rollease acmeda AUTOMATE Pulse 2 Manual

Pulse 2 Hub | Set up Instructions for Android
The Pulse 2 connects to home networks to unlock the luxury of automated shade control. Experience customization with scene and timer
options as well as voice control via Google Assistant and Amazon Alexa.
THE APP ALLOWS FOR:
1. Individual and group control –Group Automate shades by room and conveniently control them accordingly.
2. Remote connectivity - Control shades remotely, whether home or away on a local network or an internet connection.
3. Scene control - Personalize shade control and organize how your shades operate by specific daily events.
4. Timer functionality - Set and forget. Lower, raise and activate shade scenes automatically at the optimal time.
5. Sunrise and Sunset - Utilizing time zone and location, the Pulse 2 can automatically raise or lower Automate shades according to the
position of the sun.
6. Compatible IoT Integrations:
-IFTTT via applets
-Amazon Alexa devices
-Google Home
-Smart Things
GETTING STARTED:
To experience automated shade control through the Automate Pulse 2 app, you will need to have:
•Downloaded the free app via the Google Play Store.
• Purchased one ormore Hub’s depending on the size of the area you would like to cover.
•Familiarized yourself with the app navigation guide below.
•Created a Location then pair hub to that location. Our step by step guide will explain in more detail.
WI-FI HUB TECHNICAL SPECIFICATIONS:
•Radio Frequency range: ~60 feet (no obstructions)
•Radio Frequency: 433MHz
•Wi-Fi 2.4GHz or Ethernet Connectivity (CAT 5)
•Power: 5VDC
•For Indoor Use Only
BEST PRACTICES FOR PAIRING THE HUB ON YOUR WIFI NETWORK:
•Only pair your hub via 2.4GHZ Wi-Fi (Lan Pairing is not supported) Do not connect ethernet cable to the hub.
•The Hub must be within signal range ofboth theautomated shades and 2.4GHZ Wi-Fi.
•Ensure 5Ghz are disabled on your Wi-Fi router or disconnected from your mobile device.
•Check your phone and confirm if the Home App has been installed.
• Environments with multiple WAPs (wireless access points) may need all but the main router temporarily disabled.
•Security settings onyourrouterandonphonemay need to be temporarily disabled.
•Place the Hub in a horizontal position. (avoid metal enclosures / ceiling or any other locations that may affect the range.
•Before starting the Hub installation, make sure that all your shades are functional and charged. You can test the shade using a remote
control or pressing a “P1” Button on the motor head.
•In case of range issues, it is recommended you deploy the antenna or reposition the hub in your installation.
•Add additional repeaters if is required (Only two per Hub).
CAPABILITIES:
•Motors per Hub:30
•Locations per account:5
• Hub’s per location: 5
•Rooms per Location:30
•Scenes per Location: 20 (100 per location)
•Timers per Location: 20 (100 per location)

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
WHAT’S IN THE BOX?
UNPACKING THE HUB 2.0:
APP NAVIGATION
Home Page
Home: Shows the main control screen with rooms and devices tabs
Favorites: Allows you to create a list of your favorite Devices or Scenes
Scenes: Show a list of scenes created
Timers: Show a list of scene timers
App Version: 2.0.(13)
Menu
Rooms
Locations
Devices
Home
Favorite
Scenes
Timers
A.
AutomatePulse2
Hub
B.
USB Power
Supply
C.
32” (80cm) USB
PowerCord
E.
Quick Start Guide
D.
Ethernet cable
1. Unpack thePulse 2.
2. Check the Box Contents.
5. Plug the Power Supply
into the outlet and place
the Hub in a central
location in your home.
3. Plug the USB Cord
into the Power Supply
4. Connect the Micro
USB end into the back
of the Pulse 2

