Rotel RAS-5000 User manual

RAS-5000
Amplied Streamer
Streamer Amplié
Verstärkter Streamer
Streamer amplicado
Versterkte streamer
Streamer amplicato
Förstärkt Streamer
Интегрированный Сетевой Стример
Owner’s Manual
Manuel de l’utilisateur
Bedienun gsanleitung
Manual de Instrucciones
Gebruikershandleiding
Manuale di istruzioni
Instruktionsbok

POWER
RAS-5000
COAX/OPTeARCUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER

2
RAS-5000 Amplied Streamer
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
The apparatus should be used in non tropical
climate.
The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
Touching uninsulated terminals or wiring may
result in an unpleasant sensation.
You must allow a minimum 10 cm or 4 inches
of unobstructed clearance around the unit.
POWER
RAS-5000
OPTCOAXUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER
WARNING: The rear panel power cord connector
is the mains power disconnect device. The
device must be located in an open area that
allows access to the cord connector.
The unit must be connected to a power supply
only of the type and voltage specified on the
rear panel. (USA: 120 V/60Hz, EC: 230V/50Hz)
Connect the component to the power outlet
only with the supplied power supply cable or
an exact equivalent. Do not modify the supplied
cable. Do not use extension cords.
The mains plug is the disconnect of the unit. In
order to completely disconnect the unit from
the supply mains, remove the main plug from
the unit and the AC power outlet. This is the
only way to completely remove mains power
from the unit.
Use Class 2 wiring for speaker connections to
ensure proper installation and minimize the
risk of electrical shock.
The batteries in the remote control should not
be exposed to excessive temperature such as

should be recycled or disposed as per state and
local guidelines.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following to
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
Notice
The RS232 connection should be handled by
authorized persons only.
WARNING: There are no user serviceable parts
inside. Refer all servicing to qualified service
personnel.
WARNING: To reduce the risk of fire or electric
shock, do not expose the unit to moisture or
water. Do not expose the unit to dripping or
splashing. Do not place objects filled with liquids,
such as vases, on the unit. Do not allow foreign
objects to get into the enclosure. If the unit is
exposed to moisture, or a foreign object gets
into the enclosure, immediately disconnect
the power cord from the wall. Take the unit to
a qualified service person for inspection and
necessary repairs.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer,
or sold with the apparatus. When
a cart is used, use with caution
when moving the cart/apparatus
combination to avoid injury from
tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
Rotel products are designed to comply
with international directives on the
Restriction of Hazardous Substances
(RoHS) in electrical and electronic
equipment and the disposal of Waste
Electrical and Electronic Equipment
(WEEE). The crossed wheelie bin
symbol indicates compliance and that
the products must be appropriately
recycled or processed in accordance
with these directives.
Important Safety Instructions
This symbol means that this unit
is double insulated. An earth
connection is not required.
interference received, including interference
that may cause undesired operation.

3
Figure 1-1: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Controlli e connessioni
De bedieningsorganen en aansluitingen
Kontroller och anslutningar
Органы управления и разъемы
1: Power Button
Activate the unit or put it into standby mode
2: Power LED
3: Headphone Output
Connect headphones for private listening.
4: Source Button
Selects the input signal source.
5: Display
6: Volume Knob
Adjust the volume output level.
7: MENU and - / + buttons
Access the various menus and operate the Amplifier
settings.
POWER
RAS-5000
COAX/OPTeARCUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER
SERIAL NUMBER:
This device complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
SPEAKER IMPEDANCE 8 OHMS NOMINAL
CLASS 2 WIRING
BLUETOOTH WIFIWIFI
OPT
COAX
AUX
L
R
SPEAKER
RIGHT
+LEFT +
- -
NETWORKPC-USB USB
5V/2.0A
ONOFF
CAUTION :
Replace with same type
T10AL 250V fuse
AC FUSE: T10AL 250V
100-120V/220-240V~50/60Hz
SUB
OUT
PRE
OUTIN
Chromecast built-in is a trademark of Google LLC
890-=qwe
ruoi
yt p
12 3
456
7

4
RAS-5000 Amplied Streamer
POWER
RAS-5000
COAX/OPTeARCUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER
SERIAL NUMBER:
This device complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
SPEAKER IMPEDANCE 8 OHMS NOMINAL
CLASS 2 WIRING
BLUETOOTH WIFIWIFI
OPT
COAX
AUX
L
R
SPEAKER
RIGHT
+LEFT +
- -
NETWORKPC-USB USB
5V/2.0A
ONOFF
CAUTION :
Replace with same type
T10AL 250V fuse
AC FUSE: T10AL 250V
100-120V/220-240V~50/60Hz
SUB
OUT
PRE
OUTIN
Chromecast built-in is a trademark of Google LLC
890-=qwe
ruoi
yt p
12 3
456
7
Figure 1-2: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Controlli e connessioni
De bedieningsorganen en aansluitingen
Kontroller och anslutningar
Органы управления и разъемы
8: Bluetooth Antenna
Use for wireless streaming via Bluetooth.
9: COAX Input
0: OPTICAL Input
-: PC-USB input
=: NETWORK port
q: USB Port
Use for audio playback via Flash Drive.
w: Wi-Fi Antenna
Use for wireless connection.
e: Master Power Switch
r: AUX input
Analog “line level” input.
t: PRE Output
Variable analog output for connection to an

y: SUB Output
Connect to a subwoofer.
u: Speaker Connectors
i: Fuse holder
o: AC Power Inlet
p: HDMI eARC Input
Connect to TV ARC HDMI connection to
receive 2-channel audio to RAS-5000.

