Rosslare AY-Q64 Assembly instructions

2012
December
AY-Q64
Anti-Vandal PIN & Proximity
Reader
Installation and Programming Manual

Copyright © 2012 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to REL, RSP
Inc. and/or their related companies and/or subsidiaries’ (hereafter:”ROSSLARE”).
Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the express written
permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or
other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN
THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS
AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND
TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION
MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third
party any license to these patents, trademarks, copyrights or other intellectual
property rights, except as expressly provided in any written agreement of
ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time,
without being obliged to announce such revisions or changes beforehand or
after the fact.

Table of Contents
AY-Q64 Installation and Programming Manual iii
Table of Contents
1. Introduction ................................................................7
2. Technical Specifications..............................................8
3. Key Features..............................................................10
4. Installation ................................................................11
4.1 Mounting the AY-Q64 .......................................................... 11
4.2 Wiring the AY-Q64 ............................................................... 12
5. Transmit Mode ..........................................................13
6. Programming the AY-Q64.........................................14
6.1 Entering Programming Mode................................................. 15
6.2 Exiting Programming Mode ................................................... 15
6.3 Selecting Keypad Transmission Format ................................... 16
6.3.1 Keypad Transmission Format Option Number ...............................17
6.4 Selecting Proximity Card Transmission Format......................... 21
6.4.1 Wiegand Card + PIN Transmission Format ....................................22
6.5 Changing the Programming Code.......................................... 23
6.6 Changing the Facility Code.................................................... 24
6.7 Return to Factory Default Settings.......................................... 25
6.8 Replacing a lost Programming Code....................................... 26
A. Limited Warranty ......................................................27

List of Figures
iv AY-Q64 Installation and Programming Manual
List of Figures
Figure 1: Drill Holes for AY-Q64 Controller......................................................11

List of Tables
AY-Q64 Installation and Programming Manual v
List of Tables
Table 1: Wire Color Guide ...............................................................................12
Table 2: Programming Menus..........................................................................14
Table 3: Keypad Transmission Format..............................................................17

Notice and Disclaimer
vi AY-Q64 Installation and Programming Manual
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the
purchase documents.
ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or
subsidiaries’ (hereafter:"ROSSLARE") exclusive warranty and liability is
limited to the warranty and liability statement provided in an appendix at
the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all
functions described in this manual may be available in the specific system
and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital or
injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction
AY-Q64 Installation and Programming Manual 7
1. Introduction
The AY-Q64 is a vandal resistant programmable Wiegand and Clock
& Data proximity card and keypad reader. The AY-Q64 supports
multiple proximity card and keypad formats providing a high level of
compatibility and connectivity with host controllers.
The unit can be programmed to output proximity card data in 26-Bit
Wiegand, Clock & Data, or Wiegand Card + PIN formats.
The keypad can also be programmed to output eight different data
formats.
The AY-Q64 utilizes flash firmware for easy upgrades.
The AY-Q64 package contains the following items:
AY-Q64 access control unit
Installation kit
Installation and operating instructions
Additional non-supplied equipment required:
Compatible host controller
Power supply – 5 to 16 VDC (from a regulated power supply)
Other Rosslare accessories can be found at Rosslare's website:
http://www.rosslaresecurity.com

Technical Specifications
8 AY-Q64 Installation and Programming Manual
2. Technical Specifications
Electrical Characteristics
Power Supply Type Linear type – recommended
Operating Voltage Range 5–16 VDC
Input Current
(not including attached
devices)
Standby: 30 mA
Max: 98 mA
Card Read Distance* 2.5 in. (65 mm) maximum read range
Proximity Card Modulation •26-Bit Wiegand, ASK at 125 KHz
•
Clock & Data, ASK at 125 KHz
Proximity Card Compatibility All 26-Bit EM cards
Keypad Transmit Format •Single Key, Wiegand 6-Bit (Rosslare
Format)
•Single Key, Wiegand 6-Bit with Nibble
and Parity Bits
•Single Key, Wiegand 8-Bit, Nibbles
Complemented
•4 Keys Binary + Facility Code, Wiegand
26-Bit
•1 to 5 Keys + Facility Code, Wiegand
26-Bit
•6 Keys BCD and Parity Bits, Wiegand
26-Bit
•Single Key, 3x4 Matrix Keypad
•1 to 8 Keys BCD, Clock & Data
LED Control Input Dry Contact, N.O.
Tamper Output Open Collector, active low, maximum sink
current is 32 mA
* Measured using Rosslare Proximity Card (AT-14) or equivalent. Range also
depends on electrical environment and proximity to metal

