Rosslare AC-215 Assembly instructions

AC-215
Single-Door and Double-Door
Access Control Unit
Hardware Installation Manual
Models:
AC-215
AC-215U

Copyright © 2017 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’ (hereafter:
"ROSSLARE"). Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of
ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or other
intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS
DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER
LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD
PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL
PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third party any
license to these patents, trademarks, copyrights or other intellectual property rights,
except as expressly provided in any written agreement of ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.

Table of Contents
AC-215 Installation Manual iii
Table of Contents
1. Introduction....................................................................... 8
1.1 Control Panel Components............................................................... 10
1.2 Software........................................................................................... 10
2. Technical Specifications ................................................. 11
2.1 Panel ................................................................................................ 11
2.2 Transformer...................................................................................... 11
2.3 PS-14 Power Supply Specifications .................................................... 12
3. Inputs and Outputs ......................................................... 13
3.1 Inputs............................................................................................... 13
3.1.1 Release to Exit Button (REX) ....................................................................... 13
3.1.2 Door Monitor ............................................................................................ 13
3.1.3 Tamper ..................................................................................................... 14
3.1.4 General..................................................................................................... 14
3.1.5 Outputs .................................................................................................... 14
3.1.6 Door Lock ................................................................................................. 14
3.1.7 Door Alarm ............................................................................................... 15
3.1.8 Auxiliary.................................................................................................... 15
3.1.9 General..................................................................................................... 15
3.1.10 Card Readers............................................................................................. 16
3.1.11 Keypad ..................................................................................................... 16
4. DIP Switch Settings Configuration ............................... 17
4.1 ACU Baud Rate................................................................................. 17
4.2 ACU Type ......................................................................................... 18
4.2.1 Single Door Controller ............................................................................... 18
4.2.2 Double Door Controller ............................................................................. 18
4.3 ACU Addressing ............................................................................... 19
5. Communications ............................................................. 21
5.1 Serial Connection ............................................................................. 21
5.1.1 RS-232 Connection ................................................................................... 21

Table of Contents
iv AC-215 Installation Manual
5.1.2 RS-485 Connection to the PC .................................................................... 21
5.1.3 Daisy Chain............................................................................................... 22
5.2 Modem ............................................................................................ 22
5.3 Communication through the Local Area Network (LAN) .................... 23
6. Wiring............................................................................... 24
6.1 General Wiring Diagram ................................................................... 24
6.2 Inputs............................................................................................... 25
6.3 Outputs............................................................................................ 25
6.3.1 Power Supply ............................................................................................ 28
6.4 AC-215 Access Control Panel Diagram.............................................. 29
6.5 Reader.............................................................................................. 30
A. Connecting between MD-N32 and AC-215 ................... 31
A.1 Hardware Requirements.................................................................... 31
A.2 Topics............................................................................................... 31
A.3 Connections – PC Side ...................................................................... 31
A.4 Connections – AC-215 Panel Side ..................................................... 31
A.5 MD-N32 Configuration with AxTraxNG............................................. 32
B. Connecting between MD-N33 and AC-215 ................... 35
B.1 Hardware Requirements.................................................................... 35
B.2 Topics............................................................................................... 35
B.3 Connections – PC Side ...................................................................... 35
B.4 Connections – AC-215 Panel Side ..................................................... 35
B.5 MD-N33 Configuration with AxTraxNG............................................. 36
B.6 PC Modem – Configuration and Initialization .................................... 37
B.7 Remote Modem – Configuration and Initialization............................. 38
B.8 Remote Modem Status ..................................................................... 39
B.9 Restoring Factory Default Configuration............................................ 40
C. Limited Warranty ............................................................ 41

List of Figures
AC-215 Installation Manual v
List of Figures
Figure 1: AxTraxNG™ and AC-215 System ..................................................... 9
Figure 2: Remote Site Modem Configuration................................................ 22
Figure 3: MD-N32 Configuration Connecting a Single Panel ......................... 23
Figure 4: Connecting Multiple Access Control Panels with MD-N32 .............. 23
Figure 5: Wiring ........................................................................................... 24
Figure 6: Wiring Four AC-215 Inputs ............................................................ 25
Figure 7: Door Lock – Fail Closed.................................................................. 26
Figure 8: Door Lock – Fail Open.................................................................... 27
Figure 9: AC-215 Wiring to Power Supply..................................................... 28
Figure 10: AC-215 Wiring Communications.................................................. 29
Figure 11: Reader Cable Coloring ................................................................. 30

List of Tables
vi AC-215 Installation Manual
List of Tables
Table 1: Description of AC-215 Panels ............................................................ 8
Table 2: DIP Switches and their Functions ..................................................... 17
Table 3: Switch Baud Rates........................................................................... 17
Table 4: Available Panel Addresses ............................................................... 19
Table 5: RS-232 Connection......................................................................... 21

