Roland E-600 Operating and maintenance manual

SERVICE NOTES
Issued by RES
First edition
E-600
INTELLIGENT KEYBOARD
E-600
DISASSEMBLY
3,5 x 16 Self Tapping Screw
Cod. J2289131
July, 1999
1
SN00030 K6018353 Printed in Italy (AC00) (AD) Copyright © 1999 by ROLAND CORPORATION
All rights reserved. No parts of this publication may be reproduced in any form whithout the written permission of ROLAND CORPORATION.
TABLE OF CONTENTS Page
SPECIFICATIONS 1
LOCATION OF CONTROLS 2
EXPLODED VIEW 3
WIRING DIAGRAM 4
KEYBOARD PARTS LIST 4
PARTS LIST 5/6
BLOCK DIAGRAM 7
MAIN PCB ASSY 8
CIRCUIT DIAGRAM - MAIN PCB ASSY 9
CIRCUIT DIAGRAM - ESP. SECTION/MAIN PCB ASSY 10
CIRCUIT DIAGRAM - MIC. SECTION/MAIN PCB ASSY 10
CIRCUIT DIAGRAM - LCDC SECTION/MAIN PCB ASSY 10
INVERTER PCB ASSY & CIRCUIT DIAGRAM 11
AMPLIFIER PCB ASSY & CIRCUIT DIAGRAM 11
LCD CONTROL PCB ASSY & CIRCUIT DIAGRAM 12
OUTPUT PCB ASSY 12
CIRCUIT DIAGRAM OUTPUT PCB ASSY 13
CONTROL PCB ASSY 14
CIRCUIT DIAGRAM CONTROL PCB ASSY 15
RIGHT & LEFT CONTACT PCB ASSY w/RUBBER CONTACT & CIRCUIT DIAGRAM 16
TEST MODE 17/21
SPECIFICATIONS
llKeyboard
61 Keys
3 levels touch sensitivity
Modes:
- Whole
- Adjustable Split point
- Layer
- Arranger
- Piano Style Arranger
- Manual Drum/SFX
llSound Source
Conforms to GM/GS
64 voice Polyphony
499 Tones
12 Drum Sets + 1 SFX Set
Footage Organ edit
Transpose (-6, +5)
Master Tuning
llEffects
- Reverb (8 types)
- Chorus (8 types)
- Sympathetic Resonance, Rotary and 40 other types
llVocal Effects
Voice Transformer
Harmonist
Digital Eco
llArranger
133 Styles x 4 types
22 Pianist Styles
Style Converter
Style Composer
Melody Intelligence (24 types)
llComposer
Sequencer: up to 16 tracks
1 song (30.000 notes)
30 Rhythm Pattern types
Graphic Metronome
llStorage
Floppy Disk Drive
Max 99 songs on floppy disk
Max 240.000 notes on floppy disk
User Programs on Floppy Disk (max 99)
Load while playing
llOthers
320 x 128 dot backlit LCD /Touchscreen
Lyrics on display and via MIDI OUT
Help ( English, German, French, Spanish, Japanese)
Educational Games on display
One Touch (Piano, Organ( three types), Arranger)
32 internal User Programs
4 assignable pads
llControllers
Volume slider
Brilliance slider
Balance slider
Reverb slider
Microphone Volume
Alpha dial
Pitch bender & Modulation Lever
llConnectors
Output Jacks (L/Mono, R)
Microphone Jack
Headphone Jack (Stereo)
MIDI IN OUT THRU
Damper, Sostenuto, Soft Jacks
llAmplification
2 x 10 Watt output power (RMS)
Two-way stereo system, in bass reflex boxes
10 cm x 2, 3 cm x 2
llPower supply
Universal switching (AC 100 ÷ 240 V)
llPower consumption
37 W (230 V)
llWeight
14 kg
llDimensions
1150(W) x 410(D)X 140(H) mm
llAccessories
See on page 6.
DISASSEMBLY

2
E-600 July, 1999
LOCATION OF CONTROLS
REAR VIEW

3
E-600
July, 1999
EXPLODED VIEW
No PART NAMES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
J2409102
RIGHT GRILL F/LOUDSPEAKER
61-KEY KEYBOARD ASSY TP/9
22265242
K2248124
7626223001
7711201000
K2248123
22165134
K2248126
01345012
7711202000
K2248148
K2248127
00900901
K2248128
K2418117
VARN. TOP CABINET+SILK.
PROTECTING BOX BASE F/INVERTER
WOOFER SPEAKER D.90 MM
PROTECTING BOX COVER F/INVERTER
INVERTER MODULE CXA-M10AL
LCD CONTROLS PCB ASSY
ANTIDUST F/LCD
ANTIDUST COVER PL30N
CONTROL PCB ASSY
7711210000
7711209000
K3278108
LCD LM320191( ASSYSHARP)
PITCH BENDER “SE” W/CABLE CM52+CONN
LEFT GRILL F/LOUDSPEAKER
RUBBER GUIDE BUSHING
POSITION SENSOR ROS-03-ID
FLOPPY D. DRIVER JU-257 A786P
PART NUMBERS
BRASS BUSHING
21
22
23
SWITCHING POWER SUPPLY SWM-30/02
OUTPUT PCB ASSY
7711204000
7711205000
J240910302
7698701000
MAIN BOARD PCB ASSY
AMPLIFIER PCB ASSY
A
E
D
SELF LOCK.SCREW M3x6 TC TC H6
SELF LOCK.SCREW M3x10 TC TC H6
SELF TAP.SCREW 2,9x10 TCTC
SCREW 2,9x13 TC TC PR TROP
J2289193
J2289102
J2289130
SCREW
J2289186
J2289118
J2289125
J2289131
J2289108
SCREW 3,5x16 TCPR TFR H8 BRUN
SCREW 2,9x16 TC TC PR BRUN
SCREW 2,9x10 TC TC PR TROP
SELF TAP.SCREW 3,5x16 TCTCPRBZ
B
F
H
C
G
7711203000INVERTER PCB ASSY
5
6
9
3
3
8
4
7
1
10
13
14
22
23
16
17
18
19
20
21
11
12
H
D
G
B
D
EF
A
C
A
D
B
C
DC
E
D
H
A
A
F
C
C
2
15

4
E-600 July, 1999
KEYBOARD PARTS LIST
61 KEY TP/9 KEYBOARD ASSY code 7626223001
WIRING DIAGRAM
Ref Code Description
ÀÀ
7711206000 CONTROL WIRING ASSY E-600
ÁÁ
7711207000 BOTTOM WIRING ASSY E-600 NOTE : When you substitute the BOTTOM WIRING ASSY code 7711207000 ,
please replace the:FERRITE CORE VOGT 235 07 857 10 code J2399108 too,
because it does not belong to the BOTTOM WIRING ASSY
ÂÂ7711208000 3P CABLE ASSY (8) -2C P.2 E-600 ÃÃK3468206 4P CABLE (44) -2C D/D E-600
ÄÄ7698713000 3P CABLE ASSY (78) (W/4PC+4PC) ÅÅK3468155 4P CABLE 2R/2N (28) 2C D/R ÆÆK3468154 4P CABLE ASSY (52/58) (W/4PC) ÇÇK3468207 34P FLAT CBL. ASSY (60) -2C+FERR. E-600 ÈÈK3468177 16P FLAT CABLE (56) -2C ÉÉK3468166 16P FLAT CABLE (44) -2C

E-600July, 1999
5
PRELIMINARYPARTS LIST E-600 (117V/230V/230VE/240VA)
MB =Main Board
CB =Control Board
AMP.B=Power Amp. Board
OB =Output Board
IB =Inverter Board
LCDB =LCD Control Board
RCB =Right Contact Board
LCB =Left Contact Board
CASING
7698612000 VARNISHED BOTT. CABINET G-600 / E-600
K2128119 MUSIC REST (BLACK)
K2248123 RIGHT GRILL F/LOUDSPEAKER E-500
K2248124 LEFT GRILL F/LOUDSPEAKER E-500
22208320 MUSIC SCORE HOLDER
#7711209000 VARN. + SILKSCR. TOP CABINET E-600
KNOB BUTTON
A22485303 D-RK KNOB BLK
K2478219 BUTTON MM 17.3X8.3 (BLACK)
K2478218 BUTTON MM 24.7X8.3 (GREY)
K2478220 BUTTON MM 11.7X6.8 (BLACK)
K2478225 BUTTON MM 11.7X6.8 (RED)
K2478226 BUTTON MM 11.7X6.8 (GREY)
22488183 POWER SWITCH KNOB N.001-BLACK
22485192 BLACK KNOB W/WHITE INDICATOR
SWITCH
1312975301 SWITCH EVQ-QSB 05K GR.160 SW1/SW17 onCB
A01013223 ENCODER EVQ-VEM F01-24B EN1 onLCD Control B.
JACK, SOCKET
13449252 JACK SOCKET YKB 21-5006 JK3, JK8 on OB
13449125 JACK SOCKET HLJ0520-01-110 JK1, 2, 5, 6, 7 on OB
13429273 DIN SOCKET 3PZ YKF51-5046 JK4 on OB
DISPLAY UNIT
NNoottee#01124234 LCD LM320191(SHARP) ASSY E-600
DISK DRIVE UNIT
NNootteeJ2409102 FLOPPY D. DRIVER JU-257 A786P
BENDER UNIT
NNoottee#K3278108 PITCH BENDER SE + CABLE(52) E-600
SPEAKER
K2418117 WOOFER SPEAKER D.90 MM
K2418118 TWEETER SPEAKER W/CABLES
KEYBOARD
7626223001 61-KEY KEYBOARD ASSY TP/9
NOTE :For details, refer to KEYBOARD PARTS LIST (Page 4)
POWER SUPPLY UNIT
NNoottee#J240910302 SWITCHING POWER SUPPLY SWM-30/02
WARNING!!! : FOR THIS MODEL DO NOT USE THE FOLLOWING PREVIOUS VERSIONS OF SWITCHING POWER SUPPLY SWM-30:
- SWITCHING POWER SUPPLY SWM-30/00 code J2409103
- SWITCHING POWER SUPPLY SWM-30/01 code J240910301
NOTE : Replacement SWITCHING P.S.SWM-30/02 should be made on a unit basis.
No replacements available for individual parts. Replacement only be a unit.
PCB ASSY
7698701000 AMPLIFIER PCB ASSY E-500
#7711201000 CONTROL PCB ASSY E-600
#7711203000 INVERTER PCB ASSY E-600
#7711202000 LCD CONTROL PCB ASSY E-600
#7711204000 MAIN BOARD PCB ASSY E-600
#7711205000 OUTPUT PCB ASSY E-600
7624504000 RIGHT CONTACT PCB ASSY W/RUBBER
7624505000 LEFT CONTACT PCB ASSY W/RUBBER
IC
00900901 INVERTER MODULE CXA-M10AL on INVERTER Board
15229718RI I.C. 6N 137 PHOTO-COUPLER IC4 on OB
A01562267 I.C. MASK ROM UPD23C32000AGX517 IC33 on MB
A01562278 I.C. MASK ROM UPD23C32000AGX518 IC31 onMB
A01344245 I.C. LHMNOPYL (32M WAVE ROM) IC32 onMB
A01344278 I.C. HD6437034AD72F CPU IC14 onMB
15169550RI I.C. 74 HC138 DIP CMOS IC6 > IC9 on CB
J5159107 I.C. 74 HC574 CMOS IC4 on CB
00232645 I.C. TC7W14F FLATIC22 onMB
J5259102 I.C. 74 HC 273 FLATCMOS IC27 onMB
A15259821 I.C. TC74HC573AF IC30 onMB
A15259864 I.C. TC74HC4052AF IC24 onMB
00343823 I.C. M60205-0601FP CUSTOM IC IC5 onMB
00129278 I.C. SSC1080 FOB CUSTOM IC IC1 onMB
J5259110 I.C. HM62256LFP-7T FLAT SRAM IC62 onMB
J5259120 I.C. HM5118160CJ-6 FLATIC11 onMB
A01126612 I.C. TC514260DJS-60 FLATIC8, IC53 onMB
A00899812 I.C. FLASH LH28F800-NF70 IC38 onMB
15199780 I.C. HD63266FP-64A FDC IC2 onMB
00897078 I.C. TC170C200AF-005 CUSTOM IC IC18 onMB
J5259116 I.C. SED1335F0B LCD CONTR. IC61 onMB
A00892556 I.C. TC170C140AF-003 ESP2 IC51 onMB
15259884 I.C. TC7S08F MOS CMOS IC46 onMB
15259885 I.C. TC7S32F CMOS IC7, 17, 20, 36 onMB
J5169105 I.C. TC7W08F FLATIC6 onMB
15249116 I.C. TC7W00F TE12L CMOS IC15 onMB
15249104 I.C. TC7S04F FLATIC29, 37 onMB
K5258146 I.C. TC74VHC139F FLATIC26 onMB
A15249121 I.C. TC7W04F IC25 onMB
A00232634 I.C. TC7W74F IC66 onMB
A01455312 I.C. TC7WH74FU IC52 onMB
A01560823 I.C. TC74VHC164F IC44 onMB
A01348945 I.C. TC7SH32FU FLATIC57 onMB
15269214 I.C. 74LS05 FLAT TTL IC5 onOB
15219183 I.C. M51953 AL STANDING IC3, 10 onOB
15189210 I.C. BA 5218F OP AMP IC1, 2 onOB
15189186 I.C. UPC 4570C OP AMP IC1 on LCD Control B.
15189250 I.C. M5218 AL STANDING IC1, 2, 3, 10 on CB
15289105 I.C. UPC 4570G OP AMP IC12, 42, 47, 50, on MB // IC6, 8, 9 onOB
J5259112 I.C. PCM69AU DAC RED LINE IC3 on MB
J5189102 I.C. TD 62593 AP DIP IC5 on CB
00458312 I.C. NJM 2360M FLATIC7 on OB
A15289141 I.C. M5223FP-600D IC65 onMB
A01126767 I.C. UDA1309H ADC/DAC IC48 onMB
15289402 I.C. TA 78L05F REGUL.+5V IC4, 49 onMB
J5199101 I.C. TDA 7350 POWER AMP IC6 on AMP.B.
TRANSISTOR
15119155RI TRANSISTOR BC/560-B Q1 on AMP.B.
15119154RI TRANSISTOR BC/549-B Q2 on AMP.B.
15129114 TRANSISTOR 2SC-1815GR Q2, 4 on LCD Control B.
15119113 TRANSISTOR 2SA-1015 GR Q1, 3 on LCD Control B.
15129136 TRANSISTOR 2SC-2878-A/B Q1, 2 onOB
15319101 TRANSISTOR 2SC-2412 Q3, 4, 7, 8 on OB // Q8 on MB
15309101 TRANSISTOR 2SA-1037KR Q5, 6 on OB
15329516 TRANSISTOR DTC-114EK Q7 on MB
15119163 TRANSISTOR RN2227 Q1 > Q11 on CB
00898201 TRANSISTOR RN2421 Q1 on MB
DIODE
15019159RI DIODE 1N-4148 D2 on AMP.B.// D1 > D70 onCB //
D1 > D64 onLCB // D65 > D122 onRCB
15339108 DIODE DA-204K D2 > D6 on OB
00893912 DIODE SFPB-56 CHIP D11 on OB
A01121323 DIODE DA-204U T-106 CHIP DA1 > DA8 on MB
15029320RI LED DIODE TLHG4401 GREEN D76, 96, 97, 98 on CB
15029284RI LED DIODE TLHR4401 RED D71 > D95, D99 > D132 on CB
J5019101 ZENER DIODE BZX55C 4V7 D1 on OB
#01560834 DIODE ZENER 02CZ16-X TE85L D1 on MB
J5019105 DIODE 1N 4002 D1 on AMP.B.
E
SAFETY PRECAUTIONS :
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!When ordering any parts listed in the parts list,please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
CONSIDERATION ON PARTS ORDERING
NOTE:
#The parts marked " #'' are new (Initial Parts).
AThe parts marked " A'' are new (Initial Parts) for RES butalready used by RJA.
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >>Component for EMC.
NNoottee ::Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
!
!