5
Figure 2: Remote Control
Télécommande infra-rouge
Fernbedienung
Mando a Distancia
Telecomando
De afstandsbediening
Fjärrkontroll
Пульт ДУ
A: Power Button
Activate or deactivate the unit.
B: Navigation and OK Buttons
Access the various menus and operate

C: Mute Button
Mute the audio.
D: Volume Buttons
Adjust the volume output level.
E: Source Buttons
Selects the input signal source.
F: Preset Buttons
Station preset and recall buttons.
G: Setup button
Activates the setup menu on the
front display.
H: Back Button
Return to the previous selection
screen.
I: Playback Control Buttons
Control the play, pause, next track
and previous track of the audio.
OPT / COAX AUX
STREAM
PRESET
OK
VOLUME
USB
PC-USB
eARC
BT
1 2 3
A
B
C
D
E
H
G
I
F

6
RAS-5000 Amplied Streamer
Figure 3: Antennas, Analog Input and Speaker Output Connections
Branchements d’antennes, entrée analogique et sorties enceintes acoustiques
Anschlussdiagramm
Conexiones para las antenas, Entrada analógica y Salida a las Cajas Acústicas
Aansluitingen van Antennes, Analoge ingang en de luidsprekeruitgangen
Collegamenti di antenne, ingresso analogico e diusori
Antenner-, Signal- och högtalaranslutningar
Подсоединение Антенны, источников сигнала и акустических систем
SERIAL NUMBER:
This device complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
SPEAKER IMPEDANCE 8 OHMS NOMINAL
CLASS 2 WIRING
BLUETOOTH WIFIWIFI
OPT
COAX
AUX
L
R
SPEAKER
RIGHT
+LEFT +
- -
NETWORKPC-USB USB
5V/2.0A
ONOFF
CAUTION :
Replace with same type
T10AL 250V fuse
AC FUSE: T10AL 250V
100-120V/220-240V~50/60Hz
SUB
OUT
PRE
OUTIN
Chromecast built-in is a trademark of Google LLC
Rotel RAS-5000
Audio Player
Speakers

7
Figure 4: Digital Input Connections
Branchements Entrées numériques
Digitaleingänge-Anschlüsse
Conexiones Entradas Digitales
Digitale ingang verbinding
Collegamenti ingressi digitali
Anslutningar för digitala ingångar
Подсоединение к цифровым входам
SERIAL NUMBER:
This device complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
SPEAKER IMPEDANCE 8 OHMS NOMINAL
CLASS 2 WIRING
BLUETOOTH WIFIWIFI
OPT
COAX
AUX
L
R
SPEAKER
RIGHT
+LEFT +
- -
NETWORKPC-USB USB
5V/2.0A
ONOFF
CAUTION :
Replace with same type
T10AL 250V fuse
AC FUSE: T10AL 250V
100-120V/220-240V~50/60Hz
SUB
OUT
PRE
OUTIN
Chromecast built-in is a trademark of Google LLC
Computer
(Supplied)
RAS-5000
Rotel RCD-1572MKII

8
RAS-5000 Amplied Streamer
Figure 5: HDMI eARC Connections
Connexions HDMI eARC
HDMI eARC-Verbindungen
Conexiones HDMI eARC Posterior
HDMI eARC-aansluitingen op de achterkant
Collegamento delle prese HDMI eARC posteriori
HDMI eARC-anslutning på baksidan
Подключение к HDMI eARC разъему на
задней панели
HDMI TV
ARC
SERIAL NUMBER:
This device complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation.
SPEAKER IMPEDANCE 8 OHMS NOMINAL
CLASS 2 WIRING
BLUETOOTH WIFIWIFI
OPT
COAX
AUX
L
R
SPEAKER
RIGHT
+LEFT +
- -
NETWORKPC-USB USB
5V/2.0A
ONOFF
CAUTION :
Replace with same type
T10AL 250V fuse
AC FUSE: T10AL 250V
100-120V/220-240V~50/60Hz
SUB
OUT
PRE
OUTIN
Chromecast built-in is a trademark of Google LLC
RAS-5000

9
Important Notes
When making connections be sure to:
4Turn off all the components in the system before hooking up any components, including loudspeakers.
4Turn off all components in the system before changing any of the connections to the system.
It is also recommended that you:
4Turn the volume control of the unit all the way down before the unit is turned on or off.
Remarques importantes
Pendant les branchements, assurez-vous que :
4Tous les maillons sont éteints avant leur branchement, quels qu’ils soient, y compris les enceintes acoustiques.
4Éteignez tous les maillons avant  quoi que ce soit au niveau de leurs branchements, quels qu’ils soient.
Il est également recommandé de :
4Toujours baissez le niveau sonore via le contrôle de volume, avant d’allumer ou d’éteindre 
Wichtige Hinweise
Achten Sie beim Herstellen der Verbindungen auf Folgendes:
4Schalten Sie alle Komponenten im System ab, bevor Sie Geräte (einschließlich Lautsprecher) anschließen.
4Schalten Sie alle Komponenten im System ab, bevor Sie Anschlüsse im System verändern.
Ferner empfehlen wir, dass
4Sie die Lautstärke herunterdrehen, bevor Sie die Endstufe ein- oder abschalten.
Notas Importantes
Cuando realice las conexiones, asegúrese de que:
4Desactiva todos los componentes del equipo, cajas acústicas incluidas, antes de conectar cualquier nuevo componente en el mismo.
4Desactiva todos los componentes del equipo antes de cambiar cualquier conexión del mismo.
También le recomendamos que:
4antes de activarlo o desactivarlo.
Héél belangrijk
Bij het maken van de verbindingen:
4Zorg dat niet alleen de RAS-5000, maar de gehele installatie uitstaat, als nog niet alle verbindingen gemaakt zijn.
4Zorg dat niet alleen de RAS-5000, maar de gehele installatie ook uitstaat, als u verbindingen gaat wijzigen.
Wij raden u ook aan om
4de volumeregelaar van de voorversterker geheel dicht te draaien (volkomen naar links) wanneer u uw eindversterker aan- of uitzet.
Note importanti
Quando effettuate i collegamenti assicuratevi di:
4Spegnere tutti i componenti del sistema prima di collegare qualsiasi componente, inclusi i diffusori.
4Spegnere tutti i componenti del sistema prima qualsiasi connessione nel sistema.
Vi raccomandiamo inoltre di:
4Portare il volume a zero prima di accendere o spegnere 
Viktigt
Tänk på följande när du gör anslutningar:
4Stäng av alla komponenter i anläggningen innan du ansluter nya komponenter, inklusive högtalare.
4Stäng av alla komponenter i anläggningen innan du ändrar någon anslutning i anläggningen.
Vi rekommenderar också föjlande::
4Vrid ner volymen på förstärkaren helt och hållet innan förstärkaren slås på eller av.
Важные замечания
Перед подсоединением:
4 все 
4 все  менять.
Рекомендуется также:
4минимум,  включать или выключать .

