x 2
[India]
M12-M13 Sitar x 2
M14-M15 SantoorSantoor x 2
M16-M17 Tambura x 2
[Middle East][Middle East]
M18-M19 Hammer DulcimerHammer Dulcimer x 2
[Africa]
M20 Kalimba
M21 Log Drum
M22 Balaphone
M23 Afro Zither
[China]
M24 Yang Qinang Qin
[Southeast Asia]
M25 Bonang
M26 Gender
M27 SaronSaron
M28 Angklung
[Melodic Instruments][Melodic Instruments]
M29-M30M29-M30 Gamelan x 2
M31 GlassGlass
M32 Iron HammerIron Hammer
M33 Bamboo
M34 Drip
M35-M36M35-M36 Synth StringsSynth Strings x 2
M37-M43M37-M43 BrassBrass x 7
M44-M52M44-M52 Choir x 9
M53-M59M53-M59 Bass x 7
Analog Percussion
A01 DR-55 ClavesDR-55 Claves
A02 CR-78 CowbellCR-78 Cowbell
A03 CR-78 Metallic BeatCR-78 Metallic Beat
A04A04 CR-78 GuiroCR-78 Guiro
A05A05 CR-78CR-78 Tambourineambourine
A06A06 CR-78 MaracasCR-78 Maracas
A07A07 CR-78 BongoCR-78 Bongo
A08A08 CR-78 ClavesCR-78 Claves
A09A09 TR-707 CowbellTR-707 Cowbell
A10A10 TR-727 AgogoAgogo
A111 TR-808 Conga
A12A12 TR-808 Claves
A13A13 TR-808 Maracas
A14A14 TR-808 CowbellTR-808 Cowbell
A15A15 TR-808 Hand ClapTR-808 Hand Clap
A16 TR-909 Hand ClapTR-909 Hand Clap
Dance Sounds
d01-d02 Hand Clap x 2
d03 Little ClapLittle Clap
d04 Hip ClapHip Clap
d05 Afro ClapAfro Clap
d06-d10 Scratch x 5
d11-d12 Scratch Bass DrumScratch Bass Drum x 2
d13 Scratch SnareScratch Snare
d14 Jungle Hat
d19-d21 High-QHigh-Q x 3
d22 Air Blip
d23 Techno Snapechno Snap
d24 Organ ChordOrgan Chord
d25 Distortion GuitarDistortion Guitar
d26 Auh Voiceoice
d27 Techno Chordechno Chord
d28 Techno Sceneechno Scene
d29 Synth HitSynth Hit
d36 Retro UFORetro UFO
d37 Metal SweepMetal Sweep
d38 Bounce
d39 Distortion SwishDistortion Swish
d40 PCM Press
d41 Jungle Roll Kick
d42 Jungle Roll Snare
d43 Techno Loop (*2)echno Loop (*2)
Sound Effects
E01 Burt
E02-E03 Boing x 2
E04 OnkeyOnkey
E05 Tom Noiseom Noise
E06 Lazer
E07 Feedback WFeedback Wave
E08 AtmosphereAtmosphere
E09 Bend Synth
E10 Toy Gun
E27-E30 NoiseNoise Accent x 4
E31-E34 Random Noise x 4
E35 Slide
E36 Uut?
E37 Drop
E38 EmergencyEmergency
E39-E40 Woody x 2
E41 Monster DrumMonster Drum
E42 Can DrumCan Drum
E43-E46 Wah Guitarah Guitar x 4
Natural Sounds,Natural Sounds, Human Voiceoice
n01-n02n01-n02 Telephone x 2
n03 Doorbell
n04 Dog BarkDog Bark
n05 BirdBird
n06n06 Car DoorCar Door
n07 Car StopCar Stop
n08n08 Horn
n09n09 Punch
n13 Machine GunMachine Gun
n14n14 PistolPistol
n15 SirenSiren
n23 Oww!Oww!
n24n24 Woa!
n25 Ooh!
n26 Chiki!Chiki!
n27 Hey!
n28 Ou!
n29n29 Ou! Up
n30 Scream
n31 Voice Loop (*2)oice Loop (*2)
Ambience, ReReverversed Soundssed Sounds
r01r01 KickKick Ambience
r20r20 Reverse Tom
(*1): Y(*1): You can continuously changeou can continuously change
the tone and length of the soundthe tone and length of the sound
from closed to opened by using theom closed to opened by using the
hi-hat contrhi-hat control pedal.ol pedal.
(*2): These ar(*2): These are shoreshort phrases typicaltphrases typical
of that music genrof that music genre. By using thee. By using the
pedal switch, you can hold thepedal switch, you can hold the
phrase loop.phrase loop.
Kick
1 Kick
2 Mix Kick
3 Jazz Kick 1
4 Jazz Kick 2
5 MONDO Kick
6 HipHop Kick
7 808 Kick 1
8 808 Kick 2
9 Electronic Kick
Snare
10 Standard Snare
11 Dance Snare
12 HipHop Snare 1
13 HipHop Snare 2
14 Dopin’ Snare
15 Gated Snare
16 808 Snare
17 Electronic Snare 1
18 Electronic Snare 2
19 Cross Stick
20 Snare Roll
21 Brush Roll Snare
22 Brush Swish Snare
23 Brush Slap Snare
Tom-Tom
24 High Tom 1
25 High Tom 2
26 Mid Tom 1
27 Mid Tom 2
28 Low Tom 1
29 Low Tom 2
30 Room High Tom
31 Room Mid Tom
32 Room Low Tom
33 Power High Tom 1
34 Power High Tom 2
35 Power Mid Tom 1
36 Power Mid Tom 2
37 Power Low Tom 1
38 Power Low Tom 2
39 808 High Tom 1
40 808 High Tom 2
41 808 Mid Tom 1
42 808 Mid Tom 2
43 808 Low Tom 1
44 808 Low Tom 2
45 Electronic High Tom
46 Electronic Mid Tom
47 Electronic Low Tom
Hi-Hat Cymbal
48 Closed Hi-Hat [EXC 1]
49 Pedal Hi-Hat [EXC 1]
50 Open Hi-Hat [EXC 1]
51 808 Closed Hi-Hat 1 [EXC 1]
52 808 Closed Hi-Hat 2 [EXC 1]
53 808 Open Hi-Hat [EXC 1]
Cymbal
54 Crash Cymbal 1
55 Crash Cymbal 2
56 Splash Cymbal
57 Ride Cymbal 1
58 Ride Cymbal 2
59 808 Cymbal
60 Reverse Cymbal
Percussion
61 High Bongo
62 Low Bongo
63 Open High Conga
64 Mute High CongaMute High Conga
65 Low Conga
66 Cowbell
67 Claves
68 Long GuiroLong Guiro [EXC 2][EXC 2]
69 Short Guiro [EXC 2][EXC 2]
70 Maracas
71 Shaker
72 Tambourine
73 High Timbaleimbale
74 Low Timbale
75 Vibra-Slap
76 HighHigh Agogo
77 LowLow AgogoAgogo
78 Open Cuica [EXC 3]
79 Mute Cuica [EXC 3]
80 Open Surdo [EXC 4]
81 Mute Surdo [EXC 4]
82 WhistleWhistle
83 High WHigh Wood Block
84 Low WLow Wood Blockood Block
85 Bell Tree
86 Open Triangle [EXC 5]
87 Mute Triangle [EXC 5]
88 Metronome BellMetronome Bell
89 Metronome ClickMetronome Click
Dance
9090 Hand Clap
9191 Scratch
9292 Scratch Pull [EXC 6]
9393 Scratch Push [EXC 6]
9494 High QHigh Q
9595 SlapSlap
9696 Guitar SlideGuitar Slide
9797 String Slap
Sound Effects
9898 Telephoneelephone
9999 Dog
100100 KittyKitty
101101 Car-Engine
102102 Car-Stop
103103 Car-Crash
104 Door CreakingDoor Creaking
105 Door
106 Foot StepFoot Step
107 Heart Beat
108 Screaming
109 PunchPunch
110 Laughing
111 Thunder
112 Gun ShotGun Shot
113 Lasergun
[EXC*]: Sounds of the same number[EXC*]: Sounds of the same number
will not play simultaneouslywill not play simultaneously.