E-600 July, 1999
6
RESISTOR
15399965 RESISTOR ARRAY RCE9A-103-JA RA1, RA4, RA6 > RA12, RA18, 33, 37, 39 on MB
J3919107 RESISTOR ARRAY EXB-V8V-101-JV RA29, 30, 32 on MB
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA13 > RA17, RA19 > RA22, RA27, 31, 38 on MB
J3919109 RESISTOR ARRAY EXB-V8V-470-JV RA23 > RA26, RA28, RA34 > RA36, RA40 > RA42 on MB
13819132RI UNINFL.RES. 100 OHM 0.6W 5% R14 > R21 on CB // R1, 2, 11, 12 on OB
# J3809155 UNINFL.. RESISTOR 2200 0.6W 5% R86, 87 on OB
J3809132 UNINFL.RES. 270 OHM 1/4W R30, 31, on CB // R68, 69 on OB
J3809134 UNINFL.RES. 27 OHM 0.6W 5% R23 on CB
A15229941 TERMISTOR 10KD-5 T1 on Control B.
J3809152 OXIDE RESISTOR 0.22 OHM 1W 5% R64 on OB
POTENTIOMETER
13299227RI TRIM.POT. 22KOHM 5X10 H CERMET P1, P2 on AMP. B.
13279988 ROT.POT. RK09K12A0A2AAc VR1 on OB
00671589 SLIDER POT. NFX-X10 B14 VR2 on CB
00671556 SLIDER POT. NNK-X10-B14 VR1, 4 on CB
00346178 SLIDER POT. RS30111CA VR3 on CB
CAPACITOR
15359780 POLYEST. COND. 1.5N 0805 5% C151 153, 215, 218, 219, 220, 221 on MB
15359776 POL.COND. 390P 0805 5% C49 on OB
01015889 POLYEST. COND. 470P 0805 5% C152, 154, 171, 172 on MB
15359774 POLYEST.COND. 680P 0805 5% C117, 118, 216, 217 on MB // C38 on OB
#00568789 CER CONDENSER ECJIVF 1C224Z C222, 223, 225, 226 on MB
J3629144 ELCTRL.COND. 470UF 16V AXIAL C31 on CB
J3469156 ELECTR. COND. 33U 16V P.5 C32, 33, 34, 45, 51, 53, 54, 55, 58 on OB
13639661RI ELECTRL.COND.-V 2200UF 25V C4, 5 on AMP. B.
J3629103 ELECTRL.COND. 100U 25V P.5 C3, 4, 20, 21, 29, 30, 46 on OB // C1, 2 on AMP.B.
J3629147 ELECTR. COND. 220U 25V P.5 C3, 9, 10 on AMP.B.
J3629133 ELECTROL.COND. 22U 25V P.5 C12 on AMP. B.
J3629135 ELECTRL. COND. 470U 35V P.5 C2 on IB
J3629132 ELECTRL.COND. 100U 50V P.5 C50 on OB
J3629104 ELECTRL.COND. 10U 50V P.5 C59 on OB // C8 on AMP.B.
J5369103 ELECTR. COND. 100U 16V (SMD) C77 on MB
J5369104 ELECTR. COND. 10U 16V (SMD) C160, C275 on MB
# J5369105 ELECTR. COND. 33U 16V (SMD) All on MB
# J5369106 ELECTR. COND. 1U 50V (SMD) C298 on MB
J3629137 ELECTR. COND. 33U 16V H.7 C10, 11, 12, 16, 19, 20, 21, 26, 29, 30 on CB
J3629150 ELECTR.COND. 47U 16V H.7 C1, 4, 5 on LCD Control B.
13649103J0 UNPOL.COND. 10U 16V P.5 C1, 2, 39, 40 on OB // C21, 34 on AMP. B.
INDUCTOR, COIL, FILTER
<<EMI>> 22448240 NOISE SUP. BL02RN2-R62 L3, 4, 5 on OB
<<EMI>> 12449370 NOISE SUP. SBT-0160W L1,2, L7 > L12, 14 on OB
<<EMI>> 12449326 NOISE SUP. SBT-0460 L6 on OB
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1 > FL5 on CB
<<EMI>> 12449380 NOISE SUP. EXC-ELDR25V L1 on CB
<<EMI>> 12449449 INDUCTOR RCH-875-151K L13 on OB
<<EMI>> A01566956 NOISE SUP. N2012ZA202T01 CHIP L23, L24, R176, R177, R78, R79 on MB
<<EMI>> A01455623 NOISE SUP. N2012Z102T01 CHIP L1 > L18 on MB
CRYSTAL, RESONATOR
00894023 QUARTZ 20,000 MHZ MA-406 X2 on MB
00894034 QUARTZ 16,000 MHZ MA-406 X1 on MB
A01560812 OSCILLATOR SG-8002JC-49 X3 on MB
RELAY
12439224RI RELAY DS2YS-12V RL1 on AMP.B.
CONNECTOR
13419677RI 16P FEM. CONNECTOR AMP 1.27 CN1, 2 on MB // CN3 on LCB // CN4 on RCB //
A00897923 CONNECTOR SLP4R-5 CN2 on LCD Control B.
A01454112 CONNECTOR 00 6216 012 100 808 CN3 on LCD Control B.
13369688RI 4P MALE CONN. P 2.5 M CN1, 3 on AMP.B. // CN1 on IB
J3439103 6P MALE CONNECTOR P 2.5 M CN2 on AMP.B.
J3439109 5P MALE CONNECTOR P 2.5 M CN3 on OB
J3439113 7P MALE CONNECTOR P 2.5 M CN2 on OB // CN4, 5 on AMP.B.
J3439121 6P MALE CONNECTOR P.2 M CN20 on MB
J3439122 8P MALE CONNECTOR P.2 M CN5 on CB // CN1 on OB
J3439125 5P MALE CONNECTOR P.2 M CN3 on CB // CN4 on OB // CN14 on MB
J3439151 9P MALE CONNECTOR P.2 M CN2 on CB // CN6 on MB
J3439143 34P MALE CONNECTOR P. 1.27 M CN3 on MB
J3439126 12P MALE CONNECTOR P.2 M CN1 on CB // CN5 on MB
J3429120 3P MALE CONNECTOR P.2 M CN4, 7 on CB // CN4, 7 on LCD Control B. //
CN4, 12 on MB
J3439148 7P MALE CONNECTOR P.2 M CN6 on LCD Control B // CN16 on MB
J3439162 13P MALE CONNECTOR P.2 M CN5 on LCD Control B // CN11 on MB
A13369568 B3B-PH-K-S CONNECTOR CN5 on OB // CN17 on MB
A13369566 B6B-PH-K-S CONNECTOR CN7 on OB // CN21 on MB
A13369503 B7B-PH-K-S CONNECTOR CN8 on OB // CN7 on MB
A13369564 B12B-PH-K-S CONNECTOR CN23 on MB
A13369582 B13B-PH-K-S JST CONNECTOR CN6 on OB
A01349645 S2(4-2.3)B-XH-A CONNECTOR CN2 on IB
WIRING, CABLE
K3468155 4P CABLE 2R/2N (28) 2C D/R See WIRING DIAGRAM on page 4.
K3468154 4P CABLE ASSY (52/58) (W/4PC) 
# K3468206 4P CABLE (44) -2C D/D E-600 
K3468166 16P FLAT CABLE (44) -2C 
K3468177 16P FLAT CABLE (56) -2C 
7698713000 3P CABLE ASSY (78) (W/4PC+4PC) 
# K3468207 34P FLAT CABLE ASSY (60) -2C + FERRITE E-600 
# 7711208000 3P CABLE ASSY (8) -2C P.2 E-600 
# 7711206000 CONTROL WIRING ASSY E-600 
# 7711207000 BOTTOM WIRING ASSY E-600 
NOTE : When you substitute the BOTTOM WIRING ASSY code 7711207000 , please replace the:
FERRITE CORE VOGT 235 07 857 10 code J2399108 too, because it does not belong to the BOTTOM WIRING ASSY
SCREW
J2289101 SELF TAP.SCREW 2.9X 6 TC TC
J2289102 SELF TAP.SCREW 2.9X10 TC TC
J2289125 SCREW 2.9X10 TC TC PR TROP
J2289130 SCREW 2.9X13 TC TC PR TROP
J2289131 SELF TAP.SCREW 3.5X16 TCTCPRBZ
J2289118 SCREW 2.9X16 TC TC PR BRUN
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN
J2289113 NUT 3MA H.3
J2139101 FLAT WASHER I/D 4
J2139102 TOOTHED WASHER I/D 3
22165134 BRASS BUSHING
PACKING
K2638175 RIGHT POLYST. END-SIDE E-500
K2638176 LEFT POLYST. END-SIDE E-500
K2678105 CARTENE ENVELOPE HD 140X57
K2678106 POLYETH.ENVELOPE 4OX55
# K2618211 OUTER PACKING E-600
MISCELLANEOUS
K2168105 SPACER F/LED H.12 HEX.
J2359101 SPACER 3M ART. SJ5012
22265242 RUBBER GUIDE BUSHING
J2159103 DOUBLE ELASTIC PLATE
J2399108 FERRITE CORE VOGT 235 07 857 10
K2248126 ANTIDUST COVER PL30N
# K2248148 ANTIDUST F/LCD E-600
A01345012 POSITION SENSOR ROS-03-ID
K2248127 PROTECTING BOX COVER F/INVERTER
K2248128 PROTECTING BOX BASE F/INVERTER
# K2238125 SILKSCREENED MYLAR E-600
K253810302 FUSE WARNING LABEL
ACCESSORIES
J3439150 MAINS CABLE H05VV+POL.SOCKET (230V)
13499152RI CABLE BS/13/H05VV-F3G0.75-V (230VE)
J3439167 MAINS CABLE SAA/2-H05VV 2X1-C17 (240VA)
J3439128 CABLE 498/3SJT 2X18 AWG-C17 (117V)
# K2378113 STYLE / ACOUSTIC DISK E-600
# 7711211000 VERSION UP DISK E-600
K6018109 MIDI GUIDE
# K6018350 O.MANUAL (E/D/F)* E-600
# K6018351 O.MANUAL (IT/SP/OL)* E-600
# K6018352 MIDI IMPLEMENTATION MANUAL E-600
(E/D/F)* = English/ German/ French
(IT/SP/OL)* = Italian/ Spanish/ Dutch
!
!
!
!

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
7
11
E-600
July, 1999
BLOCK DIAGRAM
1
4
2
5
31
4
2
5
31
4
2
5
3
3 1 2 3 1 2 3 1 2 3 1 2 3 1 2
8 7 3 2 4 5 1 8 7 3 2 4 5 1
1 2
1
2
1
4
2
AB
EN
31
42
XRST
10MHz
20MHz
ADDRESS BUS
DATABUS
CS BUS
MASK
ROM
D[0-15]
A[1-21]
D[0-15] D[0-15]
DRAM FLASH
XCS RAS,CAS
A[0-21] D[0-15]
XRP
XWP
VPP
A[1-19]A[1-10]
XRAS
XLCAS
XUCAS
XCS6
XCS4
XCS2
VPP
CNT
XRST
PA7
PA8
A[0-5,19-21]
D[0-7]
PORT1
XCS4 XCS2
SH GA
CKIN CKOUT
XECS
A[0-13] D[0-15]
SS[0-3]
LS[0-3]
XSSENLLCK
XRST
PD[0-7]
TONE GEN.
XCS XRST
CK
X2
XTAL
WA WD
D XCS
EA ED
ADD ADD I/O R,C
KEYBOARD
3.5"
FDD
FDD BUS
IC31 IC11 IC38
XRST PB0
XRST CLK XCS
A0,1
D[0-7]
KEY
SCAN
FDC
D[0-7]
A0
LCD
CNTR
VD
VIDEO
SRAM
AD
X1
XTAL
A0,1
D[0-7]
16MHz
20MHz
IC2
IC1
Q1
IC5
SH-uC
WAVE
ROMs
EFFECT
DRAM
IC8
IC32,IC33
OUTP1
BCKC
SDOC
CK
X3
PWM1
VA
IC61
320X240
DECODER DECODER
LATCH
DRIVER
DRIVER
IC6,IC7
IC8,IC9
Q1-Q11
IC4,IC5
DAMP
SWITCH
SOST SOFT
SWITCH SWITCH PHONES L/MR
OUTPUT
MIDI
IN OUT THRU
BUFFER BUFFER
SQLC SQLC
Q2 Q1
RXD0 TXD0 RXD1 TXD1
BUFFER
AN2,3,4,5
IC1
BUFFER
RESET MUTING SQUELCH
CONTROL
PEDALS
IC3 IC10 Q3,Q4,Q5
IC4 IC5
INVERTER
INVERTER BOARD
LCD
CONTRAST
CONTROL
IC65,Q7,Q8
IC62
IC14
IC18
MATRIX
SWITCH
LED
MATRIX
XXPCS0,1 RAS-CAS
XCS
XCS
OUTPUT BOARD
[0-8]
MAIN BOARD
BCKB
XCS
XRES
OSC1
ESP
A[0-13] D[0-7] XCS
49.152MHz
ADD I/O R,C
ESP
DRAM
IC53
SDIA[0..5]
SDOA[0..5]TRR[0..5]
TRS[0..5]
IC51
ED R-CAS
:2
IC52
OSC
ADDABCKLRCKMCK EA
XRST
IC48
IC47IC50
BA VOL
I/V
DAC
I/V LPF
IC3
LPF
MIKE LEVEL
MIKE_INPUT
BUFFER
IC6
MIXER
IC2
BRILLIANCE
BUFF.
IC3
BUFF.
+5V FLOPPY
+5V DIG
VR4
VOLUME
MODULATION
-12V ANG
CONTROL
CONTROL
&
+12V ANG
POWER SWITCH
+17V POW
REV-BAL
BENDER
CONTROL BOARD
+5V LCD AC INLET
POWER SUPPLY
SWITCHING
CONTROL
IC12
AN0 AN7
Y0 Y1 X0
IC24
AN6
MUX
AN1
IC42
TOUCH
CONTROL
ENCA
ENCB
IC1,Q1,2,3,4
LCD CONTROL BOARD
BUFFER
VR1
VR2,VR3
IC10
IC1IC2
IC8,IC9
+5V +27V
IC7
STEP_UP
A/D&D/A
VOR
ADDABCKWSSYCK
DRIVER
SPEAKER L
AMP
POW. AMPLIFIER BOARD
L
RELAY
RELAY
SPEAKER R
TWETEER R
R
IC6
AMP
TWETEER L
Q1,Q2
PRE
LPF
EMPHASIS
ENCODER

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
8
11
E-600 July, 1999
MAIN PCB ASSY ASSY 7711204000
E
View from component side View from solder side

