Rotel A11 User manual

A11
Stereo Integrated Amplier
Amplicateur Stéréo Intégré
Stereo-Vollverstärker
Amplicador Integrado Estereofónico
Geïntegreerde stereoversterker
Amplicatore integrato stereo
Integrerad stereoförstärkare
Интегрированный стерео усилитель
Owner’s Manual
Manuel de l’utilisateur
Bedienungsanleitung
Manual de Instrucciones
Gebruikershandleiding
Manuale di istruzioni
Instruktionsbok
Инструкция пользователя

2A11 Stereo Integrated Amplier
You must allow a minimum 10 cm or 4 inches of unobstructed
clearance around the unit.
WARNING: The rear panel power cord connector is the mains power
disconnect device. The device must be located in an open area that
allows access to the cord connector.
The unit must be connected to a power supply only of the type and
voltage specified on the rear panel. (USA: 120 V/60Hz, EC: 230V/50Hz)
Connect the component to the power outlet only with the supplied
power supply cable or an exact equivalent. Do not modify the supplied
cable. Do not use extension cords.
The mains plug is the disconnect of the unit. In order to completely
disconnect the unit from the supply mains, remove the main plug from
the unit and the AC power outlet. This is the only way to completely
remove mains power from the unit.
Use Class 2 wiring for speaker connections to ensure proper installation
and minimize the risk of electrical shock.
The batteries in the remote control should not be exposed to excessive
temperature such as sunshine, re or other heat sources. Batteries
should be recycled or disposed as per state and local guidelines.
Notice
The RS232 connection should be handled by authorized persons only.
WARNING: There are no user serviceable parts inside. Refer all
servicing to qualified service personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose
the unit to moisture or water. Do not expose the unit to dripping or
splashing. Do not place objects filled with liquids, such as vases, on
the unit. Do not allow foreign objects to get into the enclosure. If the
unit is exposed to moisture, or a foreign object gets into the enclosure,
immediately disconnect the power cord from the wall. Take the unit
to a qualified service person for inspection and necessary repairs.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use with caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
The apparatus should be used in non tropical climate.
Rotel products are designed to comply with
international directives on the Restriction of Hazardous
Substances (RoHS) in electrical and electronic
equipment and the disposal of Waste Electrical and
Electronic Equipment (WEEE). The crossed wheelie bin
symbol indicates compliance and that the products must
be appropriately recycled or processed in accordance
with these directives.
Important Safety Instructions
This symbol means that this unit is double insulated.
An earth connection is not required.

3
Figure 1: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Controlli e connessioni
De bedieningsorganen en aansluitingen
Kontroller och anslutningar
Органы управления и разъемы
1 3 4 5 6
7 8
9 0 - = q w e r
t y u i o
2

4A11 Stereo Integrated Amplier
A
B
C
D
E
F
G
H
I
N
L
K
J
M
Figure 2: Remote Control RR-AX1401
Télécommande infra-rouge RR-AX1401
Fernbedienung RR-AX1401
Mando a Distancia RR-AX1401
Telecomando RR-AX1401
De afstandsbediening RR-AX1401
Fjärrkontroll RR-AX1401
Пульт ДУ RR-AX1401

5
Figure 3: Preamp Input and Speaker Output Connections
Branchements des entrées sources et sorties enceintes acoustiques
Anschlussdiagramm
Conexiones para Entrada de Señal y Salida a las Cajas Acústicas
Collegamenti ingressi e diffusori
De signaalingangen en de luidsprekeruitgangen
Signal- och högtalaranslutningar
Подсоединение источников сигнала и акустических систем
CD PLAYER
PHONO
Amplifier A11

6A11 Stereo Integrated Amplier
Figure 4: 12V Trigger Connections
Branchements trigger 12 V
12V-Trigger-Anschlüsse
Conexiones para Señal de Disparo de 12V
Amplifier A11
CLASS 1
LASER PRODUCT
APPAREIL LASER
DE CLASSE 1
MODEL NO.: CD11
RP-587
CD Player CD11
De 12V trigger aansluitingen
Collegamenti segnali Trigger 12 V
12 V-anslutning för styrsignal
Подсоединение 12-В триггерного сигнала