(*1): You can continuously change
the tone and length of the sound
from closed to opened by using the
hi-hat control pedal.
(*2): These are short phrases typical
of that music genre. By using the
pedal switch, you can hold the
phrase loop.
SPD-20
Kick
1 Kick
2 Mix Kick
3 Jazz Kick 1
4 Jazz Kick 2
5 MONDO Kick
6 HipHop Kick
7 808 Kick 1
8 808 Kick 2
9 Electronic Kick
Snare
10 Standard Snare
11 Dance Snare
12 HipHop Snare 1
13 HipHop Snare 2
14 Dopin’ Snare
15 Gated Snare
16 808 Snare
17 Electronic Snare 1
18 Electronic Snare 2
19 Cross Stick
20 Snare Roll
21 Brush Roll Snare
22 Brush Swish Snare
23 Brush Slap Snare
Tom-Tom
24 High Tom 1
25 High Tom 2
26 Mid Tom 1
27 Mid Tom 2
28 Low Tom 1
29 Low Tom 2
30 Room High Tom
31 Room Mid Tom
32 Room Low Tom
33 Power High Tom 1
34 Power High Tom 2
35 Power Mid Tom 1
36 Power Mid Tom 2
37 Power Low Tom 1
38 Power Low Tom 2
39 808 High Tom 1
40 808 High Tom 2
41 808 Mid Tom 1
42 808 Mid Tom 2
43 808 Low Tom 1
44 808 Low Tom 2
45 Electronic High Tom
46 Electronic Mid Tom
47 Electronic Low Tom
Hi-Hat Cymbal
48 Closed Hi-Hat [EXC 1]
49 Pedal Hi-Hat [EXC 1]
50 Open Hi-Hat [EXC 1]
51 808 Closed Hi-Hat 1 [EXC 1]
52 808 Closed Hi-Hat 2 [EXC 1]
53 808 Open Hi-Hat [EXC 1]
Cymbal
54 Crash Cymbal 1
55 Crash Cymbal 2
56 Splash Cymbal
57 Ride Cymbal 1
58 Ride Cymbal 2
59 808 Cymbal
60 Reverse Cymbal
Percussion
61 High Bongo
62 Low Bongo
63 Open High Conga
64 Mute High Conga
65 Low Conga
66 Cowbell
67 Claves
68 Long Guiro [EXC 2]
69 Short Guiro [EXC 2]
70 Maracas
71 Shaker
72 Tambourine
73 High Timbale
74 Low Timbale
75 Vibra-Slap
76 High Agogo
77 Low Agogo
78 Open Cuica [EXC 3]
79 Mute Cuica [EXC 3]
80 Open Surdo [EXC 4]
81 Mute Surdo [EXC 4]
82 Whistle
83 High Wood Block
84 Low Wood Block
85 Bell Tree
86 Open Triangle [EXC 5]
87 Mute Triangle [EXC 5]
88 Metronome Bell
89 Metronome Click
Dance
90 Hand Clap
91 Scratch
92 Scratch Pull [EXC 6]
93 Scratch Push [EXC 6]
94 High Q
95 Slap
96 Guitar Slide
97 String Slap
Sound Effects
98 Telephone
99 Dog
100 Kitty
101 Car-Engine
102 Car-Stop
103 Car-Crash
104 Door Creaking
105 Door
106 Foot Step
107 Heart Beat
108 Screaming
109 Punch
110 Laughing
111 Thunder
112Gun Shot
113 Lasergun
[EXC*]: Sounds of the same number
will not play simultaneously.
