Rosslare PS-A25T User manual

PS-x25T/TU/LT
Intelligent Dual-Relay Secured Power Supply
Installation Manual
1
1. Introduction
The PS-x25 family of secured power supplies converts AC power to 12
VDC power limited output (see Section 2) with an integrated battery
charger, designed for use with all of Rosslare's convertible and secure
access controller units (ACU).
The PS-x25 family contains two power supplies, one for the lock
output and the other for the ACU.
This design isolates the lock from the ACU, securing the functionality
of the lock even if the ACU is tampered with.
When a valid code is entered via the ACU, it communicates with the
PS-x25 family using a Rosslare proprietary protocol sending a
command to activate the lock or auxiliary relay.
Similarly, the Release-to-Exit (REX) button is attached directly to the PS-
x25 unit.
If the data line between the ACU and the PS-x25 unit is cut, the system
immediately detects that the data line has been tampered with and
generates a one-minute siren and closes the lock output. In addition,
the auxiliary relay can be activated by the ACU.
A sealed lead acid battery charger is built-in to provide backup power
for the ACU and the lock. The PS-x25 can also power an external
speaker to annunciate bell and siren tones.
Figure 1: PS-A25T/TU/LT Figure 2: PS-C25T/TU/LT
2. Technical Specifications
2.1 Electrical Characteristics
PS-A25T*
PS-C25T* PS-C25TU
Input 230 VAC, 50 Hz, 0.14 A 16 VAC (25 VA)
x25LT models: 16 to 24 VAC (25 VA)
Internal
Transformer
230/16 VAC, 25 VA N/A
DC Output DC output: 11.7~13.2 VDC, 1 A max. combined ACU output
and lock power supply
Lock Output 5 A, SPDT relay.
Max Switched current: 5 A
Max Switched voltage: 150 VDC or 300 VAC
UL Rating: 5 A at 30 VDC or 5 A at 125 VAC
Auxiliary
Output
5 A, SPDT relay.
Max Switched current: 5 A
Max Switched voltage: 150 VDC or 300 VAC
UL Rating: 5 A at 30 VDC or 5 A at 125 VAC
Speaker In casing In casing External
Speaker Output 8 Ohm, 0.25 W (minimum) for bell chime and siren alerts
Space for
Backup Battery
No Yes
Battery Backup N/A Built-in charger for sealed UL certified 7 Ah
battery lead acid or gel
Maximum charge current 1.2 A
Automatic switch over to stand-by battery when
AC fails
Risk of explosion when battery is
replaced with a wrong battery
type.
Visual Indicators DC output LED indicator on PCB
Additional
Features
Short circuit and thermal overload protection
Includes battery leads
Communications
Rosslare proprietary protocol
*Model not UL listed
2.2 5BEnvironmental Characteristics
Operating Temperature -10°C to 50°C (14°F to 122°F)
Operating Humidity 0 to 85% (non-condensing)
2.3 6BPhysical Characteristics
PS-A25T PS-C25T/LT PS-C25TU
Dimensions
(H x W x D)
182 x 80 x 68 mm
(7.2 x 3.1 x 2.7 in.)
225 x 230 x 76 mm
(8.85 x 9.05 x 3.00 in.)
Weight 1.24 kg (2.73 lb) 2.44 kg (5.38 lb) 1.5 kg (3.3 lb)

2
3. Installation
The PS-x25 should be installed in accordance with article 760 of the
National Electric Code NFPA 72 as well as applicable local codes.
The circuit breaker must be closed to the PS-x25 and must be
accessible.
3.1 Mounting
The PCB mounting holes dimensions for the C-box are provided in
Figure 3.
Figure 3: PCB Mounting Holes Dimensions
3.2 Wiring
Refer to the wiring diagram in Section 4.
To wire the unit:
1. Mount the PS-x25 within the secured perimeter.
2. Connect AC power (16.5 VAC, 60 Hz to the marked terminals, "~
VIN ~". Use a Class 2 transformer such as DSC Part No.
PTC1640U.
Use 18 AWG or larger for all power connections (battery, DC
output).
Ensure that the power-limited circuit is wired separately from the
non-power limited wiring (16.5 VAC, battery)
3. Connect the ACU’s power input to the power terminal marked
[SECURED CONTROLLER +V and (-)]
4. Connect the two lock outputs to the power terminal marked
[LOCK 12VDC N.C or N.O]
5. Connect the auxiliary relay if needed.
6. [OPTIONAL] Connect the battery terminal to power terminal
marked [12V DC +Bat and (-)] (Battery leads included)
A backup battery is optional. When a battery is not used, loss of
AC results in the loss of output voltage. When using a backup
battery, it must be a UL certified "lead acid" or "gel" type.
7. Panic hardware shall not be used with this device.
3.3 Maintenance
For proper operation, the unit should be tested at least once a year.
3.3.1 Output Voltage Test
Check DC output for proper voltage level under normal load
conditions.
3.3.2 Battery Test
Check specified voltage, at both battery terminal and board terminals
marked [12VDC +Bat and (-)] under normal load conditions, verify that
the battery is fully charged and insure there is no break in the battery
connection wires.
Maximum charging current under discharges is 1.2 A.
Expected battery life is 5 years; however, it is recommended to
change batteries in 4 years or less if needed.
Dispose of used batteries according to manufacturers’
instructions.
4. Wiring Diagram

3
