Rolls PS16 User manual

Owners Manual
Rolls Corporation
Salt Lake City, UT
6/02
LIMITED WARRANTY
This product is warranted to the original consumer purchaser to be
free from defects in materials and workmanship under normal installation, use
and service for a period of one (1) year from the date of purchase as shown on
the purchaser’s receipt.
The obligation of Rolls Corporation under this warranty shall be
limited to repair or replacement (at our option), during the warranty period of
any part which proves defective in material or workmanship under normal
installation, use and service, provided the product is returned to Rolls Corpora-
tion, TRANSPORTATION CHARGES PREPAID. Products returned to us or to
an authorized Service Center must be accompanied by a copy of the purchase
receipt. In the absence of such purchase receipt, the warranty period shall be one
(1) year from the date of manufacture.
This warranty shall be invalid if the product is damaged as a result of
defacement, misuse, abuse, neglect, accident, destruction or alteration of the
serial number, improper electrical voltages or currents, repair, alteration or
maintenance by any person or party other than our own service facility or an
authorized Service Center, or any use violative of instructions furnished by us.
This one-year warranty is in lieu of all expressed warranties,
obligations or liabilities. ANY IMPLIED WARRANTIES, OBLIGATIONS, OR
LIABILITIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICU-
LAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE ONE YEAR
DURATION OF THIS WRITTEN LIMITED WARRANTY. Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
IN NO EVENT SHALL WE BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS
OR ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, WHATSO-
EVER. Some states do not allow the exclusion or limitation of special,
incidental or consequential damages so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
PS16
POWER CENTER
Personal Monitor
Power Supply
Signal Distribution
PS16 POWER CENTER
The PS16 supplies the DC power and distributes
the Monitor signal to up to ten of the PM50s, the
PM50sOB, and the PM350 units. This
dramatically increases efficiency and eliminates
the need for multiple wall-warts and adapter
cables.
• Supplies power for up to ten PM50s,
PM50sOB, and PM350 units.
• Directly supplies a monitor signal to the
above listed units.
• Unbalanced 1/4" and TRANS
FORMER-balanced XLR inputs.
power status
PS16
+
-
LINE INPUTS
unbal balanced
PERSONAL MONITOR POWER CENTER
OUT 1 OUT 2 OUT 3 OUT 4
WARNING: THIS UNIT MAY BE DAMAGED IF THE LIGHT IS OFF WHEN POWER IS APPLIED - IMMEDIATELY UNPLUG ALL OUTPUTS. USE TIP-RING-SLEEVE PLUGS ONLY.
12VAC
www.rolls.com
READ THIS MANUAL FOR IMPORTANT OPERA- TION INSTRUCTION. TIP-RING-SLEEVE PLUGS ARE REQUIRED FOR THE OUTPUTS OF THIS
UNIT.

SPECIFICATIONS
Input Power: 12 VAC, 700 mA
Output Power: 12 VDC on the Ring terminal of each OUT jack.
Size: 3.125" x 3.125" x 1.25"
Weight: 1 lb (.45 Kg)
1
ROLLS CORPORATION
5968 S 350 West
MURRAY UT 84107
1
PS16.SCH A
22 MAY 2002
Document Number:
Date:
Rev:
Sheet of
PS16 PM POWER CENTER
Ba
IN 9-15 VAC/VDC
HIGH OUT
PM SERIES OUTS
LOW OUT
J1
PHONE 1/4
C7
1U
J2
PHONE 1/4
J3
PHONE 1/4
J4
PHONE 1/4
2
3
1
J10
JAPDC
D5
LDRR
R1
4.7K
D1
1N4001
D2
1N4001
D3
1N4001
D4
1N4001 C17
2200UF 16V
J2
PHONE 1/4
1 2
3
J11
XLR JACK M T1
XFMR AUDIO
I
1
G
2
O3
U1
7812
SCHEMATIC
INTRODUCTION
Thank you for your purchase of the PS16 Personal Monitor Power Center.
The PS16 supplies the DC power and distributes the Monitor signal to up
to ten of the PM50s, the PM50sOB, and the PM350 units. This dramati-
cally increases efficiency and eliminates the need for multiple wall-warts
and adapter cables.
The power AND monitor signal are carried from each PS16 output using
an ordinary 1/4" stereo cable to the Monitor input of the PM50s, sOB, and
350.Using stereo “Y”adapters, up to ten of the Personal Monitor Amplifi-
ers may be daisy-chained.
NOTE: Older PM50s and PM50sOB units may need
a slight modification in order to operate with the
PS16. Any PM50s or PM50sOB WITHOUT a
ground lift jumper and mono/stereo jumper will need
this modification. Call the factory at [phone]
for details.
FEATURES
- Supplies power for up to ten PM50s, PM50sOB, and PM350 units.
- Directly supplies a monitor signal to four of the above units, indirectly (by
using stereo “Y”adapters) will provide signal for up to ten units.
- Unbalanced 1/4" andTRANSFORMER-balanced XLR inputs.
DESCRIPTION
LINE INPUTS
UNBALANCED:1/4'Tip-Sleeve jack.Connects to a mixer's unbalanced
Monitor or Auxiliary Send.
BALANCED:Transformer isolated
female XLR jack.Connects to a mixer's
balanced Monitor or Auxiliary Send.
12VAC:Connects to the included Rolls
PS12 power adapter.
OUT 1 - 4:1/4"Tip-Ring-Sleeve jacks.
TheTip of the connector contains the
audio signal, the Ring has the 12 volts
DC required to operate the Personal
Monitor devices, and the Sleeve con-
nects to ground.
power
status
PS16
+
-
LINE INPUTS
unbal balanced
PERSONAL MONITOR
POWER CENTER
OUT 1 OUT 2 OUT 3 OUT 4
WARNING:
THIS UNIT MAY BE DAMAGED IF THE LIGHT IS OFF
WHEN POWER IS APPLIED - IMMEDIATELY UNPLUG
ALL OUTPUTS. USE TIP-RING-SLEEVE PLUGS ONLY.
12VAC
www.rolls.com
CONNECTION / OPERATION
•Connect the Send of the mixer to the appropriate Input of the PS16
(balancedorunbalanced).
•Connect the PS12 adapter to the 12VAC input of the PS16.The Power/
Status LED should light.If not, immediately unplug the power as this
indicates a short from the Ring of an Output jack to ground.
•Connect theTIP-RING-SLEEVE STEREO cables from the PS16
Outputs to the PM series Monitor Inputs.Refer to the Personal Monitor
unit owners manual for proper operation of that unit.
FOR APPLICATION DIAGRAMS, VISIT OUR WEBSITE
AT WWW.ROLLS.COM.