9
E-600
July, 1999
CIRCUIT DIAGRAM (MAIN PCB ASSY)
12
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
V
W
X
Y
Z
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
V
W
X
Y
Z
12345678910 1213141516171819202122232425262728293011 31 32 33 34 35 36 37 38 39 40 41 42 43345678910 1213141516171819202122232425262728293011 31 32 33 34 35 36 37 38 39 40 41 42 43
MAIN/MIC BLOCK
DA
AD
LRCK
BCK
MCK
MICIN MICOUTR
MICOUTL
MAIN/LCDC BLOCK
D[0..15]A[0..21]
XWRL
XRD
XVGA
10MHz
XSCL
LP
YD
DISP_ON
LCD27V
DISP_CONT
GPWM0
XLCDINT
LCDVEE
XRST-A
TEMPCNT1
TEMPCNT2
XD[0..3]
MAIN/ BLOCKESP
SDOA[0..5]
SYO
XESPINT0
D[0..15]
XRD
XESP
DA
AD
LRCK
BCK
MCK
BCKA
XWRESP
A[0..21]
ESPCK
XRST-A
SDIA[0..5]
IC2
HD63266F
VCC1
25 VCC2 44 VCC3 45 VCC4 46
VSS1 10 VSS2 11 VSS3 23 VSS4 41 VSS5 42 VSS6 49 VSS7 54 VSS8 59 VSS9 64
8"/5"8"/
1
IFS 28
SFORM 29
RS1
9
RS0
8
D7
19
D6
18
D5
17
D4
16
D3
15
D2
14
D1
13
D0
12
RESET
3
RD
4
WR
5
CS
6
IRQ
21
DREQ
20
DACK
7
DEND
22
EXTAL2
37
XTAL2
36
EXTAL1
40
XTAL1
39
1/2EX1
24
XTALSEL
2NUM2 27
NUM1 26
RDATA 35
INDEX 34
TRK0 33
WPRT 32
READY 31
INP 30
WDATA 48
WGATE 47
STEP 50
HDIR 51
HLOAD 52
HSEL 53
DS3 58
DS2 57
DS1 56
DS0 55
MON3 63
MON2 62
MON1 61
MON0 60
NC 38
NC 43
RA4
10K
12
3
4
5
6
7
8
9
RA6
10K
12
3
4
5
6
7
8
9
RA7
10K
12
3
4
5
6
7
8
9
RA11
10K
12
3
4
5
6
7
8
9
IC4
TA78L05F
IN
3OUT 1
COM 2
CN3
PS-34PE-D4T1-B1-K
DGND
1
HDSTATUS
2
NC
3
INUSE
4
DGND
5
DSEL3
6
DGND
7
INDEX
8
DGND
9
DSEL0
10
DGND
11
DSEL1
12
DGND
13
DSEL2
14
DGND
15
MO
16
DGND
17
DIRSEL
18
DGND
19
STEP
20
DGND
21
WRDATA
22
DGND
23
WRGATE
24
DGND
25
TRACK00
26
DGND
27
WRPRTCT
28
DGND
29
RDDATA
30
DGND
31
SIDESEL
32
DGND
33
READY
34
RA14 10K
18
27
36
45
RA15 10K
18
27
36
45
RA16
10K
18
27
36
45
CN5
53014-1210
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
CN6
53014-0910
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
CN8
NIU
11
22
33
44
55
66
77
88
99
X1
MA406-16.000MHZ
14
RA17
10K
1 8
27
36
45
RA18
10K
12
3
4
5
6
7
8
9
RA19
10K
18
27
36
45
RA20
10K
18
27
36
45
RA21
10K
18
27
36
45
RA22
10K
18
27
36
45
R2 1K
R3 1K
R4 1K
R5 1K
R6 1K
R13
NIU
R20
10K
R26 NIU
R30 NIU
R36
33K
R37
6.8K
R43
6.8K
R48
6.8K
R50 10K
C26
33/16
21
C27
33/16
21
R57 NIU
R59 NIU
R60 0R0
R61
NIU
C33
NIU
C35
22P
C36
22P
C37
22P
C38
22P
C39
22P
C40
22P
C41
22P
C42
22P
C43
22P
C44
22P
C45
22P
C46
22P
C47
22P
C48
22P
C49
22P
C50
22P
C51
22P
C52
22P
C55 100P
C56 100P
C57 100P
C58 100P
C59 100P
C60 100P
C61 100P
C62 100P
C63 100P
C64 100P
C65 100P
C66 100P
C67 100P
C68 100P
C69 100P
C70 100P
C71 100P
C72 100P
C73 100P
C74 100P
C75 100P
C76 100P
C78 NIU
C79 NIU
C80 NIU
C81 NIU
C82
33/16
21
C84
33/16
21
C85
33/16
21
C86
33/16
21
C88
33/16
21
C89
33/16
21
C91
33/16
21
R72
0R0
R73
NIU
C94
0.1
C95
0.1
C96
0.1
R74
0R0
C100
12P
C101
12P
C107
NIU
C109
NIU
C110
NIU
C111
NIU
C112
NIU
C113
NIU
C114
NIU
C115
NIU
C116
NIU
C117
680P
C118
680P
IC12A
UPC4570G
2
3
1
+
-
RA24 47
18
27
36
45
RA25 47
18
27
36
45
RA26 47
18
27
36
45
IC15C
TC7W00F
84
RA27 10K
18
27
36
4
5
X2
MA406-20.000MHZ
14
R77
0R0
R78
0R0
R79
0R0
C130
33/16
21
IC18
RA01-005
VDD
20 VDD 40 VDD 60 VDD 80 VDD
100 VDD 120 VDD 140 VDD 160
VSS 1 VSS 10 VSS 30 VSS 41 VSS 50 VSS 59 VSS 70 VSS 81 VSS 90 VSS 110 VSS 121 VSS 130
VSS 139 VSS 150
CA11
19
CA10
17
CA9
18
CA8
21
CA7
23
CA6
25
CA5
26
CA4
27
CA3
28
CA2
29
CA1
31
CA0
32
CD12
47
CD11
51
CD10
46
CD9
42
CD8
36
CD7
35
CD6
39
CD5
45
CD4
49
CD3
48
CD2
44
CD1
38
CD0
34
CS
53
DS( )RDDS(
16
EA8
133
EA7
135
EA6
137
EA5
141
EA4
143
EA3
142
EA2
138
EA1
136
EA0
134
WA23 61
WA22 62
WA21 64
WA20 63
WA19 65
WA18 66
WA17 87
WA16 84
WA15 82
WA14 78
WA13 76
WA12 74
WA11 72
WA10 69
WA9 67
WA8 68
WA7 71
WA6 73
WA5 75
WA4 77
WA3 79
WA2 83
WA1 86
WA0 85
WD14 95
WD13 99
WD12 104
WD11 107
WD10 103
WD9 98
WD8 94
WD7 93
WD6 97
WD5 102
WD4 106
WD3 105
WD2 101
WD1 96
WD0 92
WCS5 114
WCS4 113
WCS3 112
WCS2 111
WCS1 109
WCS0 108
CA13
24
CA12
22
CD15
33
CD14
37
CD13
43
WREQ 117
WACK 118
WD15 91
WCS7 116
WCS6 115
WOE1 88
WOE0 89
OUTP2 11
OUTP1 9
OUTP0 12
WCKC 8
BCKC 7
SDOD 6
SDOC 5
WCKB 4
BCKB 3
SDIB 2
SDOB 159
WCKA 158
BCKA 157
SDIA5 151
SDIA4 152
SDIA3 153
SDIA2 154
SDIA1 155
SDIA0 156
SDOA5 144
SDOA4 145
SDOA3 146
SDOA2 147
SDOA1 148
SDOA0 149
AS
55
RW( )WRRW(
15
WAIT
52
INT
56
CK
58
RESET
54
ED7
119
ED6
122
ED5
123
ED4
124
ED3
125
ED2
126
ED1
127
RAS
131
CAS
132
EWE
129
SYO
13
SYI
14
TEST
57
ED0
128
C152
470P
RA28 47
18
27
36
45
IC22B
TC7W14F
35
IC22C
TC7W14F
62
RA31
10K
18
27
36
45
IC15B
TC7W00F
5
6
3
IC15A
TC7W00F
1
2
7
R97 0R0
R98 0R0
R99 0R0
R103
4.7K
R107
10K
R125
0R0
R126 0R0
R127 0R0
C180
0.1
C181
0.1
R130 NIU
R131 NIU
R132 NIU
RA33
10K
12
3
4
5
6
7
8
9
R144 NIU
R149 NIU
CN20
53014-0610
1
1
2
2
3
3
4
4
5
5
6
6
C192
33/16
21
C193
33/16
21
IC12C
UPC4570G
84
+
-
IC22D
TC7W14F
84
RA37
10K
12
3
4
5
6
7
8
9
R166
10K
IC12B
UPC4570G
6
5
7
+
-
IC42C
UPC4570G
84
+
-
R69
0R0
C147 0.1
C139
33/16
21
C134
33/16
21
R80 0R0
R104
4.7K
C179
0.1
C177
0.1
IC27
TC74HC273F
D8
18
D7
17
D6
14
D5
13
D4
8
D3
7
D2
4
D1
3
CR
1
CK
11
Q8 19
Q7 16
Q6 15
Q5 12
Q4 9
Q3 6
Q2 5
Q1 2
VCC
20 GND 10
IC22A
TC7W14F
17
C191
33/16 21
C190
0.1
RA39
10K
12
3
4
5
6
7
8
9
RA29
100
18
27
36
45
RA30
100
18
27
36
45
CN11
53014-1310
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
R140 NIU
R141 0R0
IC32
LHMNOPYL
A20
44
A19
43
A18
2
A17
3
A16
34
A15
35
A14
36
A13
37
A12
38
A11
39
A10
40
A9
41
A8
42
A7
4
A6
5
A5
6
A4
7
A3
8
A2
9
A1
10
A0
11
*/D15 31
BYTE
33
CE
12
OE
14
D14 29
D13 27
D12 25
D11 22
D10 20
D9 18
D8 16
D7 30
D6 28
D5 26
D4 24
D3 21
D2 19
D1 17
D0 15
A21
1
VCC 23
VSS 13
VSS 32
R27 NIU
R152
NIU
R134
NIU
R145 0R0
R156
10K
R90
NIU
C178
0.1
IC25B
TC7W04F
35
IC25C
TC7W04F
62
IC25A
TC7W04F
17
R136
NIU
C164
0.01
C163
0.01
C2
100P
C1
100P
C166
100P
C13
100P
C6
100P
C5
100P
C4
100P
C3
100P
DA1
DA204U
21
3
DA2
DA204U
21
3
DA3
DA204U
21
3
DA4
DA204U
21
3
C158
0.1
R135
0R0
CN17
53253-0310
1
1
2
2
3
3
CN23
53253-1210
1
12
23
34
45
56
67
78
89
910
10 11
11 12
12
R139
NIU
R45
5.6K
R46
5.6K
R39
5.6K
R40
5.6K
R34
5.6K
R33
5.6K
CN21
53253-0610
1
1
2
2
3
3
4
4
5
5
6
6
R403
10K
R404
10K
R405
10K
C260 1.0
C10
1.0
C9
1.0
C77
100/6.3
21
C8
1.0
C34
0.1
C90
0.1
C92
0.1
C87
0.1
C20
0.1
C29
0.1
C30
0.1
C28
0.1
C168
0.1
C131
1.0 C132
1.0
C133 1.0
C135
1.0
C136
1.0
C137 1.0
C266
33/16
21
C267
33/16
21
C273
33/16
21
C275
10/16
21
C198
33/16
21
C199
33/16
21
C31
0.1
C15
0.1
C140
1.0 C141
1.0
C142
1.0
R86
10K
C185
120P
C169
120P
C167
120P
C161
NIU
C155
NIU
C128
NIU
C127
NIU
C195
NIU
C197
NIU
C196
NIU
C21
NIU
CN12
53014-0310
1
12
23
3
C279
100P
C282
100P
C238
NIU
C230
NIU
C231
NIU
C276
100P
IC25D
TC7W04F
84
CN9
NIU
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
37
37
38
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
46
46
47
47
48
48
49
49
50
50
CN10
NIU
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
35
35
36
36
37
37
38
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
46
46
47
47
48
48
49
49
50
50
CN19
NIU
1
1
2
2
3
3
4
4
C160
10/16
21
C23
1.0
C19
0.1
C126
NIU
C104
1.0
C105
1.0
C143 1.0
C144 1.0
C145 1.0
C146 1.0
C148 1.0
C149 1.0
C150
1.0
C98
12P
C99
12P
C188
NIU
C189
NIU
IC9
NIU
A8
26
A7
25
A6
24
A5
23
A4
22
A3
19
A2
18
A1
17
A0
16
NC
11
NC
12
NC
15
NC
30
RAS
14
UCAS
28
LCAS
29
WRITE
13
OE
27
I/O16 39
I/O15 38
I/O14 37
I/O13 36
I/O12 34
I/O11 33
I/O10 32
I/O9 31
I/O8 10
I/O7 9
I/O6 8
I/O5 7
I/O4 5
I/O3 4
I/O2 3
I/O1 2
VCC 1
VCC 6
VCC 20
VSS 21
VSS 35
VSS 40
IC11
HM5118160AJ-6
A11
15
A10
16
A9
28
A8
27
A7
26
A6
25
A5
24
A4
23
A3
20
A2
19
A1
18
A0
17
NC
11
NC
12
NC
32
RAS
14
UCAS
30
LCAS
31
WE
13
OE
29
I/O16 41
I/O15 40
I/O14 39
I/O13 38
I/O12 36
I/O11 35
I/O10 34
I/O9 33
I/O8 10
I/O7 9
I/O6 8
I/O5 7
I/O4 5
I/O3 4
I/O2 3
I/O1 2
VCC 1
VCC 6
VCC 21
VSS 22
VSS 37
VSS 42
IC30
TC74HC573F
D7 9
D6 8
D5 7
D4 6
D3 5
D2 4
D1 3
D0 2
OE 1
LE 11
Q7
12
Q6
13
Q5
14
Q4
15
Q3
16
Q2
17
Q1
18
Q0
19
VCC
20 GND 10
IC31 uPD23C32000AGX-518
A20
44
A19
43
A18
2
A17
3
A16
34
A15
35
A14
36
A13
37
A12
38
A11
39
A10
40
A9
41
A8
42
A7
4
A6
5
A5
6
A4
7
A3
8
A2
9
A1
10
A0
11
*/D15 31
BYTE
33
CE
12
OE
14
D14 29
D13 27
D12 25
D11 22
D10 20
D9 18
D8 16
D7 30
D6 28
D5 26
D4 24
D3 21
D2 19
D1 17
D0 15
A21
1
VCC 23
VSS 13
VSS 32
IC33
uPD23C32000AGX-517
A20
44
A19
43
A18
2
A17
3
A16
34
A15
35
A14
36
A13
37
A12
38
A11
39
A10
40
A9
41
A8
42
A7
4
A6
5
A5
6
A4
7
A3
8
A2
9
A1
10
A0
11
*/D15 31
BYTE
33
CE
12
OE
14
D14 29
D13 27
D12 25
D11 22
D10 20
D9 18
D8 16
D7 30
D6 28
D5 26
D4 24
D3 21
D2 19
D1 17
D0 15
A21
1
VCC 23
VSS 13
VSS 32
IC34A NIU
1
2
7
IC34B NIU
5
6
3
L9 N2012Z102
L8 N2012Z102
L7 N2012Z102
L6 N2012Z102
L5 N2012Z102
L4 N2012Z102
L3 N2012Z102
L2 N2012Z102
L1 N2012Z102
L11 N2012Z102
L12 N2012Z102
L10 N2012Z102
L13 N2012Z102
L14 N2012Z102
L15 N2012Z102
L16 N2012Z102
L17 N2012Z102
L18 N2012Z102
L23
N2012ZA202
L24
N2012ZA202
R84 100
R85 100
RA40
47
18
27
36
45
RA36
47
18
27
36
45
RA35
47
18
27
36
45
RA34
47
18
27
36
45
R52 100
R53 100
R54 100
R55 100
R58 NIU
R129 0R0
R128 NIU
R133 NIU
IC40
NIU
A20
4
A19
5
A18
6
A17
7
A16
8
A15
10
A14
11
A13
12
A12
13
A11
17
A10
18
A9
19
A8
20
A7
22
A6
23
A5
24
A4
25
A3
26
A2
27
A1
28
A0
32
RY/BYRY/
53
CE1
2
CE0
14
WE
55
OE
54
WP
56
BYTE
31
RP
16
3/53/
1
DQ15 52
DQ14 50
DQ13 47
DQ12 45
DQ11 41
DQ10 39
DQ9 36
DQ8 34
DQ7 51
DQ6 49
DQ5 46
DQ4 44
DQ3 40
DQ2 38
DQ1 35
DQ0 33
NC 3
NC 29
NC 30
VPP 15
VCC 9
VCC 37
VCC 43
VSS 21
VSS 42
VSS 48
IC43
NIU
A20
4
A19
5
A18
6
A17
7
A16
8
A15
10
A14
11
A13
12
A12
13
A11
17
A10
18
A9
19
A8
20
A7
22
A6
23
A5
24
A4
25
A3
26
A2
27
A1
28
A0
32
RY/BYRY/
53
CE1
2
CE0
14
WE
55
OE
54
WP
56
BYTE
31
RP
16
3/53/
1
DQ15 52
DQ14 50
DQ13 47
DQ12 45
DQ11 41
DQ10 39
DQ9 36
DQ8 34
DQ7 51
DQ6 49
DQ5 46
DQ4 44
DQ3 40
DQ2 38
DQ1 35
DQ0 33
NC 3
NC 29
NC 30
VPP 15
VCC 9
VCC 37
VCC 43
VSS 21
VSS 42
VSS 48
IC8
TC514260DJS-60
A8 26
A7 25
A6 24
A5 23
A4 22
A3 19
A2 18
A1 17
A0 16
NC 11
NC 12
NC 15
NC 30
RAS 14
UCAS 28
LCAS 29
WRITE 13
OE 27
I/O16
39
I/O15
38
I/O14
37
I/O13
36
I/O12
34
I/O11
33
I/O10
32
I/O9
31
I/O8
10
I/O7
9
I/O6
8
I/O5
7
I/O4
5
I/O3
4
I/O2
3
I/O1
2
VCC
1
VCC
6
VCC
20
VSS
21
VSS
35
VSS
40
C263
33/16
21
C264
33/16
21
C270
33/16
21
CN1
AMPC1.2716P
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
CN2
AMPC1.2716P
3
4
5
6
7
8
2
1
9
20
19
18
17
16
15
14
13
12
1110
RA41
47
18
27
36
45
IC26C
TC74HC139AF
VCC
16
GND 8
C176 0.1
IC10
NIU
A8
26
A7
25
A6
24
A5
23
A4
22
A3
19
A2
18
A1
17
A0
16
NC
11
NC
12
NC
15
NC
30
RAS
14
UCAS
28
LCAS
29
WRITE
13
OE
27
I/O16 39
I/O15 38
I/O14 37
I/O13 36
I/O12 34
I/O11 33
I/O10 32
I/O9 31
I/O8 10
I/O7 9
I/O6 8
I/O5 7
I/O4 5
I/O3 4
I/O2 3
I/O1 2
VCC 1
VCC 6
VCC 20
VSS 21
VSS 35
VSS 40
RA13
10K 1
8
2
7
3
6
4
5
IC14
HD6437034AD72F
VPP
77
VCC
15
VCC
43
VCC
70
VCC
75
VCC
83
VSS 3 VSS 12 VSS 22 VSS 31 VSS 40 VSS 52 VSS 61 VSS 72 VSS 96
CS0
48
PB4/TP4/TIOCA4
102
PB3/TP3/TIOCB3
101
PB2/TP2/TIOCA3
100
PB1/TP1/TIOCB2
98
PC7/AN7
95
PC6/AN6
94
PC5/AN5
93
PC1/AN1
88
PC0/AN0
87
PB8/TP8/RXD0 107
PB9/TP9/TXD0 108
PB10/TP10/RXD1 109
PB11/TP11/TXD1 110
A21 47
A20 46
A19 45
A18 44
A17 42
A16 41
A15 39
A14 38
A13 37
A12 36
A11 35
A10 34
A9 33
A8 32
A7 30
A6 29
A5 28
A4 27
A3 26
A2 25
A1 24
A0( )HBSA0( 23
AD15 21
AD14 20
AD13 19
AD12 18
AD11 17
AD10 16
AD9 14
AD8 13
AD7 11
AD6 10
AD5 9
AD4 8
AD3 7
AD2 6
AD1 5
AD0 4
NMI
76
PB0/TP0/TIOCA2
97
PC4/AN4
92
PC3/AN3
90
PC2/AN2
89
AVREF
86
AVSS
91
IREQ7/TP15
2
IREQ6/TP14
1
IREQ5/TP13/SCK1
112
IREQ4/TP12/SCK0
111
IREQ3DREQ1/
69
IREQ0DACK0/
66 IREQ1DREQ0/
67 IREQ2DACK1/
68
PA11/TIOCB1 65
PA10/TIOCA1 64
VSS 106
RESET 79
EXTAL
73
XTAL
74
CK
71
WDTOVF 78
VCC
84
VCC
99
CS7WAIT/
56
CS6
55 MD2 82
MD1 81
CS5RAS/
54
CS4
53 MD0 80
CS3CASL/
51
CS2
50
CS1CASH/
49
PA8/BREQPA8/
62
PA7/BACKPA7/60
RD
59
PA5/WRHPA5/
58
WRL
57
PA9/ /PA9/IREQOUTPA9/ AHPA9/
63
AVCC
85
PB7/TOCXB4
105
PB6/TOCXA4
104
PB5/TP5/TIOCB4
103
Q1
RN2421
1
23
R407
NIU
C265
NIU
R11
100
R25 NIU
C183
0.1
C175
0.1
DA7
DA204U
21
3
CN14
53014-0510
11
22
33
44
55
R105
4.7K
R95
100
IC13B
NIU
VCC
8
GND 4
R161
100
DA6
DA204U
21
3
C170
1.0
RA32
100
18
27
36
45
IC13A
NIU
D
2
CK
1
Q5
Q3
PR
7CR 6
DA5
DA204U
21
3
IC45E
NIU
14 7
R101
4.7K
IC45A NIU
1
2
3
C240
0.1
IC39
NIU
A20
4
A19
5
A18
6
A17
7
A16
8
A15
10
A14
11
A13
12
A12
13
A11
17
A10
18
A9
19
A8
20
A7
22
A6
23
A5
24
A4
25
A3
26
A2
27
A1
28
A0
32
RY/BYRY/
53
CE1
2
CE0
14
WE
55
OE
54
WP
56
BYTE
31
RP
16
3/53/
1
DQ15 52
DQ14 50
DQ13 47
DQ12 45
DQ11 41
DQ10 39
DQ9 36
DQ8 34
DQ7 51
DQ6 49
DQ5 46
DQ4 44
DQ3 40
DQ2 38
DQ1 35
DQ0 33
NC 3
NC 29
NC 30
VPP 15
VCC 9
VCC 37
VCC 43
VSS 21
VSS 42
VSS 48
C121 1.0
R19
4.7K
R10
100
IC26B
TC74HC139AF
B
13
A
14
G
15
Y3 9
Y2 10
Y1 11
Y0 12
R102
4.7K DA8
DA204U
21
3
RA42
47
18
27
36
45
R18
4.7K
R106
4.7K
R21
100
R68 NIU
IC21
NIU
24
53
RA1
10K
12
3
4
5
6
7
8
9
IC26A
TC74HC139AF
B
3
A
2
G
1
Y3 7
Y2 6
Y1 5
Y0 4
R22
100
R138 NIU
C120 1.0
C186
0.1
C248
0.1
CN16
53014-0710
11
22
33
44
55
66
77
R56 47
R172 NIU
R160
4.7K
R142
NIU
R137 NIU
R1
1.5K
C119
NIU
C165
NIU
C187
NIU
C122 1.0
C123 1.0
C124 1.0
C125 1.0
R406
4.7K
RA10
10K
12
3
4
5
6
7
8
9
RA9
10K
12
3
4
5
6
7
8
9
RA8
10K
12
3
4
5
6
7
8
9
R110
10K
IC45D NIU
12
13
11
IC45B NIU
4
5
6
C129
0.1
R24
10K
R23
10K
IC38
LH28F800SUT-70
A19
5
A18
6
A17
7
A16
8
A15
10
A14
11
A13
12
A12
13
A11
17
A10
18
A9
19
A8
20
A7
22
A6
23
A5
24
A4
25
A3
26
A2
27
A1
28
A0
32
RY/BYRY/
53
CE1
2
CE0
14
WE
55
OE
54
WP
56
BYTE
31
RP
16
3/53/
1
DQ15 52
DQ14 50
DQ13 47
DQ12 45
DQ11 41
DQ10 39
DQ9 36
DQ8 34
DQ7 51
DQ6 49
DQ5 46
DQ4 44
DQ3 40
DQ2 38
DQ1 35
DQ0 33
NC 3
NC 4
NC 29
NC 30
VPP 15
VCC 9
VCC 37
VCC 43
VSS 21
VSS 42
VSS 48
IC45C NIU
9
10
8
RA23 47
18
27
36
45 R159
NIU
R96
10K
R158
10K
R143
10K
R65
47
R70
0R0
RA12
10K
12
3
4
5
6
7
8
9
R155
10K
C157
0.1
C156
0.1
R71
100
R93
10K
R154
10K
R94 100
R91
NIU
C93
0.1
R89
NIU
R92
NIU
C14
0.01
IC5
M60205-0601FP
VDD
2
VDD
29
VDD
52
VDD
79
VSS 1 VSS 28 VSS 33 VSS 40 VSS 53 VSS 80
MIDIIN 6
WRHO 4
WRLO 5
WAITIN 25
PORT7 66
PORT6 65
PORT5 64
PORT4 63
PORT3 62
PORT2 61
PORT1 60
PORT0 59
PWM2 3
PWM1 67
ENCB 69
ENCA 68
SS3 74
SS2 73
SS1 72
SS0 71
LS3 78
LS2 77
LS1 76
LS0 75
SSEN 70
LLCK 81
PD7 89
PD6 88
PD5 87
PD4 86
PD3 85
PD2 84
PD1 83
PD0 82
RS/CD 90
R/WR/ 91
LE/RDLE/ 92
LCD7 100
LCD6 99
LCD5 98
LCD4 97
LCD3 96
LCD2 95
LCD1 94
LCD0 93
A21
23
A20
22
A19
21
A5
20
A4
19
A3
18
A2
17
A1
16
A0
15
D7
14
D6
13
D5
12
D4
11
D3
10
D2
9
D1
8
D0
7
XRD
34
XWRH
35
XWRL
36
XDREQ
31
XDACK
32
WAITOUT
37
CS6
41
CS4
39
CS2
38
XIREQ
24
ECS11
55
ECS10
54
ECS9
51
ECS8
50
ECS7
49
ECS6
48
ECS5
47
ECS4
46
ECS3
45
ECS2
44
ECS1
43
ECS0
42
EXTINT2
58
EXTINT1
57
EXTINT0
56
CLKIN
27
CLKOUT
30
RESET
26
R122
NIU
R81
10K
R49
10K
IC35 NIU
24
53
R14
10K
MAIN/ BLOCKOSD
XWRL
D[0..15]
XOSD1
XOSD2
VIDEOIN
VIDEOOUT
LINESELECT
XRST-A
IC1
SSC1080
VDD
7
VDD
33
VSS 20 VSS 46
SC10
24
PR10
23
SC9
22
PR9
21
SC8
19
PR8
18
SC7
17
PR7
16
SC6
15
PR6
14
SC5
13
PR5
12
SC4
11
PR4
10
SC3
9
PR3
8
SC2
6
PR2
5
SC1
4
PR1
3
SC0
2
PR0
1
T7
31
T6
30
T5
29
T4
28
T3
27
T2
26
T1
25
T0
32
CLK 49
A1 48
A0 47
D7 44
D6 43
D5 42
D4 41
D3 40
D2 39
D1 38
D0 37
INT 34
RD 36
WR 35
CS 45
RESET 50
TEST1 51
TEST2 52
R157
NIU
C18
0.01 C54
0.01
R115
10K
R174
10K
R15
10K
IC57
TC7SH32FU
1
2
4
53
R162
10K
R31
10K
R67
10K
R12
10K
R28
NIU
R112
10K
R75
10K
C24
0.01
IC17
TC7S32F
1
2
4
53
C138
0.1
IC3
PCM69AU
VCOML 2
NC
3
IOUTL 4
SERVO 5
REF 6
IOUTR 7
+VCC
1AGND 10
VCOMR 9
NC
8
DGND 11
TP2
12
DATAR
13
BCK
14
SYSCK
15
WDCK
16
DATAL
17
TP3
18
TP1
19
+VDD
20
R8
NIU
R7
10K
C25
0.01
C32
100P
C262
NIU
IC46
TC7S08F
1
2
4
53
IC24 74HC4052
Y3
4
Y2
2
Y1
5
Y0
1
X3
11
X2
15
X1
14
X0
12
Y3
X13
INH 6
B9
A10
VEE 7
VCC
16 GND 8
R123
NIU
R88
10K
R111
10K
R63
NIU
R116
10K
R113
10K
IC20
TC7S32F
1
2
4
53
C194
NIU
R29
NIU
R114
10K
C108
NIU
R82
10K
CN4
53014-0310
11
22
33
R66
10K
R109
10K
R163
10K
R150
0R0
R16
10K
R120
NIU
R51
10K
R62
NIU
R32
10K
R17
10K
R173
NIU
C7
1.0
CN7
53253-0710
11
22
33
44
55
66
77
IC34C
NIU
84
C102
47P
C97
NIU
IC36 TC7S32F
1
2
4
53
R124
NIU
IC29 TC7S04F
24
53
IC44
TC74VHC164F
B2
A1
QA
3QB
4QC
5QD
6
CLR 9
CK 8
QE
10 QF
11 QG
12 QH
13
VCC
14 GND 7
R117
NIU
R170
10K
IC41
NIU
24
53
C53
47P
C103
47P
IC16
NIU
24
53
R169
10K
R76
NIU
R119
NIU
R171
10K
C184
0.01
R118
NIU
R9 100
IC7
TC7S32F
1
2
4
53
R121
NIU
R87
10K
C83
33/16
21
R47
6.8K
R64
150
R42
33K
C154
470P
C153
1500P
R38
6.8K
R35
6.8K
IC42B
UPC4570G
6
5
7
+
-
C12
33/16
21
C151
1500P
C172
470P
C11
33/16
21
R41
6.8K
IC42A
UPC4570G
2
3
1
+
-
C171
470P
R44
6.8K
SYO
BCKA
ESPCK
TOUCH3 XESPINT0
TOUCH2
TOUCH1
TOUCH0
LINESELECT
DISP_ON DA
64M_BANK_SEL XWRESP
MICIN
AD
XESP
LRCK
BCK
MCK
VIDEOIN
VIDEOOUT
XVGA XSCL
LP
YD
XD0
10MHz XD1
DISP_CONT XD2
DISP_ON XD3
LCDVEE
LCD27V
TEMPCNT1
GPWM0 TEMPCNT2
XLCDINT
XSTYLE_L
PB3
PB2 PB3
RDYCNTL PB2
RDYCNTL
FDCRST FDCRST XSTYLE_U
AN2
AN2
AN1
AN0 AN1
XPINT
XPINT 64M_BANK_SEL
AN0 XFDCINT XFDCINT
XKEYINT XKEYINT
XDREQ1 XDREQ1
XPSINT XPSINT
XLCDINT XLCDINT
MPX1
MPX0
XFDCDEND
FDCCONT
XFDCDEND
FDCCONT
10MHz
XWRESP
PB3
PB2 XSTYLE
XSTYLE_L
WD11
WA22 WD15 WD4
MK10 WA21 WD14 WD3
BR10 WA20 WD13 WD12 RDYCNTL
BR2 MK9 WA19 WD12 WD10
MK1 BR9 WA18 WD11 WD5
BR1 MK8 WA17 WD10 WD2
MK0 BR8 WA16 WD9 WD13 FDS2
BR0 MK7 WA15 WD8 WD9 FDS1
BR7 WA14 WD7 WD6 FDS0
WA13 WD6 WD1 FDS3
BR6 WREQ WA12 WD5 WD14 XINP
WA11 WD4 WD8
WA10 WD3 WD7
WA9 WD2 WD0 XRDATA
MK7 WA22 WA8 WD1 WD15 XINDEX XINDEX FDS3
BR7 WA21 WA7 WD0 XTRK0
MK8 WA20 WA6 XWPRT XRDATA XINDEX
BR8 WA19 WA5 XWPRT
MK9 BR2 XKEYINT WA18 WA4 XINP XTRK0 FDS0
BR9 MK1 WA17 WA 3 XINDEX
MK10 BR1 WA16 WA2 WA21 XINP HDIR FDS1
BR10 MK0 WA15 WA 1 WA20 XWDATA
T0 BR0 WA14 WA9 XWGATE XSTEP FDS2
T1 WA13 XWOE0 WA10 XSTEP
T2 T7 WA12 WA11 HDIR XWDATA MON0
T3 T6 WA11 WA12 FDCRST
T4 T5 WA10 WA13 XHSEL XWGATE HDIR
T5 T4 WA9 WA14
T6 T3 WA8 WA15 XDS3 XTRK0 XSTEP
T7 T2 WA7 WA16 XFDCINT
T1 WA6 WA17 FDS1 XWDATA
T0 WA5 XWCS0 XDREQ1 XDS0 XDS0
WA4 XWPRT XWGATE
WA3 XFDCDEND FDS0
WA2 XWCS3 XTRK0
WA1 FDCCONT
WA22 WD15 XWOE0 XRDATA XWPRT
BR10 MK10 WA21 WD14 XWCS0 WD0 MON0
WD15 WA20 WD13 WD8 XHSEL XRDATA
BR9 MK9 WD14 WA19 WD12 WD1
WD13 WA18 WD11 WD9 XHSEL
BR8 MK8 WD12 WA17 WD10 XXPCS3 XWCS3 WD2
WD11 WA16 WD9 XXPCS7 WD10
BR7 MK7 WD10 WA15 WD8 WD3
WD9 WA14 WD7 WD11
BR6 WD8 WA13 WD6 WA19
WD7 WA12 WD5 WA18
WD6 WA11 WD4 WA8
WD5 WA10 WD3 WA7
WD4 WA9 WD2 WA6
WD3 WA8 WD1 WA5
WD2 WA7 WD0 WA4
XPINT WD1 WA 6 WA3 LCD27V
BR2 WD0 WA5 XWCS1 WA2
WA4 WA1
BR1 MK1 XXPCS7 WA3 XWCS1 PHONES_SENSE
XXPCS6 WA2 XWCS2
BR0 MK0 XXPCS5 WA1 XXPCS2 XWCS2
XXPCS4 XXPCS1 XXPCS6
ED7 XXPCS3 XXPCS2 XWOE0
ED6 XXPCS2
ED5 XXPCS1 WD15 MIDI_SEL
ED4 WD7 MUTE
ED3 WD14
ESPCK ED2 WD6
ED1 XWOE0 WD13
ED0 WD5
WD12
E_RAS WA22 WD4
E_CAS
EWE
XWCS0
ED7 EA8
ED6 EA7
ED5 EA6
ED4 EA5 XWCS1
ED3 EA4
ED2 EA3
ED1 EA2
ED0 EA1 XXPCS0
EA0 XXPCS4
XXPCS1
XXPCS5
SDOA5
E_RAS SDOA4
E_CAS SDOA3 SDOA5
SDOA2 SDOA4
EWE SDOA1 SDOA3
SDOA0 SDOA2
SDOA1
SDOA0
SYO
WA20 WD15 WA20 WD15
WA19 WD14 WA19 WD14
WA18 WD13 WA18 WD13
WA17 WD12 WA17 WD12
WA16 WD11 WA16 WD11
WA15 WD10 WA15 WD10
WA14 WD9 WA14 WD9
WA13 WD8 WA13 WD8
WA12 WD7 WA12 WD7
WA11 WD6 WA11 WD6
WA10 WD5 WA10 WD5
WA9 WD4 WA9 WD4
WA8 WD3 WA8 WD3
WA7 WD2 WA7 WD2
WA6 WD1 WA6 WD1
WA5 WD0 WA5 WD0
WA4 WA4
WA3 WA3
WA2 WA2
WA1 WA1
WA21
XXPCS3 XXPCS3
XWOE0 XWOE0
XRST-A
SDOA[0..5] SDIA[0..5]
XD[0..3] XD[0..3]
SDOA[0..5]
WA21
LINESELECT
MK4
BR5
BR5
MK4
BENDER
PART_BAL
PB4
PB4
XSTYLE_U
AN6
XO-PORT
XSTYLE
AN7
RXD1
RXD1
XOSD2
XRAS
XRAS
XCASL
MPX1
AN5
XCASL
WPCNT
TOUCH1
CTS
AN3
RTS
A10
XSTYLE
XI-PORT
AN6
REVERB
XRAS
AN5
TOUCHX
TOUCHY
XSTYLE
TXD1
RTS
MPX0
PB4
AN3
XOSD1
XSTYLE_U
AN5
AN7
64M_BANK_SEL
XSTYLE
AN4
XOSD1
AN3
TXD1
TOUCH2
XCASH
AN4
CTS
XRAS
1MHz
XSTYLE_L
XCASH
TOUCH3
TOUCH0
XCASL
1MHz
XWRA
XCASH
AN4
MK2
MK5
MK2
MK2
MK5
MK3
MK3
MK6
MK3
MK6
BR3
BR4
MK6
BR4
BR3
BR3
BR4
BR6
MK5
BR5
MK4T0
T1
T2
T3
T4
T5
T6
T7
MK10
BR10
T1
T2
T3
T4
T5
T6
T7
MK9
MK0
BR0
MK1
BR1
MK2
BR2
MK3
BR3
MK4
BR4
BR4
MK5
BR5
MK6
BR6
MK7
BR7
MK8
BR8
MK4
XRDB
XRDA
XXPCS0
XXPCS0
VPP
WPCNT
VPP
WPCNT
VPPCNT
VPPCNT
WPCNT
XDWR
XWRB
XDWR
XDWR
XWRA
XRDA
SCD0
XETCCS
GPWM0
XVGA
XCS4
LS1
SCD4
LS1
SCD0
XCS4
XP
SS0
XCS4
LCD6
SCD6
SCD3
XRD
SCD7
SCD1
LCD3
XXPS
XP
20MHz
SCD2
SCD2
XGWAIT
SCD7
XRD
XFLASH
LS3
LLP
LCD1
XPWAIT
LCD6
XCS2
LCD4
LS0
XGWAIT
RS
LE
SS2
SS1
LLP
LCD7
XESP
XFLASH
XP
XRD
XRD
XXPS
LS0
SCD6
RS
XGWAIT
XVGA
XETCCS
XWRHXWRH
XCS2
LCD3
SS3
XRD
XSCNEN
SCD7
XRD
XPWAIT
XFLASH
LS3
XFDC
XRD
XRD
XGINT
SCD4
XFDC
SCD4
R/W
LCD1
XRD
SCD5
R/W
SCD5
SCD3
CTSINT
20MHz
20MHz
LCD0
XRD
XP
SS0
LCD2
XETCCS
XRD
XGINT
CTSINT
SS2
LS2
LCD2
XESP
SCD5
XCS2
SCD1
MIDI_SEL
SCD0
SS3
SS1
LCD5
SCD6
XSCNEN
SCD2
LCD0
XP
XRD
XRD
XFDC
SCD1
SCD3
MUTE
LS2
XESPINT0
LCD7
XESP
XRD
CTSINT
LE
LCD5
LCD4
XWRH
XGINT
PHONES_SENSE
XESPINT0
XRST-A
XRST-A
XRST-A
XRST-A
XRST-A
XRST-A
XRST-A
XRST-A
XINDEXINT
XINDEXINT
XRST-A
XRST-A
XKEY
XWRL
XWRL
XWRL
XWRL
XWRL
XWRL
XWRL
XWRL
XKEY
XKEY
XWRL
XWRL
10MHz
XWRL
D14
D0
D0
D0
D15
D8
D8
D6
D6
D6
D2
D5
D5
D1
D13
D0
D15
D4
D4
D4
D4
D9
D9
D2
D5
D1
D12
D12
D0
D7
D7
D6
D6
D10
D5
D5
D5
D1
D11
D[0..15]
D14
D12
D7
D7
D4
D4
D8
D5
D5
D3
D13
D11
D12
D15
D8
D9
D9
D9
D2
D2
D5
D1
D1
D3
D14
D12
D0
D10
D2
D5
D5
D3
D13
D14
D15
D15
D6
D6
D10
D2
D2
D5
D1
D1
D3
D12
D0
D7
D4
D4
D6
D2
D11
D14
D8
D8
D6
D10
D10
D1
D3
D14
D0
D7
D7
D4
D8
D6
D13
D11
D11
D[0..15]
D4
D10
D2
D3
D11
D14
D12
D0
D0
D0
D7
D15
D9
D6
D10
D2
D2
D1
D1
D3
D3
D13
D0
D7
D4
D9
D2
D1
D3
D3
D11
D11
D12
D0
D7
D15
D4
D8
D6
D6
D10
D10
D2
D5
D14
D14
D7
D4
D9
D6
D10
D5
D1
D3
D13
D13
D11
D12
D12
D0
D0
D7
D7
D15
D8
D6
D2
D2
D1
D1
D3
D13
D11
D7
D7
D15
D4
D4
D8
D9
D9
D5
D1
D3
D3
D3
D13
D13
XOSD2
D[0..15]
D15
SDIA0
SDIA0
SDIA5
SDIA2
SDIA1
SDIA1
SDIA3
BCKA
BCKA
SDIA4
SDIA4
SDIA2
SDIA3
SDIA[0..5]
SDIA5
XWRB
XRDB
BR9
T0
SDOC
WCKCWCKC
SYSCKSYSCK
SDOC
BCKCBCKC
A9
A10
A4
A4
A5
A5
A5
A7
A16
A18
A1
A19
A8
A14
A13
A20
A18
A9
A9
A10
A10
A3
A21
A4
A4
A6
A0
A11
A11
A9
A12
A12
A21
A19
A19
A19
A5
A17
A13
A20
A3
A12
A1
A4
A8
A5
A0
A2
A4
A6
A8
A5
A17
A7
A7
A2
A2
A2
A9
A3
A1
A1
A4
A6
A6
A0
A17
A7
A7
A13
A2
A[0..21]
A15
A15
A10
A6
A6
A8
A3
A12
A1
A1
A1
A8
A5
A14
A13
A16
A9
A9
A15
A21
A17
A7
A13
A2
A2
A18
A18
A3
A1
A6
A8
A0
A14
A14
A7
A20
A16
A11
A2
A3
A12
A1
A21
A6
A14
A11
A18
A10
A10
A1
A4
A5
A5
A9
A15
A3
A1
A1
A8
A5
A7
A13
A20
A16
A11
A11
A2
A18
A3
A3
A4
A8
A0
A20
A9
A15
A4
A6
A17
A7
A10
A3
A12
A19
A19
A8
A17A16
A2
A20
D14
SOST
SOFT
DAMP
MODUL.
TXD0
TXD0
RXD0
TXD0
RXD0
MIDI_IN
D
D
D
D
D
D
D
D
D
D
D
D
D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
D
+5D
+5D
+5D
D
+5D
D
2
+1
A
+5A
A
A
2
+1
2-1
2-1
2
+1
A
+5D +5A
A
A A
D
AD
D
+5D
D
D
+5D
D
+5D
+5D
D
+5D
D
D
+5D
+5D
+5D
D
+5D
D
+5D
+5D
+5D
D
A D
D
D
D
D
D
+5D
D
+5D
D
+5D
D
D
+5D
D
D
+5D
D
+5D
+5D
D
+5D
D
+5D
D
D
D D D D
D
D
D
D
D
+5D
+5D
+5D
+5D
+5D
D
+5D
+5D
+5D
+5D
D
+5D
D
+5D
D
D
D
+5D
D
+5D
D
+5D
D
+5D
+5D
D
D
+5D
D
+5D
D
D
+
-
REF
D
+5D
D
+5D
+5D
D
+5D
+5D
+5D
D
+5D
D
D
+5D
D
D
D
D
D
+5D
+5D
D
+5D
+5D
D
D
+5D
D
D
D
+5D
+5D
+5D
+5D
D
D
D
+5D
D
+5D
D
+5D
D
D D
+5D
D
D
+5D
D
D
+5D
+5D
+5D
D
D
+5D
+5D
+5D
+5D
D
+5D
D
+5D
D
D
D
+5D
D
+5D
+5D
D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
D
+5D
+5D
+5D
+5D
+5D
+5D +5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
+5D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D D
D
D
D
D
DD
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
2
+1
2
+1
A
A
A
A
A
A
A
A
SDOA[0..5] SDIA[0..5]
SYO
XRD
XESP
XESPINT0
BCKA
A[0..21] D[0..15]
XOSD1
XOSD2
LINESELECT
LINESELECT
DISP_ON
64M_BANK_SEL XWRESP
XVGA
10MHz
XD[0..3]XD[0..3]
DISP_ON
LCD27V
GPWM0
ESPCK
SDIA[0..5]
SDOA[0..5]
SYO
XRST-A
BCKA
XWRL
VPP
MPX1
VPP
XOSD2
XOSD1
MPX0
GPWM0
ToRight Contact B.
ADDRESS MAPPING
0000000 - 000FFFF (64KB) SH ROM ---
A27=H : WORD ACCESS
L : BYTE ACCESS
9000000 - 90FFFFF XRAS
A000000 - A0FFFFF 8Mbit FLASH XCS2 XECS0
C000000 - C0FFFFF XCS4 XECS4
4100000 - 417FFFF SSC1080 XCS4 XECS5
FDC HD63266 XCS4 XECS6
---
---
4180000 - 41FFFFF
ADDRESS DEVICE SH CS EXCITION
KEY SCANNING BUS
A/D SIGNAL BUS
EXCITION XCS4 ---4380000 - 43FFFFF
C280000 - C2FFFFF XCS4 XECS8
XCS6 ---E000000- EFFFFFF (4MB)
ESP XCS4
(1MB)
(1MB)
A280000 - A2FFFFF XCS2 XECS2
2300000 - 23FFFFF XCS2 XECS3
4200000 - 427FFFF XECS7
XP(MASTER)
2280000-229FFFF
22A0000-22BFFFF
22C0000-22DFFFF
22E0000-22FFFFF
OSD1
OSD2
EXTENDED OUTPUT PORT
EXTENDED INPUT PORT
VGA(SED1335)
ETC.
32M(64M) MASK
ETC
DATA_BUS
ADDRESS_BUS
CONTROL_BUS
16Mbit DRAM
NIU
ToOutput
Board
CN4
ToOutput
Board
ToLeft Contact B.
CN7
ToLCD Board
CN5
ToLCD Board
CN4
ToPanel Board
CN1
ToPanel Board
CN2
ToFDD UNIT
ToOutput Board
CN5
ToOutput Board
CN6
CN3
ToOutput Board
CN6
ToLCD Board
CN4
ToOutput Board
ToControl Board
CN8
(NOT IN USE)

