Ronix 5601 User manual

DUST COLLECTION TABLE SAW
5601

USER MANUAL 1
SPECIFICATIONS
Model 5601
Power 2000W
Voltage 220V
Frequency 50Hz
No-load Speed 5000RPM
Blade size 216x2.4mmx60T
Disc diameter 216mm
Max Cutting Capacity 90° : 60mm
45° : 40mm
Weight 22Kg

DUST COLLECTION TABLE SAW
2
PARTS LIST
17
18
19
20
6
8
9
10
11
1213
14
15
7
5
4
1
23
16
1-Main Switch
2-Overcurrent Protector
3-Handle Wheel
4-Lock Lever
5-Graduation Ruler
6-Cross Cutting Fence Holder
7-Rip Fence Seat
8-Extended Table
9-Rip Fence
10-Suction Pipe Holder
11-Suction Pipe
12-Cutting Plate
13-Circular Saw 216 mm
14-Blade Guard
15-Cross Cutting Fence
16-Dust Bag
17-Riving Knife
18-Blade Guard Seat
19-Blade and Wrench Seat
20-Push Stick

USER MANUAL 3
INTENDED USE
The table saw is a bench top saw, in which tilting the saw blade, the angle
of the cutting plane can change. Wood and plastic and similar materials,
in dimensions as in the instructions for use are capped. Only saw blades
approved by the manufacturer, as specified in the instructions for use,
may be used.
All applications with the device not mentioned in the chapter “Intended
Use”, are considered as improper use.
The table saw must not be used for the following purposes:
- Cutting firewood
- Cutting iron and metals
- Cutting with grinding wheel
- Sanding with sanding sheet
There is a risk of injury.
For all resulting property damage as well as personal injury due to
misuse incurred, the user of the device is liable.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery operated (cordless) power tool.
WROK AREA SAFETY
a) Keep work area clean and well lit. cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
11-Suction Pipe
12-Cutting Plate
13-Circular Saw 216 mm
14-Blade Guard
15-Cross Cutting Fence
16-Dust Bag
17-Riving Knife
18-Blade Guard Seat
19-Blade and Wrench Seat
20-Push Stick

DUST COLLECTION TABLE SAW
4
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
distractions can cause you to lose control.
ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
f) if operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
NOTE the term “residual current device (RCD)” can be replaced by the
term “ground fault circuit interrupter (GFCI)” or “earth leakage circuit
breaker (ELCB)”.
PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. do not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A moment of inattention while

USER MANUAL 5
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair
and clothing away from moving parts. Loose clothes, jewelry or long hair
can be caught in moving parts.
g) Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
POWER TOOL USE AND CARE
a) Do not force the power tool. use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety

DUST COLLECTION TABLE SAW
6
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
SERVICE
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Additional Safety warnings for table saw:
.GUARDING RELATED WARNINGS
a) Keep guards in place. Guards must be in working order and be
properly mounted. A guard that is loose, damaged, or is not functioning
correctly must be repaired or replaced.
b) Always use saw blade guard, riving knife for every through-cutting
operation. For through-cutting operations where the saw blade cuts

USER MANUAL 7
completely through the thickness of the workpiece, the guard and other
safety devices help reduce the risk of injury.
c) Immediately reattach the guarding system after completing an
operation (such as rabbeting, dadoing or resawing cuts) which requires
removal of the guard, riving knife. The guard, riving knife help to reduce
the risk of injury.
d) Make sure the saw blade is not contacting the guard, riving knife
or the workpiece before the switch is turned on. Inadvertent contact of
these items with the saw blade could cause a hazardous condition.
e) Adjust the riving knife as described in this instruction manual. Incorrect
spacing, positioning and alignment can make the riving knife ineffective
in reducing the likelihood of kickback.
f) For the riving knife to work, they must be engaged in the workpiece.
The riving knife is ineffective when cutting workpieces that are too short
to be engaged with the riving knife. Under these conditions a kickback
cannot be prevented by the riving knife.
g) Use the appropriate saw blade for the riving knife. For the riving knife
to function properly, the sawblade diameter must match the appropriate
riving knife and the body of the saw blade must be thinner than the
thickness of the riving knife and the cutting width of the saw blade must
be wider than the thickness of the riving knife.
.CUTTING PROCEDURES WARNINGS
DANGER!
Never place your fingers or hands in the vicinity or in line with the saw
blade. A moment of inattention or a slip could direct your hand towards
the saw blade and result in serious personal injury.
b) Feed the workpiece into the saw blade or cutter only against the
direction of rotation. Feeding the workpiece in the same direction that
the saw blade is rotating above the table may result in the workpiece
and your hand, being pulled into the saw blade.
c) Never use the mitre gauge to feed the workpiece when ripping and

