ROPES RARK EQUIPMENT TWEEZLE KEY User manual

TWEEZLE KEY ™
User Manual
Tweezle Key User Manual V01 | November 2021 | English

V01 | November 2021 | English
2
TWEEZLE KEY
Identification Marker for the self-securing system
LockD Clips ™
Subject to technical changes
BRIEF DESCRIPTION
INTENDED USEINTENDED USE
The identification marker TWEEZLE KEYThe identification marker TWEEZLE KEY
serves to identify the safety-wire rope/anchorserves to identify the safety-wire rope/anchor
points and to lock the securing system LockDpoints and to lock the securing system LockD
Clips. TWEEZLE KEYS in different colours canClips. TWEEZLE KEYS in different colours can
be used to indicate course direction or difficultybe used to indicate course direction or difficulty
levels.levels.
All other uses are deemed improper. TheAll other uses are deemed improper. The
manufacturer will not be liable for anymanufacturer will not be liable for any
ensuing damages. The user is liable for allensuing damages. The user is liable for all
risks associated with use.risks associated with use.
FUNCTIONFUNCTION
The identification marker serves to lock theThe identification marker serves to lock the
securing system LockD Clips.securing system LockD Clips.
EQUIPMENT
• 2 TWEEZLE KEY halves for wire rope Ø
12.0 mm (also 1/2 “)
• 4 screws M5
• If necessary depending on the diameter
of the securing wire rope, appropriate
adapters for ropes with diameters 9, 10
and 11 mm (also 3/8 “)
• Available in various colours
USEUSE
Identification marker for the LockD ClipsIdentification marker for the LockD Clips
securing system.securing system.
GENERAL INFORMATIONGENERAL INFORMATION
It should be attached using a cordlessIt should be attached using a cordless
screwdriver with an Allen bit 3.0mm.screwdriver with an Allen bit 3.0mm.

V01 | November 2021 | English
3
TWEEZLE KEY
Screw M5
TWEEZLE KEY Pin
TWEEZLE KEY halves

4
INFORMATION BEFORE MOUNTING
• Anchor points may only be installed by
qualified persons.
• Ensure that terminations are per designed
strength.
• Ensure that both children and adults can
reach the TWEEZLE KEY easily. If necessary,
attach appropriate steps to the platforms.
• To ensure best climbing fun with the LockD
Clips system, RPE recommends installing
the securing wire ropes at a height of 1.00
m (3.2 ft) to 2.00 m (6.5 ft), depending
on the LockD Clips length and size of the
participants. Observe/read the User Manual
of the LockD Clips system.
• It should be possible to reach the
TWEEZLE KEY without excessive bending of
the LockD Clips system.
• Color use must be clearly explained to
the participant because simultaneous
tweezling with both carabiners can
damage the LockD Clips cable.
• We recommend installing waiting loops so
that slower guests can be overtaken and
several people can wait on a platform.
• Avoid courses where guests are tempted
to trick or manipulate the system, e.g.
labyrinths, dead ends.
VISUAL/FUNCTION TEST
• Ensure that the TWEEZLE KEY is
undamaged before mounting.
• Test the function of the identification marks
on the LockD Clips system before using.
V01 | November 2021 | English
Always check before use!

V01 | November 2021 | English
5
MOUNTING / USE OF THE TWEEZLE KEY
MOUNTING
A. Mount the TWEEZLE KEY as close as possible
to the obstacle or element that needs to be
passed (tree).
B. The distances between the TWEEZLE KEYS
must be kept as small as possible but far
enough apart so that it is not possible to skip
or tweezle both carabiners at the same time
and bend the LockD Clips.
C. Ensure that the TWEEZLE KEY is mounted
so that the LockD Clips hook falls down after
tweezling. This avoids bending loads. Avoid
vertical ascent.
D. On zip lines or other rolling devices, attach
the TWEEZLE KEYS so that the LockD Clips
carabiner cannot become caught at the
start, i.e. steps must be taken to ensure that
the LockD Clips does not get stuck in the
TWEEZLE KEY or slide behind it.
E. Install the TWEEZLE KEY halves onto the
securing wire rope, making sure the TWEEZLE
KEY does not move.
F. If necessary affix using the assembly clamps
Screw the screws M5 into TWEEZLE KEY
using an appropriate wrench.
CAUTION:
Avoid over-tightening as this could damage the
TWEEZLE KEY.
A
C
D
EF

6
SAFETY INSTRUCTIONS
DANGER! Risk of serious injury or death if
safety instructions are not followed.
• RISK OF LIFE-THREATENING INJURIES: It is
prohibited to stand under suspended loads!
• Do not use compromised safety attachment
points.
• Independent modifications or repairs are not
allowed.
• Must be used by trained personnel only.
• Clothing and shoes must be suitable for the
task at hand and the weather conditions.
• Do not use if impaired and/or under the
influence of alcohol or drugs.
• Before using, ensure adequate clearance
below the user to prevent impact on a
protruding object or the ground.
• Protect personal protective equipment
during storing, use and transportation
against the effects of heat (e.g. welding
flames or sparks, burning cigarettes) and
chemicals (e.g. acids, alkalis, oils, etc.) and
mechanical effects (e.g. sharp edges).
• Rope courses must comply with local and/
or national/international standards and
guidelines.
• Check the compatibility of the wire ropes
approved for the application!
V01 | November 2021 | English

V01 | November 2021 | English
7
OTHER
SALES
• The dealer must ensure that the User
Manual is supplied in the language of the
designated use zone. The total translation
must be approved by Ropes Park Equipment.
SERVICE
• If you have any further questions about
safe use of this product. Please send your
question to our E-Mail:
Offi[e-mail]
REGULAR INSPECTION
• All PPE including harnesses and lanyards
must be inspected regularly (at least once a
year) by a qualified person. The result must
be documented and available for future
reference.
• PPE and securing systems used in rope
courses are subject to an extremely high
usage frequency. Greater levels of wear
can be expected. The test cycles must be
adapted accordingly!
• Rope courses must comply with local and/
or national/international standards and
guidelines.
• Check the compatibility of the wire ropes
approved for the application!
MAINTENANCE
• Maintenance may only be carried out by a
qualified person. All instructions in this User
Manual or any maintenance instructions
must be strictly observed.
