The AC-x32 is a series of indoor standalone controllers. The units
accept up to 500 users and allow entry via a personal identification
number (PIN) or by presenting a proximity card.
1.1 Reader/Controller Types
The six types of units described in this manual are:
Keypad Type PIN Proximity
AC-B32 3X4 Standard 
AC-C32 2X6 Mullion 
AC-D32 3X4 Standard 
1.2 Equipment
The following equipment is provided in every AC-x32 package:
AC- x32 controller
Installation kit
1 drilling template (label/sticker)
1 security spline key
1 security hex screw
4 mounting screws and wall plugs
Installation and operating instructions

Introduction
AC-x32 Series Installation and Programming Manual 9
1.3 Additional Equipment
The following additional equipment is required:
Electric Lock Strike Mechanism – Fail Safe (Power to Lock) or Fail
Secure (Power to Open)
Power supply with backup battery – 12 to 16 VDC (from a
regulated power supply)
Request to Exit (REX) button – Normally Open Type; switch is
closed when pressed.
BL-D40 External Sounder (optional) – Provides siren, bell, and
chime functions to the controller
Other Rosslare accessories can be found at Rosslare's website:
http://www.rosslaresecurity.com

Technical Specifications
10 AC-x32 Series Installation and Programming Manual
2. Technical Specifications
Electrical Characteristics
Operating Voltage Range 12–16 VDC
From a regulated power supply
Input Current (excluding
attached devices)
Standby: 40 mA
Max: 90 mA
Relay Outputs •Lock Strike Relay – Electronic, 3.5 A
with built-in suppressor protection
•Auxiliary Relay – Form C, 1 A
Inputs •REX – N.O., Dry Contact
•Auxiliary Input (In/Monitor)
•Monitor Mode – N.C., Dry Contact
•Input Mode – N.O., Dry Contact
LEDs Two tri-colored LEDs
Built-In Proximity Reader •Read Range: 90 mm (3.5 in.)*
•Modulation: ASK at 125 kHz
• Compatible cards: All 26-Bit EM cards
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.

Technical Specifications
AC-x32 Series Installation and Programming Manual 11
Environmental Characteristics
Operating Temp. Range -31°C to 63°C (-25°F to 145°F )
Operating Humidity Range 0 to 95% (non-condensing)
Physical Characteristics
Dimensions
(Length x Width x Depth)
AC-B32: 92 x 92 x 24 mm
(3.6 x 3.6 x 0.9 in.)
AC-C32: 130 x 42 x 18 mm
(5.1 x 1.7 x 0.7 in.)
AC-D32: 122 x 75 x 24 mm
(4.8 x 3.0 x 0.9 in.)
Weight AC-B32: 124 g (4.4 oz)
AC-C32: 55 g (1.9 oz)
AC-D32: 115 g (4.1 oz)

Installation
12 AC-x32 Series Installation and Programming Manual
3. Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s specifications. To diminish this
interference, use a plastic spacer when mounting the reader.
3.1 Mounting
Before starting, select the location to mount the controller. This
location should be at shoulder height and on the same side as the
door handle.
The AC-x32 is designed to be easily mounted onto a US Gang Box.
To mount the controller:
1. Peel off the back of the self-adhesive mounting label template
and place it on the required mounting location.
2. At the bottom of the unit’s case, remove the screw.
3. Carefully remove the snap-off front cover of the unit to reveal the
screw holes.
4. Screw the controller onto a US Gang Box through the two
mounting holes provided (see Figure 1, Figure 2, and Figure 3).
Figure 1: AC-B32 – Mounting Holes and Terminal Blocks

Installation
AC-x32 Series Installation and Programming Manual 13
Figure 2: AC-C32 – Mounting Holes and Terminal Blocks
Figure 3: AC-D32 – Mounting Holes and Terminal Blocks
5. Wire the controller as shown in Section 3.2.
6. Screw the back plate into the surface. Ensure the screws are the
size specified on the installation template.
The unit can also be mounted using strong epoxy glue. After
application, firmly hold the unit in place until the glue dries.
7. Carefully re-attach the front cover of the unit.
8. Secure the front cover by using the supplied security Torx screw.
A Torx security screw tool is provided to tighten the security Torx
screw.

