Rosslare PC-15R Operation and maintenance manual

PC-15R WITH ENCLOSURES
PS-A15R / PS-E15R
The PS-A15R and
PS-E15R enclosures
includes a built-in
speaker and enough
room for a CE or UL
approved transformer.
The PS-A15R comes with a built-in CE
approved transformer. That is Class II Rated
(Double insulated) and contains thermal fuse
protection. Max: 125 C, 1A. See transformer
specifications below.
230 VAC ~ 50Hz, 0.14 A
16 VAC ~ 1.5A, 25 VA
CE
A1:1998
EN 61558-1:1997
EN 61558-2-6:1997
The PS-E15R is shipped without a
transformer and is designed to be powered
from an external transformer. When sold in
the United States a UL approved transformer
is recommended.
The enclosure weight and dimensions are
provided below.
182mm (7.2”) Length
80mm (3.1”) Width
68mm (2.7”) Depth
1.24Kg (2.7lbs) PS-A15R
0.63Kg (1.3lbs) PS-E15R
PS-A15R
PS-E15R
Input:
Output:
Certifications:
Compliance:
Dimensions:
Weight:
°
PC-15R / PS-A15R/ PS-B15R
PS-E15R / PS-F15R
POWER SUPPLY
INSTALLATION INSTRUCTIONS
INTRODUCTION & KEY FEATURES
The PC-15R Power Supply is designed for use
with all Rosslare conventional stand-alone
Access Control Units (ACU).
The power supply is also capable of driving an
external speaker that is controlled by the ACU to
annunciate the Bell tone.
COMPATIBLE CONTROLLERS
List of compatible controllers by model
number.
AC-05
AC-06
AC-07
AC-08
The PC-15R has a regulated charging circuit
designed to keep a backup 12 VDC lead acid
battery fully charged, for use in the event of a
power failure. For best results a 12 VDC battery
with up to 7AH is recommended.
The bell button on any compatible ACU will
activate the PC-15R auxiliary output. The output
will remain active for as long as the bell button is
pushed.
A release to exit (REX) button can also be
attached to the power supply if it is required.
ROSSLARE
ELECTRICAL SPECIFICATIONS
AC Input:
DC Battery Charger:
DC Input wired to backup battery
terminals:
Lock Strike Output and Power Supply:
Controller Power Supply:
Auxiliary Output:
Power LED & Speaker Output:
16 ~ 18 VAC (1.5 A, 25 VA)
12V DC Lead Acid Battery
Up to 7AH recommended
10-16VDC
Battery current draw depends
on attached devices.
5 A Relay
SPDT connection available via
terminal blocks.
12 VDC, constant voltage
1.2 A current limit.
12 VDC, constant voltage
1.2 A current limit.
Open collector, active low
50 mA max. sink current @ 12 VDC
Power LED indicator.
8 OHM, 0.25 W (Minimum)
For bell, chime and siren alerts.
ENVIRONMENTAL SPECIFICATIONS
MECHANICAL SPECIFICATIONS
WIRING RECOMMENDATIONS
PCB MOUNTING DIMENSIONS
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
(14
56 grams (0.11 lbs)
77mm (3.0”) Length
57mm (2.2”) Width
33mm (1.3”) Depth
Maximum distance between the Controller
and the PC-15R is 150m (500ft).
Lock wiring should be 20 Gage
Communication wiring (R1 & R2) should be
twisted Pair, 22 Gage, shielded or unshielded.
Dimensions for PCB mounting holes are
provided below.
-10°C to 70°C °F to 158°F)
0 to 95% (Non-Condensing)
66mm (2.6”)
46mm (1.8”)

PS-15R WITH ENCLOSURES
PS-B15R / PS-F15R
The PS-B15R and
PS-F15R enclosures
includes a built-in
speaker and enough
room for a CE or UL
approved transformer
as well as a lead acid
backup battery (up-to
7 AH).
The PS-B15R comes with a built-in CE
approved transformer. That is Class II Rated
(Double insulated) and contains thermal fuse
protection. Max: 125 C, 1A. See transformer
specifications below.
230 VAC ~ 50Hz, 0.14 A
16 VAC ~ 1.5A, 25 VA
CE
A1:1998
EN 61558-1:1997
EN 61558-2-6:1997
The PS-F15R is shipped without a
transformer and is designed to be powered
from an external transformer. When sold in
the United States a UL approved transformer
is recommended.
The enclosure weight and dimensions are
provided below.
205mm (8.1”) Length
200mm (7.9”) Width
82mm (3.2”) Depth
1.24Kg (2.7lbs) PS-B15R
0.63Kg (1.3lbs) PS-F15R
PS-B15R
PS-F15R
Input:
Output:
Certifications:
Compliance:
Dimensions:
Weight:
°
WIRING DIAGRAM
Wiring diagram and schematic for the PC-15R, PS-A15R, provided
below.
PS-B15R, PS-E15R, PS-F15R are
+V R1 R2
SPLIT CONTROLLER
N.C. N.O. AUX.
LOCK 12VDC
VIN +BAT
16VAC 12VDC
ROSSLARE
PC-15R
SPEAKER OUT
OUTPUT LED
OP-PSA13-V3
(O.C)
16V AC (1.5A, 25VA)
Not provided in
PS-E15R and PS-F15R
12V LEAD ACID
BATTERY
UP TO 7 AH
RECOMMENDED
COMPATIBLE
ROSSLARE
CONTROLLER
ELECTRIC LOCK
STRIKE
FAIL SAFE
or
FAIL SECURE
REX
RELEASE TO
EXIT BUTTON
(NORMALLY OPEN)
TECHNICAL SUPPORT
WARRANTY
International Web Site:
Asia, Australia, & South America
Europe, Russia, Middle East, Africa
United States and Canada
http:///www.rosslare.com.hk/support/
Rosslare Enterprises Ltd.
905-912 Wing Fat Industrial Bldg.,
12 Wang Tai Road, Kowloon Bay,
Hong Kong.
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Rosslare Security Products S.r.l
Via F.lli Gabba 5, 20121 Milano, Italy
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
[email protected]
Rosslare NAPDC
200 East Howard Street, Suite 238,
Des Plaines, IL 60018
USA
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
:
:
:
The Manufacturer's warranty on this product is for a period
of two years from the date of manufacture against defects
in materials and workmanship. Manufacturer's warranty
hereunder is limited to repair or replacement, at the
manufacturer's sole option, if the product is found to be
defective in normal use during the warranty period. The
warranty is given in favor of the original purchase only.
Subject to the above warranty, manufacturer's liability and
that of it's distributors, re-sellers and agents and is wholly
limited to the original purchase price and no payment will
be made for related or consequential loss including but not
limited to labor costs incurred in inspection, replacement or
repair of defective products. This warranty is given
expressly and in place of all other expressed or implied
warranties of merchantability and fitness for a particular
purpose and this warranty is the only warranty made by the
manufacturer. No agent, representatives or employee of
the manufacturer has the authority to waive, alter or add to
the printed provisions of this warranty, to make
representation of warranty not contained herein or to
extend this warranty to anyone other than the original
purchaser of the product. The PC-15R, PS-A15R, PS-
B15R, PS-E15R, and PS-F15R are guaranteed against
defects in workmanship and material for a period of 24
(Twenty Four) months from date of purchase. Return the
faulty product with a dated proof of purchase to your dealer
for replacement.
-
+V
R1
R2
N.C.
N.O.
FROM A TRANSFORMER
0706-0820026-00
(12 VDC @ 1.2 A)
AC Mains
AUXILIARY OUTPUT