7
Important Notes
When making connections be sure to:
4Turn off all the components in the system before hooking up any components, including loudspeakers.
4Turn off all components in the system before changing any of the connections to the system.
It is also recommended that you:
4Turn the volume control of the amplifier all the way down before the amplifier is turned on or off.
Remarques importantes
Pendant les branchements, assurez-vous que :
4Tous les maillons sont éteints avant leur branchement, quels qu’ils soient, y compris les enceintes acoustiques.
4Éteignez tous les maillons avant de modifier quoi que ce soit au niveau de leurs branchements, quels qu’ils soient.
Il est également recommandé de :
4Toujours baissez le niveau sonore via le contrôle de volume, avant d’allumer ou d’éteindre l’amplificateur.
Wichtige Hinweise
Achten Sie beim Herstellen der Verbindungen auf Folgendes:
4Schalten Sie alle Komponenten im System ab, bevor Sie Geräte (einschließlich Lautsprecher) anschließen.
4Schalten Sie alle Komponenten im System ab, bevor Sie Anschlüsse im System verändern.
Ferner empfehlen wir, dass
4Sie die Lautstärke herunterdrehen, bevor Sie die Endstufe ein- oder abschalten.
Notas Importantes
Cuando realice las conexiones, asegúrese de que:
4Desactiva todos los componentes del equipo, cajas acústicas incluidas, antes de conectar cualquier nuevo componente en el mismo.
4Desactiva todos los componentes del equipo antes de cambiar cualquier conexión del mismo.
También le recomendamos que:
4Reduzca el nivel de volumen de su amplificador a cero antes de activarlo o desactivarlo.
Héél belangrijk
Bij het maken van de verbindingen:
4Zorg dat niet alleen de A11, maar de gehele installatie uitstaat, als nog niet alle verbindingen gemaakt zijn.
4Zorg dat niet alleen de A11, maar de gehele installatie ook uitstaat, als u verbindingen gaat wijzigen.
Wij raden u ook aan om
4de volumeregelaar van de voorversterker geheel dicht te draaien (volkomen naar links) wanneer u uw eindversterker aan- of uitzet.
Note importanti
Quando effettuate i collegamenti assicuratevi di:
4Spegnere tutti i componenti del sistema prima di collegare qualsiasi componente, inclusi i diffusori.
4Spegnere tutti i componenti del sistema prima di modificare qualsiasi connessione nel sistema.
Vi raccomandiamo inoltre di:
4Portare il volume a zero prima di accendere o spegnere l’amplificatore.
Viktigt
Tänk på följande när du gör anslutningar:
4Stäng av alla apparater i anläggningen innan du ansluter nya komponenter eller högtalare.
4Stäng av alla apparater i anläggningen innan du ändrar någon anslutning.
Du rekommenderas också:
4Vrid ner volymen på förförstärkaren helt och hållet innan förstärkaren slås på eller av.
Важные замечания
Перед подсоединением:
4Выключите все компоненты, включая колонки.
4Выключите все компоненты в вашей системе, прежде чем что-то в ней менять.
Рекомендуется также:
4Вывести громкость усилителя на минимум, перед тем как включать или выключать его.