10
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
E-600
July, 1999
V
W
X
Y
Z
A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
V
W
X
Y
Z
12345678910 1213141516171819202122232425262728293011 31 32 33 34 35 36 37 38 39 40 41 42 4312345678910 1213141516171819202122232425262728293011
CIRCUIT DIAGRAM (ESP. SECTION / MAIN PCB ASSY)
31 32 33 34 35 36 37 38 39 40 41 42 43
IC51
TC170C140
CA13
74
CA12
75
CA11
76
CA10
77
CA9
78
CA8
79
CA7
81
CA6
82
CA5
83
CA4
84
CA3
85
CA2
86
CA1
87
CA0
88
CD7
92
CD6
93
CD5
94
CD4
95
CD3
96
CD2
97
CD1
98
CD0
99
INT1
66
INT0
67
CS
68
WR
69
RD
70
TRR5 62
TRR4 61
TRR3 60
TRR2 59
TRR1 58
TRR0 57
TRCKIN 56
RST2 51
RST1 52
VPOUT 53
TRS5 101
TRS4 102
TRS3 103
TRS2 104
TRS1 105
TRS0 106
TRCKO 107
DIRECT
64
TYPE
65
SYO 132
SYI 133
PSEA16 136
PSEA15 137
PSEA14 138
PSEA13 139
PSEA12 140
PSEA11 141
PSEA10 142
EA9 27
EA8 26
EA7 25
EA6 24
EA5 23
EA4 22
EA3 21
EA2 20
EA1 17
EA0 16
ED23 49
ED22 48
ED21 47
ED20 46
ED19 45
ED18 44
ED17 43
ED16 42
ED15 39
ED14 38
ED13 37
ED12 36
ED11 35
ED10 34
ED9 33
ED8 32
ED7 10
ED6 9
ED5 8
ED4 7
ED3 6
ED2 5
ED1 4
ED0 3
WE 13
CAS 14
RAS 15
OSC
29
DA7
111
DA6
112
DA5
113
DA4
114
DA3
115
DA2
116
DA1
117
DA0
118
AD3
120
AD2
121
AD1
122
AD0
123
LRCK1
124
LRCK0
125
BCK1
128
BCK0
129
MCK1
130
MCK0
131
VDD
1VDD
12 VDD 18 VDD 30 VDD 41 VDD 54 VDD 72 VDD 90 VDD
108 VDD 109 VDD 126 VDD 134 VDD 144
VSS
2
VSS
11
VSS
19
VSS
28
VSS
31
VSS
40
VSS
50
VSS 55 VSS 63 VSS 71 VSS 73 VSS 80 VSS 89 VSS 91 VSS 100 VSS 110 VSS 119 VSS 127 VSS 135 VSS 143
R300
0R0
R301
0R0
C239
33/16
21
R204 0R0
IC52A
TC7WH74FU
D2
CK 1
Q
5
Q
3
PR
7CR 6
IC52B
TC7WH74FU
VCC
8
GND 4
R203 NIU
R200 NIU
RA38
10K
18
27
36
45
C300
1.0
C301
1.0
C302
1.0
R108 0R0
R146 0R0
R147 0R0
C16
1.0
C17
1.0
C22
1.0
C106
1.0
C159
1.0
C162
1.0
C173
1.0
C174
1.0
C246
1.0
C245
1.0
C244
1.0
C243
1.0
C242
1.0
C241
1.0
IC53
TC514260DJS-60
A8
26
A7
25
A6
24
A5
23
A4
22
A3
19
A2
18
A1
17
A0
16
NC
11
NC
12
NC
15
NC
30
RAS
14
UCAS
28
LCAS
29
WRITE
13
OE
27
I/O16 39
I/O15 38
I/O14 37
I/O13 36
I/O12 34
I/O11 33
I/O10 32
I/O9 31
I/O8 10
I/O7 9
I/O6 8
I/O5 7
I/O4 5
I/O3 4
I/O2 3
I/O1 2
VCC 1
VCC 6
VCC 20
VSS 21
VSS 35
VSS 40
X3
SG-8002JC 49.152MHz
OE 1
GND
2OUT 3
VDD
4
R201 22
R202 22
R205 22
R199 0R0
A13 SDOA5
A12 SDOA4
A11 SDOA3
A10 SDOA2
A9 SDOA1
A8 SDOA0
A7 BCKA
A6
A5 XRST-A
A4
A3
A2
A1
A0 SDIA5
SDIA4
D7 SDIA3
D6 SDIA2
D5 SDIA1
D4 SDIA0
D3 BCKA
D2
D1
D0 SYO
XESPINT0
XESP
XWRESP
XRD
ESPA8
ESPA7
ESPA6 ESPA8
ESPA5 ESPA6
ESPA4 ESPA4 ESPD22
ESPA3 ESPA2 ESPD20
ESPA2 ESPA0 ESPD18
ESPA1 ESPA1 ESPD16
ESPA0 ESPA3 ESPD14
ESPA5 ESPD12
49.152MHz ESPD23 ESPA7 ESPD13
ESPD22 ESPD15
ESPD21 ESPD17
ESPD20 ESPD19
ESPD19 ESPD21
ESPD18 ESPD23
ESPD17
ESPCK ESPD16
ESPD15
ESPD14
ESPD13
ESPD12
DA
AD
LRCK XEWE
XECAS
BCK XERAS
MCK
A[0..21]
SDOA[0..5]
SDIA[0..5]
D[0..15]
D
D
+5D
D
D
+5D
+5D
+5D
D
+5D
+5D
D
D
+5D
D
+5D
SYO
SDIA[0..5]
XESPINT0
A[0..21]
XRD
XESP
XRST-A
D[0..15]
DA
AD
LRCK
BCK
MCK
BCKA
XWRESP
ESPCK
SDOA[0..5]
(SSOP)
C290
0.01
IC61
SED1335F0B
OSC1
17
OSC2
18
D7
29
D6
28
D5
27
D4
26
D3
25
D2
24
D1
23
D0
22
A0
20
RD
13
WR
14
CS
19
RES
10
SEL2
15
SEL1
16
XD3
30
XD2
31
XD1
32
XD0
33
XSCL
35
XECL
34
LP
37
WF
38
YSCL
41
YD
40
YDIS
39
VA15 50
VA14 51
VA13 52
VA12 53
VA11 54
VA10 55
VA9 56
VA8 57
VA7 58
VA6 59
VA5 1
VA4 2
VA3 3
VA2 4
VA1 5
VA0 6
VD7 42
VD6 43
VD5 44
VD4 45
VD3 46
VD2 47
VD1 48
VD0 49
VWR 7
VRD 9
VCE 8
VDD
21 VSS 36
NC 11
NC 12
NC 60
C296
0.01
C297
0.01
Q7
DTC114EK
1
23
IC66A
TC7W74F
D2
CK 1
Q
5
Q
3
PR
7CR 6
IC66B
TC7W74F
VCC
8
GND 4
IC37
TC7S04F
24
53
IC6A
TC7W08F
1
2
7
IC6B
TC7W08F
5
6
3
IC6C
TC7W08F
84
IC65C
M5223AFP
84
+
-
R243
33K
R245
330
R248
33K
R246
33K
R244
56K
R249
18K
Q8
2SC2412KR
1
23
C298
1/50
21
IC65B
M5223FP
6
5
7
+
-
IC65A
M5223FP
2
3
1
+
-
C182
0.1
C291
0.1
C288
0.1
R83
NIU
R241
820K
R100
NIU
C294
0.1
IC62
HM62256LFP-7T
A14
1
A13
26
A12
2
A11
23
A10
21
A9
24
A8
25
A7
3
A6
4
A5
5
A4
6
A3
7
A2
8
A1
9
A0
10
CS
20
WE
27
OE
22
I/O8 19
I/O7 18
I/O6 17
I/O5 16
I/O4 15
I/O3 13
I/O2 12
I/O1 11
VCC 28
VSS 14
D1
02CZ16-X
13
10MHz
LCDA14 LCDD7
LCDA13 LCDD6
D7 LCDA12 LCDD5
D6 LCDA11 LCDD4
D5 LCDA10 LCDD3
D4 LCDA9 LCDD2
D3 LCDA8 LCDD1
D2 LCDA7 LCDD0
D1 LCDA6
D0 LCDA5
LCDA4
A0 LCDA3
XRD LCDA1
XWRL LCDA0
XVGA
XRST-A LCDD7
LCDD6
LCDD5
LCDD4
LCDD3
XD3 LCDD2
XD2 LCDD1
XD1 LCDD0
XD0
XVWR
XSCL XVRD
XLCDINT
YD
TEMPCNT1
LP
TEMPCNT2
LCD27V
LCDVEE
GPWM0
DISP_ON
D[0..15]
A[0..21]
XD[0..3]
LCDA2
+5D
D
D
+5D
D
D
D
D
+5D
+5D
D
+5D
D
D
D
D
D
D
D
+5D
D
D
10MHz
D[0..15]
A[0..21]
XRD
XWRL
XVGA
XRST-A
XD[0..3]
XSCL
LP
XLCDINT
YD
DISP_CONT
DISP_ON
LCD27V
GPWM0
LCDVEE
TEMPCNT1
TEMPCNT2
IC47A
UPC4570G
2
3
1
+
-
IC47B
UPC4570G
6
5
7
+
-
R175
0R0
IC49
TA78L05F
IN
3OUT 1
COM 2
IC50A
UPC4570G
2
3
1
+
-
IC50B
UPC4570G
6
5
7
+
-
IC50C
UPC4570G
84
+
-
IC47C
UPC4570G
84
+
-
C209
10P
C208
10P
C234
33/16
21
C207
33/16
21
C229
33/16
21
C237
33/16
21
C236
33/16
21
C232
33/16
21
C233
33/16
21
R183
6.8K
R186
6.8K
C213 33P
C214
33/16
21
R187
6.8K
C235
33/16
2
1
R189
1.5K
R188
68K
R190
680K
R192
6.8K
R191
6.8K
C205
33/16
21
C206
33/16
21
R198
6.8K
R197
6.8K
R182
150
R238
150
R195
3.3K
R193
3.3K
C218
1500P
C221
1500P
C216
680P
C217
680P
C200 NIU
C211 NIU
IC48
UDA1309H
ADBCK
1
ADWS
2
MODE0 3
ADENB
4
OVLOAD
5
ADPON
6
VSSA(AD)
7
VDDA(AD)
8
VREF(NEG)
9
VREF
10
VREF(POS)
11
BAOL
12
BAIL
13
BAIR
14
BAOR
15
ADREF
16
IREF
17
DAREF 18
VDDO 19
VSSO 20
VOL 21
DACL 22
DACR 23
VOR 24
VDD(DA) 25
VSSA(DA) 26
VSSD 27
VDDD
28
DAPON 29
DADEM 30
DABCK 31
DAWS 32
VSSD(F) 33
VDDD(F)
34
DASDA 35
ANLPTR
36
TEST0 37
TEST1 38
VSS(I/O) 39
SYSCLK
40
ADSDA
41
MODE1 42
MODE2 43
CLKEDGE
44
C201
1.0
C202
1.0
C203
1.0
C204
1.0
C210
1.0
C212
1.0
C222
0.22
C223
0.22
C225
0.22
C226
0.22
C224
0.1
C227 0.1
C228 0.1
R185 27K
C215
1500P
C219
1500P
C220
1500P
R176
N2012ZA202
R177
N2012ZA202
R178
N2012ZA202
R179
N2012ZA202
R180
47K
R184 33K R194
33K
R196
33K
R181
0R0
AD
DA
BCK
LRCK
MCK
MICIN
MICOUTL
MICOUTR
D D
D
D
D
D
+5D +5D
+5D +5D
D
REF
+
FER +5
FER +5 FER +5
FER +5FER +5
+
-
+
-
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
REF
DA
LRCK
BCK
MCK
MICIN
AD
MICOUTL
MICOUTR
41.3mA
CIRCUIT DIAGRAM (MIC. SECTION / MAIN PCB ASSY)
CIRCUIT DIAGRAM (LCDC. SECTION / MAIN PCB ASSY)