10
RAS-5000 Amplied Streamer
About Rotel
Our story began over 60 years ago. Over the decades, we have received

of people who take their entertainment seriously – like you.
Rotel was founded by a family whose passionate interest in music led them

Through the years, that passion has remained undiminished and the
family goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.

new product until it reaches their exacting musical standards. They are
free to choose components from around the world in order to make

the United Kingdom and Germany, semiconductors from Japan or the
United States, while toroidal power transformers are manufactured in
Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced it is especially important for a manufacturer
to do all it can to engineer products that have a minimum impact on
the environment.
At Rotel, we are proud to do our part. We have reduced the lead content
in our products by using special lead-free ROHS solder and components.

without compromise to quality. When in standby mode Rotel products use
minimal power to meet global Standby Power Consumption requirements.
The Rotel factory is also doing their part to help the environment through
constant improvements to product assembly methods for a cleaner and
greener manufacturing processes.
All of us at Rotel thank you for buying this product. We are sure it will
bring you many years of enjoyment.
Getting Started

used in a high-quality music audio system, Rotel products will provide
years of musical enjoyment.
This unit is a full featured, high performance component. All aspects of the
design have been optimized to retain the full dynamic range and subtle
nuances of your music. The unit has a highly regulated power supply
incorporating a Rotel custom-designed toroidal power transformer. This
low impedance power supply has ample power reserves, which enables
the unit to easily reproduce the most demanding audio signals. This type
of design is more expensive to manufacture, but it is better for the music.
The printed circuit boards (PCB) are designed with Symmetrical Circuit
Traces. This ensures that the precise timing of the music is maintained
and faithfully recreated. The circuitry uses metal film resistors and
polystyrene or polypropylene capacitors in important signal paths. All
Contents
Important Safety Instructions ...................................2
Figure 1-1: Controls and Connections 3
Figure 1-2: Controls and Connections 4
Figure 2: Remote Control 5
Figure 3: Analog Input and Speaker Output Connections 6
Figure 4: Digital Input Connections 7
Figure 5: Rear HDMI Connection 8
Important Notes 9
About Rotel ...................................................10
Getting Started................................................10
A Few Precautions 11
Placement 11
Cables 11
The Remote Control ............................................11
Remote Control Batteries 11
AC Power and Control .........................................12
AC Power Input o 12
Master Power Switch e12
Power Switch 1Aand Power Indicator 2 12
Protection Indicator 2........................................12
Input Signal Connections ......................................12
Aux Input r12
Digital Inputs 120 12
Output Connections ..........................................12
PRE Output t12
SUB Output y13
Headphone Output 313
Speaker Outputs u...........................................13
Speaker Wire Selection 13
Polarity and Phasing 13
Speaker Connection 13
Display 5.....................................................13
aptX™ HD Bluetooth Connection 8............................13
Rear USB port q..............................................13
PC-USB Input -...............................................13
HDMI eARC Input p...........................................14
Network Connection =w .....................................14
Streaming ...................................................14
Wi-Fi Stream Connection 14
Audio Streaming 15
Roon Ready ..................................................15
Spotify®......................................................15
Tidal Connect ................................................15
Overview of Buttons and Controls. . . . . . . . ....... . . . . . . . . . . . . . . . 16
Main Menu ....................................................17
Troubleshooting...............................................17
Power Indicator Is Not Illuminated 17
Network Does Not Work 17
Fuse Replacement 17
No Sound 17
Cannot Connect via Bluetooth 17
Playable Audio Formats 18
RAS-5000 APP ................................................19
Specications .................................................19

11
aspects of this design have been examined to ensure the most faithful
music reproduction.
The main functions of the RAS-5000 are easy to install and use. If you

perplexing. Simply plug in the associated components and enjoy.
A Few Precautions
WARNING: To avoid potential damage to your system, turn off ALL
the components in the system when connecting or disconnecting
the loudspeakers or any associated components. Do not turn the
system components back on until you are sure all the connections
are correct and secure. Pay particular attention to the speaker wires.
There must be no loose strands that could contact the other speaker
wires, or the chassis of the unit.
Please read this manual carefully. It provides information on how to
incorporate the unit into your system as well as information that will help
you get optimum sound performance. Please contact your authorized
Rotel dealer for answers to any questions you might have. In addition, all
of us at Rotel welcome your questions and comments.
Save the shipping carton and all enclosed packing material for future use.
Shipping or moving the unit in anything other than the original packing
material may result in severe damage to your unit.
If included in the box please complete the owner’s registration card or
register on line. Also be sure to keep the original sales receipt. It is your
best record of the date of purchase, which you will need in the event
warranty service is ever required.
Placement
Like all audio components that handle low level signals, this unit can
be affected by its environment. Avoid placing the unit on top of other
components. Also avoid routing audio signal cables near power cords.
This will minimize the chance it will pick up hum or interference.
The unit generates heat as part of its normal operation. The heat sinks
and ventilation openings in the unit are designed to dissipate this heat.
The ventilation holes in the top cover must be open. There should be 10

through the installation location, to prevent the unit from overheating.
POWER
RAS-5000
OPTCOAXUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER
Remember the weight of the unit when you select an installation location.
Make sure that the shelf or cabinet can support it. We recommend
installing the unit in furniture designed to house audio components.
Such furniture is designed to reduce or suppress vibration which can
adversely affect sound quality. Ask your authorized Rotel dealer for advice
about component furniture and proper installation of audio components.
Cables
Be sure to keep the power cords, digital signal cables and analog
audio signal cables in your installation away from each other. This will
minimize the chance of the analog audio signal cables picking up noise
or interference from the power cords or digital cables. Using only high
quality, shielded cables will also help to prevent noise or interference from
degrading the sound quality of your system. If you have any questions
see your authorized Rotel dealer for advice about the best cable to use
with your system.
The Remote Control
Some functions can be done with either the front panel controls, or the
supplied the remote control. When these operations are described, the
square call out numbers refer to the main unit, while the encircled letters
refer to the remote control.
Remote Control Batteries


Insert a new CR 2035 battery into the battery holder according to the
marking (+ on the battery facing downwards). Now insert the holder as
shown and use two screws to fasten the holder.
Figure 1
NOTE: Use only the tool supplied with the unit to remove the screw
to avoid damage to the hex screw.
NOTE: Do NOT over-tighten the screw to avoid damage to the screw
or remote control.