8A11 Stereo Integrated Amplier
About Rotel
Our story began over 50 years ago. Over the decades, we have received
hundreds of awards for our products and satised hundreds of thousands
of people who take their entertainment seriously – like you.
Rotel was founded by a family whose passionate interest in music led them
to manufacture high-delity components of uncompromising quality.
Through the years, that passion has remained undiminished and the family
goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.
Rotel’s engineers work as a close team, listening to, and ne tuning, each
new product until it reaches their exacting musical standards. They are
free to choose components from around the world in order to make that
product the best they can. You are likely to nd capacitors from the United
Kingdom and Germany, semiconductors from Japan or the United States,
while toroidal power transformers are manufactured in Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced it is especially important for a manufacturer to do all
it can to engineer products that have a minimum impact on the environment.
At Rotel, we are proud to do our part. We have reduced the lead content
in our products by using special lead-free ROHS solder and components.
Our engineers continually strive to improve power supply efciency without
compromise to quality. When in standby mode Rotel products use minimal
power to meet global Standby Power Consumption requirements.
The Rotel factory is also doing their part to help the environment through
constant improvements to product assembly methods for a cleaner and
greener manufacturing processes.
All of us at Rotel thank you for buying this product. We are sure it will bring
you many years of enjoyment.
Getting Started
Thank you for purchasing the Rotel A11 Stereo Integrated Amplier. When
used in a high-quality music audio system, Rotel products will provide years
of musical enjoyment.
This amplier is a full featured, high performance component. All aspects
of the design have been optimized to retain the full dynamic range and
subtle nuances of your music. The un it has a highly regulated power supply
incorporating a Rotel custom-designed toroidal power transformer. This low
impedance power supply has ample power reserves, which enables the
amplier to easily reproduce the most demanding audio signals. This type
of design is more expensive to manufacture, but it is better for the music.
The printed circuit boards (PCB) are designed with Symmetrical Circuit
Traces. This ensures that the precise timing of the music is maintained and
faithfully recreated. The circuitry uses metal lm resistors and polystyrene
or polypropylene capacitors in important signal paths. All aspects of this
design have been examined to ensure the most faithful music reproduction.
The main functions of the A11 are easy to install and use. If you have
experience with other stereo systems, you shouldn’t nd anything perplexing.
Simply plug in the associated components and enjoy.
Contents
Important Safety Instructions ..........................................2
Figure 1: Controls and Connections 3
Figure 2: Remote Control RR-AX1401 4
Figure 3: Preamp Input and Speaker Output Connections 5
Figure 4: 12V Trigger Connections 6
Important Notes 7
About Rotel .......................................................8
Getting Started ....................................................8
A Few Precautions 9
Placement 9
Cables 9
The RR-AX1401 Remote Control........................................9
Second Amplier Remote Code 9
Remote Control Batteries 9
AC Power and Control ...............................................9
AC Power Input o 9
Power Switch 1Aand Power Indicator 2 10
12V Trigger Connection e10
Protection Indicator 2..............................................10
Input Signal Connections ............................................10
Phono Input 0and Ground Connection (GND) 910
Line Level Inputs -=t 10
Preamp Output y................................................10
Speaker Outputs ui .............................................10
Speaker Selector Switch 410
Speaker Selection 10
Speaker Wire Selection 10
Polarity and Phasing 10
Speaker Connection 11
Headphone Output 3..............................................11
Display 5......................................................11
APTX Bluetooth Connection q........................................11
Audio Controls ....................................................11
Volume Control 6E11
Balance Control 8B 11
Source Input Selector 7I 11
Tone Control .....................................................11
Tone Bypass 11
Tone Enabled 11
Tone Rotel Boost 12
Tone Rotel Max 12
Bass and Treble Controls 8B 12
Dimmer Control ...................................................12
Display Dimmer 8D 12
LED Dimmer 8 12
EXT REM IN Jack w...............................................12
RS232 Connector r...............................................12
Settings Menu ....................................................12
Troubleshooting ...................................................13
Power Indicator Is Not Illuminated 13
Fuse Replacement 13
No Sound 13
Playable Audio Formats 13
Cannot Connect via Bluetooth 13
Specications.....................................................14

