rosseto Avant Guarde RD001 User manual

1. Carefully remove all parts from packaging.
2. Make sure you have all parts listed:
a. 2 Metal Leg Assemblies
b. 1 Clear or Bronze Panel
c. 7 Barrel & Screws
d. 4 Casters with locks
e. 4 Hex Nuts
3. To assemble, lay 1 metal assembly (a) face down. Place the panel (b) on top where
the holes aligh. Then place the 2nd metal assembly (a) face up on top of panel. It is
easiest to do this on a large table or clean oor space. Move parts carefully so they do
not become scratched. See Figure 1.
4. Place the screw barrel (c) in one side of the hole and place the screw (c) on the
opposite side. Hold the barrel in place with one screwdriver and use a second screw
driver to tighten the screw. Repeat for remaing screws. See Figure 2.
5. Assemble casters (d) to the bottom of the metal assembly by placing the threading in caster hole and securing with hex
nut (e). Tighten with wrench. See Figure 3.
6. Once all screw are in, carfully stand the divider up. See Figure 4.
7. Check to make sure all screws are tight and in place. You may need to adjust a few.
SETTING UP YOUR PRODUCT
NEED ASSISTANCE? Customer Service Support: 847-763-1215
Address: 3714 Jarvis Avenue Skokie, IL 60076
Website: www.rosseto.com
Avant Guarde™ Room Divider
Instruction & Specication Sheet
Figure 1 Figure 2
Figure 3 Figure 4
* Two Phillips screwdrivers and wrench required for assembly.
b
a
a
Place parts as shown
and align holes in metal
and polycarbonate.
c
c
e
d
Attach parts together with barrel
and screw.
Secure casters with hex nut. Carefully stand divider up and
retighten loose screws.
RD001 - Clear
RD002 - Bronze

Item
Number
SMM035
SMM037
SMM036
Description
Barrel & Screw
Casters (Set of 4)
Hex Nut for Caster
Material
Stainless Steel
Plastic
Stainless Steel
IS057 R1 06192020
CLEANING & CARE INSTRUCTIONS
REPLACEMENT PARTS
NEED ASSISTANCE? Customer Service Support: 847-763-1215
Address: 3714 Jarvis Avenue Skokie, IL 60076
Website: www.rosseto.com
Avant Guarde™ Room Divider
Instruction & Specication Sheet
• DO NOT use any abrasive materials such as scrapers or metal-based brushes.
• DO NOT use harsh chemicals or abrasive cleaners.
Polycarbonate Care:
To maintain the quality of your polycarbonate, wipe down with a warm damp cloth and mild soap. Use a clean, damp cloth to
rinse off soap. Dry with a soft sponge or cloth to prevent water spots. Be careful to not get water in the interior channels of the
polycarbonate as it will be hard to remove water spots that form on the inside.
Stainless Steel Care:
Metal Care: Wipe down with damp microber cloth and always wipe dry with a microber cloth. Store in a
dry and well-ventilated place.
H
WD
SPECIFICATIONS
DIMENSIONS 48(W) X 21(D) X 72 (H)IN
121.9(W) X 53.34(D) X 182.88(H) CM
WEIGHT 17 Pounds
7.7 Kilograms