12
RAS-5000 Amplied Streamer
AC Power and Control
AC Power Input o

the country where you purchased it (either 120 volts AC or 230 volts AC

is noted on the back panel.
NOTE: Should you move your unit to another country, the unit will
detect and reconfigure for use on a different line voltage. Consult
a qualified service person or the Rotel factory service department
for information.
NOTE: Some products are intended for sale in more than one country
and as such are supplied with more than one AC cord. Please only
use the one appropriate for your country/region.
Because of its relatively high power rating, the unit can draw considerable
current. Therefore, it should be plugged directly into a polarized wall outlet
using the supplied cable or other compatible cable as recommended by
your authorized Rotel dealer. Do not use an extension cord. A heavy duty
multi-tap power outlet strip may be used if it (and the wall outlet) can
handle the current demanded by the unit and all the other components
connected to it.
If you are going to be away from home for an extended period of time
such as a month-long vacation, it is a sensible precaution to unplug your
unit (as well as other audio and video components) while you are away.
Master Power Switch e
The large rocker switch on the rear panel is a master power switch. When
it is in the OFF position, power to the unit is completely off. When it is
in the ON position, the front panel POWER and remote control ON/OFF
buttons can be used to activate the unit or put it into standby mode.
Power Switch 1Aand Power Indicator 2
Press the front panel Power Switch button 1, to turn the unit on. The
Power Indicator light is illuminated when the unit is on. Press Power
Switch button again to turn the unit off.
When the power switch is in the ON position, the remote control
button may be used to activate the RAS-5000. In Standby mode the
power light is red, but the display is turned OFF.
Protection Indicator 2
The unit has both thermal and over-current protection circuitry that
protects the unit against damage in the event of extreme or faulty
operating conditions. The protection circuits are independent of the audio
signal and have no impact on sonic performance. Instead, the protection
circuits monitor the temperature of the output devices and shut down
the unit if temperatures exceed safe limits.
Most likely, you will never see this protection circuitry in action. However,
should a faulty condition arise, the unit will stop playing and will display
“PROTECTION“ on the front panel. The power indicator on the front
panel will turn red.
If this happens, turn the unit off. Let it cool down for several minutes, and
attempt to identify and correct the problem that caused the protection
circuitry to engage. When you turn the unit back on, the protection
circuit will automatically reset and the power indicator should turn blue.
In most cases, the protection circuitry activates because of a fault condition
such as shorted speaker wires, or inadequate ventilation leading to an
overheating condition. In very rare cases, highly reactive or extremely low
impedance speaker loads could cause the protection circuit to engage.
If the protection circuitry triggers repeatedly and you are unable to isolate
and correct the faulty condition, contact your authorized Rotel dealer for
assistance in troubleshooting.
Input Signal Connections
NOTE: To prevent loud noises that neither you nor your speakers
will appreciate, make sure the system is turned off when you make
any signal connections.
AUX Input r
See Figure 3
The Aux input of the streamer is for connecting components such as CD
players or other audio playback devices with an analog audio output.
The Left and Right channels are labeled and should be connected to the
corresponding channels of the source component. The Left connectors
are white, the Right connectors are red. Use high quality RCA cables for
connecting input source components to the unit. Ask your authorized
Rotel dealer for advice about cables.
Digital Inputs 90
See Figure 4
There is one set of digital inputs labeled COAX and OPT respectively.
Connect the COAXIAL or OPTICAL outputs of your source component
into these sockets. The digital signals will be decoded and played by the
unit. The unit is capable of decoding PCM signals up to 24 bit, 192kHz.
Output Connections
PRE Output t
The unit has a set of preamp outputs labeled PRE OUT. The currently
selected source input is available from this output. Typically the PRE OUT

zone or to drive higher output power from the unit.
NOTE: Changes to the settings of the Volume, Balance or Tone
controls affect the signal from the PRE OUT output.
SUB Output y
There is a connector for subwoofer output to connect to the subwoofer.
This sub output is summed with both the left and right audio signal. The

Headphone Output 3
The headphone output allows you to connect headphones for private
listening. This output accepts a standard 3.5mm (1/8”) mini stereo
headphone connector. Plugging in a set of headphones cuts off the
signal to the speakers, Pre output and SUB output.

13
NOTE: Because the sensitivity of speakers and headphones can
vary widely, always reduce the volume level before connecting or
disconnecting headphones.
Speaker Outputs u
See Figure 3
Speaker Wire Selection
Use insulated two-conductor stranded wire to connect the unit to the
speakers. The size and quality of the wire can have an audible effect on
the performance of the system. Standard speaker wire will work, but
can result in lower output or diminished bass response, particularly
over longer distances. In general, heavier wire will improve the sound.
For best performance, you may want to consider special high-quality
speaker cables. Your authorized Rotel dealer can help in the selection of
cables for your system.
Polarity and Phasing
The polarity - the positive/negative orientation of the connections - for
every speaker and streamer connection must be consistent so all the
speakers will be in phase. If the polarity of one connection is reversed,
bass output will be very weak and stereo imaging degraded. All wire is
marked so you can identify the two conductors. There may be ribs or
a stripe on the insulation of one conductor. The wire may have clear
insulation with different color conductors (copper and silver). There may
be polarity indications printed on the insulation. Identify the positive and
negative conductors and be consistent with every speaker and streamer
connection.
Speaker Connection
Turn off all the components in the system before connecting the speakers.
The unit has color-coded binding post type speaker connectors on the
back panel. These connectors accept bare wire, connector lugs, or dual
banana type connectors. (Except in European Community countries
where their use is not permitted.)
Route the wire from the unit to the speakers. Give yourself enough slack so
you can move the components to allow access to the speaker connectors.
If you are using dual banana plugs, connect them to the wires and then
plug into the backs of the binding posts. The thumbscrews of the binding
posts should be screwed in all the way (clockwise).
If you are using terminal lugs, connect them to the wires. If you are
attaching bare wires directly to the binding posts, separate the wire
conductors and strip the insulation from the end of each conductor. Be
careful not to cut into the wire strands. Unscrew (turn counterclockwise)
the binding post thumbscrews. Place the connector lug or wire around
the binding post shaft. Turn the thumbscrews clockwise to clamp the

