ropelux XHY-UFO User manual

Use & Care Guide
UFO Solar Light
Model No.:XHY - UFO
· 1 · · 2 ·
Model NO.
Solar Panel
Solar Panel Material
Color Temperature
Waterproof
Charging Time
XHY - UFO
6.5V
Polycrystalline Silicon
6000K-6500K
IP65
6-8Hrs
INTRODUCTION
FEATURES
PRODUCT DETAILS
SPECIFICATIONS
Thank you for purchasing the UFO Solar light，we hope you enjoy our
solar lighting solution. To ensure proper operation of this solar light,
please read this user manual carefully and keep it for future reference.
· 3 ·
eVatmaster Consulting GmbH
EC REP Bettinastr. 30
60325 Frankfurt am Main, Germany
[email protected]
EVATOST CONSULTING LTD
UK REP
Suite 11, First Floor, Moy Road Business Centre,
Taffs Well, Cardiff, Wales, CF15 7QR
[email protected]
Solar Charging
IP65 Waterproof
All Weather Resistant
Remote Control
Green Energy Saving
Easy To Install
Motion Sensor
Mode Switch
Press to switch 5 modes in turn
ON/OFF Switch
Green Light
Battery level indicator light
6.9inch
2.56 inch
7.87 inch
1.57 inch
5.91 inch
16.4ft
Cable
Connector
4.72 inch
Turn ON
Mode
Switch
Turn OFF
Adjust the brightness (20%-40%-60%-80%-100%)
Options of lighting time after sensing the motion
(25sec-35sec-45sec).
Remark:Use two AAA batteries, please distinguish
the and poles of the batteries and install
them correctly.
Red Light
In charing indicator light
10% 40% 70% 100%

INSTALLATION
· 4 ·
Installation accessories
5 MODES
· 5 · · 6 ·
Stay on as dim light, gets brighter when detects a motion, back on dim light after 16s.
Mode 1
16sec
When using for the first time,place the product in a sunny place for charging
for several hours.
When the product is not used for a long time,please place the product in a
sunny place for charging for 1 day.In order to maintain the function of the
battery,it is better to put it in the sufficient sunlight once a month.
The charging time and charging efficiency of solar panels may be affected
by weather and installation location.
The product is equipped with an internal battery, please do NOT: 1）
Replace it by yourself. 2）Put it with household garbage .3) place it near
sources of heat. It should be taken to your local battery disposal center.
A full charge requires up to 8 hours of sunlight. Mounting location,weather
conditions and seasonal variation will directly influence the actual run time
experienced.
NOTICE
MADE IN CHINA
Solar Panel Large Screw
Small
Screw
Smalle Plastic
Anchor
Flat Tail
Screw
Light Pole Nut
Large Plastic Anchor
UFO Light
Base
Step 1.Install the solar panel
We recommended to install it within 16.4ft
from the UFO light and in a direct sunlight place.
①Make 2 marks on the wall where you want to
install, drill holes and insert the large plastic anchor.
②Mount the solar panel to the wall with large screws.
And adjust the best angle of the solar panel to
receive sunlight.
Step 2.Insatll UFO light
①Make 2 marks on the wall where you want to install,
drill holes and insert the small plastic anchor.
②Mount the base to the wall with small screw.
③Snap the two ends of the light pole into the base
and the light body respectively.Fix them with flat
tail screws and nuts.
Step 3. Connect Cable
Connect and tighten cables of solar panel and UFO light.
①
②
③
①
②
·There is a built-in light sensor, so for Mode 1,2 and 3, the solar light only operates at night.
·Please fully covered the solar panel when testing the light during daytime when at mode 1/2/3.
·Mode 1/2/3 only light up at night, Mode 4 and Auto Mode light up both in day and night.
Tips
Auto on when detects a motion, auto off after 16s.
Mode 2
16sec
Light sensor is off,for both daytime and night time, light will automatically turn on when detects
a motion，auto off after 16s.
Mode 4
Mode 4
Light sensor is off,for both daytime and nighttime,Always on and switch to mode 4 when 50%
power left, the next day cycle.
AUTO Mode
20sec
Always on as dim light.
Mode 3
50%
the next day cycle
Email: [email protected]
Web: www.ropelux.net