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
SETTING UP:
QUICK START SETUP:
NOTE: You cannot pair the hub via the Ethernet cable connection, Wi-Fi only via a 2.4GHZ connection.
Refer to troubleshooting for more information.
STEP 1 –Quick Start
Please power up the Hub then
follow the Quick Start guide.
Select “YES”.
STEP 2 –Add Location
You can create a name for your
location or select “Next” to use
the Default “My House”.
Email
l
Email
l
Email
l
STEP 3 –Sign Up
Creating an account will require
an email address and password.
STEP 4 –Sign In
If you already have an account,
Log in with your account
information.
STEP 1 –Open the App
Open the Automate Pulse 2
mobile App.
STEP 2 –Sign Up
If required, create a new
account. Select Sign Up on the
Top Right corner of the screen.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 3 - Configure a Hub
Wait as the App creates a Location
for the Hub.
STEP 4 –Time Zone
Select your Time Zone. This is
important for timers to operate
correctly. Ensure daylight savings is
enabled.
STEP 5 - Configure a Hub
Make sure that your current Wi-Fi
Network aligns with the network you
want the hub connected to.
STEP 6 - Configure a Hub
Open your Wi-Fi settings and connect to
the appropriate RA-PULSE-xxx network
that corresponds with your hub.
STEP 10 - Wi-fi Network
Hub
Enter your correct Wi-Fi networks
password.
STEP 7 - Configure a Hub
Open your Wi-Fi settings and
connect to the appropriate
RA-PULSE-xxx network that
corresponds with your hub.
STEP 8 - Configure a Hub
In the app, verify you are connected
to your RA_PULSE-xxxx network,
press ‘NEXT’ to pair the hub.
STEP 9 –Wi-fi Network
Verify if your Wi-Fi network is listed.
If it is not, type in the correct
network name.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 15 - Pairing Completed
The Hub is ready to be used! Press
‘DONE’ to start the Application.
STEP 11 - Configure a Hub
Wait while the hub connects to your
Wi-Fi Network.
STEP 12 - Configure a Hub
Before selecting ‘NEXT’ verify the
network changes over to your home
Wi-Fi network.
STEP 13 - Configure a Hub
Select ‘NEXT’ to continue the setup
process.
STEP 14 - Finalizing
Wait as the hub finalizes the setup.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
ADDING ADDITIONAL HUB TO EXSITING LOCATION:
STEP 5 - Configure a Hub
Make sure that your current Wi-Fi
Network aligns with the network you
want the hub connected to.
STEP 6 - Configure a Hub
Open your Wi-Fi settings and connect
to the appropriate RA-PULSE-xxx
network that corresponds with your
hub.
STEP 7 - Configure a Hub
Open your Wi-Fi settings and
connect to the appropriate
RA-PULSE-xxx network that
corresponds with your hub.
STEP 8 - Configure a Hub
In the app, verify you are connected to
your RA_PULSE-xxxx network, press ‘NEXT’
to pair the hub.
STEP 1 - Configure a Hub
Select the location desired to add a
new hub to.
STEP 2 –Add a New Hub
Click on “ADD NEW HUB” to
start the process to setting up
your HUB on the App.
STEP 3 - Configure a Hub
Follow on the screen
instructions and click on the
button to connect to NEW
HUB.
STEP 4 –Time Zone
Select your Time Zone. This is important
for timers to operate correctly. Ensure
daylight savings is enabled.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 12 - Configure a Hub
Before selecting ‘NEXT’ verify the
network changes over to your home
Wi-Fi network.
STEP 9 –Wi-fi Network
Verify if your Wi-Fi network is listed.
If it is not, type in the correct
network name.
STEP 10 - Wi-fi Network
Enter your correct Wi-Fi networks
password.
STEP 11 - Configure a Hub
Wait while the hub connects to your
Wi-Fi Network.
STEP 13 - Configure a Hub
Select ‘NEXT’ to continue the setup
process.
STEP 14 - Finalizing
Wait as the hub finalizes the setup.
STEP 15 - Pairing Completed
The Hub is ready to be used! Press
‘DONE’ to start the Application.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
CREATING A LOCATION:
ADDING A CUSTOM HOME IMAGE:
STEP 1 –Custom Home Image
From the main menu select the
location you wish to change the home
image for.
STEP 2 –Custom Home Image
Select “Change Location Image”.
STEP 3 –Custom Home Image
Choose to “Select Image from
Library”.
STEP 4 –Custom Home Image
You will need to Allow Pulse 2 access
to import a picture, Select the image
and crop as desired.
STEP 1 - Add Location
Open the App from the home
screen and select the menu
button, click “ADD NEW
LOCATION”.
STEP 2 –Add Location
Select the default location and
update the location name if
desired. Select Ok then Done.
STEP 3 –Toggle Location
If you have setup multiple locations,
select the ‘Location’ icon in the upper
right corner to toggle between
locations.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
HOW TO PAIR A MOTOR TO THE APP:
During the setup, the hub may need to be moved room to room during the pairing process.
We recommend setting up your motors with a remote prior to syncing with the App.
v
STEP 5 –Pair a motor
Choose your pairing method: ‘PAIR USING
HUB’ or ‘COPY FROM REMOTE’.
*We recommend copying from a remote for
the best results.
STEP 1 –Pair a motor
On the home screen select ‘DEVICES’
then select the ‘Plus’ icon to add a
new shade.
STEP 2 –Pair a motor
From the list select the HUB you wish
to pair the motor too.
STEP 3 –Pair a motor
Select which device type best
represents your shade.. (NOTE this
can’t be changed later)
STEP 4 –Pair a motor
Make sure the shade device is
plugged in or ready to be paired and
select ‘NEXT’.
STEP 6 –Pair with Remote
Make sure the remote is tuned to the
shade’s individual channel (not Ch 0).
Remove the remote battery cover and press
the upper left P2 button Twice, then “Next”.
STEP 7 –Pair with HUB
Press and hold the P1 button on the motor
head ~2 seconds. The motor will jog up and
down once and you will hear one audible
beep. Press ‘PAIR’ on the app screen.
STEP 8 –Pair a motor
Wait as the app searches for the new
device.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
HOW TO OPERATE SHADES:
STEP 9 –Pair a motor
If the pairing process was successful, Press
‘NEXT’ to finalize pairing.
If pairing fails, try the process again.
STEP 10 –Shade Details
Input a Device Name to customize
your treatment name. Press “Done”
to complete setup.
STEP 11 –Pair a motor
The “New Device” will now be added
to the ‘DEVICE’ tab.
STEP 12 –Shade Ready
Shade is now ready for operation
from Pulse 2 App.
STEP 3 - Close a shade
Open the shade by pressing the “Up
arrow” icon or scrolling the black line
to the top.
STEP 1 –Operate Shade
Select the device that you wish to
operate.
STEP 2 - Open a shade
Close the shade by pressing the
“Down Arrow” icon or scrolling the
black line to the bottom.
STEP 4 - Move a shade
Move the shade to the position
desired by scrolling the line to any
position. Press the stop button to stop
the shade anytime.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
DEVICE INFORMATION:
HOW TO CREATE A ROOM:
STEP 4 –Create a Room
Select ‘ROOM PICTURE’ to select an
icon to represent the room.
STEP 1 –Create a Room
Once the Shade is paired to the App.
Click ‘ROOMS’ tab. Select the “Plus”
icon to add a new room.
designation, return to the home
STEP 2 –Create a Room
Select the ‘ROOM NAME’ to enter the
desired room name.
STEP 3 –Create a Room
Enter the Room Name and click “OK”.
Device Information
From the device window if you select
“Edit” you can see all the motors
device settings and the device
information.
Battery Device Information
Top left corner, there is the battery
icon –This icon has 3 levels. Full,
Medium & Low.
Signal Device Information
Top right there is the Signal Strength
icon. 4 Levels. Excellent, Satisfactory,
Low & No Signal.
Refer to Page 18 for more information about the battery status and Signal Strength Status