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
11
11
E-600
July, 1999
INVERTER PCB ASSY & CIRCUIT DIAGRAM
ASSY 7711203000
View from component side
2
1
3
Q1
BC560B
R5
4K7
R6
10K
+VR
MUTE
1
2
D2
1N4148
MUTE
ROUT
AGND
LOUT
AGND
3
4
2
1
5
6
CN2
5045-06A
FROM OUTPUT B.
(CN3)
R
2
1
3
Q2
BC549B
R7
10K
R8
22K
C10
220uF25
C12
22uF25
1
3
2
P2
22KOR
R10
220
R9
22K
C8
10uF16
C11
0.1C
+VS
R12
56K
C21
10uF16BP
TO SPEAKERS
L
R
1
2
D1
1N4001
+
1
C
M
2
4
N
C
2
6
N
O
2
8
-
1
6
C
M
1
1
3
N
C
1
1
1
N
O
1
9
RL1
MR602-12SR
R40
100
R39
100
R41
270
1/4W
+RIGTH WOOFER
+
4 OHM
4 OHM
-
-
LEFT WOOFER
RIGHT TWEETER
LEFT TWEETER
C38
0.1C
C39
0.1C
C40
0.1C
SPR+
SPR-
SPL+
SPL-
RL
RL L
R
3
4
2
1
CN1
5045-04A
C3
220uF25
R1
2K2
R2
2K2
C35
0.1C
C36
0.1C
C37
0.1C
C5
2200uF25
C4
2200uF25
+VS+VR
R4
NIU R3
NIU
C7
NIU C6
NIU
L
GND
FROM SWITCHING B. 3
4
2
1
CN3
5045-04A
C9
220uF25
1
3
2
P1
22KOR
C13
220nF
C14
220nF
VCC-VCC
JP1
P
G
N
D
6
IN2+
5
S
V
R
7
S
G
N
D
3
I
N
1
-
2
O
B
R
4
OUT2 8
V
S
9
S
B
1
1
OUT1 10 IN1+
1
IC6
TDA7350
R11
56K
C34
10uF16BP
+17V
(CN1)
-12V
+12V
AGND
+5V
+5V
DGND
DGND
3
4
2
1
5
6
7
CN4
5045-07A
(CN2)
-12V
+12V
AGND
+5V
+5V
DGND
DGND
3
4
2
1
5
6
7
CN5
5045-07A
(CN2)
C1
100uF25 C2
100uF25
LR
FROM OUTPUT B.
FROM SWITCHING B.
View from component side
NOT mounted component
Jumper
POWER AMPLIFIER PCB ASSY & CIRCUIT DIAGRAM
ASSY 7698701000
To LCD
2
1
CN2
S2(4-2.3)B-XH-A
JP1
JP2
DC-IN
1
DC-GND
2
AC-OUT1 3
AC-OUT2 4
AC-GND 5
MOD1
CXA-K10A-L
C1
100nFC
C2
470uF16
From Power Supply
Cn3
3
4
2
1
CN1
5045-04A