DUST COLLECTION TABLE SAW
8
do not use the rip fence as a length stop when cross cutting with the
mitre gauge. Guiding the workpiece with the rip fence and the mitre
gauge at the same time increases the likelihood of saw blade binding
and kickback.
d) When ripping, always apply the workpiece feeding force between the
fence and the saw blade. Use a push stick when the distance between
the fence and the saw blade is less than 150 mm, and use a push block
when this distance is less than 50mm. work helping devices will keep
your hand at a safe distance from the saw blade.
e) Use only the push stick provided by the manufacturer or constructed
in accordance with the instructions. This push stick provided by the
manufacturer or constructed in accordance with the instructions. This
push stick provides sufficient distance of the hand from the saw blade.
f) Never use a damaged or cut push stick. A damaged push stick may
break causing your hand to slip into the saw blade.
g) Do not perform any operation 3freehand3. Always use either the rip
fence or the mitre gauge to position and guide the workpiece. 3Freehand3
means using your hands to support or guide the workpiece, in lieu of
a rip fence or mitre gauge. Freehand sawing leads to misalignment,
binding and kickback.
h) Never reach around or over a rotating saw blade. Reaching for a
workpiece may lead to accidental contact with the moving saw blade.
i) Provide auxiliary workpiece support to the rear and/or sides of the saw
table for long and/or wide workpieces to keep them level. A long and/
or wide workpiece has a tendency to pivot on the table’s edge, causing
loss of control, saw blade binding and kickback.
j) Feed workpiece at an even pace. Do not bend or twist the workpiece. If
jamming occurs, turn the tool off immediately, unplug the tool then clear
the jam. Jamming the saw blade by the workpiece can cause kickback
or stall the motor.
k) Do not remove pieces of cut-off material while the saw is running. The
material may become trapped between the fence or inside the saw blade
guard and the saw blade pulling your fingers into the saw blade. Turn the

USER MANUAL 9
saw off and wait until the saw blade stops before removing material.
l) Use an auxiliary fence in contact with the table top when ripping
workpieces less than 2 mm thick. A thin workpiece may wedge under
the rip fence and create a kickback.
.KICKBACK CAUSES AND RELATED WARNINGS
a) Never stand directly in line with the saw blade. Always position your
body on the same side of the saw blade as the fence. Kickback may
propel the workpiece at high velocity towards anyone standing in front
and in line with the saw blade.
b) Never reach over or in back of the saw blade to pull or to support the
workpiece. Accidental contact with the saw blade may occur or kickback
may drag your fingers into the saw blade.
c) Never hold and press the workpiece that is being cut off against the
rotating saw blade. Pressing the workpiece being cut off against the saw
blade will create a binding condition and kickback.
d) Alight the fence to be parallel with the saw blade. A misaligned fence
will pinch the workpiece against the saw blade will create a binding
condition and kickback.
d) Align the fence to be parallel with the saw blade. A misaligned fence
will pinch the workpiece against the saw blade and create kickback.
e) Use a featherboard to guide the workpiece against the table and fence
when making non-through cuts such as rabbeting, dadoing or resawing
cuts. A featherboard helps to control the workpiece in the event of a
kickback.
f) Use extra caution when making a cut into blind areas of assembled
workpieces. The protruding saw blade may cut objects that can cause
kickback.
g) Support large panels to minimize the risk of saw blade pinching and
kickback. Large panels tend to sag under their own weight. Support(s)
must be placed under all portions of the panel overhanging the table top.
h) Use extra caution when cutting a workpiece that is twisted, knotted,
warped or does not have a straight edge to guide it with a mitre gauge