9
A Few Precautions
WARNING: To avoid potential damage to your system, turn off ALL
the components in the system when connecting or disconnecting the
loudspeakers or any associated components. Do not turn the system
components back on until you are sure all the connections are correct
and secure. Pay particular attention to the speaker wires. There must
be no loose strands that could contact the other speaker wires, or the
chassis of the amplifier.
Please read this manual carefully. It provides information on how to
incorporate the unit into your system as well as information that will help
you get optimum sound performance. Please contact your authorized Rotel
dealer for answers to any questions you might have. In addition, all of us
at Rotel welcome your questions and comments.
Save the shipping carton and all enclosed packing material for future use.
Shipping or moving the amplier in anything other than the original packing
material may result in severe damage to your amplier.
If included in the box please ll out and send in the owner’s registration
card. Also be sure to keep the original sales receipt. It is your best record
of the date of purchase, which you will need in the event warranty service
is ever required.
Placement
Like all audio components that handle low level signals, this amplier
can be affected by its environment. Avoid placing the unit on top of other
components. Also avoid routing audio signal cables near power cords. This
will minimize the chance it will pick up hum or interference.
The unit generates heat as part of its normal operation. The heat sinks and
ventilation openings in the amplier are designed to dissipate this heat.
The ventilation slots in the top cover must be open. There should be 10 cm
(4 inches) of clearance around the chassis, and reasonable airow through
the installation location, to prevent the amplier from overheating.
Remember the weight of the amplier when you select an installation location.
Make sure that the shelf or cabinet can support it. We recommend installing
the unit in furniture designed to house audio components. Such furniture is
designed to reduce or suppress vibration which can adversely affect sound
quality. Ask your authorized Rotel dealer for advice about component
furniture and proper installation of audio components.
Cables
Be sure to keep the power cords, digital signal cables and analog audio
signal cables in your installation away from each other. This will minimize
the chance of the analog audio signal cables picking up noise or interference
from the power cords or digital cables. Using only high quality, shielded
cables will also help to prevent noise or interference from degrading the
sound quality of your system. If you have any questions see your authorized
Rotel dealer for advice about the best cable to use with your system.
The RR-AX1401 Remote Control
Some functions can be done with either the front panel controls, or the
supplied RR-AX1401 remote control. When these operations are described,
the square call out numbers refer to the main unit, while the encircled letters
refer to the remote control.
Second Amplier Remote Code
The factory setting is remote code 1. If you nd that the remote is conicting
with other Rotel ampliers, you can change to remote code 2 with the
following steps.
1. From the remote control press Tuner Iand 2 Mat the same time for 5
seconds, to set the remote control to send Audio Code 2.
2. Point the remote at the unit and press 2 Mbutton for 14 seconds. The
unit will show “Audio Code SET 1 -> 2”.
3. Repeat the above procedure and press “1” button instead of “2” to
change the unit back to Code 1.
NOTE: The remote control can be used to operate the basic functions
of Rotel tuners and CD players. Remote control keys labeled GHMN
can be used to operate CD or Tuner functions in your system. For the
remote to operate properly, make sure both the remote and the CD or
Tuner are both in same remote code, either Code 1 or 2.
Remote Control Batteries
Two AAA size batteries (supplied) must be installed before the remote control
can be used. To install the batteries, remove the cover on the back of the
RR-AX1401. Install the batteries as shown in the illustration in the battery
well. Test the control for proper operation, then replace the cover. When the
batteries become weak the remote control won’t operate the A11 consistently.
Installing fresh batteries should eliminate the problem.
AC Power and Control
AC Power Input o
Your unit is congured at the factory for the proper AC line voltage in the
country where you purchased it (either 120 volts AC or 230 volts AC with
a line frequency of either 50 Hz or 60 Hz). The AC line conguration is
noted on a decal on the back panel.
NOTE: Should you move your amplifier to another country, it is possible
to reconfigure it for use on a different line voltage. Do not attempt to
perform this conversion yourself. Opening the enclosure of the unit
exposes you to dangerous voltages. Consult a qualified service person
or the Rotel factory service department for information.
NOTE: Some products are intended for sale in more than one country
and as such are supplied with more than one AC cord. Please only use
the one appropriate for your country/region.
The unit does not draw high levels of current from the power outlet. However,
it should be plugged directly into a polarized wall outlet using the supplied
cable or other compatible cable as recommended by your authorized Rotel
dealer. Do not use an extension cord. A heavy duty multi-tap power outlet
strip may be used if it (and the wall outlet) can handle the current demanded
by the amplier and all the other components connected to it.
If you are going to be away from home for an extended period of time
such as a month-long vacation, it is a sensible precaution to unplug your
amplier (as well as other audio and video components) while you are away.