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
12
11
E-600 July, 1999
OUTPUT PCB ASSY ASSY 7711205000
View from component side
T1
IC1A
UPC4570C
2
3
1
+
-
R3
5.6k
IC1C
UPC4570C
84
+
-
Q3
2SA1015GR
3
21
Q1
2SA1015GR
3
2
1
CN5
53014-1310
11
22
33
44
55
66
77
88
99
10 10
11 11
12 12
13 13
C4
47/16
CN3
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
Q2
2SC1815GR
3
1
2
C2
1nF
CN4
53014-0310
11
22
33
C5
47/16
R10
100K
IC1B
UPC4570C
6
5
7
+
-
R4
2.7k
C3
1nF
R9
100K
C1
47/16
R5
2.7k
R7
5.6k
R6
5.6k
R1
5.6k
R2
2.7k
Q4
2SC1815GR
3
1
2
R8
2.7k CN2
SLP4R-2
1
1
2
2
3
3
4
4
53014-0710
11
22
33
44
55
66
77
CN7
53014-0310
11
22
33
EN1A
EVQVEC@
1 4 2
AB
EN
R11
0
2
+1
2-1
+5D
+5D
2
+1
2-1
+5D
D
D
D
D
D
D
+5D
D
D
To MAIN B.
pass to Graphic LCD
Encoder
From CONTROL B.
10KD-5
From MAIN B.
To Graphic
LCD
CN11
CN7
CN12
(Cn16)
To
Touch
Screen
Cn6
To MAIN B.
View from component side
LCD CONTROL PCB ASSY & CIRCUIT DIAGRAM
ASSY 7711202000