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 5 –Create a Room
Select the appropriate icon for the
Room.
STEP 6 -Add Shades to a Room
Select ‘ROOM DEVICES’ to add a new
device to the room.
STEP 7 -Add Shades to a Room
Select the devices you wish to be
added to the room.
STEP 8 -Add Shades to a Room
Press ‘DONE’ to complete the setup of
the room.
STEP 9 -Add Shades to a Room
Wait for the App to conclude the
process of room set up.
STEP 10 –Operate a Room
Select the Room to operate All shades
that have been added to the room at
the same time.
STEP 11 –Operate a Room
Operate all shades in the Room with
the three buttons options available:
Open, Close and move 50%.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
HOW TO CREATE A SCENE:
You can create scenes to set a treatment or group of treatments to specific heights or capture all the devices that you previously moved to the desired position even from the
App or using a remote.
STEP 1 –Create a Scene
Select Scenes then, ‘Add New Scene’
to begin programming your desired
scene.
STEP 2 –Create a Scene
Select the ‘SCENE NAME’ to customize
the name of your scene.
STEP 3 –Create a Scene
Input your scene name.
STEP 4 –Create a Scene
Select ‘SCENE PICTURE’ to customize
the icon for your scene.
STEP 8 –Manual Scene Creation
Choose custom heights (by %) or set
open/close for all selected window
treatments.
STEP 5 –Create a Scene
Select the icon that represents your
scene.
STEP 6 –Automatic a Scene
Automatic scene creation Set all devices
with the remote to desired position. Then
use the “Capture All Devices” button to
create a scene of all current shades are
positions. Select “Done”.
STEP 7 –Manual Scene Creation
Or Select ‘UPDATE SCENE DEVICES’
to add devices into the Scene.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
PROGRAMMING TIMERS:
You can program timers to trigger the specific operation of your shades and scenes at your desired times throughout the day.
STEP 10 –Activate a Scene
To activate your custom scene just
press ‘GO’ next to the desired scene
name.
STEP 9 –Manual Scene Creation
Repeat for all shade in that scene. Set
the shade height percentage if
necessary. Select ‘DONE’ to create
your scene.
STEP 1 –Create a Timer
Select ‘TIMERS’ then, ‘ADD NEW
TIMER’ to program your timer.
STEP 2 –Create a Timer
Select ‘TIMER NAME’.
STEP 3 –Create a Timer
Input your desired timer name.
STEP 4 –Create a Timer
Select ‘TIMER ICON’ to add an icon
for your timer.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 5 –Create a Timer
Select the appropriate icon for the
Timer.
STEP 6 –Create a Timer
Select the ‘TIMER SCENE’ to choose
the scene you wish the timer to
activate.
STEP 7 –Create a Timer
In the Scene list, add the scenes you
wish to operate.
STEP 8 –Create a Timer
Set the time you wish the timer to
trigger shade control.
STEP 9 –Create a Timer
Select the days you wish the timer to
operate.
STEP 10 –Create a Timer
If you prefer, track your timer
through the Sunrise/Sunset functions.
Select ‘DONE’ to finalize your timer.
STEP 11 –Enable /Disable Timer
Your timers can be manually enabled
and disabled by toggling the switch
for each timer.
STEP 12 –Pause/Un-Pause Timer
Your timers can be paused and un-
paused to switch all timers on and off
at the same time.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
HOW TO CREATE FAVORITE:
HOW TO ADJUST LIMITS:
STEP 3 –Setting Limits
Modify the Top or Bottom position of
the Device as desired
STEP 4 –Setting Limits
Select the ‘Top Position’ to change
the upper limit of your shade. Press
‘OK’ to continue
STEP 1 –Adjust Limits
Select the device you want to adjust
the limits on.
STEP 2 –Adjust Limits
Select ‘EDIT’ in the top right to open
the shades settings page.
STEP 1 –Create a Favorite Device
Select the “Plus” icon to add a
favorite device to your “Favorite”
STEP 2 –Edit a Favorite Device
Select “EDIT”in the upper right
corner to remove the favorite device
from your screen.
STEP 3 –Create a Favorite Scene
Select the “Plus” icon to add a
favorite scene to your “Favorite”
STEP 4 –Create a Favorite Scene
Select ‘EDIT’ in the upper right corner
to remove the favorite scenes from
your screen.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
STEP 5 –Setting Limits
To move your shade a little bit, press
the arrow buttons or slide the double
arrow button. Press ‘SET TOP
POSIITION’ to save.
STEP 6 –Setting Limits
The app will configure the new top
position.
STEP 7 –Setting Limits
Press the “Bottom Position”to change
the lower limit of your shade. Press
‘OK’ to continue.
STEP 8 –Setting Limits
To move your shade a little bit, press
the arrow buttons or slide the double
arrow button. Press “SET BOTTOM
POSIITION”to save.
STEP 9 –Setting Limits
The app will configure the new
Bottom Position.