NOTE: Be sure there are no loose wire strands that could touch
adjacent wires or connectors.
Display 5
The front panel display shows the current unit status and streaming
source information. Album artwork is also display on supported source

options of the unit.
aptX™ HD Bluetooth
Connection 8
The Bluetooth Antenna 8on the RAS-5000’s back panel is for wireless
streaming via Bluetooth, from your device (i.e. mobile phones, tablets
or computers). From your device, look for “Rotel RAS-5000 / xxx--xxxxxx
(series number)” and connect to it. Connection is normally automatic,
but if prompted for a password, please enter “0000” on your device. The
RAS-5000 supports traditional Bluetooth, AAC and aptX™ HD Bluetooth
audio streaming.
Rear USB Port q
The rear USB port allows playback of audio from a USB Flash device.


sequential order.
PC-USB Input -
See Figure 4
Connect this input using a USB cable to the PC-USB socket of your
computer.
The RAS-5000 supports USB Audio Class 2.0 modes. To use the PC-USB
connection you will need to install the Windows driver supplied on the
USB stick included with the RAS-5000.
Many audio playback applications do not support 384kHz sampling



your computer may “down sample” to a lower audio sample rate. For
more information please refer to your audio player or operating system
information.
NOTE: USB Audio Class 2.0 requires installation of the Windows PC
driver on the USB stick included with the RAS-5000.
NOTE: MAC computers do not require a driver to support PC-USB
Audio Class 2.0.
NOTE: Upon successful installation of the driver, you may need to
select the ROTEL audio driver from the audio/speaker setup of your
computer.

14
RAS-5000 Amplied Streamer
HDMI eARC Input
The HDMI eARC (Audio Return Channel) input allows audio from a TV
be received by the RAS-5000. Audio sent via eARC must be down-mixed
to 2-channel stereo. The RAS-5000 cannot process multi-channel audio
such as Dolby®digital audio. To use the eARC input the HDMI cable must
be connected to the TV’s ARC HDMI connector.
Network Connection =w
This unit can connect to a wired or wireless network. If using a wired
network, connect your network cable to the socket marked NETWORK
=then the front panel will display the wired icon . If using a
wireless network, please connect the Wi-Fi antennas (supplied) to
both of the connectors marked Wi-Fi wthen the front panel will
display the Wi-Fi icon or the depending on the wireless
connection status.
When connected to a Wired or Wireless network the unit will automatically
update the software when new software versions are available.
Streaming
The RAS-5000 supports the wireless streaming of audio from network
attached storage devices and multiple Internet based audio streaming
services.
Wi-Fi Stream Connection
To utilize the Streaming services you will need to do the following:
Connecting RAS-5000
For hardwire connections attach the network cable to the rear panel
NETWORK port on the unit.
For wireless connections ensure the Wi-Fi antennas have been installed
and power on the RAS-5000 unit. The Wi-Fi icon will be displayed on
the front panel. This means the RAS-5000 is ready to connect to your
Wi-Fi network.
Streaming
From your device (phone, tablet), download the Google Home App or Apple
Home App on Google Play or from the Apple App store. After download,
launch and run the Google Home App on your devices, following the
relevant steps below, dependent on your device type:
For iOS devices (using Wi-Fi Setup):
1. Go to the SETTINGS menu on your iOS device.
2. Select the Wi-Fi settings menu and ensure Wi-Fi is enabled.
3. Wait for up to 90 seconds for the list of available Wi-Fi networks to be

bottom of the list under the “SET UP NEW AIRPLAY SPEAKER” option.
＜Settings Wi-Fi
Wi-Fi
√Network
CHOOSE A NETWORK
Network
Other...
SET UP NEW AIRPLAY SPEAKER...
RAS-5000-XXXX ＞
Ask to Join Networks
Known networks will be joined automatically. If no known
networks are available, you will have to manually select a
network.
i
i
10:17 AM 32%

Fi network by choosing the desired Network listed and selecting Next.
√
Cancel AirPlay Setup Next
Network
Show Other Network
Speaker Name RAS-5000-XXXX
SPEAKER PASSWORD
Password Optional
Verify Verify Password
10:17 AM 32%
This AirPlay speaker will be set up to join “Network”.
NETWORK

15

settings and attach to the wireless network. When connected, the
Wi-Fi icon will show on the front display.
Streaming
6. You’re connected!
For iOS devices (using Apple Home):
1. Open the Apple Home App.
2. Press the “Add Accessory” button or “+” button and select “Accessory”.
3. Select the “More options” option.
4. Select the RAS-5000 unit and follow the setup wizard instructions to


and attach to the wireless network. When connected, the Wi-Fi icon
will show on the front display.
Streaming
6. You’re connected!
For AndroidTM Device:
1. Launch the Google Home App on your device.
2. Press the “+” icon in the top left corner and select “Set up device” -->
“New devices”. The App will search for the RAS-5000. Select the unit
to begin the setup wizard.
3. If prompted, enter the Wi-Fi encryption key of your wireless network


to the wireless network. When connected, the Wi-Fi icon will show
on the front display.
Streaming
5. You’re connected!
Audio Streaming

5000. Open your music App and select the device or multiple devices you
want to control. Then select an audio service to begin streaming audio.
Roon Ready

software.
Being Roon Ready means that Rotel uses Roon streaming technology, for
an incredible user interface, simple setup, rock-solid daily reliability, and
the highest levels of audio performance, without compromise.
To use Roon setup the RAS-5000 in the Roon software as a streaming
endpoint and follow the instructions in Roon.
Spotify ®
Spotify Connect
Use your phone, tablet or computer as a remote control for Spotify. Go
to spotify.com/connect to learn how.
NOTE:The Spotify Software is subject to third party licenses found
here: www.spotify.com/connect/third-party-licenses.
There are multiple streaming services available with the RAS-5000
including the ability to use AirPlay 2 and Chromecast built-in™ to stream
your favorite music.