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
13
11
E-600
July, 1999
CIRCUIT DIAGRAM (OUTPUT PCB ASSY)
XRST
+5V
+5V
DIG.GND
DIG.GND
SEND_R
AN.GND
SEND_L
-12V
+5V
+5V
-12V
+12V
SEND_L
AN.GND
SEND_R
+12V
-12V
RET_L
RET_R
AN.GND
RET_R
RET_L
XRST
AN.GND
DIG.GND
DIG.GND
TO MAIN B.
TO CONTROL B.
FROM POWER
AMPLIFIER B.
MUTE
MIDI_SEL
3
4
5
6
7
8
2
1
CN1
53014-0810
3
4
2
1
5
6
7
CN2
5045-07A
3
4
5
6
7
8
2
1
9
10
11
12
13
CN6
53014-1310
VCC-VCC 5VC
(CN5)
(CN23)
L
R
MUTES
MUTER
PHL
PHR
L1=L2=L3=BL02RN2R62
AGND
LOUT
MUTER
MUTE
TO POWER
R10
560s
1
2
D1
BZX79C4V7
L3
L4
L5
2
3
1
84
IC1A
BA5218F
FLAT
6
5
7
IC1B
BA5218F FLAT
2
1
3
Q3
2SC2412
2
1
3
Q4
2SC2412
2
1
3
Q5
2SA1037
R15
100KS
R16
220KS
R17
47KS
R18
47KS
R19
47KS
R20
10KS
R21
10KS
R22
1KS
R23
220S
C12
0.1S
C13
0.1S
R47
27KS
R48
27KS
3
4
2
1
5
CN3
5045-05A
R11
100I
0.6W
R12
100I
0.6W
C14 100pFS
C15 100pFS
C16
100pFS
VCC
-VCC
VCC
C5
1uF16
NIU
P
H
O
N
E
S
IN
OUT
THRU
M
I
D
I
L3=L4=L5=SBT0160W
8
7
3
2
4
5
1
JK3
YKB21-5006
NC
1
LA
2
LC
3
NC
4GND 5
OUT 6
EN 7
VCC 8
IC4
6N137
2
1
3
4
5
6
7
8
9
JK4
YKF51_5046
L6
SBT0460
C23
0.1s
R28
220s
R29
220s
R30
220s
R31
220s
R32
220s
R33
22Ks
R34
22Ks
R36
4K7s
R37
4K7s
2
1
3
Q6
2SA1037
C25
0.1s
1
2
4
3
L7
1
2
4
3
L8
1
2
4
3
L9
3
4
IC5B
74LS05
flat
1
2
1
4
7
IC5A
74LS05
flat
9
8
IC5D
74LS05
flat
2
1
3
D2
DA204K
5VC
5VC
5VC
5VC
XRST
M_OUT
M_IN
SWITCH
SWITCH
SWITCH
SOFT
SOST
DAMP
SOFT
SOST
DAMP
R35
1Ks
C24
0.1s
5
6
IC5C
74LS05
3
1
2
JK5
HLJ0520_01_110
1
2
4
3
L10
SBT0160W
R38
1Ks
R39
22Ks
3
1
2
JK6
HLJ0520_01_110
1
2
4
3
L11
SBT0160W
R40
1Ks
R41
22Ks
3
1
2
JK7
HLJ0520_01_110
1
2
4
3
L12
SBT0160W
R42
1Ks
R43
22Ks
R44
22Ks
11
10
IC5E
74LS05
flat
13
12
IC5F
74LS05
flat
C26
1nF
C27
1nF
C28
1nF
21
3
D3
DA204K
21
3
D4
DA204K
21
3
D5
DA204K
5VC
ref5V
ref5V
ref5V
5VC
M_IN
M_OUT
SOFT
SOST
DAMP
C29
100uF16
C58
33uF16
R73
560Ks
R74
560Ks
R75
560Ks
3
4
2
1
5
6
7
CN8
53014-0710
R70
100s
R71
100s
R72
100s
C56
0.1s
C57
0.1s
TP9
R69
270I
2
3
1
84
IC8A
UPC4570G2
6
5
7
IC8B
UPC4570G2
6
5
7
IC9B
UPC4570G2
2
3
1
84
IC9A
UPC4570G2
Vdd
Vss Vdd
VCC
ref5V
R
L/M O
U
T
P
U
T
RXD0
TXD0
REFGND
SOFT
SOST
DAMP
REF+5
FROM MAIN B.
3
1
2
JK1
HLJ052001110
3
1
2
JK2
HLJ052001110
C3
100uF16
C4
100uF16
TP1 TP4
C9
0.1S
FIX1
FIX2
FIX3
C55
33uF16
R68
270I
R1
100I
0.6W
R2
100I
0.6W
FIX4
Vss
VCC V
-VCC
5VC
V--VCC
(CN7)
C6
0.1S
FIX6
FIX7
FIX8
C7
0.1S
C8
0.1S
FIXING
L
R
AGND
ROUT
RET_R
RET_L
AMPLIFIER B.
MOUT_R
MOUT_L
C1
10uF16BP
C2
10uF16BP
1
2
4
3
L1
SBT0160W
1
2
4
3
L2
SBT0160W
R7
680s
R8
680s
R9
220Ks
R13
560s
R14
100KS
2
3
1
84
IC2A
BA5218F
FLAT
C17
0.1S
C18
0.1S
6
5
7
IC2B
BA5218F
FLAT
R26
100KS
C39
10uF16BP
C40
10uF16BP
R6
1Ks
R5
1Ks
R76
NIU
R4
1Ks
R3
1Ks
R77
NIU
C19
100pFS
3
1
2
Q1
2SC2878
3
1
2
Q2
2SC2878
R46
15KS
R24
15KS
R45
15KS
R25
15KS
R58
18Ks
R57
18Ks
C41
330nF
C42
330nF
V-
V
-VCC
(CN2)
R59
22Ks
R60
22Ks
R78
15Ks
R79
15Ks
+12V
XRST
RESET
(CN21)
C20
100uF16
C21
100uF16
R27
1Ks
NC
2
GND
3
RES 5
CAP 4
VCC
1
IC3
M51953A
TP7
TP8
C54
33uF16
3
4
2
1
5
6
CN7
53014-0610
C53
33uF16
C22
100nF
C30
100uF16
5VC
VCC
-VCC
(CN5)
SW1
EVQ-QVT
5VC
5VC
2
1
3
Q8
2SC2412 2
1
3
Q7
2SC2412
C59
10uF16
NC
2
GND
3
RES 5
CAP 4
VCC
1
IC10
M51953A
FROM MAIN BOARD
L15
NIU
R80
1Ks
R81
47Ks
R82
100Ks
R83
100Ks
(CN20)
R51
3K3s
R50
5K6s
6
5
7
IC6B
UPC4570G2
C43
220pFs
C44
150pFs
3
4
2
1
5
CN4
53014-0510
TO MAIN BOARD
C32
33uF16
C33
33uF16
C34
33uF16
C45
33uF16
C51
33uF16
2
34
5
1
VR1
10KBX2
RK09K12A0A2AA
R61
6K8s
R62
6K8s
R53
68Ks
R49
5K6s
R52
680s
R54
6K8s
R55
6K8s
C35
0.1s
C36
0.1s
2
3
1
84
IC6A
UPC4570G2
C37
150nF
C38
680pFs
C52
220pFs
C31
150pFs
2
1
3
D6
DA204K
1
2
4
3
L14
SBT160W
R56
330s
V- V
V
V-
TP2
TP3
TP5
TP6
C46
100uF16
CS 1
ES 2
CT 3
GND
4INV 5
V+
6SI
7CD
8
IC7
NJM2360M
FLAT
R64
0.22I
1W
8
7
3
2
4
5
1
JK8
YKB21-5006
TP10
MIC INPUT
R63
180
1/4W
(CN17)
SWITCHING CIRCUIT
+27V
C47
NIU
12
D11
SFPB-56
3
2
1
CN5
53014-0310
L13
RCH-875-151K
TO MAIN BOARD
C50
100uF35
C49
390pFs
5% np0
R65
2K7s
1%
R66
18Ks
1%
R67
1Ks
1%
R86
2K2I
0.6W
R87
2K2I
0.6W
STEP-UP

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
14
11
E-600 July, 1999
CONTROL PCB ASSY ASSY 7711201000
View from component side

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 12131415161718192021222324252627282930
15
11
E-600
July, 1999
CIRCUIT DIAGRAM (CONTROL PCB ASSY)
12
D72
red
12
D73
red
R15
100I
R16
100I
R17
100I
R18
100I
R19
100I
R20
100I
R21
100I
L
D
1
L
D
2
L
D
3
L
D
4
L
D
5
L
D
6
L
D
7
RESETSTOP
SPLIT_LOW
3
1
2
Q1
RN2227
C5
0.1C
D1
2Q1 19
D2
3Q2 18
D3
4Q3 17
D4
5Q4 16
D5
6Q5 15
D6
7Q6 14
D7
8Q7 13
D8
9Q8 12
CLK
11
OC
1
V
C
C
2
0
G
N
D
1
0
IC4
74HC574AP
N
C
1
0
G
N
D
9
I7
8I6
7I5
6I4
5I3
4I2
3I1
2I0
1
O7 11
O6 12
O5 13
O4 14
O3 15
O2 16
O1 17
O0 18
IC5
TD62593AP
SW10
1
2
D10
SW11
1
2
D11
SW18
1
2
D18
SW19
1
2
D19
1
2
D24
1
2
D25
12
D71
red
R14
100I
S
C
D
7
SCD0
SCD1
SCD2
SCD3
SCD4
SCD5
SCD6
SCD7
LLP
LD0
LD1
LD2
LD3
LD4
LD5
LD6
LD7
L
D
0
LLSC0
VLED
5VD
RHYTHMWHOLE
PLAYRECBWDFWDMEM
MARKER/COUNT_IN TRANSPOSE
SPLIT_WHOLESPLIT_UPBASS_ACCOMPLOWER
1
2
D1
SW2
1
2
D2
SW3
1
2
D3
1
2
D4
SW5
1
2
D5
SW6
1
2
D6
SW7
1
2
D7
SW8
1
2
D8
SW9
1
2
D9
1
2
D12
SW13
1
2
D13
SW14
1
2
D14
SW15
1
2
D15
SW16
1
2
D16
SW17
1
2
D17
1
2
D20
1
2
D21
1
2
D22
1
2
D23
S
C
D
1
S
C
D
2
S
C
D
3
S
C
D
4
S
C
D
5
S
C
D
6
DISK
UPPER
VOCAL_EFFECTS
(CN5)
A
1
B
2
C
3
G1
6
G2A
4
G2B
5
Y0 15
Y1 14
Y2 13
Y3 12
Y4 11
Y5 10
Y6 9
Y7 7
V
C
C
1
6
G
N
D
8
IC6
74HC138AP
3
4
5
6
7
8
2
1
9
10
11
12
CN1
53014-1210
3
4
5
6
7
8
2
1
9
CN2
53014-0910
C30
33uF16
R22
100K
R23
27I
0.6W
C31
470uF16
AXIAL
SW1
SW4
SW12
SCD7
SCD6
SCD5
SCD4
SCD3
SCD2
SCD1
SCD0
LLP
SS0
SS1
SS2
SS3
LS0
LS1
SSEN
LSSC0
LSSC2
LSSC3
LSSC4
LSSC5
LSSC0
LSSC2
LSSC3
LSSC4
S
C
D
0
VLED5VD
5VD
FROM MAIN B.
FROM MAIN B.
FANTASIA
METRONOME
PAGE_LOW
DISK_STYLE
START/STOP
(CN6)
C1
0.1C
C2
0.1C
A
1
B
2
C
3
G1
6
G2A
4
G2B
5
Y0 15
Y1 14
Y2 13
Y3 12
Y4 11
Y5 10
Y6 9
Y7 7
V
C
C
1
6
G
N
D
8
IC7
74HC138AP
A
1
B
2
C
3
G1
6
G2A
4
G2B
5
Y0 15
Y1 14
Y2 13
Y3 12
Y4 11
Y5 10
Y6 9
Y7 7
V
C
C
1
6
G
N
D
8
IC8
74HC138AP
SW26
SW34
SW36
SW39
SW47
SW55
LS2
LS3
LS0
LS1
LS2
LS3
LSSC8
LSSC9
LSSC11
LSSC12
LSSC13
LLSC0
LLSC2
LLSC3
LLSC4
LLSC5
LSSC5
LSSC8
LSSC9
LSSC10
LSSC11
LSSC12
LSSC10
5VD
5VD
5VD
ORGANGUITAR/BASSSTRINGSSAXBRASS
1TOUCH_ORGAN1TOUCH_DRUMS 1TOUCH_ARRANGMELODY/INTELLEFFECTS
SONG
PAGE_UP
LATINWALTZMARCH_KIDSWORLDSCREEN
FILL_TO_VARFILL_TO_ORIGSYNCINTRO_ENDING_1INTRO_ENDING_2
SW20 SW21 SW22 SW23
1
2
D26
SW27
1
2
D27
SW28
1
2
D28
SW29
1
2
D29
SW30
1
2
D30
SW31
1
2
D31
1
2
D34
SW35
1
2
D35
1
2
D36
SW37
1
2
D37
1
2
D39
SW40
1
2
D40
SW41
1
2
D41
SW42
1
2
D42
SW43
1
2
D43
SW44
1
2
D44
1
2
D47
SW48
1
2
D48
SW49
1
2
D49
SW50
1
2
D50
SW51
1
2
D51
SW52
1
2
D52
1
2
D55
SW56
1
2
D56
SW57
1
2
D57
SW58
1
2
D58
SW59
1
2
D59
SW60
1
2
D60
FANTASIA
PIANOVIBES
1TOUCH_PIANO VOCAL_EFF
UPPER
BEAT_2
ACCOMP
COUNTRYSWING
TEMPO-TEMPO+
3
1
2
Q2
RN2227
3
1
2
Q3
RN2227
3
1
2
Q4
RN2227
3
1
2
Q5
RN2227
3
1
2
Q6
RN2227
3
1
2
Q7
RN2227
3
1
2
Q8
RN2227
SW24 SW25
SW32
1
2
D32
SW33
1
2
D33
SW38
1
2
D38
SW45
1
2
D45
SW46
1
2
D46
SW53
1
2
D53
SW54
1
2
D54
SW61
1
2
D61
SW62
1
2
D62
12
D77
red
12
D88
red
12
D100
red
12
D96
green
LLSC2
LLSC3
LLSC4
LLSC5
LLSC8
LLSC9
LLSC11
VLED
VLED
VLED
VLED
VLED
VLED
VLED
PIANOVIBESORGANGUITAR/BASSSTRINGSSAXBRASS
1TCH_DRUMSEFFECTS
SPLIT_LOWSPLIT_UP SPLIT_WHOLE
PLAYRECMEM
MARKER TRANSPOSE
RHYTHMWHOLEBASS_ACCLOWER
BEAT_3BEAT_1 BEAT_0
MELODY/INT
12
D74
red
12
D75
red
12
D78
red
12
D79
red
12
D80
red
12
D81
red
12
D82
red
12
D83
red
12
D84
red
12
D85
red
12
D86
red
12
D87
red
12
D89
red
12
D90
red
12
D91
red
12
D92
red
12
D93
red
12
D94
red
12
D95
red
12
D99
red
12
D101
red
12
D102
red
12
D103
red
12
D76
green
12
D97
green
12
D98
green
SONGPAGE_LOW PAGE_UP
DEMOFUNCTIONUSER_PROGPAD_1PAD_2PAD_3
POPBALLADROCK
COUNTRY
PIANO_STY
SWINGLATINWALTZMARCH_KIDSWORLDSCREEN
FILL_TO_VARSYNCINT_END_2 INT_END_1 FILL_TO_ORI
PHRASEUSER STYL_ORCH.
12
D105
red
12
D106
red
12
D107
red
12
D108
red
12
D109
red
12
D110
red
12
D111
red
12
D113
red
12
D114
red
12
D115
red
12
D116
red
12
D117
red
12
D119
red
12
D120
red
12
D121
red
12
D122
red
12
D123
red
12
D124
red
12
D125
red
12
D127
red
12
D128
red
12
D129
red
12
D130
red
12
D131
red
12
D132
red
METRONOME
KEYBOARDDEMO
STYLE_ORCH.PHRASE
PAD_4
DISK_STY
START/STOP
OLDIES
3
1
2
Q9
RN2227
3
1
2
Q10
RN2227
3
1
2
Q11
RN2227
C23
150pF
SW69
1
2
D69
SW70
1
2
D70
12
D104
red
12
D112
red
12
D118
red
12
D126
red
LLSC12
LLSC13
LLSC14
VLED
VLED
VLED
FUNCTIONUSER_PROGRAMPAD_1PAD_2PAD_3
USERPOPPIANO_STYLEBALLADROCK
1
2
D63
SW64
1
2
D64
SW65
1
2
D65
SW66
1
2
D66
SW67
1
2
D67
SW68
1
2
D68
TO MAIN B. REFGND
REF5V
BENDER
REVERB
PART_BAL
PAD_4
OLDIES
(CN14)
C3
0.1C
C4
0.1C
6
5
7
IC1B
M5218AL
C12
33uF16
R3
680
1
3
2
VR2
EWANFXX10B14
1
3
2VR3
RS30111CA
A
1
B
2
C
3
G1
6
G2A
4
G2B
5
Y0 15
Y1 14
Y2 13
Y3 12
Y4 11
Y5 10
Y6 9
Y7 7
V
C
C
1
6
G
N
D
8
IC9
74HC138AP
3
4
2
1
5
CN3
53014-0510
C32
0.1C
SW63
LS0
LS1
LS2
LLSC8
LLSC9
LSSC13
LLSC13
LLSC11
LLSC12
LLSC14
5VD
5VD
REF5V
BEND
TO BENDER
MOD
REFGND
MOD
BEND
REFGND
REF5V1
2
3
4
GRN
BLEU
ORG
RED
YEL
12
MODULATION
BENDER
BRWN
MODULATION
TO MAIN B.
(CN4)
2
13
FL1
2
13
FL2
2
13
FL3
2
13
FL4
2
13
FL5
C8
0.1C
C9
0.1C
C10
33uF16
C11
33uF16
2
3
1
84
IC1A
M5218AL
R1
680
R2
680
6
5
7
IC2B
M5218AL
2
3
1
84
IC2A
M5218AL
R4
680
R24
68K
R25
10K
R26
0
R27
0R28
68K
Vss Vcc
Vcc Vss
REF5V
REF5V
REF5V
+12V
-12V
L1
EXCLDR25V
3
2
1
CN4
53014-0310
3
4
2
1
5
6
CN6
53014-0610
BRILLIANCE
1
3
2
VR1A
10KB
EWANNKX10B14
4
6
5
VR1B
10KB
EWANNKX10B14
C13
0.1C
R6
6K8
R7
6K8
R8
6K8
R9
6K8
C14
150pF
C15
150pF
C16
33uF16
C17
0.1C
C18
0.1C
C19
33uF16
6
5
7
IC10B
M5218AL
2
3
1
84
IC10A
M5218AL
C7
22nF
C6
22nF
R29
5K6
R5
5K6
C33
0.1C
+12V -12V
C20
33uF16
C21
33uF16
SEND_L
SEND_R
RETURN_L
RETURN_R
VOLUME
FROM OUTPUT B.
AGND
AGND (CN1)
R10
6K8
R11
6K8
R12
6K8
C22
150pF
R13
6K8
6
5
7
IC3B
M5218AL
2
3
1
84
IC3A
M5218AL
C26
33uF16
C27
0.1C
C28
0.1C
C29
33uF16
1
3
2
VR4A
10KB
EWANNKX10B14
4
6
5
VR4B
10KB
EWANNKX10B14
3
4
5
6
7
8
2
1
CN5
53014-0810
+12V -12V
-12V
+12V
TO LCD B.
(CN7)
R30
270I
R31
270I
-12V
+12V
3
2
1
CN7
53014-0310

