Brief Instructions

22
Thank you for buying this Rollei digital camera.
Please read these instructions carefully to fully understand the different features of your
camera.
Check whether the contents of your package is complete. Should this not be the case, consult
your camera dealer or contact an authorized Customer Service Center.
• Camera
• Size AA alkaline batteries (4x)
• Video cable
• Wrist strap
• Camera case
• USB cable
• Software on CD-ROM:
USB drivers for Windows®98/ Windows®98 Second Edition/Windows 2000 Prof/Me
USB drivers for Mac OS 8.6/9/9.0.2/9.0.4
Windows®/ Macintosh (PDF) Manual
Adobe PhotoDeluxe 4.0 Family Edition,
CD-ROM for Windows®
Adobe PhotoDeluxe 2.0 CD-ROM for Macintosh
• Documentation (hard copy)
Warranty Card
This symbol confirms conformity of the camera with European Union
regulations governing electrical equipment. CE stands for Conformité
Européenne (European Conformity).
BEFORE YOU START…

3
DESCRIPTION OF PARTS
Flash* Lens* Terminal
cover
CAMERA BODY
Strap eyelet
LCD screen*
Card slot
Four-way toggle
MENU button
ENTER button
DISPLAY button
Viewfinder
eyepiece*
Focus lamp
(green)
Flash ready
lamp
(orange)
ON/OFF switch
Shutter
release
Control
dial Data monitor
Viewfinder window
Self-timer lamp
* Do not touch!
Flash
sensor*

4
DESCRIPTION OF PARTS
Tripod socket 1/4“
DESCRIPTION OF PARTS
TERMINALS
Power supply
BOTTOM PLATE
Battery-compartment
cover
* The number of images remaining can only be approximate because it varies with JPEG
compression which is a function of subject characteristics.
No. of images remaining*/
No card
Battery condition Self-timer
Flash mode
DATA MONITOR
The diagram below shows all the data that can be displayed on the data monitor.
Image size
Video out USB connector

5
INSTALLING THE DRIVER SOFTWARE
Installing the driver software
To install the drivers for Windows 98 / Windows 98 SE / Windows 2000 Prof. / Windows,
proceed as follows:
3
2
1Insert the installation CD-ROM into your CD-
ROM drive.
Double-click on the Setup icon.
The Setup dialog box appears. Please wait.
When the “Welcome” dialog appears,
click [Next].
When the Software License Agreement box
appears, read it carefully and decide what to
do:
[Back]: to preceding box.
[Yes]: to accept.
[No]: to reject and exit.
4
5

6
6
7
When the Start Copying Files box appears,
select:
[Next]: to start installation.
[Back]: to go back to the previous dialog box.
[Cancel]: to exit.
When the Setup Complete box appears, click
[Finish] to complete installation.
INSTALLING THE DRIVER SOFTWARE

7
2
1
3
The following steps apply equally to OS 8.6 and OS.9
Choose the appropriate driver for your
system.
Start the installation program by double-
clicking.
When the Welcome box appears, click
[Continue].
INSTALLING THE DRIVER SOFTWARE

4
5
7
6
To start installation, click [Install].
Read the warnings, then click on [Continue].
If necessary, you may quit the program by clicking
[Cancel].
INSTALLING THE DRIVER SOFTWARE
Installation has been completed successfully.
To initial the newly installed software, restart your
computer (suggested) or click [Continue] if you
wish to continue installing.
Please take the detailed manual from the Acrobat Reader file on the
software CD.
Technical specifications are subject to alterations