16
RAS-5000 Amplied Streamer
Internet radio services can be utilized on the RAS-5000 using the supported
Apps and various streaming methods.
The RAS-5000 may also include additional streaming services in the
future. For the latest information on streaming services please check the
Owner’s Manual on the www.rotel.com website under the Support tab.
For more information on the offerings available from each streaming
service please check with the service provides.
Tidal Connect
The RAS-5000 supports Tidal Connect streaming allowing access to a vast
library of music including high-resolution music. To utilizes Tidal Connect
open the Tidal App on your phone, tablet or computer and select the
RAS-5000 as the streaming device.
Overview of Buttons and
Controls
This section provides a basic overview of the buttons and controls on
the front panel and remote control. Detailed instructions on the use of
these buttons are provided in the more complete operating instructions
in the following sections.
Navigating and OK BButtons: Use the navigation buttons ///
Band the “OK“ on the remote control to access the various menus and
operate the unit settings.
MENU, - / + and ENTER 7Buttons : Use the MENU button, the -/+ and
ENTER buttons on the front panel to access the various menus and
operate the unit settings.
Power 1A: The Power button on the front panel and on the remote
control activate or deactivate the unit. To power on the unit, the rear panel
master POWER switch must be in the ON position for the front panel
and the remote standby function to operate.
Power On - To power on the unit push and release the Power 1 button
on the front panel or PUSH-HOLD the remote control Power A button
for 2 seconds until the unit powers on (up to 7 seconds).
Power Off/Standby - To power off the unit to standby push and release
the front panel Power 1 button or PUSH-HOLD the remote control
Power A button for 2 seconds until the unit powers off (up to 3 seconds).
Button C:Push the button once to mute the audio. An indication
appears in the front panel display. Press the button again to restore the
previous volume level.
VOLUME Knob 6and VOL +/- Buttons D: The VOLUME +/- buttons on
the remote and the rotary control on the front panel provide the master
VOLUME control, adjusting the output level.
Source Button 4E: Press the corresponding input button on the front
panel 4or remote control Eto select the desired listening source.
Push the front panel source buttons to select STREAMING, BLUETOOTH,
PC-USB, COAX/OPT, AUX, eARC and USB or use the dedicated source
button on the remote control. The COAX/OPT and USB/PC-USB are toggle
source input and will switch between the Coaxial and Optical also the
USB and PC-USB inputs when pressed repeatedly.
Preset Buttons F: The Preset buttons are used to memorize and recall
a Spotify playlists. To save a preset PUSH-HOLD the preset button for 3
seconds. To recall a preset simply push and release the desired button.
NOTE: Preset functions are not available for all streaming services.
Button G: The SETUP button activates the setup menu on the front
display. Push the SETUP button again to move to the next setup menu
option.
Button H: 
or exits the setup menu if you are in the top menu level.
Playback Control Buttons I: Press the Play /Pause button to
start playing or stop. and buttons are used to select tracks of the
selected audio source.
Main Menu
Setup
Bass
Treble
Balance
+ / - to Navigate, Enter to change
You can enter the Setup menu from the front panel by pressing the
Gbutton on the remote control or the MENU 7button on the front
panel. To select the desired menu, use the +/- 7button on the front
panel or the /Barrow buttons on the remote control to toggle
between the menus and press ENTER button 7on the front panel or

values of the selected setting by pressing the - or + button on the front
panel or the /Barrow buttons on the remote control then press the
“OK” button on the remote control or the ENTER button 7on the front
panel to save and to return to the previous menu.
Bass: Bass level can be changed to desired settings.
Options include: -10 - +10.
Treble: Treble level can be changed to desired settings.
Options include: -10 - +10.
Balance: Adjusts the left-to-right balance of the sound output. The factory
default is the center position or “0”.
Options include: L15 - R15.

17
Dimmer: Sets the brightness of the front display. The Menu Setup will
always activate at the brightest level regardless of the Dimmer setting to

Options include: High (Default), Medium, Low.
LED Dimmer: Sets the brightness of the ON level of the front panel
Power LED.
Options include: High (Default), Medium, Low.
Power On Max Volume: This sets the maximum volume level when the
unit is turned on. “50%” is the factory default.
Options include: 50%-100%.
Auto Power Off: Set the amount of time the units stays powered on when
there is no audio signal. The unit will automatically go to standby mode

Options include: 20 Minutes (Default), Disable, 1 Hour, 2 Hours, 5 Hours,
12 Hours.
Signal Sense: When enabled the unit monitors if an audio signal is
present on the currently selected source. If there is no audio detected
for 10 minutes, the unit will enter Signal Sense Power Mode. When in
Signal Sense Power Mode and the unit detects audio on the Streaming
Input, the unit will automatically power on and begin streaming the
audio. To disable this function, select the “Disabled” option which is the
factory default setting.
NOTE: When the Signal Sense function is activated, the Amplifier
will consume additional power in signal sense standby mode.
Network Info:Shows the network connection status and network settings,
Wi-Fi MAC, Bluetooth MAC and Ethernet MAC.
Software Info: Shows the current software version loaded into the unit.
Wi-Fi Reset: This option erases all current Wi-Fi settings in the unit.
Factory Reset: This option sets the unit back to the original setting as
when it left the factory including resetting the Wi-Fi settings. All user
settings will be erased.
NOTE: Use caution when resetting the unit to factory defaults as all
user configured options will be erased and reset to original factory
settings.
EXIT: Exits this setting menu.
Troubleshooting

or improper control settings. If you encounter problems, isolate the area

fault and make the necessary changes. If you are unable to get sound
from the unit, refer to the suggestions for the following conditions:
Power Indicator Is Not Illuminated
The Power Indicator and the basic items in the Display window should be
illuminated whenever the unit is plugged into the wall power outlet and
the Power button is pushed in. If it does not illuminate, test the power
outlet with another electrical device, such as a lamp. Be sure the power
outlet being used is not controlled by a switch that has been turned off.
Network Does Not Work
If you have trouble connecting to your wired/wireless network, check your
network setting carefully, these steps may help to resolve the problem.

the same network.

section.

