Rose electronics UEB-8UB Manual

ELECTRONICS
UltraView Pro
Rose Electronics product overview
n
n
n
n
n
n
n
n
Full featured single user KVM switch family
Connect one KVM to as many as 256 computers
Perfect for use in computer rack or server room
Full range of products
PC version: 3 chassis sizes
Multi-platform: 3 chassis sizes
dvanced on-screen display technology simplifies
onfiguration and operation
250 Mhz bandwidth
nstallation can be done without powering down servers
Steel chassis with rackmount option for 19”/23”/24” racks
A
c
I

UtraView Pro
Rose Electronics product overview
ELECTRONICS
n
n
n
n
n
n
Superior cable management uses
DB25 connectors for compatibility
with UltraCable cabling system
Multi-platform model supports
PC, Apple, Sun, and Unix computers
such as IBM, HP, DEC, and SGI
Security system with user and configuration passwords
prevents unauthorized access and configuration
Lifetime free flash upgrade
Switch from keyboard or front panel or serial port
LEDs show computer power, and computer select

UltraView Pro On-Screen Display
Rose Electronics product overview
ELECTRONICS
Main configuration menu
Configure System
Configure computer
Configure overlay
Configure security
Exit
Use arrow keys to highlight
selection and press enter
or press escape to exit
View/change keyboard, mouse, expansion, and scanning
ELECTRONICS
UltraView Pro version UP16 Copyright 1990-1999 Rose Electronics n
n
n
n
n
n
More professional appearance than
competing units
Help line shown for each item
Transparent colors
Pop-up boxes for intuitive interface
Programmable color, position, and
font for computer name
Programmable color and position for
computer select window
Configuration screen

UltraView Pro Chassis Sizes
Rose Electronics product overview
ELECTRONICS
2 or 4 port
8 port
4, 8, 12, or 16 port
boards can be field installed