SPD-6
Bass Drum (Kick)
b01-b03 Dry Kick x 3
b04 Meat Kick
b05 Pillow Kick
b21-b22 Reverb Kick x 2
b23-b25 Mondo Kick x 3
b26-b27 Solid Kick x 2
b39-b44 TR-808 Kick x 6
b45-b48 TR-909 Kick x 4
b49 TR-606 Distortion Kick
b50 CR-78 Kick
Snare Drum
S01-S03 Piccolo Snare x 3
S04-S06 Beech Snare x 3
S07-S09 Acoustic Snare x 3
S10-S12 Steel Snare x 3
S13-S15 Loose Snare x 3
S16-S21 Medium Snare x 6
S22-S26 Concert Snare x 5
S27 Roll Snare
S39-S45 Brush Snare x 7
S46 Rock Snare
S47 Rocker Snare
S70-S71 Jungle Snare x 2
S72-S73 Electronic Snare x 2
S74-S75 TR-808 Snare x 2
S76 TR-909 Snare
S77 TR-707 Snare
S78 TR-606 Snare
S79 CR-78 Snare
S80-S86 Cross Stick x 7
Tom-Tom
t01-t04 Big Tom x 4
t05-t08 Studio Tom x 4
t09-t12 Jazz Tom x 4
t27-t28 Room Tom x 2
t29-t30 Acoustic Tom x 2
t38 TR-808 Tom
t39-t40 TR-909 Tom x 2
Hi-Hat Cymbal
h01-h05 Pop Hi-Hat x 5
h06-h10 Real Hi-Hat x 5
h11-h12 Brush Hi-Hat x 2
h26-h29 TR-808 Hi-Hat x 4
h30-h31 TR-909 Hi-Hat x 2
h32-h33 CR-78 Hi-Hat x 2
Hi-Hat Cymbal for pedal control
H01-H02 Pop Hi-Hat x 2
H17 Hand Cymbal Hi-Hat
Crash/Ride Cymbal
C01-C04 Crash Cymbal x 4
C05-C07 Chinese Cymbal x 3
C15-C20 Ride Cymbal x 6
C21-C26 Sizzle Ride Cymbal x 6
C35 TR-808 Cymbal
C36 TR-606 Cymbal
Latin Percussion (Cuban, Brazilian)
L01-L05 Bongo x 5
L06-L13 Conga x 8
L14-L18 Cowbell x 5
L19-L20 Claves x 2
L21-L22 Guiro x 2
L23 Maracas
L24-L26 Shaker x 3
L27-L28 Tambourine x 2
L29-L32 Timbale x 4
L33 Vibra Slap
L34-L38 Agogo x 5
L39 Cabasa
L40-L45 Cuica x 6
L46-L52 Pandeiro x 7
L53-L57 Surdo x 5
L58-L61 Tamborim x 4
L62-L65 Samba Whistle x 4
L66 Cax ix i
L67-L70 Berimbau x 4
L71-L74 Caix a x 4
L75 Rain Stick
L76 Samba Bateria
L77 Samba Loop (*2)
L78 Shaker Loop (*2)
Indian Percussion
i01 Sarna Bell
i02-i06 Baya x 5
i07-i14 Tabla x 8
i15-i20 Pot Drum x 6
i21-i24 Dholak x 4
i25-i27 Madal x 3
i28 Khole
i29-i32 Dhol x 4
i33 Tabla Baya Loop (*2)
African/Middle
Eastern/Australian/Other Percussion
[Africa]
F01 Shekere
F02-F06 Djembe x 5
F07-F09 Talking Drum x 3
F10-F13 Afro Drum x 4
F14 Metal Castanets
[Middle East]
F15 Bell Tree
F16-F17 Sagat x 2
F18-F20 Darbuka x 3
F21-F22 Doira x 2
F23-F27 Doholla x 5
F28-F31 Rek x 4
F32 Bendir
F33 Dawul
[Australia]
F34 Clapstick
F35 Boomerang
[Others]
F36 Bloom Bell
[Africa]
F37 Afro Loop (*2)
Japanese/Korean/Chinese/
Southeast Asian Percussion
[Japan]
J01 Biwa
J02 Atarigane
J03 Hyoshigi
J04 Ohkawa
J05-J07 Tsuzumi x 3
J08-J09 Shime Taiko x 2
J10-J11 Matsuri Taiko x 2
J12-J14 Taiko x 3
J15 Matsuri
J16 Yyoo Dude
[Korea]
J17-J18 Buk x 2
J19 Jang-Gu
J20-J22 Jing x 3
J23-J25 Gengari x 3
[China]
J26-J28 Ban Gu x 3
J29-J30 Gu x 2
J31-J32 Tang Gu x 2
J33-J34 Hu Yin Luo x 2
J35 Nao Bo
J36 x iao Bo
J37-J38 Tam-Tam x 2
J39-J42 Gong x 4
[Southeast Asian]
J43 Finger Cymbal
J44 Rama Cymbal
J45-J46 Chenchen x 2
J47-J48 Bali Cymbal x 2
J49 Thai Gong
J50-J51 Jaws Harp x 2
Orchestral Percussion
o01 Sleigh Bell
o02 Tree Chimes
o03-o04 Triangle x 2
o05-o06 Castanets x 2
o07 Wood Block
o08 Slapstick
o09-o10 Concert Bass Drum x 2
o11-o14 Timpani x 4
o15 Church Bell
o16-o18 Percussion Hit x 3
o19-o24 Orchestra Hit x 6
Melodic Percussion/Melodic
Instruments
M01 Glockenspiel
M02 Vibraphone
M03 x ylophone
M04-M05 Marimba x 2
M06 Bass Marimba
M07 Celesta
M08-M09 Tubular Bells x 2
[Central America]
M10-M11 Steel Drum x 2
[India]
M12-M13 Sitar x 2
M14-M15 Santoor x 2
M16-M17 Tambura x 2
[Middle East]
M18-M19 Hammer Dulcimer x 2
[Africa]
M20 Kalimba
M21 Log Drum
M22 Balaphone
M23 Afro Zither
[China]
M24 Yang Qin
[Southeast Asia]
M25 Bonang
M26 Gender
M27 Saron
M28 Angklung
[Melodic Instruments]
M29-M30 Gamelan x 2
M31 Glass
M32 Iron Hammer
M33 Bamboo
M34 Drip
M35-M36 Synth Strings x 2
M37-M43 Brass x 7
M44-M52 Choir x 9
M53-M59 Bass x 7
Analog Percussion
A01 DR-55 Claves
A02 CR-78 Cowbell
A03 CR-78 Metallic Beat
A04 CR-78 Guiro
A05 CR-78 Tambourine
A06 CR-78 Maracas
A07 CR-78 Bongo
A08 CR-78 Claves
A09 TR-707 Cowbell
A10 TR-727 Agogo
A11 TR-808 Conga
A12 TR-808 Claves
A13 TR-808 Maracas
A14 TR-808 Cowbell
A15 TR-808 Hand Clap
A16 TR-909 Hand Clap
Dance Sounds
d01-d02 Hand Clap x 2
d03 Little Clap
d04 Hip Clap
d05 Afro Clap
d06-d10 Scratch x 5
d11-d12 Scratch Bass Drum x 2
d13 Scratch Snare
d14 Jungle Hat
d19-d21 High-Q x 3
d22 Air Blip
d23 Techno Snap
d24 Organ Chord
d25 Distortion Guitar
d26 Auh Voice
d27 Techno Chord
d28 Techno Scene
d29 Synth Hit
d36 Retro UFO
d37 Metal Sweep
d38 Bounce
d39 Distortion Swish
d40 PCM Press
d41 Jungle Roll Kick
d42 Jungle Roll Snare
d43 Techno Loop (*2)
Sound Effects
E01 Burt
E02-E03 Boing x 2
E04 Onkey
E05 Tom Noise
E06 Lazer
E07 Feedback Wave
E08 Atmosphere
E09 Bend Synth
E10 Toy Gun
E27-E30 Noise Accent x 4
E31-E34 Random Noise x 4
E35 Slide
E36 Uut?
