Rollei Sunglasses Cam 100 User manual

2
Dear Customer:
Congratulations on purchasing a high quality Rollei product. You have
chosen a modern Sunglasses Cam with excellent technical equipment
and related accessories that is particularly easy to use. Please read all the
instructions carefully and thoroughly. Pay particular attention to all safety
instructions.
You have a two year warranty on the device.
If the Sunglasses Cam should ever break down, you will need the enclosed
warranty card and your purchase receipt. Store them carefully with the
operating instructions. When passing the device on to a third party, be sure
to include the instruction manual.
1. Package Contents
Unpack the Sunglasses Cam carefully and check that all the items listed below are
included:
1. Rollei Sunglasses Cam
2. 4 GB microSD memory card, including SD card adapter
3. USB cable
4. 2 additional interchangeable lenses
5. Cleaning cloth
6. Bag
7. Warranty and service documents
Rollei Sunglasses Cam 100

3
2. Table of Contents
1. Introduction and Package Contents 2
2. Table of Contents 3
3. Notes Regarding Risks, Safety and Warnings 4
4. Welcome to Your Sunglasses Cam 7
Front view 7
Controls 7
Changing the lenses 8
5. Descriptions of Functions 9
5.1. Inserting a memory card 9
5.2. Charging the battery 10
5.3. Switching the Sunglasses Cam on and off 11
5.4. Setting the date and time 12
5.5. Changing the settings 12
5.6. Resetting the Sunglasses Cam 14
5.7. Connecting to a computer 15
6. Conformity 16
7. Maintenance 17
8. Disposal 17
9. Technical Data 18
10. Warranty and Service 19
www.rollei-actioncam.com

4
3. Notes Regarding Risks, Safety and Warnings
Handling the Sunglasses Cam and its accessories improperly poses a risk to your-
self and others, or the Sunglasses Cam can be damaged or destroyed. Therefore,
please read and strictly observe the following notes regarding risks, safety
and warnings.
Purpose
• ThisSunglassesCamcontainsavideocamerathatisintendedforrecording
video clips. It is designed for personal use and is not suitable for commercial
use.
Risks to children and persons with limited abilities for using
electronic devices
• TheSunglassesCam,itsaccessoriesandpackagingarenottoysforchildren.
Keep children away from them. Among other things, there are risks of electric
shock, poisoning and suffocation.
• TheSunglassesCamanditsaccessoriesmaynotbeusedbychildrenandper-
sons with limited ability to operate devices. The Sunglasses Cam may be used
only by persons who are physically and mentally able to use them safely.
Risk of electric shock due to moisture and humidity
• TheUSBcableandtheUSBpoweradapter(notincluded)mustnotbeexposed
to dripping or splashing water. In addition, containers filled with liquids, such
as vases or glasses, must not be placed on them or in their immediate vicinity.
There is a risk of fire and electric shock.
• DonotchargetheSunglassesCamnearwater.Thereisariskoffireandelectric
shock. Do not charge the Sunglasses Cam in areas with high levels of humidity,
steam, smoke or dust. There is a risk of fire and electric shock.
Rollei Sunglasses Cam 100

5
Electrical hazard
• IfforeignobjectsoraliquidhasenteredtheSunglassesCam,turnitoff.Let
everything dry thoroughly. Otherwise, there is a risk of fire or electric shock.
• IfthehousingoftheSunglassesCamhasbeendamaged,turnthecamoff.
Otherwise, there is a risk of fire or electric shock.
• TheSunglassesCammustnotbetakenapart,modifiedorrepaired.
There is a risk of fire and electric shock.
Heat damage – fire hazard
• DonotplacetheSunglassesCaminalocationwherethetemperaturemayrise
significantly(e.g.inacar).Thecaseorinternalpartscouldbedamagedasa
result, which can in turn cause a fire.
• DonotwraptheSunglassesCaminanythinganddonotplaceitontextiles.This
could cause heat to build up in the Sunglasses Cam, whereby the housing can
deform and pose the risk of fire.
Risks due to the use of the lithium-ion battery
Thebatteryisintegratedinthedeviceandcannotbereplaced.Thereisanexplosi-
on hazard if the battery is improperly removed.
Injuries and property damage
• DonotusetheSunglassesCamwhilewalkingordriving.Youcouldtriporcause
a traffic accident.
• Donotplaceasourceofnakedflame,suchasalightedcandle,onornearthe
device.
• Damagetotheelectronicsorthecasethathasbeencausedbyexternal
influences such as impacts, dropping, or similar are not covered by the warranty.
Therefore repair or replacement in such cases must be paid for by the customer.
www.rollei-actioncam.com