10 A11 Stereo Integrated Amplier
Power Switch 1Aand Power Indicator 2
Press the front panel Power Switch button 1to turn the unit on. The Power
Indicator light 2is illuminated when the unit is on. Press Power Switch
button again to turn the unit off.
When the power switch is in the ON position, the remote control ON and
OFF buttons may be used to activate the A11. In Standby mode the power
LED is red, but the display is turned OFF.
12V Trigger Connection e
See Figure 4
Some audio components can be turned on automatically when they receive
a 12V turn on signal. The two 12V Trigger Outputs of the A11 unit provide
the required signal. Connect compatible components to the amplier with a
conventional 3.5mm mini plug cable. When the unit is in standby mode or
turned off, the trigger signal is interrupted, and the components controlled
by it are turned off.
Protection Indicator 2
The amplier has both thermal and over-current protection circuitry that
protects the amplier against damage in the event of extreme or faulty
operating conditions. The protection circuits are independent of the audio
signal and have no impact on sonic performance. Instead, the protection
circuits monitor the temperature of the output devices and shut down the
amplier if temperatures exceed safe limits.
Most likely, you will never see this protection circuitry in action. However,
should a faulty condition arise, the amplier will stop playing and will
display “AMP PROTECTION“ on the front panel. The power indicator 2
on the front panel will turn red.
If this happens, turn the amplier off. Let it cool down for several minutes,
and attempt to identify and correct the problem that caused the protection
circuitry to engage. When you turn the amplier back on, the protection
circuit will automatically reset and the power indicator 2should turn blue.
In most cases, the protection circuitry activates because of a fault condition
such as shorted speaker wires, or inadequate ventilation leading to an
overheating condition. In very rare cases, highly reactive or extremely
low impedance speaker loads could cause the protection circuit to engage.
If the protection circuitry triggers repeatedly and you are unable to isolate
and correct the faulty condition, contact your authorized Rotel dealer for
assistance in troubleshooting.
Input Signal Connections
See Figure 3
NOTE: To prevent loud noises that neither you nor your speakers will
appreciate, make sure the system is turned off when you make any
signal connections.
Phono Input 0and Ground Connection (GND) 9
Plug the cable from the turntable into the appropriate left and right phono
inputs. If the turntable has a “ground” wire, connect it to the screw terminal
to the left of the Phono inputs. It will help prevent hum and noise.
Line Level Inputs -=t
The CD, Tuner, and Aux inputs of the amplier are “line level” inputs. These
are for connecting components such as CD players or other audio playback
devices with an analog audio output.
The Left and Right channels are labeled and should be connected to the
corresponding channels of the source component. The Left connectors
are white, the Right connectors are red. Use high quality RCA cables for
connecting input source components to the unit. Ask your authorized Rotel
dealer for advice about cables.
Preamp Output y
The amplier has a set of preamp outputs labeled PRE OUT. The currently
selected source input is available from this output. Typically the PRE OUT
output is used to provide a signal to another integrated amplier or power
amplier, which is used to drive remote speakers.
NOTE: Changes to the settings of the Volume, Balance or Tone controls
affect the signal from the Preamp Output.
Speaker Outputsui
See Figure 3
Speaker Selector Switch 4
The amplier has two sets of speaker outputs, labeled “SPEAKER A” uand
“SPEAKER B” i. The speaker outputs are controlled by the A-B speaker
selector buttons 4on the front panel or Jon the remote control.
Speaker Selection
If only one set of speakers will be used at any given time, the speakers may
have an impedance as low as 4 ohms. If there are times when both the A
and B speakers will be used, all the speakers should have an impedance
of 8 ohms or more. Speaker impedance ratings are less than precise. In
practice, very few loudspeakers will present any problems for the unit. See
your authorized Rotel dealer if you have any questions.
Speaker Wire Selection
Use insulated two-conductor stranded wire to connect the unit to the speakers.
The size and quality of the wire can have an audible effect on the performance
of the system. Standard speaker wire will work, but can result in lower
output or diminished bass response, particularly over longer distances. In
general, heavier wire will improve the sound. For best performance, you
may want to consider special high-quality speaker cables. Your authorized
Rotel dealer can help in the selection of cables for your system.
Polarity and Phasing
The polarity - the positive/negative orientation of the connections - for every
speaker and amplier connection must be consistent so all the speakers will
be in phase. If the polarity of one connection is reversed, bass output will
be very weak and stereo imaging degraded. All wire is marked so you can
identify the two conductors. There may be ribs or a stripe on the insulation
of one conductor. The wire may have clear insulation with different color
conductors (copper and silver). There may be polarity indications printed
on the insulation. Identify the positive and negative conductors and be
consistent with every speaker and amplier connection.