E37 Drop
E38 Emergency
E39-E40 Woody x 2
E41 Monster Drum
E42 Can Drum
E43-E46 Wah Guitar x 4
Natural Sounds, Human Voice
n01-n02 Telephone x 2
n03 Doorbell
n04 Dog Bark
n05 Bird
n06 Car Door
n07 Car Stop
n08 Horn
n09 Punch
n13 Machine Gun
n14 Pistol
n15 Siren
n23 Oww!
n24 Woa!
n25 Ooh!
n26 Chiki!
n27 Hey!
n28 Ou!
n29 Ou! Up
n30 Scream
n31 Voice Loop (*2)
Ambience, Reversed Sounds
r01 Kick Ambience
r20 Reverse Tom
PERCUSSION PAD
Innovative Percussion Pads
for Stage and Studio.
The SPD-20 Total Percussion Pad and SPD-6
Percussion Pad make it easy to add a wide variety of
high-quality drum and percussion sounds to your live
performances, studio gigs and rehearsals.
Flagship sounds and features Infinitely expressive
The SPD-20’s sound set includes everything from ethnic
and world percussion instruments to classic and modern
acoustic and electronic drum sounds—700 sounds total!
Out of the box, you get 99 Preset Patches and six rhythm
loops that can be played via eight high-quality pads with
natural response—even when playing with common
drumming techniques like rolls and flams.
Play it by hand or with sticks
Thanks to its Sensitivity Selection switch, the SPD-6 can be
played by hand or using drum sticks. Its compact and
easy-to-use design makes it a great choice not only for
drummers, but for anyone who wants to add 113 high-
quality drum sounds to their music. A total of 16 Preset
and 16 User Patches are provided, which can be played
using the six rubber pads.
Compact design with room to grow
By connecting two optional footswitches, you can turn the
SPD-6 into a super compact and portable electronic drum
kit. It even works as a MIDI controller and sound module!
Best of all, the SPD-6 can run on AC or battery power, so
you can take it anywhere. There’s never been an easier
way to bring electronic percussion into your music.
Four external dual-trigger inputs make the SPD-20 compatible
with a dedicated hi-hat or kick drum controller and any of
Roland’s drum pads (including V-Pads™). The trigger inputs
can also be used with acoustic drum triggers for triggering
acoustic drums. Other noteworthy features include a velocity-
sensitive Layer function, onboard effects and MIDI connections
for using the SPD-20 as a controller or sound module.
• Max. Polyphony 14 voices • Number of Instruments 700 • Internal Memory 99 Patches, 8
Patch Chains • Sound Parameters Instrument, Level, Pitch, Decay, Pan, Curve, Effect Send Level
• Effects Reverb, Delay, Chorus, Flanger • Number of Pads 8 • Display 7-segment, 3-character
LED • Connectors Output (L/Mono, R), Phones (Stereo), External Trigger Input* x 3 (Dual), Hi-Hat
Control/Trigger4 Input* (Dual), MIDI (In, Out), Footswitch (Dual), AC IN *Trigger inputs 1 and 2
accept rim shots from the PD-7, -9, -80R and -120 while inputs 3 and 4 accept rim shots from the
PD-7 and -9. • Power Supply AC12V, AC Adaptor • Current Draw 420mA • Dimensions 450 (W)
x 350 (D) x 70 (H) mm / 17-3/4 (W) x 13-13/16 (D) x 2-13/16 (H) inches • Weight 2.8 kg /6 lbs. 3
oz. (excl. AC Adaptor) • Accessories BOSS BRA-Series AC Adaptor, Slit Tape
REAR VIEW
SPECIFICATIONS
• Max. Polyphony 4 voices • Number of Instruments 113 • Internal Memory Preset: 16, User: 16
• Number of Pads 6 • Connectors OUTPUT 1 (PHONES) / OUTPUT 2 (MONO), Pedal SW 1/2 (for
DP-2, FS-5U) for Kick/Hi-Hat control, MIDI OUT, AC Adaptor • Switches SENS, POWER, BANK x4,
NUMBER x4 - Control Volume • Power Supply DC 9V dry battery (AA type x6) or AC Adaptor
(BOSS PSA series) • Current Draw 100mA • Dimensions 318 (W) x 241 (D) x 67 (H) mm / 12-9/16
x 9-1/2 x 2-11/16 inches • Weight 1.6 kg, 3 lbs. 9 oz. (incl. Batteries) • Accessories MIDI cable,
Battery AA type x6 • Options PSA-Series AC Adaptor (BOSS)
REAR VIEW
SPECIFICATIONS
Preset Instruments

LATIN
P01 01 Conga
P01 02 Bongo
P01 03 Timbales
P01 04 LatinToys
P01 05 CONGAbongo
P01 06 TimbaleMix
P01 07 Conga II
P01 08 Bongo II
P01 09 TimbalesII