Technical Specifications
AY-Q64 Installation and Programming Manual 9
Environmental Characteristics
Operating Temp. Range -25°F to 145°F (-32°C to 63°C)
Operating Humidity 0 to 95% (non-condensing)
Suitable for outdoor use (meets IP65)
Dimensions
Length x Width x Depth 4.72 x 3 x 1.0 in. (120 x 76 x 27 mm)
Weight 0.9 lb (410 g)

Key Features
10 AY-Q64 Installation and Programming Manual
3. Key Features
Built-in proximity card reader (125 KHz ASK modulation)
Programmable Proximity Card Transmission Format
Clock & Data
Wiegand 26-Bit
Wiegand Card + PIN
Built-in keypad for PIN code entry
Programmable keypad transmission format
Built-in case and back tamper
Tamper output and LED control Input
Programmable Facility code
Two tri-colored LEDs
Internal buzzer provides audible interface feedback
Comes with mounting template for easier installation
Comes with installation kit that includes a security screw and a
security screw tool

Installation
AY-Q64 Installation and Programming Manual 11
4. Installation
4.1 Mounting the AY-Q64
Before starting, select the location to mount the AY-Q64 reader.
This location should be at shoulder height.
1. Drill holes into the back of the metal according to how you want
to mount the AY-Q64. For US Gang Box installation, there are
two indicators on the back of the metal cover specifically aligned
for the US Gang Box (see ”A” in Figure 1). For a four-screw
custom installation, there are four indicators on the back (see “B”
in Figure 1).
Figure 1: Drill Holes for AY-Q64 Controller
2. Route the interface cable from the reader to the controller. A
linear type power supply is recommended.
3. Screw the AY-Q64 back cover to its mounting location.
4. Return the front cover of the AY-Q64 to the mounted back plate.
5. Secure the front cover by using the supplied security screw in the
installation kit. An L-shaped tool is provided for use when
tightening the security screw.

Installation
12 AY-Q64 Installation and Programming Manual
4.2 Wiring the AY-Q64
The reader is supplied with a 16-inch pigtail, having a 6-conductor
cable.
To connect the reader to the controller:
1. Prepare the reader cable by cutting the cable jacket back 1¼
inches and strip the wire ½ inch. Prepare the controller cable by
cutting the cable jacket back 1¼ inches and strip the wire ½ inch.
2. Splice the reader pigtail wires to the corresponding controller
wires and cover each connection (see Table 1).
Table 1: Wire Color Guide
Color Description
Red VDC
Black Ground
White Data 1/Clock
Green Data 0/Data
Brown LED control
Purple Tamper
3. If the tamper output is being utilized, connect the purple wire to
the correct input on the controller.
4. Trim and cover all conductors that are not used.

Transmit Mode
AY-Q64 Installation and Programming Manual 13
5. Transmit Mode
When the AY-Q64 is in Transmit mode, it is ready to receive data
from a presented proximity card or an entered PIN code.
When the reader is in Transmit Mode, the
Transmit LED is red and the Program LED is off.
When a proximity card or keyboard entry is being transmitted, the
Transmit LED turns green momentarily and then returns to red.
Keyboard data can be sent via one of eight different keypad
transmission formats (see Section 6.3).
Proximity cards presented to the reader are always sent in Wiegand
26-Bit, Clock & Data, or Wiegand Card + PIN format formats (see
Section 6.4).
Transmit
Program
Red

Programming the AY-Q64
14 AY-Q64 Installation and Programming Manual
6. Programming the AY-Q64
Programming the AY-Q64 is done solely via the unit's keypad driven
programming menu system. To reach the programming menu system,
the AY-Q64 must first be placed into Programming mode (see Section
6.1).
During the AY-Q64's manufacturing process, certain codes and
settings are pre-programmed. These settings are the called the default
factory settings.
Table 2 shows the names of all the AY-Q64 menus.
Default factory settings are marked by an *sign.
Table 2: Programming Menus
Menu Description Menu Number
Selecting Keypad Transmission Format
Single Key, Wiegand 6-Bit (Rosslare Format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
1
*
Selecting Proximity Card Transmission Format
Wiegand 26-Bit
Clock & Data
Wiegand Card + PIN
2
*
Changing the Programming Code 3
Changing the Facility Code 4
Return to Factory Default Settings 0