4. Do a hard power off (unplug the AC mains) and let the unit restart the
network scanning cycle.
5. If using Wi-Fi connection, make sure the placement of your unit allows
it to receive the Wi-Fi signal.
Fuse Replacement
If another electrical device works when plugged into the power outlet,
but the Power Indicator still will not illuminate when the unit is plugged
into the wall outlet, it indicates that the power fuse may have blown. If you
believe this has happened, unplug the unit removing the AC power and
use the tool to open the fuse holder ion the rear panel then replace
the blown fuse with a new one of the exact type and rating, or contact
your authorized Rotel dealer to get the fuse replaced.
No Sound
Check the signal source to see if it is functioning properly. Make sure the
cables from the signal source to the unit inputs are connected properly.
Be sure the Input Source is set to the proper input. Check the wiring
between the unit and the speakers.
Cannot Connect via Bluetooth
If you cannot pair your Bluetooth enabled device to the unit, delete the
memory of the previous connection on your device. On your device this is
often listed as “Forget this Device”. Then try to make the connection again.

18
RAS-5000 Amplied Streamer
Playable Audio Formats
aptX™ HD and AAC Bluetooth
Format Notes
Any format
supported by the
sending device.
May exclude Apps designed to play formats not
originally supported by the sending device.
PC-USB
Format Notes
Format determined
by the Media Player/
Server software that
you use.
Any supported format by the PC software
PCM Audio:
44.1k, 48k, 88.2k, 96k, 176.4k, 192k, 352.8k, 384k (16
bit, 24 bit)
MQA, MQA Studio (24 bit / 384k)
Coax/Optical
Format Notes
SPDIF LPCM 44.1k, 48k, 88.2k, 96k, 176.4k, 192k,
16 bit, 24 bit
USB Flash Drive
Format Notes
MP3,
FLAC, WAV, OGG 64k, 128k, 192k, 256k, 320k, HQ.
RAS-5000 APP
The RAS-5000 App can be downloaded by scanning the QR code
below.
For iOS devices:
For Android devices:

19
Specications
Power OutputPower Output 220 watts/ch, 4 ohms
140 watts/ch, 8 ohms
Total Harmonic DistortionTotal Harmonic Distortion < 0.03%
Intermodulation DistortionIntermodulation Distortion
(60 Hz : 7k Hz, 4:1) < 0.03%
Frequency ResponseFrequency Response
Line Level Inputs 10 Hz - 100k Hz, ± 0.5 dB
Damping FactorDamping Factor
(20 Hz – 20k Hz, 8 ohms) 290
Input Sensitivity / ImpedanceInput Sensitivity / Impedance
Line Level Inputs 0.78 V / 46k Ohms
Input OverloadInput Overload
Line Level Inputs 4.1 V
Tone Controls – Bass / TrebleTone Controls – Bass / Treble ±10 dB at 100Hz / 10k Hz
Signal to Noise RatioSignal to Noise Ratio (A weighting)
Line Level Inputs 103 dB
Digital SectionDigital Section
Frequency ResponseFrequency Response 10Hz - 70k Hz (± 3dB, MAX)
Signal to Noise RatioSignal to Noise Ratio (A weighting) 105 dB
Input Sensitivity / ImpedanceInput Sensitivity / Impedance - 8 dBFS / 75 ohms
Digital InputsDigital Inputs SPDIF LPCM
(up to 192k Hz/24 bit)
PC-USBPC-USB USB Audio Class 2.0
(up to 384k Hz/24 bit)*
*Driver installation required
Support MQA and MQA Studio
Rood Ready
HDMIHDMI Support eARC function
GeneralGeneral
Power RequirementsPower Requirements
USA 120V, 60 Hz
EC 230V, 50 Hz
Standby Power ConsumptionStandby Power Consumption
Normal < 0.5 watts
Power ConsumptionPower Consumption 380 watts
BTUBTU (4 ohms, 1/8th power) 1027 BTU/h
DimensionsDimensions (W, H, D) 431 x 144 x 425 mm
17 x 5 7/8x 16 ins
Panel HeightPanel Height 3U (132.6 mm / 5 1/4ins).
WeightWeight (net) 15.7 kg, 34.6 lbs.

Rotel reserves the right to make improvements without notice.
Rotel logo is registered trademark of The Rotel Co., Ltd. Tokyo, Japan.
Use of the Works with Apple badge means that an accessory has been


standards.
To control this AirPlay 2–enabled speaker, iOS 11.4 or later is required.
Apple, AirPlay, Apple TV, Apple Watch, iPad, iPad Air, iPad Pro, iPhone,
and Lightning are trademarks of Apple Inc., registered in the U.S. and
other countries.
‘MQA’ or ‘MQA Studio’ indicates that the product is decoding and playing

is identical to that of the source material. ‘MQA Studio’ indicates it is playing




Google, Android, Google Home, Google Play, and Chromecast built-in
are trademarks of Google LLC.