P01 10 BONGO-BRS-
P01 11 TimbalSong
P01 12 Steel Drum
P01 13 Pandeiro
P01 14 Surdo
P01 15 ESCOLA
P01 16 Berimbau
P01 17 PandeiroII
P01 18 Surdo II
P01 19 Brazil Mix
P01 20 Perc Echos
P01 21 SpaceConga
P01 22 808 Latin
AFRICAN
P02 01 TalkingDrm
P02 02 Djembe S
P02 03 Djembe L
P02 04 Frame Drum
P02 05 Pot Drum
P02 06 Kalimba
P02 07 Log Drum
P02 08 Balaphone
P02 09 Gyilli
P02 10 AfroZither
P02 11 MonguDrum
P02 12 AfricaToys
P02 13 Gyilli&Cng
P02 14 NaturePerc
P02 15 GyliBalaph
P02 16 TalkDrm II
P02 17 PotDrum II
INDIAN
P03 01 Tabla
P03 02 Dholak
P03 03 Madal
P03 04 Dhol
P03 05 DrmOfIndia
P03 06 MadalTalan
P03 07 Tabla II
P03 08 Tabla III
P03 09 TABLATIX
P03 10 Sitar
P03 11 SantoorMaj
P03 12 SantoorMin
P03 13 Tambura
P03 14 Darabukka
P03 15 Rek
P03 16 Doholla
P03 17 Doira
P03 18 Turk-Mltry
ASIAN
P04 01 JAPAN
P04 02 MATSURI
P04 03 CHINA
P04 04 Yang Qin
P04 05 Korean4Drm
P04 06 Gamelan
P04 07 JavaGameln
P04 08 BaliGameln
P04 09 Bali&Java
P04 10 Gongs
P04 11 Angklung
P04 12 Bonang
P04 13 Gender
P04 14 Saron
ORCH
P05 01 Vibraphone
P05 02 Glockenspl
P05 03 Xylophone
P05 04 Marimba
P05 05 Bs Marimba
P05 06 TubularBel
P05 07 Timpani
P05 08 Orch Hit
P05 09 LightOrch
P05 10 OrchPerc
P05 11 Aux Perc
DRUMS
P06 01 Standard
P06 02 Jazzbrush
P06 03 Analog
P06 04 TR-808
P06 05 TR-909
P06 06 Studio
P06 07 Rock Stage
P06 08 Swing
P06 09 Brushes
P06 10 Orch Set
P06 11 Mexi-Set
P06 12 Hi-Boy
P06 13 Low&Dry
P06 14 Jazz Mix
P06 15 JzBrush&Bs
P06 16 BluesClub
P06 17 Drum&Horns
P06 18 TechnoGate
P06 19 FlangeDrms
P06 20 JunkyDrums
P06 21 Brush Box
DANCE
P07 01 Clap&ScrchClap&Scrch
P07 02 FILTERED
P07 03 Trash Beat
P07 04 LatinHouse
P07 05 Techey
P07 06 TechDance
P07 07 EthniDance
P07 08 Cosmo 21
P07 09 Industrial
P07 10 UndaGroundUndaGround
P07 11 StreetBeat
P07 12 909-2000
P07 13 AlienDance
P07 14 TechNow
P07 15 Sweep 808
P07 16 RevolutionRevolution
P07 17 Backbeat
P07 18 AmberWAmberWater
P07 19 SynthDrums
P07 20 DiscoticaDiscotica
P07 21 Dance 6Dance 6
P07 22 Lock OutLock Out
P07 23 DanceMenu1
P07 24 DanceMenu2
SFX
P08 01 PsycoDrama
P08 02 ForestForest
P08 03 GrandBlue
P08 04 NoiseSonic
P08 05 ArpegPerc
P08 06 CartoonFX
P08 07 Silly FX
P08 08 Rol&FiltMeRol&FiltMe
P08 09 MetalMania
P08 10 ChaosSoniq
P08 11 SFX Menu 1
P08 12 SFX Menu 2
P08 13 SFX Menu 3
OTHERS
P09 01 Laserwave
P09 02 Heavy GtrHeavy Gtr
P09 03 Acous Bass
P09 04 SH101 Bass
P09 05P09 05 FluteFlute
P09 06P09 06 Syn StringSyn String
P09 07P09 07 Saw Wave
P09 08P09 08 Juno Rave
P09 09P09 09 Fantasia
P09 10P09 10 Thick PadThick Pad
P09 1P09 11CalliopeCalliope
P09 12P09 12 Melody-808
LOOPS
P10 01P10 01 Latin LoopLatin Loop
P10 02P10 02 Samba LoopSamba Loop
P10 03P10 03 AfricaLoop
P10 04P10 04 IndianLoop
P10 05P10 05 Asian LoopAsian Loop
P10 06P10 06 FusionLoop
P10 07P10 07 Dance LoopDance Loop
P10 08P10 08 Shot &Shot & Tap
LATIN
L01-L05,L07 Bongo Hi x 6
L06, L08 Bongo Lo x 2
L09-L18,
L28-L29 Conga Hi x 12
L19-L27,L30 Conga Lo x 10
L31-L34 Cowbell x 4
L35-L36 Claves x 2
L37-L40 Guiro x 4
L41 Maracas x 1
L42-L44 Shaker x 3
L45-L46 Tambourine x 2
L47-L59 Timbale x 13
L60 Vibra-slap x 1
L61-L62 Steel Drum x 2
L63-L69 Agogo x 7
L70 Cabasa x 1
L71-L78 Cuica x 8
L79-L84 Pandeiro x 6
L85-L89 Surdo x 5
L90-L93 Tamborim x 4
L94-L96 Whistle x 3
L97 Caxixi x 1
L98-l03 Berimbau x 5
l04-l06 Caixa x 3
l07-l08 Rain Stick x 2
l09 SambaBateria x 1
l10-l11 SpaceConga x 2
l12-l13 E.Conga x 2
l14-l25 AnalogPercs x 12
AFRICAN
F01 Shekere x 1
F02-F07 Djembe x 6
F08-F13 Small Djembe x 6
F14-F16 TalkingDrm x 3
F17-F20 Afro Drum x 4
F21 Metal Casta x 1
F22-F31 Pot Drum x 10
F32 Kalimba x 1
F33 Log Drum x 1
F34-F41 Gyilli x 8
F42-F49 Balaphone x 8
F50 Afro Zither x 1
F51 Afro Feet x 1
F52 Afro Stomp x 1
F53-F54 Hand Drum x 2
F55-F57 Mongu x 3
F58 Clapstick x 1
F59 Boomerang x 1
F60 Bamboo x 1
F61 BloomBell x 1
INDIAN
I01 Sarna Bell x 1
I02-I09 Tabla x 8
I10-I14 Baya x 5
I15-I19 Dholak x 5
I20-I23 Madal x 4
I24 Khole x 1
I25-I28 Dhol x 4
