Ronix 4120 User manual

JIGSAW
4120

USER MANUAL 3
SPECIFICATIONS
Model 4120
Power 650W
Voltage 220V
Frequency 50Hz
Max Capacity in Wood 60mm
Max Capacity in Metal 10mm
Orbital Action 4-Position
Bevel Cutting Capacity 0-45Degree
No-load RPM 0-3100 RPM
Weight 2.75kg
Accessories Hex Key 2pc , Wood Blade 2pc
PARTS LIST
On-Off Trigger Lock-On Button
Adjustable
Base Plate
Cutting Blade
Cutting Speed
Adjust Key
Blade Guard

JIGSAW
4
SAFETY INSTRUCTIONS
.FOR YOUR SAFTY
Read all instructions. Failure to follow all instructions listed below
may result in electric shock, re and/or serious injury.
Additionally, the general safety instructions either in the enclosed
booklet or those added in the center of these operating instructions
must be observed.
SAVE THESE INSTUCTION.
- Secure the workplace. A workplace clamped with clamping
devices or in a vice is held more secure than by hand.
- Do not work materials containing asbestos. Asbestos is considered
carcinogenic.
- Always wait until the too; has come to a complete stop before
placing it down. The tool insert can jam and lead to loss of control
over the power tool.
- Do not use a power tool with a damaged power cord. Do not
touch the damaged cord and pull the power plug when the cord
is damaged while working. Damaged cords increase the risk of
an electric shock.
- Connect power tools that are used in the open via a ground
fault circuit interrupter.
- Keep hands away from the cutting area. Do not reach under
the material being cut. Contact whit the saw blade may result
in injury.
- Guide the tool against the workplace only when it is switched
on. Otherwise there may be danger of kickback when the tool
insert jams in the work place.
- Pay attention that the footplate rests securely on the material
while sawing. A jammed saw blade can break or lead to kick back.
- After the cut, switch off the power tool and wait until the saw

USER MANUAL 5
blade has come to a stop before pulling it out of the cut. This
avoids kickback and the tool can be placed down securely.
- Use only undamaged blades that are in proper condition. Bent
or dull saw blades can break or cause kickback.
- After switching off, do not (brake) the saw blade by applying
sideward pressure against it. The saw blade can become
damaged, break or cause kickback.
- Use appropriate detectors to determine if utility lines are hidden
in the work area or call the local utility company for assistance.
CAUTION:
Always be sure that the tool is switched off and unplugged before
catting out any work on the tool.
.INSTALLING OR REMOVING SAW BLADE
CAUTION:
Always clean out all chips or foreign matter adhering to the blade
and/or blade holder. Failure to do so may cause insufcient
tightening of the blade, resulting in a serious personal injury.
Donottouchthebladeortheworkplaceimmediatelyafteroperation;
they may be extremely hot and could burn your skin. Always secure
the family. Insufcient tightening of the blade may cause blade
breakage or serious personal injury.
To install the blade, loosen the bolt counterclockwise on the
blade holder with the hex wrench. With the blade teeth facing
forward, insert the blade into the blade holder as far as it will go.
Make sure that the back edge of the blade ts in to the roller.
Then tighten the bolt clockwise to secure the blade. To remove
the blade, follow the installation procedure in reverse.

JIGSAW
6
NOTE:
Occasionally lubricate the roller.
.HEX WRENCH STORAGE
When not in use, store the hex wrench as shown in the gure to
keep it from being lost.
.ANTI-SPLINTERING DEVICE
For splinter-free cuts, the anti-splintering device can be used.
To install the anti-splintering device, move the base all the way
forward and insert it between the two protrusions of the base.
NOTE:
The anti-splintering device cannot be used when making bevel cuts.
OPRATION
CAUTION:
Always hold the base ush with the workplace. Failure to do so
may cause blade breakage, resulting in a serious injury. Advance
the tool very slowly when cutting curves or scrolling.
Forcing the tool may cause a slanted cutting surface and blade
breakage. Turn the tool on without the blade making any contact
and wait until the blade attains full speed. Then rest the base
at on the workplace and gently move the tool forward along the
previously marked cutting line.
.BEVEL CUTTING
CAUTION:
Always be sure that the tool is switched off and unplugged before

USER MANUAL 7
tilting the base. Raise the dust cover all the way before making
bevel cuts.
With the base titled, you can make bevel cuts at any angle between
0° and 45° (left or right). Loosen the bolt on the back of the base
with the hex wrench. Move the base so that the bolt is positioned
in the center of the cross-shaped slot in the base.
.FRONT FLUSH CUTS
Loosen the bolt on the back of the base with the hex wrench
and slide the base all the way back. Then tighten the bolt to
secure the base.
.CUT OUT
Cutouts can be made with either of two methods A or B.
A) Boring a starting hole
For internal cutouts without a lead-in cut from an edge, pre-drill
a starting hole 12 mm (1/2 in) or more in diameter. Insert the
blade into this hole to start your cut.
B) Plunge cutting
You need not bore a starting hole or make a lead-in if you carefully
do as follows.
1) Tilt the tool up on the front edge of the base with the blade
point positioned just above the workplace surface.
2) Apply pressure to the tool so that the front edge of the base
will not move when you switch on the tool and gently lower the
back end of the tool slowly.
3) As the blade pierces the workplace, slowly lower the base of
the tool down into the workplace surface.
4) Complete the cut in the normal manner.

JIGSAW
8
.FINISHING EDGES
To trim edges or make dimensional adjustment, run the blade
lightly along cut edges.
.METAL CUTTING
Always use a suitable coolant (cutting oil) when cutting metal.
Failure to do so will cause signicant blade wear. The underside
of the workplace can be greased instead of using a coolant.
MAINTENANCE
CAUTION:
Always be sure that the tool is switched off and unplugged
before attempting to perform inspection or maintenance. To
maintain product SAFETY and RELIBILITY, repairs, carbon
brush inspection and replacement.
.ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing them as waste the
power tool, its accessories and packaging materials should be
sorted for environmentally-friendly recycling.
CAUTION:
Wear hearing protection!
The typical hand-arm vibration is below 2.5 m/s 2.