20 RAS-5000 Streamer Amplié
l’appareil, afin d’éviter tout risque de blessure
ou des dommages à l’appareil.
Débranchez le câble d’alimentation en cas
d’orage, ou si l’appareil ne doit pas être utilisé
pendant une longue période.
L’appareil doit être immédiatement éteint,
débranché puis retourné au service après-
vente agréé dans les cas suivants : le câble
d’alimentation secteur ou sa prise est
endommagé; un objet est tombé, ou du liquide
a coulé à l’intérieur de l’appareil; l’appareil a
été exposé à la pluie; l’appareil ne fonctionne
manifestement pas normalement; l’appareil est
tombé, ou le coffret est endommagé.
L’appareil doit être utilisé dans un climat non
tropical.
Veuillez ne pas obstruer les orifices de ventilation
par des journaux, magazines, tissus, nappes ou
rideaux, etc…
Aucune source de flamme nue, telle que
des bougies allumées, ne doit être placé sur
l’appareil.
Toucher des bornes ou des câbles non isolés
peut provoquer une sensation désagréable.
Vous devez réserver un espace libre d’une
dizaine de centimètres minimum autour de
l’appareil.
POWER
RAS-5000
OPTCOAXUSBSTREAMING AUX BTPC-USB
PHONES MENU ENTER
ATTENTION : La prise d’alimentation située
à l’arrière constitue le principal moyen
pour déconnecter l’appareil du secteur. Cet
équipement doit être positionné dans un espace
ouvert qui permet de garder l‘accès au câble
d’alimentation.
Cet appareil doit être branché sur une prise
d’alimentation secteur, d’une tension et d’un
type conformes à ceux qui sont indiqués sur
la face arrière de l’appareil (USA : 120 V/60 Hz,
CE : 230 V/50 Hz).
Brancher l’appareil uniquement grâce au cordon
secteur fourni, ou à un modèle équivalent. Ne
pas tenter de modifier ou changer la prise. Ne
pas utiliser de cordon rallonge.
La prise d’alimentation secteur constitue le
moyen radical de déconnexion de l’appareil.
Elle doit donc rester en permanence accessible,
Remarque
La prise RS232 ne doit être utilisée que par une
personne qualifiée.
ATTENTION : Il n’y a à l’intérieur aucune pièce
susceptible d’être modifiée par l’utilisateur.
Adressez-vous impérativement à une personne
qualifiée.
ATTENTION : Pour réduire tout risque
d’électrisation ou d’incendie, ne pas exposer
l’appareil à une source humide, ou à tout type
de risque d’éclaboussure ou de renversement
de liquide. Ne pas poser dessus d’objet
contenant un liquide, comme un verre, un
vase, etc. Prenez garde à ce qu’aucun objet
ou liquide ne tombe à l’intérieur de l’unité
par ses orifices de ventilation. Si l’appareil est
exposé à l’humidité ou si un objet tombe à
l’intérieur, débranchez-le immédiatement
de son alimentation secteur, et adressez-
vous immédiatement et uniquement à une
personne qualifiée et agréée.
Tous les conseils de sécurité et d’installation
doivent être lus.
Conservez soigneusement ce livret.
Tous les conseils de sécurité doivent être
soigneusement respectés.
Respectez les procédures d’installation et de
fonctionnement indiquées dans ce manuel.
Ne pas utiliser cet appareil près d’un point d’eau.
L’appareil doit être nettoyé uniquement avec
un chiffon sec ou un aspirateur.
Il ne doit pas être posé sur un fauteuil, un
canapé, une couverture ou toute autre surface
susceptible de boucher ses ouïes d’aération ;
ou placé dans un meuble empêchant la bonne
circulation d’air autour des orifices d’aération.
Cet appareil doit être placé loin de toute source
de chaleur, tels que radiateurs, chaudières,
bouches de chaleur ou d’autres appareils
produisant de la chaleur.
Notamment, ne pas tenter de supprimer la prise
de terre (troisième broche de la prise) si celle-ci
est présente. Si la prise n’est pas conforme à
celles utilisées dans votre installation électrique,
consultez un électricien agréé.
Prendre garde à ce que ce cordon d’alimentation
ne soit pas pincé, écrasé ou détérioré sur tout son
trajet, et à ce qu’il ne soit pas mis en contact avec
une source de chaleur. Vérifiez soigneusement
la bonne qualité des contacts, à l’arrière de
l’appareil comme dans la prise murale.
N’utilisez que des accessoires préconisés par
le constructeur.
N’utilisez que des meubles, supports, systèmes
de transport suffisamment solide
pour supporter l’appareil. Procédez
toujours avec la plus extrême
précaution lorsque vous déplacez
L’éclair dans un triangle équilatéral indique
la présence interne de tensions électriques
élevées susceptibles de présenter des
risques graves d’électrocution.
Le point d’exclamation dans un triangle
équilatéral indique à l’utilisateur la
présence de conseils et d’informations
importantes dans le manuel d’utilisation
accompagnant l’appareil. Leur lecture est
impérative.
Tous les appareils Rotel sont conçus
en totale conformité avec les
directives internationales concernant
les restrictions d’utilisation de
substances dangereuses (RoHS)
pour l’environnement, dans les
équipements électriques et
électroniques, ainsi que pour le
recyclage des matériaux utilisés
(WEEE, pour Waste Electrical and
Electronic Equipment). Le symbole
du conteneur à ordures barré par
une croix indique la compatibilité
avec ces directives, et le fait que les
appareils peuvent être correctement
recyclés ou traités dans le respect
total de ces normes.
Remarques importantes concernant la sécurité
Ce symbole signifie que cet appareil
bénéficie d’une double isolation
électrique. Le branchement d’une
mise à la masse ou à la terre n’est
pas nécessaire.
car sa déconnexion constitue la seule assurance
que l’appareil n’est plus alimenté par le secteur.
Utilisez uniquement des câbles de Classe 2 pour
réalise les connexions aux enceintes acoustiques
et offrant une isolation suffisante pour minimiser
les risques de chocs électriques.
Les piles de la télécommande infra-rouge ne
doivent en aucun cas exposées à une chaleur
excessive notamment au feu ou au soleil direct.
Les batteries doivent être recyclées ou éliminées
selon les directives nationales et locales.
Cet appareil répond aux normes de l’article 15
de la FCC sous les conditions suivantes : 1) Cet
appareil ne doit pas causer d’interférence très
sensible. 2) Cet appareil doit pouvoir accepter
n’importe quelle interférence externe, y compris
celles dues à une utilisation fortuite.