Notice and Disclaimer
AC-215 Installation Manual vii
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND
THE USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not
all functions described in this manual may be available in the specific
system and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the
purpose of illustration and reference only.
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital
or injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
8 AC-215 Installation Manual
1. Introduction
In this manual, unless otherwise stated, “AC-215” refers to both the regular
AC-215 and the UL-listed AC-215U models.
The AC-215 series of access control panels and the AxTraxNG™ PC software
are a combination that gives full control over the entrances of your premises.
The AxTraxNG software supports control for both single and double door
entrances, with which up to 1000 AC-215 access control units (ACUs) can be
monitored.
The AC-215 panels employ the latest technology to meet the requirements of
the market. They control one or two doors when used as a standalone
controller, and up to 64 doors per 32 controllers in a network and 5000 users
when used as a networked controller with the AxTraxNG software.
Table 1 summarizes the two AC-215 and AC-215U models and their respective
descriptions.
Table 1: Description of AC-215 Panels
Model Name Description
AC-215 No onboard IP, supplied with 230 VAC transformer
AC-215U No onboard IP, FCC approved and UL-294 listed.
Use a Class 2 plug-in power supply (sold separately).
The AxTraxNG software, which is user-friendly and intuitive, defines settings
and event logs. A single server, communicating to and from the ACU, can
serve unlimited network clients. The system’s database is saved in the server.
The database can be set to back up, and can import/export previous
configurations. Clients are able to modify the database; for example, define
new employees and/or their access permissions.
AxTraxNG can run under Windows 98, 2000, NT or XP operating systems.
The AxTraxNG software and associated computer monitoring equipment has
not been evaluated by UL.
Figure 1 is an example of how the AxTraxNG and AC-215 system can be set
up.

Introduction
AC-215 Installation Manual 9
Figure 1: AxTraxNG™ and AC-215 System
AxTraxNG
Software
RS-485/232
Converter
AC-215
Single Door
Up to 32 ACUs
AC-215
AC-215
Single Door
AC-215
Double Door
RS-485
RS-232
RS-485 RS-485
Door
Monitor
Door
2
Maglock
Exit
Button
Reader
Door
4
Exit Button
Reader, Keypad,
and Door Release
2 readers
for
Reader In
and
Reader
Out Door
3
Door 1
Reader,
Keypad,
and Door
Release

Introduction
10 AC-215 Installation Manual
1.1 Control Panel Components
The AC-215 control panel consists of the following components:
AC-215 controller board
Enclosure
PS-14 power supply
1.2 Software
The AxTraxNG software is user-friendly and intuitive. Its graphic interface is
used to define settings, which are downloaded to the ACU and event logs
which are uploaded to the PC to generate reports. A single server, which
communicates to and from the ACU, can serve unlimited network clients.
The system’s database is saved in the server. The database can be set to
backup and can import/export previous configurations. Clients are able to
modify the database, for example, define new employees and their access
permissions.
The software enables features to be added as and when they are required. The
modular software enables the user interface to be as powerful and strong as
required and yet remains simple to use. The software can be set for automatic
backup on a periodic basis.
AxTraxNG can be run on Windows 98, 2000, NT and XP.
For UL installations, the installer must configure the system as fail-safe to
comply with NFPA (National Fire Protection Association) regulations.

Technical Specifications
AC-215 Installation Manual 11
2. Technical Specifications
This chapter discusses the technical specification required for the system.
2.1 Panel
Electrical Characteristics
Operating Voltage 12 VDC 0.5 A (from PS-14)
Maximum Input Current
(not including attached devices)
Standby: 125 mA
Maximum: 325 mA
Relay Outputs
5 A Relay N.O. and N.C. options
General Inputs High impedance active low inputs.
Maximum voltage: 5 VDC
Reader's Electrical Requirements Voltage: 12 VDC
Max current: 300 mA
Visual 8 on
board LEDs as well as three PS LEDs (power,
low battery, output (V) Fail)
Audio Built-in sounder (bell, chime and siren)
Speaker's Electrical
Characteristics
8 Ohm, 250 mW
Environmental Characteristics
Operating Temperature Range 0°C to 49°C (32°F to 120.2°F)
Operating Humidity Range 0 to 85% (non-condensing)
Dimensions
Enclosure (L x W x D) 264 x 334 x 84.5 mm (10.4 x 13.2 x 3.4 in.)
Weight 3.8 kg (8.3 lb)
2.2 Transformer
AC-215 Input: 120/220 VAC
Output: 16 VAC 2.5 A (40 VA) supplied, internal
to unit
AC-215U Input: 120 VAC
Output: 16.5 VAC 2.42 A (40 VA) Class 2 (not
included). Use wall plug-in unit such as Universal
Power Group Part No. UB1640W.