I29-I30 Sitar x 2
I31-I32 Santoor x 2
I33-I34 Tambura x 2
I35 Bell Tree x 1
I36-I38 Sagat x 3
I39-I41 Darbukka x 3
I42-I43 Doira x 2
I44-I49 Doholla x 6
I50-I53 Rek x 4
I54 Bendir x 1
I55 Dawul x 1
I56-I57 HmrDlcmr x 2
ASIAN
A01 Biwa x 1
A02 Atarigane x 1
A03 Hyoshigi x 1
A04 Ohkawa x 1
A05-A06 Tsuzumi x 2
A07-A08 Shime Taiko x 2
A09-A10 MatsuriTaiko x 2
A11-A12 Buk x 2
A13 Jang-Gu x 1
A14-A15 Jing x 2
A16-A17 Gengari x 2
A18-A20 Ban Gu x 3
A21-A23 Gu x 3x 3
A24-A25 Tang Guang Gu x 2x 2
A26-A27 Hu Yin Luo x 2x 2
A28 Nao Bo x 1x 1
A29 Xiao Bo x 1x 1
A30 Large TamTam x 1x 1
A31 Large Gong x 1x 1
A32 Small Gong x 1x 1
A33 Bend Gong x 1x 1
A34 Yang Qinang Qin x 1x 1
A35-A36 Finger Cym x 2x 2
A37 Rama CymbalRama Cymbal x 1x 1
A38-A40 Chenchen x 3x 3
A41-A43 Bali CymBali Cym x 3x 3
A44 Thai Gong x 1x 1
A45-A47 JawsHarp x 3x 3
A48 Bonang x 1x 1
A49 Gender x 1x 1
A50 Saron x 1x 1
A51 Angklung x 1x 1
A52-A53 Gamelan x 2x 2
ORCH
O01 Sleigh Bell x 1
O02 Tree Chimes x 1
O03-O04 Triangle x 2
O05 Castanets x 1
O06-O07 Wood Block x 2
O08 SlapstickSlapstick x 1
O09-O10 Concert BsDr x 2
O11 Timpaniimpani x 1
O12 Perc Hit x 1
O13-O14 Orch Hit x 2
O15 DrmMaj Whstl x 1
O16 Glockenspiel x 1
O17 Vibraphone x 1
O18 XylophoneXylophone x 1
O19-O20 Marimba x 2
O21 Bass MarimbaBass Marimba x 1
O22 Celesta x 1
O23 Tubular Bell x 1
O24 Glass x 1
O25 Iron HammerIron Hammer x 1
DRDRUMS
R01-R12R01-R12 Kick x 12x 12
R22-R34R22-R34 Snare x 22x 22
R35-R36R35-R36 CrossStk x 2
R37-R42R37-R42 Stick x 6
R43-R56R43-R56 Tom x 14x 14
R57-R78R57-R78 Hi-Hat x 22x 22
R79-R96R79-R96 Cymbal x 18x 18
R97R97 Wheel PedalWheel Pedal x 1
R98-r01R98-r01 KickCymbal x 3
r02 Voice Kick x 1
r03 Voice Snare x 1
r04 Voice HiHat x 1
DANCE
D01-D05D01-D05 Hand Clap x 5
D06-D12D06-D12 Scratch x 7
D15-D18D15-D18 Trash x 4
D19-D21D19-D21 High-Q x 3
D29-D36D29-D36 Hit x 8
etc x 18x 18
SFX
S23-S26S23-S26 Shot x 4
S27-S36S27-S36 Noise x 10
etcetc x 50
OTHERS
T01-T05 Piano x 5
T06-T07 Organ x 2
T08-T28 GuitarGuitar x 21
T29-T41 BassBass x 13
T42-T44 Strings x 3
T45-T50 Brass x 6
T51 Tenor saxenor sax x 1
T52 Flute x 1
T53-T58 Waveave x 6
T59-T68 Synth x 10
PRESET INSTRUMENTS
LATIN
P01 01 Conga
P01 02 Bongo
P01 03 Timbales
P01 04 LatinToys
P01 05 CONGAbongo
P01 06 TimbaleMix
P01 07 Conga II
P01 08 Bongo II
P01 09 TimbalesII
P01 10 BONGO-BRS-
P01 11 TimbalSong
P01 12 Steel Drum
P01 13 Pandeiro
P01 14 Surdo
P01 15 ESCOLA
P01 16 Berimbau
P01 17 PandeiroII
P01 18 Surdo II
P01 19 Brazil Mix
P01 20 Perc Echos
P01 21 SpaceConga
P01 22 808 Latin
AFRICAN
P02 01 TalkingDrm
P02 02 Djembe S
P02 03 Djembe L
P02 04 Frame Drum
P02 05 Pot Drum
P02 06 Kalimba
P02 07 Log Drum
P02 08 Balaphone
P02 09 Gyilli
P02 10 AfroZither
P02 11 MonguDrum
P02 12 AfricaToys
P02 13 Gyilli&Cng
P02 14 NaturePerc
P02 15 GyliBalaph
P02 16 TalkDrm II
P02 17 PotDrum II
INDIAN
P03 01 Tabla
P03 02 Dholak
P03 03 Madal
P03 04 Dhol
P03 05 DrmOfIndia
P03 06 MadalTalan
P03 07 Tabla II
P03 08 Tabla III
P03 09 TABLATIX
P03 10 Sitar
P03 11 SantoorMaj
P03 12 SantoorMin
P03 13 Tambura
P03 14 Darabukka
P03 15 Rek
P03 16 Doholla
P03 17 Doira
P03 18 Turk-Mltry
ASIAN
P04 01 JAPAN
P04 02 MATSURI
P04 03 CHINA
P04 04 Yang Qin
P04 05 Korean4Drm
P04 06 Gamelan
P04 07 JavaGameln
P04 08 BaliGameln
P04 09 Bali&Java
P04 10 Gongs
P04 11 Angklung
P04 12 Bonang
P04 13 Gender
P04 14 Saron
ORCH
P05 01 Vibraphone
P05 02 Glockenspl
P05 03 Xylophone
P05 04 Marimba
P05 05 Bs Marimba
P05 06 TubularBel
P05 07 Timpani
P05 08 Orch Hit
P05 09 LightOrch
P05 10 OrchPerc
P05 11 Aux Perc
DRUMS
P06 01 Standard
P06 02 Jazzbrush
P06 03 Analog
P06 04 TR-808
P06 05 TR-909
P06 06 Studio
P06 07 Rock Stage
P06 08 Swing
P06 09 Brushes
P06 10 Orch Set
P06 11 Mexi-Set
P06 12 Hi-Boy
P06 13 Low&Dry
P06 14 Jazz Mix
P06 15 JzBrush&Bs
P06 16 BluesClub
P06 17 Drum&Horns
P06 18 TechnoGate
P06 19 FlangeDrms
P06 20 JunkyDrums
P06 21 Brush Box
DANCE
P07 01 Clap&Scrch
P07 02 FILTERED
P07 03 Trash Beat
P07 04 LatinHouse