11
Speaker Connection
Turn off all the components in the system before connecting the speakers.
The amplier has color-coded binding post type speaker connectors on the
back panel. These connectors accept bare wire, connector lugs, or dual
banana type connectors. (Except in European Community countries where
their use is not permitted.)
Route the wire from the amplier to the speakers. Give yourself enough slack
so you can move the components to allow access to the speaker connectors.
If you are using dual banana plugs, connect them to the wires and then
plug into the backs of the binding posts. The thumbscrews of the binding
posts should be screwed in all the way (clockwise).
If you are using terminal lugs, connect them to the wires. If you are attaching
bare wires directly to the binding posts, separate the wire conductors and
strip the insulation from the end of each conductor. Be careful not to cut
into the wire strands. Unscrew (turn counterclockwise) the binding post
thumbscrews. Place the connector lug or wire around the binding post
shaft. Turn the thumbscrews clockwise to clamp the connector lug or wire
rmly in place.
NOTE: Be sure there are no loose wire strands that could touch adjacent
wires or connectors.
Headphone Output 3
The headphone output allows you to connect headphones for private listening.
This output accepts a standard 3.5mm (1/8”) mini stereo headphone
connector. Plugging in a set of headphones does not cut off the signal to the
speakers. Use the front panel 4or remote control JA-B speaker selector
buttons to turn off the speakers.
NOTE: Because the sensitivity of speakers and headphones can
vary widely, always reduce the volume level before connecting or
disconnecting headphones.
Display 5
The front panel display shows the source selected, volume level and tone
settings. The display provides access to the setup and conguration menu
options of the amplier.
APTX Bluetooth Connection q
The Bluetooth Antenna qon the unit’s back panel is for wireless streaming
via Bluetooth, from your device (i.e. mobile phones, tablets or computers).
From your device, look for “Rotel Bluetooth” and connect to it. Connection
is normally automatic, but if prompted for a password, please enter “0000”
on your device. The unit supports both traditional Bluetooth and APTX
Bluetooth audio streaming.
Audio Controls
Volume Control 6E
Turn the control clockwise to increase the volume, or counter clockwise to
decrease the volume. From the remote control press the volume + or - button
to turn the volume up or down. Press the MUTE Fbutton to completely
mute the volume.
Balance Control 8B
The Balance Control adjusts the left-to-right balance of the sound output. The
factory default is the center position or “0”. To change the balance from
the front panel, press the MENU 8button to toggle the front display to
BALANCE SETTING mode. Then press the - or + buttons on the front panel to
change the value to LEFT or RIGHT. The value can change from L15 to R15.
NOTE: This setting is saved permanently including after powering off
the A11.
To make temporary changes not saved after power off, from the remote,
press the BAL Bbutton to access the BALANCE SETTING menu, then press
the up/down/left/right Carrow buttons to adjust.
Source Input Selector 7I
Press the corresponding input button on the front panel 7or remote control
Ito select the desired listening source.
Tone Control
The A11 features 4 different Tone Control options to provide a wide array
of listening options. The options include a BYPASS mode that disables the
Bass and Treble controls for the most direct audio path, ENBABLED mode
that allows user selectable Bass and Treble settings and ROTEL BOOST
and ROTEL MAX modes supporting optimized congurations for multiple
listening environments and styles.
The factory default option is set to BYPASS to provide the purest possible
sound. The tone settings can be changed using the IR remote control or
the front panel.
To temporarily change the Tone Control push the BYPASS Bbutton on the
remote control to cycle through the 4 different modes. When Tone Enabled
is selected the Bass and Treble settings can be changed using the remote
control by pressing the BASS or TREB Bbuttons then pressing the up/
down/left/right Carrow buttons on the remote to adjust the value. The
BYPASS, ROTEL BOOST and ROTEL MAX settings do not allow changes to
the Bass and Treble settings.
NOTE: These settings are temporary and are not saved after the A11
is powered off or in standby mode.
The Tone Control setting can be saved permanently (even after power off)
using the front panel setup menu. A description of the Tone Modes and
setup process is listed below.
Tone Bypass
Bass and Treble Control controls are not active to ensure the purest possible
sound. To select this option press the front panel MENU 8or IR remote
SETUP Kbutton repeatedly to toggle to the Tone Setup menu. Then press
the - or + buttons to select the BYPASS mode. This mode is the factory
default option.
Tone Enabled
When the Tone Enabled option is selected the Bass and Treble levels can
be changed using the BASS Bor TREB Bbuttons on the IR remote control
and pressing the up/down/left/right Carrow buttons to adjust the value.