Programming the AY-Q64
AY-Q64 Installation and Programming Manual 15
6.1 Entering Programming Mode
To enter Programming mode:
1. Press the #key 4 times within 2 seconds.
The Transmit LED turns off and the
Program LED turns red.
2. Enter your 4-digit Programming code.
If the Programming code is valid, the
Program LED turns green and the AY-
Q64 enters Programming mode.
•The factory default Programming code is 1234.
•If a Programming code is not entered within 30 seconds, the AY-
Q64 returns to Transmit mode.
6.2 Exiting Programming Mode
To exit Programming mode at any time:
1. Press the #key.
You hear 3 beeps.
The Program LED turns off and the
Transmit LED turns red.
This indicates that the AY-Q64 has returned to Transmit mode.
Wrong entries may reset the reader back to Transmit mode.
While in Programming mode, if no key is pressed for 30 seconds,
the AY-Q64 exits Programming mode and returns to Transmit
mode.
Transmit
Program
Red
Transmit
Program
Green
Transmit
Program
Red

Programming the AY-Q64
16 AY-Q64 Installation and Programming Manual
6.3 Selecting Keypad Transmission Format
The AY-Q64 has eight different keypad transmission selectable
formats (see Section 6.3.1).
To select a keypad transmission format:
1. Enter Programming mode.
Press "1" to enter Menu 1.
2. The Transmit LED turns red.
Enter the appropriate option number
for the keypad transmission format that
you wish to select.
One beep is emitted on success.
The system returns to Transmit mode.
The Program LED turns off and the
Transmit LED turns red.
If an incorrect option number is entered, a long beep is sounded.
The reader returns
to Transmit mode and the keypad transmission
format remains unchanged.
•Only one keypad transmission format can be active at any one time
•When using the keypad transmission format “1 to 8 keys BCD,
Clock & Data" (Option 8), an additional input is required to specify
the number of keys in the PIN code.
Transmit
Program
Green
Transmit
Program
Red
Green
Transmit
Program
Red

Programming the AY-Q64
AY-Q64 Installation and Programming Manual 17
6.3.1 Keypad Transmission Format Option Number
See Table 3 to determine the option number for the keypad
transmission format you wish to select.
Table 3: Keypad Transmission Format
Keypad Transmission Format Option Number
Single Key, Wiegand 6-Bit (Rosslare Format)
Single Key, Wiegand 6-Bit with Nibble + Parity Bits
Single Key, Wiegand 8-Bit, Nibbles Complemented
4 Keys Binary + Facility code, Wiegand 26-Bit
1 to 5 Keys + Facility code, Wiegand 26-Bit
6 Keys BCD and Parity Bits, Wiegand 26-Bit
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data Single Key
1*
2
3
4
5
6
7
8
* Option 1 is the default factory setting
More information on each of the different keypad transmission
formats is available below and on the following pages.
6.3.1.1 Single Key, 6-Bit Wiegand (Rosslare Format)
Each key press immediately sends 4 bits with 2 parity bits added; even
parity for the first 3 bits and odd parity for the last 3 bits.
0 = 1 1010 0 6 = 1 0110 0
1 = 0 0001 0 7 = 1 0111 1
2 = 0 0010 0 8 = 1 1000 1
3 = 0 0011 1 9 = 1 1001 0
4 = 1 0100 1 * = 1 1011 1 = "B" in Hexadecimal
5 = 1 0101 0 # = 0 1101 1 = "C" in Hexadecimal
6.3.1.2 Single Key, 6-Bit Wiegand, Nibble & Parities
Each key press immediately sends 4 bits with 2 parity bits added; even
parity for the first 3 bits and odd parity for the last 3 bits.
0 = 0 0000 1 6 = 1 0110 0
1 = 0 0001 0 7 = 1 0111 1
2 = 0 0010 0 8 = 1 1000 1
3 = 0 0011 1 9 = 1 1001 0