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
HOW TO SHARE THE HUB:
STEP 1 - Share a Hub
In the ‘Add a Hub’ Screen, it is
possible to connect to a shared hub.
STEP 2 - Share a Hub
The HUB must have been shared
from another account.
STEP 3 - Share a Hub
The shared Hub will be listed on the
shared Hubs list to be added.
STEP 4 - Share a Hub
After it is added, the shared hub will
appear under the Location Settings it
was added to with a red ‘S’

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
LED STATUS INDICATION:
COLOR
RESPONSE
STATUS
Blue LED blinks one time a second:
(On for 250ms and off for 850ms).
AP Mode (Pairing Mode)
Blue LED short blinks five times a second:
(On for 100ms and off for 100ms).
Firmware Updating
Blue LED long blinks two times a second:
(On for 250ms and off for 250ms).
Connected to Wi-Fi (Paired
without Internet)
Blue LED short blinks two times a second:
(On for 100ms and off for 500ms).
Pulse received configuration
via the app (Before reset after
Pairing Mode)
Blue LED is Solid
Connected to Internet (Paired)
Red LED long blinks four times a second:
(On for 250ms and off for 250ms).
Reset Button Pressed
(Paperclip Needed)
-Red LED short blinks four times a second:
(On for 100ms and off for 150ms).
Network Disconnected (Paired
without Wi-Fi)
Red LED is solid
Factory Reset Initiated (User
can release reset button)
-Green LED blinks 5 times for one second:
(On for 100ms and off 100ms).
HomeKit Identification
Re-provisioning Initiated
(User can release P button).
Green LED is solid
LED is Off
Hub is Offline

rolleaseacmeda.com
© 2020 Rollease Acmeda Group
MEANING OF ICONS:
App Screen
Icon
MEANING
STATUS
Signal
Strength
Icons
•Excellent Greater than -89
•Satisfactory Between -96 to -89
•Low Between -102 to -97
•No Signal Between -102 to -97
Battery
Percentage
Icon
3 Levels of Battery
Full 100-70%
Medium 69-11%
Low 10% or less (and motor
starts beeping)
Pop up
Motor Offline
Pop up
reminder
The motor is offline, and the control
device is not on the same network.
Motor Offline
The motor is offline, and the control
device is not on the same network.
Greyed out
Icons
Signal or Battery Icons being greyed
out when the motor is offline, it
displays the last known values