Technical Specifications
12 AC-215 Installation Manual
2.3 PS-14 Power Supply Specifications
Input Voltage 16.5 VAC, 2.42 A
Output Voltage 1 13.8 V / 300 mA for 12 V lead acid battery up
to 7 Ah.
Note: For UL installations, use a 7 Ah
battery for a 4-hour minimum
backup time.
Output Voltage 2 12 VDC, 0.5 A
Output Voltage 3 12 VDC, 1.5 A
Power Supply Indication
Tamper Output (open collector) Indicates faulty power
Power LEDs
Power In (AC) – Green LED1 Main power
Power Out (DC) – Red LED2 Low voltage
Charger (BAT) – Red LED3 Backup battery low voltage

Inputs and Outputs
AC-215 Installation Manual 13
3. Inputs and Outputs
This chapter discusses the AC-215 ACU input and output requirements.
3.1 Inputs
3.1.1 Release to Exit Button (REX)
REX enables quick exit from a premises. The following should be defined:
Single door controller Door 1 – IN1
Double door controller Door 1 – IN 1
Door 2 – IN 2
Usually the REX input is connected to a push button that is located inside the
premises. The push button opens a door without reading a proximity card or
PIN code.
Generally, the REX is located in a convenient position such as near the
reception area, and is always set as enabled in the AxTraxNG software.
3.1.2 Door Monitor
The Door Monitor connects to a door’s micro switch for door status
monitoring. The following should be defined:
Single door controller Door 1 – IN1A
Double door controller Door 1 – IN 1A
Door 2 – IN 2A
Two alarm states can be generated:
Forced alarm – When the door is forcibly opened by unauthorized persons
Door held open alarm – When the door is open for a period exceeding the
lock strike programmed open time
A door held open alert can be generated by activating chime on speaker to
remind that the door should be close.
After the ACU enables access, the lock is activated according to its
programmed time until one of the following occurs:
The ACU stops lock activation immediately after the door opens
The ACU waits for the door to close. (This can help to reduce tailgating)
When the door open time period expires, the ACU ends lock activation.

Inputs and Outputs
14 AC-215 Installation Manual
3.1.3 Tamper
The internal tamper switch must be connected to a UL Listed burglary unit.
Refer to the selected UL Listed burglary unit for connection instructions
The tamper input connects to a tamper micro switch assembled within the
ACU panel.
The following should be defined:
Single door controller Door 1 – IN2
Tamper input is activated when the panel is opened through vandalism. The
system has two additional tamper inputs on the reader terminals.
3.1.4 General
The General input connects to any general-purpose dry contact input.
Single door controller Door 1 – IN2A
This function can be used when activating the general purpose output
connections, such as alarm sensors and monitoring power supply failure. The
ACU reports activation if this input changes status.
The system has four output relays. Their contacts are voltage free and rated
5 A at 12 VAC or VDC. This indicates that output is very versatile and can
operate virtually any electrical equipment including Fail Open and Fail Close
locks, electric gates and so on.
3.1.5 Outputs
We recommend using a suppression diode for all outputs.
3.1.6 Door Lock
There are two types of door locking devices:
Fail open (fail secure)
Fail close (fail safe)
The user can select either normally open or normally closed output contacts.
The following should be defined:
Single door controller Door 1 – OUT1
Double door controller Door 1 – OUT1
Door 2 – OUT2
The output can sink current from any power supply (see Section 2.2). In a time
zone door locking is activated in the following modes:
Grant Access
Automatic Relock

Inputs and Outputs
AC-215 Installation Manual 15
The output can provide 12 VDC power up to 1.5 A for external door locks. For
higher rated door locks an external UL 294 Listed power supply must be used
to provide power to the door lock.
For UL installations, the installer must configure the system as fail-safe to
comply with NFPA (National Fire Protection Association) regulations
3.1.7 Door Alarm
This output is activated when either an alarm occurs in the system, or
automatically by a time zone. The following should be defined:
Single door controller Door 1 – OUT1A
Double door controller Door 1 – OUT1A
Door 2 – OUT2A
The output can be activated for a specified time and closes when the timer
ends.
3.1.8 Auxiliary
This output is activated when a transaction occurs in the readers that are either
associated with auxiliary, or automatically by a time zone. The following should
be defined:
Single door controller Door 1 – OUT2
The output has two activations modes:
Time – active for a specified time and closes when the timer ends
Toggle – active for every change in the output trigger – the trigger
changes state
3.1.9 General
This output is usually related to the general input or automatically by a time
zone.
The following should be defined:
Single door controller Door 1 – OUT2A
The output has three activation modes:
Follow input – output follows the input state
Toggle – active for every change in the output trigger – the trigger
changes state
Time – active for a specified time and closes when the timer ends