Programming the AY-Q64
18 AY-Q64 Installation and Programming Manual
4 = 1 0100 1 * = 1 1010 0 = "B" in Hexadecimal
5 = 1 0101 0 # = 1 1011 1 = "C" in Hexadecimal
6.3.1.3 Single Key, 8-Bit Wiegand, Nibbles Complemented
This option inverts the most significant bits in the message leaving the
least 4 significant bits as Binary Coded Decimal (BCD) representation
of the key. The host system receives an 8-bit message.
0 = 11110000 6 = 10010110
1 = 11100001 7 = 10000111
2 = 11010010 8 = 01111000
3 = 11000011 9 = 01101001
4 = 10110100 *= 01011010 = "A" in Hexadecimal
5 = 10100101 # = 01001011 = "B" in Hexadecimal
6.3.1.4 4 Keys Binary + Facility Code, 26-Bit Wiegand
This option buffers 4 keys and outputs keypad data with a three-digit
Facility code like a standard 26-bit card output.
The Facility code is set in Programming Menu number four and can be
in the range 000 to 255. The factory default setting for the Facility
code is 000 (see Section 6.6).
The keypad PIN code must be 4 digits long and can range between
0000 and 9999. On the fourth key press of the 4-digit PIN code, the
data is sent across the Wiegand Data lines as binary data in the same
format as a 26-Bit card.
If the "*" key or the "#" key are pressed during PIN code entry, the
keypad clears the PIN code entry buffer, generates a beep and is
ready to receive a new 4-digit keypad PIN code.
If the entry of the 4-digit keypad PIN code is disrupted and no number
key is pressed within 5 seconds, the keypad clears the PIN code entry
buffer, generates a beep, and is ready to receive a new 4-digit keypad
PIN code.
(EP) FFFF FFFF AAAA AAAA AAAA AAAA (OP)

Programming the AY-Q64
AY-Q64 Installation and Programming Manual 19
Where: EP = Even parity for first 12 bits
OP = Odd parity for last 12 bits
F = 8-Bit Facility code
A = 24-Bit code generated from keyboard
6.3.1.5 1 to 5 Keys + Facility Code, 26-Bit Wiegand
This option buffers up to 5 keys and outputs keypad data with a
facility code like a 26-Bit card output.
The facility code is set in Programming Menu number four and can be
in the range 000 to 255. The factory default setting for the facility
code is 000 (see Section 6.6).
The keypad PIN code can be one to five digits long and can range
between 1 and 65,535. When entering a keypad PIN code that is less
than 5 digits long, the "#" key must be pressed to signify the end of
PIN code entry. For keypad PIN codes that are 5 digits long, on the
fifth key press of the 5-digit PIN code, the data is sent across the
Wiegand Data lines as binary data in the same format as a 26- Bit
Card.
If the “*“ key or the “#“ key are pressed during PIN code entry or a
PIN code greater than 65,535 is entered, the keypad clears the PIN
code entry buffer, generates a beep and is ready to receive a new 4-
digit keypad PIN code.
If the entry of the 1 to 5 digit keypad PIN code is disrupted and no
number key or "#" key is pressed within 5 seconds, the keypad clears
the PIN code entry buffer, generates a medium length beep and is
ready to receive a new 1 to 5-digit keypad PIN code.
(EP) FFFF FFFF AAAA AAAA AAAA AAAA (OP)
Where: EP = Even parity for first 12 bits
OP = Odd parity for last 12 bits
F = 8-Bit Facility code
A = 24-bit code generated from keyboard

Programming the AY-Q64
20 AY-Q64 Installation and Programming Manual
6.3.1.6 6 Keys BCD and parity bits, 26-Bit Wiegand
Sends buffer of 6 keys, adds parity and sends a 26-bit BCD message.
Each key is a four bit equivalent of the decimal number.
The keypad PIN code must be 6 key presses long. On the sixth key
press of the 6-digit PIN code, the data is sent across the Wiegand data
lines as a BCD message.
If the entry of the 6-digit keypad PIN code is disrupted and no number
key is pressed within 5 seconds, the keypad clears the PIN code entry
buffer, generates a medium length beep and is ready to receive a new
6-digit keypad PIN code.
(EP) AAAA BBBB CCCC DDDD EEEE FFFF (OP)
Where:
A = First key entered D = Fourth key entered
B = Second key entered E = Fifth key entered
C = Third key entered F = Sixth key entered
6.3.1.7 Single Key, 3x4 Matrix Keypad (MD-P64)
This unique mode is intended to let the host controller scan the AY-
Q64 keypad while still keeping the proximity card readers 26-Bit
Wiegand or Clock & Data formats active.
An optional interface board must be used between the AY-Q64 and
the host system. Each key press is immediately sent on DATA0 as an
ASCII character at a baud rate of 9600 bits per second.
When a key is pressed, DATA1 is pulled "low" until the key is
released at which point DATA1 is set to "high". This allows the
controller to detect the duration of the key press.
The MD-P64 interface unit outputs the data received to 7 outputs
emulating a keyboard. The interface unit does not affect any data
that it receives from the proximity reader whether it is 26-Bit Wiegand
or Clock & Data.
Key pressed = ASCII Value
0 = '0' (0x30 hex) 6 = '6' (0x36 hex)
1 = '1' (0x31 hex) 7 = '7' (0x37 hex)