12 A11 Stereo Integrated Amplier
To select this option press the front panel MENU 8or IR remote SETUP
Kbutton repeatedly to toggle to the Tone Setup menu then press the - or
+ buttons to select the ENABLED mode.
NOTE: Be particularly careful when turning the tone controls up. This
increases the power output in the bass or treble range increasing the
load on the amplifier and speakers.
Tone Rotel Boost
The Rotel Boost mode is unique to Rotel and delivers a customized listening
experience. The audio performance is “boosted” and delivers a unique
blend of tonal characteristics. To select this option press the front panel
MENU 8or IR remote SETUP Kbutton repeatedly to toggle to the the Tone
Setup menu then press the - or + buttons to select the ROTEL BOOST mode.
Tone Rotel Max
Rotel Max increases the low frequency output to deliver more bass. This
feature is ideal for music, listening environments or speakers that benet
from more bass while still maintaining the tones of the vocal and midrange
frequencies. To select this option press the front panel MENU 8or IR
remote SETUP Kbutton repeatedly to toggle to the to the Tone Setup menu
then press the - or + buttons to select the ROTEL MAX mode.
NOTE: The setup menu Tone Setting is saved permanently including
after powering off the A11.
Bass and Treble Controls 8B
When Tone Control is set to ENABLED the Bass and Treble levels can be
congured in the setup menu. These settings are saved permanently including
after Power Off or when the unit is in Standby. To set the Bass or Treble levels
press the front panel MENU 8or IR remote SETUP Kbutton repeatedly
to toggle to the Bass or Treble Setting menu then press the - or + buttons
to adjust the value. The Bass and Treble values range from -10 to +10.
NOTE: The setup menu Bass and Treble settings are saved permanently
including after powering off the A11.
To temporarily change the Bass and Treble settings from the remote control,
press the BASS or TREB Bbutton, then press the up/down/left/right C
arrow buttons on the remote to adjust the value.
NOTE: Bass and Treble changes are only available when Tone Enabled
is selected (see Tone Enabled section).
A properly setup high-performance audio system produces the most natural
sound with little or no adjustment of the tone controls. Use these controls
sparingly.
Dimmer Control
Display Dimmer 8D
To change the brightness of the front display, press the MENU 8button
to toggle to the DIMMER Setting. Then press the - or + buttons on the front
panel to change the display brightness.
NOTE: This setting is saved permanently including after powering off
the A11.
To temporarily change the display brightness, press the DIM Dbutton on
the remote.
LED Dimmer 8
To change the brightness of the Power LED and the two Speaker Selector
LEDs on the front panel, press the MENU 8button to toggle to the LED
DIMMER Setting. Then press the - or + buttons on the front panel to change
the LEDs brightness.
NOTE: This setting is saved permanently including after powering off
the A11.
EXT REM IN Jack w
This 3.5mm mini-jack receives command codes from industry-standard infrared
receivers via hard-wired connections. This feature could prove useful when
the unit is installed in a cabinet and the front-panel sensor is blocked. Consult
your authorized Rotel dealer for information on these external repeaters and
the proper wiring of a jack to t the mini-jack receptacle.
RS232 Connector r
The A11 can be controlled via RS232 for integration with automation systems.
The RS232 input accepts a standard straight DB-9 Male-to-Female cable.
For additional information on the connections, software, and operating
codes for RS232 control of the A11, contact your authorized Rotel dealer.
Settings Menu
You can access the SETUP menu from the front panel by pressing the MENU
8button or the Kbutton on the remote. You can change the value of
the selected option by pressing the - or + buttons on the front panel or the
up/down/left/right Carrow buttons on the remote. Step through the
sub-menus by pressing the MENU 8button on the front panel or the K
button on the remote.
•TONE: TONE setting can be changed to BYPASS, ENABLED, ROTEL
BOOST, ROTEL MAX. (For more information refer to Tone Control section.)
NOTE: This setting is stored permanently even after the A11 is powered
off.
• BASS: BASS level can be changed to desired settings. (For more information
refer to Bass and Treble Control section.)
NOTE: This setting is stored permanently even after the A11 is powered
off.
•TREBLE: TREBLE level can be changed to desired settings. (For more
information refer to Bass and Treble Control section.)
NOTE: This setting is stored permanently even after the A11 is powered
off.
•BALANCE: Change left/right balance. (For more information refer to
Balance Control section.)
NOTE: This settings is stored permanently even after the A11 is
powered off.

13
•DIMMER: Dims the front display.
NOTE: This setting is stored permanently even after the A11 is powered
off.
•LED DIMMER: Dims the Power LED and the LEDs above the Speaker Selector
buttons on the front panel.
NOTE: This setting is stored permanently even after the A11 is powered
off.
•POWER ON MAX VOL: This sets the maximum volume level when the unit
is turned on. “45” is the factory default.
NOTE: Power On Max Volume settings do not apply to sources
configured with Fixed Gain.
•OFF TIMER: The A11 can be congured to automatically power off if
unused for a specied period. If no changes are made to the unit within
the specied “Off Timer” period the unit will automatically go to STANDBY
mode. The Auto Power Off timer will be restarted if changes are made to
the volume, source or playback. The default for Off Timer is set to 20 MINS.
Valid settings include: DISABLE, 20 MINS, 1 HOUR, 2 HOURS, 5 HOURS,
12 HOURS.
• SIGNAL SENSE: Check if a audio signal is present on the configured
Signal Sense input. The A11 monitors the data stream to determine if
there is audio. If there is no audio detected for 10 minutes, the A11 will
enter Signal Sense Power Mode. When in Signal Sense Power Mode and
the A11 detects audio on Signal Sense input, the unit will automatically
power on. To disable this function, select the OFF option which is the
factory default setting.
NOTE: When the A11 enters standby mode via the remote control,
the Signal Sense function will not operate until the unit detects the
audio has stopped for the minimum 10 minute time-out period. This
prevents the unit from immediately powering back on if there is still
active audio playing.
NOTE: When the SIGNAL SENSE function is activated the A11 will
consume additional power in Signal Sense Power mode.
•FIXED GAIN: Congures a Fixed Volume level for a specied input. To
enable this feature, select the desired xed volume level for AUX1, AUX2
or Bluetooth. When enabled and the input with a Fixed Volume is selected,
the Volume level will immediately be set to the specied level.
Valid settings include: VARIABLE, FIXED MIN, FIXED 01-95, FIXED MAX.
• AUX1 VOL: VARIABLE (disabled) is factory default.
• AUX2 VOL: VARIABLE (disabled) is factory default.
• BTOOTH VOL: VARIABLE (disabled) is factory default.
NOTE: The Volume knob on the front panel and Volume +/- buttons
on the IR remote are disabled when the volume is Fixed. To disable this
feature set the Fixed Volume level to “Variable”.
•S/W VERSION: This shows the current software version loaded into the
amplier.
•FACTORY RESET: This sets the unit back to the original state as when it
left the factory. Press the + button on the front panel or the ENT button
on the remote control to enter factory reset setting. And then press the +
button or ENT again to begin reset, or press the MENU button to cancel.
NOTE: All previously configured options will be erased and reset to
the factory default settings.
Troubleshooting
Most difculties in audio systems are the result of incorrect connections, or
improper control settings. If you encounter problems, isolate the area of the
difculty, check the control settings, determine the cause of the fault and
make the necessary changes. If you are unable to get sound from the unit,
refer to the suggestions for the following conditions:
Power Indicator Is Not Illuminated
The Power Indicator and the basic items in the Display window should be
illuminated whenever the unit is plugged into the wall power outlet and the
Power button is pushed in. If it does not illuminated, test the power outlet
with another electrical device, such as a lamp. Be sure the power outlet
being used is not controlled by a switch that has been turned off.
Fuse Replacement
If another electrical device works when plugged into the power outlet, but
the Power Indicator still will not illuminated when the unit is plugged into
the wall outlet, it indicates that the internal power fuse may have blown.
If you believe this has happened, contact your authorized Rotel dealer to
get the fuse replaced.
No Sound
Check the signal source to see if it is functioning properly. Make sure the
cables from the signal source to the amplier inputs are connected properly.
Be sure the Input Source is set to the proper input. Check the wiring between
the amplier and the speakers.
Playable Audio Formats
APTX Bluetooth
Format Notes
Any format supported
by the sending device.
May exclude Apps designed to play formats not originally
supported by the sending device.
Cannot Connect via Bluetooth
If you cannot pair your Bluetooth enabled device to the A11, delete the
memory of the previous connection on your device. On your device this is
often listed as “Forget this Device”. Then try to make the connection again.