6
Notes regarding the Sunglasses Cam
• TheSunglassesCamissuitableforuseonlyinmoderateclimates.
• TheRolleiSunglassesCamisaClass1opticaldevice.
The protective lenses provided are not suitable for looking directly at the sun.
Please observe the cleaning instructions in Section 7 on page 17.
Rollei Sunglasses Cam 100

7
4. Welcome to Your Sunglasses Cam
4.1. Front view
Video cameraOn/Off/Record
Reset button
USB port
Power LED
Memory card slot
Working LED Microphone
4.2. Controls
www.rollei-actioncam.com

8
4.3. Changing the lenses
Youcanchoosewhichoftheincludedlensesyouwanttouse.Removeanalready
installed lens with a quick downward pull. Then place the new lens in the guides
on the left and right and push it as shown below until it clicks into place.
Rollei Sunglasses Cam 100

9
5. Descriptions of Functions
5.1. Inserting a memory card
Before you can record videos with the Rollei Sunglasses Cam, you need to insert
a microSD or microSDHC memory card.
To do this, open the cover of the memory card compartment on the bottom of the
rightearpieceInsertthemicroSD/SDHCmemorycardintothecardslot(seethe
illustration)andpushthememorycardinuntilitclicksintoplace.Thenclosethe
cover of the card compartment.
To remove the memory card, press it once again; it will then pop out slightly from
thecompartment.Whenthememorycardisfull,theblue“Record”LEDlights
up for about 2 seconds when you turn on the cam; then the Sunglasses Cam will
switch off.
Note:
•microSDandmicroSDHC
memory cards up to 32 GB are
supported.
www.rollei-actioncam.com

10
5.2. Charging the battery
To charge the built-in lithium-polymer battery, you must connect the Sunglasses
Cam to the USB port of a computer or a power adapter with a USB output using
the mini-USB connector.
Open the cover of the mini-USB port on the bottom of the right earpiece and insert
the included mini-USB cable. Once you connect the other end of the USB cable to
acomputer,chargingbegins.Duringcharging,aredindicatorLEDontheinsideof
therightearpiecelightsup.Whenthebatteryisfullycharged,theindicatorLED
turns green.
Thechargingtimeforafullydischargedbatteryisapprox.1-2hours(whenusinga
USBconnectionwith500mA).Therstchargingprocesscantakeupto4hours.
AbatterychargewillletyouusetheSunglassesCamforapproximately60minutes.
Rollei Sunglasses Cam 100

11
5.3. Switching the Sunglasses Cam on and off
ToturntheSunglassesCamon,presstheOn/Offbuttonbriey.TheindicatorLED
on the inside will then go green and you will hear 4 beeps.
When the Sunglasses Cam is turned on, video recording automatically starts.
Duringrecording,theblueRecordLEDalsoashes.
IfyouturnontheSunglassesCamwithnocardinstalled,theindicatorLEDwillgo
red briefly and the Sunglasses Cam will switch itself off after a long beep.
To stop recording and shut down the Sunglasses Cam, press and hold the On/Off
button for about 3 seconds. The current video recording will be saved, then the
Sunglasses Cam will switch off.