Installation
14 AC-x32 Series Installation and Programming Manual
3.2 Wiring
Typical wiring diagrams for the various units are shown in the
following subsections.
3.2.1 AC-B32
Figure 4: AC-B32 – Wiring the Lock Strike Relay and REX
Figure 5: AC-B32 – Wiring the BL-D40 External Sounder

Installation
AC-x32 Series Installation and Programming Manual 15
3.2.2 AC-C32
Figure 6: AC-C32 – Wiring the Lock Strike Relay and REX
Figure 7: AC-C32 – Wiring the BL-D40 External Sounder

Installation
16 AC-x32 Series Installation and Programming Manual
3.2.3 AC-D32
Figure 8: AC-D32 – Wiring the Lock Strike Relay and REX
Figure 9: AC-D32 – Wiring the BL-D40 External Sounder

Operation
AC-x32 Series Installation and Programming Manual 17
4. Operation
4.1 User Levels
The controller accepts up to 500 users and provides entry via the use
of proximity cards and/or PIN codes. Each user is provided with two
code memory slots: Memory Slot 1 (Primary Code) and Memory Slot 2
(Secondary Code). The two memory slots can be programmed for
proximity cards, PIN codes, or a combination of both proximity cards
and PIN codes.
The way that the two memory slots are programmed determines a
user's access level and also determines the way that the unit grants
access in its three modes of operation.
There are three user levels:
Normal User – A Normal User only has a Primary code and is only
granted access when the unit is in Normal or Bypass mode.
Secure User – A Secure User must have a Primary and Secondary
code programmed; the two codes cannot be the same. The
Secure User can gain access when the unit is in any of its three
modes of operation. In Normal mode, the Secure User must use a
Primary code to gain entry. In Secure Mode, the Secure User must
present both a Primary and Secondary code to gain entry.
Master User – A Master User must have both Primary and
Secondary codes programmed with the same proximity card or
PIN code. The Master User can gain access during any mode of
operation by presenting the proximity card or entering the PIN
code. (The Master User is convenient, but is less secure than a
Secure User.)

Operation
18 AC-x32 Series Installation and Programming Manual
4.2 Modes of Operation
The controllers have three modes of operation:
4.2.1 Normal Mode
The Mode LED is green
Normal Mode is the default mode. In Normal mode, the door is
locked until a Primary code is presented to the controller. Special
codes such as “Open Code” and “Auxiliary Code” are active in
Normal mode (see Sections 5.3 and 5.4).
4.2.2 Bypass Mode
The Mode LED is orange
In Bypass mode, access to the premises is dependent on whether the
controller's Lock Strike Relay is programmed for Fail Safe Operation or
for Fail Secure Operation.
When the Lock Strike Relay is programmed for Fail Secure Operation,
the door is locked until the doorbell button is pressed. When the Lock
Strike Relay is programmed for Fail Safe Operation, the door is
constantly unlocked.
4.2.3 Secure Mode
The Mode LED is red
Only Secure and Master Users can access the premises during the
Secure Mode. A Secure User must enter a Primary and a Secondary
code to gain entry. After entering the Primary code, the Door LED
flashes green for 10 seconds, during which time the Secondary code
must be entered. A Master User only needs to present the proximity
card or enter the PIN code once to gain entry.
Mode
Door
Green
Mode
Door
Orange
Mode
Door
Red

Operation
AC-x32 Series Installation and Programming Manual 19
4.3 Changing the Modes of Operation
4.3.1 Changing from Normal to Secure Mode
The default factory setting for the Normal/Secure Code is 3838.
To change from Normal to Secure mode:
1. Enter the 4-digit Normal/Secure code.
The Mode LED flashes red.
2. Press #to confirm the mode change.
The Mode LED turns red.
4.3.2 Changing from Secure to Normal Mode
The default factory setting for the Normal/Secure Code is 3838.
To change from Secure to Normal mode:
1. Enter the 4-digit Normal/Secure code.
The Mode LED flashes green.
2. Press #to confirm the mode change.
The Mode LED turns green.
Mode
Door
Red
Mode
Door
Red
Mode
Door
Green
Mode
Door
Green

Operation
20 AC-x32 Series Installation and Programming Manual
4.3.3 Changing from Normal to Bypass Mode
By default, there is no Normal/Bypass code. The Normal/Bypass code
must first be programmed to use this function (see Section 5.6 to
create/modify the Normal/Bypass Code).
To change from Normal to Bypass mode:
1. Enter the 4-digit Normal/Bypass Code.
The Mode LED flashes orange.
2. Press #to confirm the mode change.
The Mode LED turns orange.
4.3.4 Changing from Bypass Mode to Normal Mode
By default, there is no Normal/Bypass code. The Normal/Bypass code
must first be programmed to use this function (see Section 5.6 to
create/modify the Normal/Bypass Code).
To change from Bypass to Normal mode:
1. Enter the 4-digit Normal/Bypass code.
The Mode LED flashes green.
2. Press #to confirm the mode change.
The Mode LED turns orange.
4.4 REX Button
The REX button is used to open the door without the use of a PIN
code, and must be located inside the premises to be secured. It is
usually located in a convenient location, such as inside the door or at
a receptionist's desk. The function of the REX button depends on
whether the Lock Strike Relay is programmed for Fail Safe Operation
Mode
Door
Orange
Mode
Door
Orange
Mode
Door
Green
Mode
Door
Green