Inputs and Outputs
16 AC-215 Installation Manual
3.1.10 Card Readers
Two card readers can be connected to the ACU. The following should be
defined:
Single door controller Door 1 – Reader 1 IN/OUT/Auxiliary
Reader 2 – IN/OUT/Auxiliary
Double door controller Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
The readers can be assigned to a single or double door controller’s door as an
IN or OUT reader and can activate the auxiliary output in a single door
configuration.
The reader’s tamper connects to the ACU and can generate an alarm. The
reader’s green LED input is activated by the ACU when in the Card and PIN
secure mode to inform the user to enter his personal PIN number after entering
his card.
3.1.11 Keypad
Two keypads can be alternatively connected to the ACU on Reader1 and
Reader2 terminals. The following should be defined:
Single door controller Door 1 – Keypad – Reader 1 IN/OUT
Keypad – Reader 2 IN/OUT
Double door controller Door 1 – Keypad – Reader 1 IN/OUT
Door 2 – Keypad – Reader 2 IN/OUT
The keypad type must be a Rosslare format keypad.
A keypad has to be connected for any reader mode that requires PIN code
entries, such as Card or PIN, PIN only or Card and PIN (Secured mode).

DIP Switch Settings Configuration
AC-215 Installation Manual 17
4. DIP Switch Settings Configuration
The ACU DIP switch controls a number of operating parameters including the
device address and baud rates for serial communication.
Power down the ACU before making changes in the dipswitch settings. Restart
the ACU after modifications are made. The new settings are automatically
defined after power up.
The following is a list of DIP switch numbers and their functions:
Table 2: DIP Switches and their Functions
DIP Switch Function
1–2 Set ACU baud rate
3 Sets ACU type (single door or double door controller)
4–8 Set ACU address
4.1 ACU Baud Rate
The ACU serial port baud rate, set in DIP switches one and two, defines the
communication speed for connecting with a PC in a network connection.
The following lists switch 1 and 2 status and baud rate:
Table 3: Switch Baud Rates
Switch 1 Switch 2 Baud Rate
Off Off 9600
Off On 19200
On Off 38400
On On 57600
The ACU baud rate must be identical to the host PC’s serial port baud rate.
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8

DIP Switch Settings Configuration
18 AC-215 Installation Manual
4.2 ACU Type
The ACU type is defined using the third DIP switch. Both the single and double
can be set.
Off – defines single door controls
On – defines a double door controls
4.2.1 Single Door Controller
This access type has two readers, IN and OUT, as follows:
Outputs:
Door lock strike
Auxiliary output
Alarm output
General purpose output
Inputs:
Release to exit
Door monitor input
Tamper input
General purpose input
For more information, see Chapter 3.
4.2.2 Double Door Controller
This access type has two readers, IN and OUT, as follows:
Outputs
Door 1 lock strike
Door 1 alarm output
Door 2 lock strike
Door 2 alarm output
Inputs
REX Door1
Door 1 monitor input
REX Door 2
Door 2 monitor input
1 2 3 4 5 6 7 8

DIP Switch Settings Configuration
AC-215 Installation Manual 19
4.3 ACU Addressing
The DIP switch is used to select the binary coded ACU address.
The ACU address is defined in the AxTraxNG software. For successful
communications, the dipswitch must be defined with the same address.
Table 4 displays the 32 address settings available:
Table 4: Available Panel Addresses
Address Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
1 Off Off Off Off Off
2 Off Off Off Off On
3 Off Off Off On Off
4 Off Off Off On On
5 Off Off On Off Off
6 Off Off On Off On
7 Off Off On On Off
8 Off Off On On On
9 Off On Off Off Off
10 Off On Off Off On
11 Off On Off On Off
12 Off On Off On On
13 Off On On Off Off
14 Off On On Off On
15 Off On On On Off
16 Off On On On On
17 On Off Off Off Off
18 On Off Off Off On
19 On Off Off On Off
20 On Off Off On On
21 On Off On Off Off
22 On Off On Off On
23 On Off On On Off
24 On Off On On On
25 On On Off Off Off
1 2 3 4 5 6 7 8

DIP Switch Settings Configuration
20 AC-215 Installation Manual
Address Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
26 On On Off Off On
27 On On Off On Off
28 On On Off On On
29 On On On Off Off
30 On On On Off On
31 On On On On Off
32 On On On On On