A
B
C
D
E
F
G
H
I
L
M
N
O
P
Q
R
S
T
U
J
K
12345678910 1213141516171819202122232425262728293011
E-600 July, 1999
RIGHT CONTACT PCB ASSY w/RUBBER ASSY 7624504000
LEFT CONTACT PCB ASSY w/RUBBER ASSY 7624505000
CIRCUIT DIAGRAM (RIGHT CONT. PCB ASSY)
CIRCUIT DIAGRAM (LEFT CONT .PCB ASSY)
16

E-600
July, 1999
TEST MODE
Required items:
·MIDI Cable  1 (1.5 m)
·Microphone
·Oscilloscope
·KR-575 LCD Calibration sheet (part number 01675978)
·Touch-pen for PMA-5 (part number 00900545)
·3,5inch Floppy Disk (formatted by E-600/ 2 HD x 1,2; DD x 1)
Test Main Menu'
In order to enter the different tests listed below, press each time the button "Next " or the button " Part Volume
Accomp ".
1. Calibration of the Touch Panel
2. Display of the Device Check and Rom Version
3. Factory Preset Setting
4. Control of buttons and LEDs
5. Control of the Speaker Panning and of Effect Sound
6. Esp check
7. A/D check
8. Touch Panel A/D check
9. Encoder check
10.MIDI check
11.Microphone check
12.FDD check
13.LCD check
14.LCD contrast check
15.Setup and Destination
16.Audio check
To enter the Test Mode
While pressing both [Track 4] and [Play] buttons, press Part Balance [Accomp].
The following display will appear and you will enter test mode.
How to go to the following test.
While you are in test mode, you can go to the following test by pressing the Part Balance [Accomp] button.
When the writing [Next] is displayed at the bottom of the screen, you can go on by touching it ([Next]).
NOTE: Do not play the keyboard while you are in test mode. If there is a malfunction, press the Part
Balance [Accomp]button several times until the display "Product Information" will be shown. Then
start the test again.
While you are in test mode (except in Device Check mode), you can adjust the LCD contrast by rotating the
Rotary Encoder keeping the Part Balance [Keyboard] button pressed.
1. Calibration of the Touch Panel
Calibrate the position of the Touch Panel this way.
To perform this test, original pen (Touch Pen for PMA-5, P/no. 00900545) and jig (KR-575Calibration Sheet,
P/No. 01675978) are required. Please order these jigs from the local Roland Service Center if necessary.
Place the Calibration sheet on the Touch Panel as shown in the following picture. The side with a notch should
become the upper.
After positioning the sheet, the display will appear as follows:
Touch the lower corner of each slit on the sheet with the Touch pen according to the
numbering shown in the following picture). When the E-600 recognizes the touch, "+" will change into "O".
This way, the writing "Touch Me" will appear to show the correct order, so please follow this indication. During
the Calibration, do not touch any point except "Touch Me". After touching the four points, the calibration step
ends and the display will show :
1
2
3
4++
+
+
Touch Me.
17

E-600 July, 1999
Note: The calibration set will be memorized at the point " 3 " Factory Preset Setting" of the Test mode.
When the calibration fails, the following display will appear:
You have to carry out the calibration again.
Press the Part Balance [Accomp] button to go to the next test.
2. Display of the Device Check and Rom Version
Note: After the calibration, turn down the general volume so as to avoid hearing the audio noise.
This control starts automatically after the calibration step. The display may change as follows:
When no problem is found, "OK" will be shown on the top of the display.
On the contrary, the following error message will appear:
The devices and contents checked are as follows:
DEVICE CONTENTS
PROGRAM ROM checks the Checksum
DRAM checks the working of the DRAM for CPU
Wave rom checks the Checksum
DSP RAM checks the RAM for XPDSP
ESP RAM checks the RAM for ESP
DATA ROM checks the Checksum
DATA ROM TYPE checks the type of DATA ROM
FDC Ex Port checks the FDC port
When the Device Check ends, touch "Next" on the screen or press the Part Balance [Accomp] button to go to
the next test.
3. Factory Preset Setting
The following display will appear:
Touch "Go" on the screen or press Part Balance [Accomp] to start the loading of the Factory Preset Setting
in the internal memory.
For not loading the Factory preset setting in the memory, touch "Skip" on the screen.
4. Buttons and LEDs check
All the LEDs light up and the following display appears:
A piano sound should be heard and the LED corresponding to each pressed button turns off.
When you press the [Metronome], [Song] and [Page] buttons, the Beat indicators turn off.
When you press the buttons without LEDs the relative name indicated on the LCD disappears.
NOTE: If you press the Part Balance [Accomp]button first, you will go on to the following test. Once you
begin the checking process for this kind of test, it is not possible to go to the following one before checking
all the buttons. Press the Part Balance [Accomp] button in the end and you will go on to the following test.
5. Speaker Panning and Effect Sound check.
The following display will appear:
Press the following buttons to check the effects and the pannings:
BUTTON OUTPUT
Pop Sound PIANO 1 Direct sound
Piano Style PIANO 1 CHORUS sound
Ballad PIANO 1 REVERB sound
Rock PIANO 1 RESONANCE sound
Oldies Sine wave from the LEFT speaker.
Country Square wave from the RIGHT speaker.
Band/Swing Sine wave from both speakers.
Once the check ends, touch [Next] on the screen or press Part Balance [Accomp] to go on in the test mode.
18

E-600
July, 1999
6. Esp check
The following display will appear:
When you press the following buttons, a corresponding sound will be heard.
BUTTON OUTPUT
Pop Sawtooth wave from the LEFT speaker
Piano Style Triangular wave from the RIGHT speaker
Note: You can adjust the output volume by rotating the Rotary Encoder.
You can not change the volume by moving the [volume] slider, instead.
7. A/D Check
The following display will appear:
When you press the pedals or move the potentiometers indicated on the display, the value will change from 0
to 9 and you will hear a Sine wave per time, except for the values "0" and "9". At value "0", you will hear no
sound; at value "9" you will hear a Metronome sound. With the [Balance] potentiometer and the Bender level
you will hear no sound even at value 5. At the end of the test, when the value has increased from "0" to "9",
the asterisk mark will disappear.
Once this check ends, you can go on to the following step.
8. Touch Panel A/D Check
The following display will appear
Move the Touch pen from the upper side of the Touch panel to the lower one and make sure that the values of
the "X= " change from "0" to "9" and that the asterisk has disappeared. Then move the pen from the right side
of the Touch Panel to the left one and make sure that the values of the "Y= " change from "0" to "9" and that
the asterisk has disappeared. When both the asterisks have disappeared, you can go on to the following step.
9. Encoder Check
The following display will appear:
Rotate the encoder in clockwise direction and make sure that the value increases until 30.
Then rotate the encoder in anticlockwise direction and make sure that the value goes back to 0.
When the value will be back to "0", you can go on to the following step.
10. MIDI check
The following display will appear:
ll
MIDI check
Connect the ( In / Out ) MIDI sockets by a MIDI cable and check that the test output is "OK". If you take away
one of the two plugs of the cable, the result is " -- ", meaning "Connection failed". If the MIDI cable has been
connected properly but the test result is not " OK ", there must be some functional problems in the board.
ll
MIDI Thru
Always during the MIDI check, take another MIDI cable and connect one of its plugs to the E-600 "Thru "
socket left and the other one to a MIDI " In " socket of another instrument. By playing the keyboard of the
E-600, you should hear the notes played from the other instrument. This proves that the E-600 Thru socket
works properly.
11. Microphone check
The following display will appear:
Make sure that the writing [Input Low] appears when there are no input sounds or when their level is low or
when the Level potentiometer is at minimum.
Make sure that the writing [Input High] appears when the input sounds level is high.
After finishing this test, touch "Next" on the screen or press the Part Balance [Accomp] button to go on to the
following test.
19

E-600 July, 1999
12. FDD check
The following display will appear:
To make this test you need 3,5" disks (HD or DD kind), formatted by E-600.
Note: When you make this test, the data contained in the floppy disk will be damaged.
Insert a 2DD floppy disk, which is write protected and check that the note "2DD Protected" will appear on the
display. Then insert an unprotected 2DD floppy disk and check that the note "2DD:OK" will appear on the
display. In the same way, insert an unprotected 2HD floppy disk and check that the note "2HD:OK" will appear
on the display.
When you insert an unformatted disk the note "Unformatted" will appear on the display
If there are some problems, the writing "NG". will appear on the display.
When this test is completed, touch "Next" on the screen or press the Part Balance [Accomp] button to go on
to the following test.
13. LCD Check
The following display will appear:
Press the One Touch Program [Piano] button and make sure that all the LCD dots lighten (White).
Then press the One Touch Program [Arranger] button and be sure that all the LCD dots turn off (Blue).
After this, press the Part Balance [Accomp] button. The following display will appear:
Notice if the vertical lines are shown clearly.
Then press the following buttons and verify the ON and OFF conditions of the display:
One Touch Program [Piano] : ON ( LCD with lines )
One Touch Program [Arranger] : OFF ( LCD Blue )
At the end of this test, press the Part Balance [Accomp]button to go to the following check
14. LCD Contrast test
The following display will appear:
Rotate the encoder completely and make sure that the number indicated on the dispaly changes from 0 to
9 and that the contrast changes according to the value indicated. Make also sure that the character is
recognizable even at value "0".
At the end of this test, touch "Next" on the screen or press the Part Balance [Accomp] button so as to go
to the following verification.
15. Destination setup
The following display will appear:
Touch the button corresponding to the destination indicated on the Touch Panel or press the corresponding
button, as follows:
Display Destination Button
DOM 100V One Touch Program [Piano]
EXP 230V/240V One Touch Program [Organ]
US 117V One Touch Program [Arranger]
Then touch "Write" on the screen or press the Part Balance [Accomp] button to start the destination setup.
When the setup ends, you will go automatically to the following step.
The following display will appear:
Turn off the instrument to exit the test mode.
20
