RoomTec X002TZLIND User manual

1

LEDWall-mountedMirror
www.room-tec.com
1
Instruc�ons & Installa�on
Statement
Please read this instruction carefully before installation, and refer to it again during the installation to ensure a safe and
correct installation of the mirror.
Compliance
All the electrical components used in this product are ETL LISTED. This product passed ETL certification.
Electrical Safety Instructions
INSTALLATION should be made by a qualified / registered electrician. DO NOT attempt to install it by yourself, as
RoomTec will not be responsible for any damage caused during installation.
According to IEEE regulations, this product is suitable for zone 2 and external zone, not zone 0 or zone 1. It is also not
suitable for installation in saunas, steam rooms or shower cubicles.
This product is only suitable for permanent installation, please do not plug in the power strip.
Please make sure to keep the electrical supply off during installation and maintenance. It is recommended to pull out the
fuse or switch off the circuit breaker before installation to disconnect the necessary circuits.
RoomTec LED mirror adopts three-pin plug, power leads must be connected to ground wire.
DO NOT put hard and sharp materials directly against the mirror surface during operation, otherwise it may result in
current leakage and even personal injury accident.
Never forget to turn off the power supply in storm days, otherwise electric components of the product could be
damaged.
DO NOT switch off the power supply directly during normal operation, otherwise electric elements of the product may
be easily damaged.
Please turn off the power supply if the product is not used for a long time.
DO NOT remove protective film or corner protectors until the mirror is completely installed.
PLEASE KEEP THIS MANUAL BOOK FOR FUTURE REFERENCE.

LEDWall-mountedMirror
www.room-tec.com
2
Specifica�on
Product Name: LED LIGHTED MIRROR Cer�ficates: ETL, CE, ROHS
Brand: RoomTec Input Voltage: 110v
Design Style: Modern Power: As specified on product label
Feature: Illuminated Lumen: 2500-3000lm
Mirror Shape: Square Input Frequency: 60Hz
Func�on: An�-fog, memory func�on Color Temperature: 3000k-6000k op�onal
Installa�on: Wall mounted IP Ra�ng: IP44
Glass Thickness: 5mm
Light Color Warm/White/Warm white changeable
Touch Sensor Yes
Material: Copper-free silvered glass
+ Aluminum frame
Dimming Func�on: Yes
Warranty: 3years
Hanging Way: Ver�cal/Horizontal
Applica�on: Bathroom, makeup room
Opera�on Instruc�ons
Light on/off
Power on, then press to turn the light on, the light is warm light.
Then second �me press , the light change to white light.
The third �me press , the light change to warm white light .
Then press again to turn the light off.
Wiring
Roomtec supply 1m cord and U.S 3-pin plug for easy connection with wall socket. This product all can connect the cord in the
wall and be controlled by wall switch.
Cleaning
When the mirror has to be cleaned, please switch off the power first.
DO NOT use abrasives or solvents when cleaning.
DO NOT let water get in the mirror and submerge mirror in water.
Wipe off all water spillages as soon as possible via a soft, damp cloth.
7
140
30

LEDWall-mountedMirror
www.room-tec.com
3
Installa�on
Ruler Spirit Level Electrical Drill Screwdriver Hammer
2 x screws and white nylon screw type plug 4xspacer
Step 1
S�ck spacers on mirror backside to keep the mirror be flat, and measure the distance of A/B(two hooks center distance)
Measurement A
Measurement B
PVC back board
Light strip
Back frame
Drive power supply
Touch module
pacer
Size
Model Measurement A(mm)
637±3mm
480±3mm
632±3mm
785±3mm
936±3mm
672±3mm
825±3mm
477±3mm
520±3mm
520±3mm
520±3mm
520±3mm
559±3mm
559±3mm
X002TZLIND
MA023030TD-OL
MA023630TD-OL
MA024230TD-OL
MA024830TD-OL
MA033630TD-OL
MA034230TD-OL
Measurement B(mm)
P
ower on, press to turn the light on, then keep pressing , the
b
rightness will change accordingly.
F
og-free instruc�on
(
For the led mirror with an�-fog func�on)
ower on, press , the mirror can be defogging.
Dimming instruc�on

LEDWall-mountedMirror
www.room-tec.com
4
Step 2
Marked 2 dots on wall with length of A/B,
and drill holes.
Step 3
Step 4
Put the white nylon screw type plug in the holes and
screws in to the plug.
Hang the mirror to wall.
Wall
Wall
M
irror
★★★ About thewire connec�on ★★★
There are two ways to connect the circuit for the mirror.
Connec�on way ①: Plug the 3-pin plug in the socket on the wall.
Wall
Measurement A/B

LEDWall-mountedMirror
www.room-tec.com
5
Connec�on way ②: Connect the mirror wire with wall switch wire via connector.
Thanks for choosing RoomTec.
Web: www.room-tec.com
Any query please feel free to email our service team : [e-mail].
Scan the QR code to watch the video of installa�on.
Field Wire
Neutral/ white
Earth/ Green
Earth/ Green
Neutral/ white
Live/ Black Live/ Black
Input Wire
of Mirror
