Roland BK-5OR User manual

www.roland.com
Drum sounds and Music
Rhythm from Middle East,
Turkey and North Africa.
Standard sounds and
Music Rhythm derived
from BK-5.
Comfortable
user interface
(Graphic LCD and Panel).
Handy playback
of backings directly
from USB Memory.
RAM 4774 RAMRES 826-12 605.00.0254www.roland.com
USB memory. Rear panel. Left panel and LCD display. Right panel and speacker on-board.
BK-5 OR SPECIFICATIONS
Roland
regards
technologies
that make
effective use
of limited energy resources as“Energy Saving
Technology”and promotes development of
environment-conscious electronic musical
instruments that incorporate such technologies
in any of the product categories.
Roland, BOSS, , and VIMA TUNES are either registered trademarks or trademarks of Roland Corporation in the United States and/or
other countries. All specifications and appearances are subject to change without notice. Company names and product names appearing in this
document are registered trademarks or trademarks of their respective owners. It is forbidden by law to make an audio recording, video recording,
copy, or revision of a third party’s copyrighted work (musical work, video work, broadcast, live performance, or other work), whether in whole
or in part, and distribute, sell, lease, perform, or broadcast it without the permission of the copyright owner. Do not use this product for
purposes that could infringe on a copyright held by a third party. We assume no responsibility whatsoever with regard to any infringements of
third-party copyrights arising through your use of this product. e copyright of content in this product (the sound waveform data, style data,
accompaniment patterns, phrase data, audio loops and image data) is reserved by Roland Corporation. Purchasers of this product are permitted to
utilize said content for the creating, performing, recording and distributing original musical works. Purchasers of this product are NOT permitted
to extract said content in original or modified form, for the purpose of distributing recorded medium of said content or making them available
on a computer network.
Display type
Graphic LCD 160 x 160 dots, backlit.
Keyboard
Keyboard 61 velocity sensitive keys.
Sound Source
Max. Polyphony 128 voices (GM2/GS/XG Lite compatible).
Sounds Over 1,100 tones. Over 50 Drum Sets.
Multitimbral parts 3 keyboard parts (UP1, UP2, LWR) + 16 song parts.
Ma ster Tun ing 415.3~466.2 Hz.
Key Control (Transpose) –6~+5 in semitones (for audio/MIDI data).
Tempo change 20~250 BPM for SMF and rhythms.
Part mute functions Track mute: rhythms, smf. Center cancel: mp3, wav, audio input signals.
Effects
Keyboard parts (UP1, UP2, LWR)
Rhythms/SMF section
Reverb: 8 types (selectable via Makeup Tools). Chorus: 8 types (selectable via Makeup Tools). MFX: 84 types for keyboard parts (selectable via
Tone Part MFX). A & B for rhythm and SMF section (selectable via Makeup Tools). Parametric EQ: 6 presets + 1 User memory.
Multi-band compressor: 6 presets + 1 User memory.
Rhythm section
Rhythms Over 250 in 6 “Rhythm” families (localized rhythms for specific areas are included).
Rhythm Composer Internal Rhythm Composer, SMF-to-Rhythm Converter provided as PC application (Windows) on the bundled CD-ROM.
One Touch memories 4 programmable registrations per rhythm.
Rhythm Makeup Tools Instrument-oriented editing.
Songs
Real-time player SMF (Format 0/1), KAR, mp3, WAV, mp3+CDG.
Song chord extractor Automatic chord detection for SMF files.
SMF Makeup tools Instrument-oriented editing.
Oriental tunings
MEMORY buttons 1, 2, 3 (storage of three USER SCALE sets of frequently used settings).
USER SCALE buttons Instant quarter-tone tuning of each naote of a scale (C~B). Adjustable tuning range (–64~+63 cent) for each button.
Tunings can also be saved to Performance memories.
Performance Memories
Performance Lists Unlimited number (storage on USB memory). Over 500 “Music Assistant” memories (internal memory).
5 “Factory Song” memories (internal memory).
Performance memories per List Max. 999.
Search function Quick location of SMF, audio and JPG files on the connected USB memory.
Recording
Media USB Flash memory.
Save format Audio files: WAV (44.1 kHz, 16-bit linear).
Video
Lyrics SMF, mp3/WAV, mp3+CDG.
Slide shows Picture folder linked to songs (recommended resolution: 512 x 384 or 1024 x 768 pixels).
Connectors
Headphone jack x 2 Stereo ¼” phone type.
Audio Input jack Stereo miniature phone type.
Audio Output jacks (R, L/MONO) ¼” phone type.
USB ports USB Computer (type B, reception and transmission of MIDI data). USB Memory (type A, data storage devices).
MIDI conneors In, Out (MIDI Visual Control funion).
Video output jacks RCA-type (CVBS, PAL or NTSC – seleable).
Foot pedal jacks Hold, Switch/Expression (programmable).
General specifications
Speakers 2x 10 cm.
Rated power output 2x 12 W RMS.
Power supply AC adaptor.
Auto Off funion Off, 10min, 30min, 240min.
Dimensions Without music rest: 1044 (W) x 317 (D) x 129 (H) mm. 41-⅛ (W) x 12-½ (D) x 5-⅛ (H) inches.
With music rest: 1044 (W) x 317 (D) x 301 (H) mm. 41-⅛ (W) x 12-½ (D) x 11-⅞ (H) inches.
Weight 7.5 kg; 16 lbs 9 oz (excluding AC adaptor and music rest).
Supplied Accessories
Owner’s Manual, AC adaptor, Power cord (for conneing the AC adaptor), Music rest, CD-ROM (Style Converter 4.0, USB driver).
Options
USB USB flash memory (M-UF-series). *
Pedals DP-series/BOSS FS-5U footswitch. Roland EV-series expression pedal.
*Use USB Flash Memory sold by Roland. We cannot guarantee operation if other produs are used.

Audio Recorder
e BK-5 OR lets you record directly
to a USB memory key. It’s a great way
to listen back and evaluate your
performances, and share your
creations with others.
Scale Tuning Controls
For fast and easy control of scale tunings,
the BK-5 OR is equipped with 12
front-panel buttons to instantly manage
each note of a scale, plus three buttons for
storing/recalling the related settings.
Rhythm Composer
e onboard Rhythm Composer can
instantly add rhythmic backing tracks to
your music. Additional rhythms can be
imported from USB memory.
More than one drum track can be
used for rhythms and SMFs.
USB Accompaniment
Add full backing accompaniment to your
performances directly from USB memory.
e BK-5 OR lets you playback and control
rhythm files, SMFs, MP3s, and WAV files.
A World of
Magical Music
Continuing a long tradition of successful
world-music products, Roland proudly
announces the BK-5 OR, addressing
the sounds of the Middle East as well as
Turkey and North Africa. e BK-5 OR
retains all characteristics and features of
the recently announced BK-5 and adds
newly created sounds and rhythms.
Sounds and
rhythms
e BK-5 OR is loaded with dozens
of expressive and exotic new
instruments, drum sounds, and
rhythms from the Middle East,
Turkey and North Africa regions.
Sounds and rhythms from the Middle East, Turkey, and North Africa
12
scale-tuning buttons with dedicated
scale memories
Instant playback of backing tracks directly from USB memory
A magical
journey through
your musical
world

www.roland.com