P07 05 Techey
P07 06 TechDance
P07 07 EthniDance
P07 08 Cosmo 21
P07 09 Industrial
P07 10 UndaGround
P07 11 StreetBeat
P07 12 909-2000
P07 13 AlienDance
P07 14 TechNow
P07 15 Sweep 808
P07 16 Revolution
P07 17 Backbeat
P07 18 AmberWater
P07 19 SynthDrums
P07 20 Discotica
P07 21 Dance 6
P07 22 Lock Out
P07 23 DanceMenu1
P07 24 DanceMenu2
SFX
P08 01 PsycoDrama
P08 02 Forest
P08 03 GrandBlue
P08 04 NoiseSonic
P08 05 ArpegPerc
P08 06 CartoonFX
P08 07 Silly FX
P08 08 Rol&FiltMe
P08 09 MetalMania
P08 10 ChaosSoniq
P08 11 SFX Menu 1
P08 12 SFX Menu 2
P08 13 SFX Menu 3
OTHERS
P09 01 Laserwave
P09 02 Heavy Gtr
P09 03 Acous Bass
P09 04 SH101 Bass
P09 05 Flute
P09 06 Syn String
P09 07 Saw Wave
P09 08 Juno Rave
P09 09 Fantasia
P09 10 Thick Pad
P09 11 Calliope
P09 12 Melody-808
LOOPS
P10 01 Latin Loop
P10 02 Samba Loop
P10 03 AfricaLoop
P10 04 IndianLoop
P10 05 Asian Loop
P10 06 FusionLoop
P10 07 Dance Loop
P10 08 Shot & Tap
PRESET PATCHES
LATIN
L01-L05,L07 Bongo Hi x 6
L06, L08 Bongo Lo x 2
L09-L18,
L28-L29 Conga Hi x 12
L19-L27,L30 Conga Lo x 10
L31-L34 Cowbell x 4
L35-L36 Claves x 2
L37-L40 Guiro x 4
L41 Maracas x 1
L42-L44 Shaker x 3
L45-L46 Tambourine x 2
L47-L59 Timbale x 13
L60 Vibra-slap x 1
L61-L62 Steel Drum x 2
L63-L69 Agogo x 7
L70 Cabasa x 1
L71-L78 Cuica x 8
L79-L84 Pandeiro x 6
L85-L89 Surdo x 5
L90-L93 Tamborim x 4
L94-L96 Whistle x 3
L97 Caxixi x 1
L98-l03 Berimbau x 5
l04-l06 Caixa x 3
l07-l08 Rain Stick x 2
l09 SambaBateria x 1
l10-l11 SpaceConga x 2
l12-l13 E.Conga x 2
l14-l25 AnalogPercs x 12
AFRICAN
F01 Shekere x 1
F02-F07 Djembe x 6
F08-F13 Small Djembe x 6
F14-F16 TalkingDrm x 3
F17-F20 Afro Drum x 4
F21 Metal Casta x 1
F22-F31 Pot Drum x 10
F32 Kalimba x 1
F33 Log Drum x 1
F34-F41 Gyilli x 8
F42-F49 Balaphone x 8
F50 Afro Zither x 1
F51 Afro Feet x 1
F52 Afro Stomp x 1
F53-F54 Hand Drum x 2
F55-F57 Mongu x 3
F58 Clapstick x 1
F59 Boomerang x 1
F60 Bamboo x 1
F61 BloomBell x 1
INDIAN
I01 Sarna Bell x 1
I02-I09 Tabla x 8
I10-I14 Baya x 5
I15-I19 Dholak x 5
I20-I23 Madal x 4
I24 Khole x 1
I25-I28 Dhol x 4
I29-I30 Sitar x 2
I31-I32 Santoor x 2
I33-I34 Tambura x 2
I35 Bell Tree x 1
I36-I38 Sagat x 3
I39-I41 Darbukka x 3
I42-I43 Doira x 2
I44-I49 Doholla x 6
I50-I53 Rek x 4
I54 Bendir x 1
I55 Dawul x 1
I56-I57 HmrDlcmr x 2
ASIAN
A01 Biwa x 1
A02 Atarigane x 1
A03 Hyoshigi x 1
A04 Ohkawa x 1
A05-A06 Tsuzumi x 2
A07-A08 Shime Taiko x 2
A09-A10 MatsuriTaiko x 2
A11-A12 Buk x 2
A13 Jang-Gu x 1
A14-A15 Jing x 2
A16-A17 Gengari x 2
A18-A20 Ban Gu x 3
A21-A23 Gu x 3
A24-A25 Tang Gu x 2
A26-A27 Hu Yin Luo x 2
A28 Nao Bo x 1
A29 Xiao Bo x 1
A30 Large TamTam x 1
A31 Large Gong x 1
A32 Small Gong x 1
A33 Bend Gong x 1
A34 Yang Qin x 1
A35-A36 Finger Cym x 2
A37 Rama Cymbal x 1
A38-A40 Chenchen x 3
A41-A43 Bali Cym x 3
A44 Thai Gong x 1
A45-A47 JawsHarp x 3
A48 Bonang x 1
A49 Gender x 1
A50 Saron x 1
A51 Angklung x 1
A52-A53 Gamelan x 2
ORCH
O01 Sleigh Bell x 1
O02 Tree Chimes x 1
O03-O04 Triangle x 2
O05 Castanets x 1
O06-O07 Wood Block x 2
O08 Slapstick x 1
O09-O10 Concert BsDr x 2
O11 Timpani x 1
O12 Perc Hit x 1
O13-O14 Orch Hit x 2
O15 DrmMaj Whstl x 1
O16 Glockenspiel x 1
O17 Vibraphone x 1
O18 Xylophone x 1
O19-O20 Marimba x 2
O21 Bass Marimba x 1
O22 Celesta x 1
O23 Tubular Bell x 1
O24 Glass x 1
O25 Iron Hammer x 1
DRUMS
R01-R12 Kick x 12
R22-R34 Snare x 22
R35-R36 CrossStk x 2
R37-R42 Stick x 6
R43-R56 Tom x 14
R57-R78 Hi-Hat x 22
R79-R96 Cymbal x 18
R97 Wheel Pedal x 1
R98-r01 KickCymbal x 3
r02 Voice Kick x 1
r03 Voice Snare x 1
r04 Voice HiHat x 1
DANCE
D01-D05 Hand Clap x 5
D06-D12 Scratch x 7
D15-D18 Trash x 4
D19-D21 High-Q x 3
D29-D36 Hit x 8
etc x 18
SFX
S23-S26 Shot x 4
S27-S36 Noise x 10
etc x 50
OTHERS
T01-T05 Piano x 5
T06-T07 Organ x 2
T08-T28 Guitar x 21
T29-T41 Bass x 13
T42-T44 Strings x 3
T45-T50 Brass x 6
T51 Tenor sax x 1
T52 Flute x 1
T53-T58 Wave x 6
T59-T68 Synth x 10
HANDSONIC
A “Hands On” Approach to
Electronic Percussion.
