Ronix 5100 User manual

MITRE SAW
5100

USER MANUAL 1
SPECIFICATION
PART LIST
On/Off SwitchDust Collecting Bag
Carbon Brush
Cover
Movable Guard
Movable Base
Gradient Base
Fence
Handle
Fixed Base
Sliding Base
Holder
Blade
Model 5100
Voltage 220V
Frequency 50Hz
Power 1450W
No load Speed 5000RPM
Blade Diameter 210mm (8")
Cutting Capacity
0°/90°:60x120 mm
45°/90°:60x85 mm
0°/45°:34x120 mm
45°/45°:34x85 mm

MITRE SAW
2
EXAMINE ALL PARTS CAREFULLY
WARNING!
If any part is missing or damaged, do not plug in the mitre saw until you
have replaced the missing or damaged parts.
GENERAL SAFETY RULES
WARNING!
When using electric tools basic safety precautions should always be
followed to reduce the risk of re, electric shock and personal injury.
Read all these instructions before attempting to operate your product.
Save these instructions for future reference.
1) Keep work area clear. Cluttered areas and benches invite injuries.
2) Consider work area environment. Do not expose tools to rain. Do not
use tools in damp or wet locations. Keep work area well lit. Do not use
tools in the presence of ammable liquids or gases.
3) Guard against electric shock. Avoid body contact with earthed or
grounded surfaces.
4) Keep other people away. Do not let others, especially children, not
involved in the work touch the tool or the extension lead and keep them
away from the work area.
5) Store idle tools. When not in use, tools should be stored in a dry
locked-up place, out of reach of children.
6) Do not force the tool. It will do the job better and safer at the rate for
which it was intended.
7) Use the right tool. Do not force small tools to do the job of a heavy
duty tool. Do not use tools for purposes not intended; for example do not
use circular saws to cut tree limbs or logs.
8) Dress properly. Do not wear loose clothing or jewellery, they can be
caught in moving parts. Non-skid footwear is recommended when work-
ing outdoors. Wear protective hair covering to contain long hair.
9) Use protective equipment. Use safety glasses. Use face or dust mask

USER MANUAL 3
if cutting operations create dust.
10) Connect dust extraction equipment. If devices are provided for the
connection of dust extraction and collecting equipment, ensure these
are connected and properly used.
11) Do not abuse the cable. Never pull the cable to disconnect it from
the socket. Keep the cord away from heat, oil and sharp edge.
12) Secure work. Where possible use clamps or a vice to hold the work.
It’s safer than using your hand.
13) Don’t overreach. Keep proper footing and balance at all time.
14) Maintain tools with care. Keep cutting tools sharp and clean for better and safer
performance. Follow instructions for lubricating and changing accessories.
Inspect tool cords periodically and if damaged have them repaired by
an authorized service facility. Inspect extension cords periodically and replace if
damaged. Keep handles dry, clean and free from oil and grease.
15) Disconnect tools. When not in use, before servicing and when
changing accessories such as blades, bits, cutters, disconnect tools
from the power supply.
16) Remove adjusting keys and wrenches. Form the habit of checking to
see that keys and adjusting wrenches are removed from the tool before
turning it on.
17) Avoid unintentional starting. Ensure switch is in “off” position when
plugging in.
18) Use outdoor extension leads. When the tool is used outdoors, use
only extension leads intended for outdoor use and so marked.
19) Stay alert. Watch what you are doing, use common sense and do
not operate the tool when you are tired.
20) Check damaged parts. Before further use of the tool, it should be
carefully checked to determine that it will operate properly and perform
its intended function. Check the alignment of moving parts, binding of
moving parts, breakage of parts, mounting and any other conditions that
may affect its operation. A guard or other part that is damaged should
be properly repaired or replaced by an authorized service centre unless
otherwise indicated in this instruction manual. Do not use the tool if the

MITRE SAW
4
switch does not turn it on and off.
21) WARNING. The use of any accessory or attachment other than one
recommended in this instruction manual may present a risk of personal
injury.
22) Have your tool repaired by a qualied person. This electric tool com-
plies with the relevant safety rules. Repairs should only be carried out by
a qualied person using original spare parts, otherwise this may result in
considerable danger to the user.
.ADDITIONAL SAFETY RULES FOR MITRE SAWS
1) This saw is recommended for cutting wood, non-ferrous metal and
plastic only.
NOTE: The TCG blade comes with this
product is not suitable for cutting metals.
2) Never use a saw blade which is not recommend in this owner’s manual.
3) Do not use saw blades with High speed steel (HSS) or damaged or
deformed.
4) Do not use the saw without guards in position, in good working order
and properly maintained.
5) Replace the table insert when worn.
6) Use only saw blades recommended by the manufacturer and which
conforms to EN847-1.
7) Connect your mitre saw to a dust collecting device (1. D. Ø32mm)
when sawing.
8) Select saw blades in relation to the material to be cut.
9) Check the maximum depth of cut.
10) When sawing long work pieces, always use extra support to provide
better support, and use clamps or other clamping devices.
11) Wear suitable personal protective equipment when necessary, this
could include:
- hearing protection to reduce the risk of induced hearing loss;
- eye protection;
- respiratory protection to reduce the risk of inhalation of harmful dust;

USER MANUAL 5
- gloves for handling saw blades (saw blades shall be carried in a holder
wherever practicable) and rough material.
WARNING!
Ensure that the arm is securely xed when bevelling
Keep the oor area around the machine level, well maintained and free
of loose materials e.g. chips and cut-offs.
Use correctly sharpened saw blades. Observe the maximum speed
marked on the saw blade.
When tted with laser, no exchange with different type of laser is permitted.
Repairs shall only be carried out by the laser manufacturer or an
authorised agent.
Refrain from removing any cut-offs or other parts of the workpiece from
the cutting area whilst the machine is running and the saw head is not
in the rest position.
Ensure that the machine is always xed to a bench, whenever possible.
12) The operator is adequately trained in the use adjustment and
operation of the machine.
13) Provide for adequate room lighting at your workplace or for adequate
lighting of the immediate work area.
14) Refrain from removing any cut-offs or other parts of the workpiece
from the cutting area whilst the machine is running and the saw head is
not the rest position.
15) Never stand on this tool. Serious injuries could occur when this tool
tips over or when coming in contact with the saw blade.
16) Never use the mitre saw near ammable liquids, vapors, or gases.
17) Remove all nails that may be in the workpiece to prevent sparking
that could cause a re.
18) To avoid re or toxic reaction, never use gasoline, naphtha acetone,
lacquer thinner or similar highly volatile solvents to clean the mitre saw.
19) Keep the saw with proper footing on a table to decrease noise and
vibration.
20) Always use the designated carrying handle for transportation.

MITRE SAW
6
SYMBOLS V ............ volts A........... amperes
Hz........... hertz W............. watts
min......... minutes - ....... alternating current
h........... hours Class II Construction
I …………...ON O ............... OFF
min -1 …………………..revolutions per minute
Wear safety goggles
Wear ear protection
Wear a breathing mask
Read and understand instruction manual: to reduce the risk of injury, user
and all bystanders must read and understand instruction manual before using
this product.
Keep hands away from blade: Failure to keep your hands away
from the blade will result in serious personal injury
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Do not dispose of electrical
appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection
systems available. If electrical appliances are disposed of in landlls or
dumps, hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and wellbeing. When replacing
old appliances with new once, the retailer is legally obligated to take back your
old appliance for disposal at least for free of charge. Disposal of discarded
material shall be in accordance with local environmental regulations.