14 A11 Stereo Integrated Amplier
Specications
Continuous Power Output 50 watts/ch
(20 - 20k Hz, < 0.03%, 8 ohms)
Total Harmonic Distortion (20 Hz - 20k Hz, 8 ohms) < 0.03%
Intermodulation Distortion (60 Hz : 7k Hz, 4:1) < 0.03%
Frequency Response
Phono Input 20 Hz - 20k Hz, ± 0.5 dB
Line Level Inputs 10 Hz - 100k Hz, ± 0.5 dB
Damping Factor (20 - 20,000 Hz, 8 ohms) 140
Input Sensitivity / Impedance
Phono Input 2.3 mV / 47k Ohms
Line Level Inputs 180 mV / 47k Ohms
Input Overload
Phono Input 50 mV
Line Level Inputs 4 V
Preamp Output / Impedance 1 V / 470 Ohms
Tone Controls - Bass / Treble ± 10 dB at 100 Hz / 10k Hz
Signal to Noise Ratio (A weighting)
Phono Input 85 dB
Line Level Inputs 100 dB
General
Power Requirements
USA 120V, 60 Hz
EC 230V, 50 Hz
Standby Power Consumption < 0.5W
Power Consumption 160 Watts
BTU (4 ohms, 1/8th power) 479 BTU/h
Dimensions (W, H, D) 430 x 93 x 345 mm
17” x 3 5/8” x 13 1/2”
Panel Height 80 mm / 3 1/8”.
Weight (net) 6.85 kg, 15.1 lbs.
All specications are accurate at the time of printing.
Rotel reserves the right to make improvements without notice.
Rotel and the Rotel HiFi logo are registered trademarks of The Rotel Co., Ltd.
Tokyo, Japan.

A11 Owner’s Manual Ver E 072618 English
The Rotel Co. Ltd.
Tachikawa Bldg. 1F.,
2-11-4, Nakane, Meguro-ku,
Tokyo, 152-0031
Japan
Rotel of America
54 Concord Street
North Reading, MA 01864-2699
USA
Phone: +1 978-664-3820
Fax: +1 978-664-4109
Rotel Europe
Dale Road
Worthing, West Sussex BN11 2BH
England
Phone: + 44 (0)1903 221 763
Fax: +44 (0)1903 221 525
Rotel Deutschland
Vertrieb: B&W Group Germany GmbH
Kleine Heide 12
D-33790 Halle/Westf., Deutschland
Tel.: 05201 / 87170
Fax: 05201 / 73370
E-Mail: [email protected]
www.rotel.com