The HPD-15 HandSonic®is an electronic percussion multi-pad
designed to be played by hand or finger. Using V-Drums®triggering
technology, this futuristic instrument allows hand percussionists to
play up to 15 sounds naturally without using sticks.
A dynamic pad with
V-Drums technology
Divided into 15 parts, the HPD-15’s ultra-sensitive 10-
inch rubber pad can be used to trigger up to 15 different
sounds using techniques from hard conga slaps to the
light finger touch needed for tabla performances. And
because the main pad supports positional sensing, you
can create timbre changes just by striking different
areas of the pad.
Divided into 15 parts, the HPD-15’s ultra-sensitive 10-
inch rubber pad can be used to trigger up to 15 different
sounds using techniques from hard conga slaps to the
light finger touch needed for tabla performances. And
because the main pad supports positional sensing, you
can create timbre changes just by striking different
areas of the pad.
Perfect for practice or composition, the HPD-15’s 4-part
pattern sequencer provides 99 Preset and User patterns.
And with MIDI In and Out, you can use the HandSonic
as a sound module or as the ultimate controller for
playing into your sequencer. Live performers will
appreciate the ability to add an optional hi-hat
controller and kick trigger, as well as the HPD-15’s
1/4-inch Line input for blending in external sounds.
The HPD-15’s knobs can be used for controlling pitch,
timbre and multi-effects, while dual ribbon controllers
create realistic conga slides and make triggering guiro
sounds more natural. You can even create rolls by
pushing harder on the pads. The D Beam, on the other
hand, uses an infrared light beam for adjusting pitch,
filter cutoff and triggering sounds like a gong or a bell
tone. An optional expression pedal may also be used.
Expressive realtime control
• Maximum Polyphony 64 voices • Instruments Pad Instruments: 600, Backing
Instruments: 54 • Preset Patches 160 • User Patches 80 • Patch Chains 10 chains (32
steps per chain) • Effect Type Reverb, Multi-Effects • Sequencer Preset Patterns : 99, User
Patterns: 99 (Maximum), Tracks: 4, Play Functions: OneShot, Loop, Tap, Resolution: 96 ticks
per quarter note, Recording Method: Real-time • Tempo 20-240 • Display 16
characters, 2 lines (backlit LCD) • Controls Volume Knob, Realtime Modify Knob 1/2/3,
Ribbon L/R, D Beam Controller • Pad 10 inches, 15 sections, Pressure-Sensitive
• Connectors Output Jacks (L/Mono, R), Phones Jack (stereo), Mix In Jack (stereo),
Expression Pedal / Hi-Hat Control Jack, Trigger Input Jack (dual), Foot Switch Jack (dual),
MIDI Connectors (IN, OUT/THRU) • Output Impedance 1k ohms • Power Supply AC
Adaptor (DC 9V) • Current Draw 1000mA • Dimensions 406 (W) x 405 (D) x 98 (H) mm /
16 (W) x 16 (D) x 3-7/8 (H) inches • Weight 2.9 kg / 6 lbs 7 oz (Excluding AC Adaptor)
• Accessories AC Adaptor (ACI/ACB Series), Label
SPECIFICATIONS
REAR VIEW
Loaded with high-quality sounds Handy performance features
Preset Patches & Preset Instruments

Setup Example
PD-9
PD-120
KD-80
KD-7
CY-12R/C
KD-80
KD-7
Setup Example
2.2 m
Stereo 1/4" 2 x 1/4"
PD-9
PD-120
CY-12R/C
Roland Corporation U.S.
5100 S.Eastern Avenue P.O. BOX 910921
Los Angeles, CA 90091-0921
Phone: [phone] Fax: [phone]
Visit us online at www.RolandUS.com
All specifications and appearances are subject to change without notice.
All trademarks are the property of their respective companies.
Printed in Japan Apr. ’03 RAM-3689 C-4 PBL-UPR-N
SPD-S SAMPLING PAD
SPD-20 TOTAL PERCUSSION PAD
SPD-6 PERCUSSION PAD
HPD-15 HANDSONIC
Options
A Monitor Built for Electronic Percussion.
The PM-1 is the perfect monitoring system for Roland’s
SPD-Series and HPD-15 HandSonic. Precisely tuned for
the needs of acoustic and electronic percussionists, the
PM-1’s 60-watt amplifier and 2-way speaker system
sound great on stage or at home. And monitoring is easy,
thanks to a smart angled design that even
accommodates drum stands.
Controls Connectors
*Requires APC-33 Clamp Set.
Extension pads for the SPD-S, SPD-20,
and HPD-15, allowing users to trigger
additional sounds using high-quality
"mesh" or rubber drum heads. PD-120 and
PD-100 pads available in red or purple.
KD-120 kick available in
red or purple. Dynamic crash, ride and hi-hat
cymbals designed to faithfully re-
create acoustic cymbal dimensions,
movements and inertia.
Affordable dual-trigger crash/ride cymbal with natural
"swinging" motion and super-accurate triggering.
*Beater and connection cable included.
*Kick drum pedal not included and
shown only for photography purposes.
*Trigger: 2 (head, rim)
Slant-type stand designed for hand
percussion products like the HPD-15
and SPD-6.
PDS-15 can be slanted
to improve HPD-15's
playability.
An affordable way to play and trigger MIDI modules
and samplers from an acoustic drum set, or expand
the capabilities of an electronic set.
Heavy-duty mounting clamp for use with
the SPD-S/20/6 and the HPD-15.
Personal Monitor Amplifier
PM-1
V-Pads™
PD-120/100/80R/80
V-Kicks
KD-120/80
V-Cymbals™
CY-12R/C, CY-14C,
CY-15R, CY-12H
Dual-Trigger Cymbal Pad
CY-6
Kick Trigger
RT-7K
Trigger MIDI Converter
TMC-6
Snare Trigger
RT-5S
Tom Trigger
RT-3T
Kick Trigger Unit
KD-7
Dual-Trigger Pads
PD-9/7
Single-Trigger Pad
PD-6
Pad Stand
PDS-15
Hi-Hat Control Pedal
FD-7
Pedal Switch
DP-2
Connection Cable
PCS-31
Expression Pedal
EV-5
Stereo Headphone
RH-50
Footswitch
FS-5U
All Purpose Clamp
APC-33
Pads
Pad Stand
Others
Kick Triggers
Acoustic Drum Triggers
Trigger MIDI Converter
Cymbals
Visit us online at www.Roland.com All specifications and appearances are subject to change.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan Apr. '03 RAM-3688 BGE-2 PBL-UPR-N
