Sencore MIP 1664 Installation and operation manual

February 2015
Form 7525A www.sencore.com | 1.605.978.4600 Revision 1.1
MIP 1664
MPEG/IP Streamer
Startup Manual

MIP 1664 –Startup Manual
Page 2 (8)
Copyright
© 2012 Sencore, Inc. All rights reserved.
3200 Sencore Drive, Sioux Falls, SD USA
www.sencore.com
This publication contains confidential, proprietary, and trade secret information. No part of this document
may be copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic
format without prior written permission from Sencore. Information in this document is subject to change
without notice and Sencore Inc. assumes no responsibility or liability for any errors or inaccuracies.
Sencore, Sencore Inc, and the Sencore logo are trademarks or registered trademarks in the United States
and other countries. All other products or services mentioned in this document are identified by the
trademarks, service marks, or product names as designated by the companies who market those products.
Inquiries should be made directly to those companies. This document may also have links to third-party web
pages that are beyond the control of Sencore. The presence of such links does not imply that Sencore
endorses or recommends the content on those pages. Sencore acknowledges the use of third-party open
source software and licenses in some Sencore products. This freely available source code can be obtained
by contacting Sencore Inc.
About Sencore
Sencore is an engineering leader in the development of high-quality signal transmission solutions for the
broadcast, cable, satellite, IPTV, and telecommunications markets. The company's world-class portfolio
includes video delivery products, system monitoring and analysis solutions, and test and measurement
equipment, all designed to support system interoperability and backed by best-in-class customer support.
Sencore products meet the rapidly changing needs of modern media by ensuring the efficient delivery of
high-quality video from the source to the home. More information about Sencore is available at the
company’s website, www.sencore.com.
All trademarks and registered trademarks mentioned herein are the property of their respective owners.

MIP 1664 –Startup Manual
Page 3 (8)
WARNING
PLEASE OBSERVE THESE SAFETY PRECAUTIONS
There is always a danger present when using electronic equipment.
Unexpected high voltages can be present at unusual locations in defective equipment
and signal distribution systems. Become familiar with the equipment you are working
with and observe the following safety precautions.
Every precaution has been taken in the design of the MIP 1664 to ensure t
hat it is as safe as possible. However, safe operation depends on you the
operator.
Always be sure your equipment is in good working order. Ensure that all p
oints of connection are secure to the chassis and that protective covers ar
e in place and secured with fasteners.
Never work alone when working in hazardous conditions. Always have an
other person close by in case of an accident.
Always refer to the manual for safe operation. If you have a question abou
t the application or operation call SENCORE for assistance.
Never allow your equipment to be exposed to water or high moisture envir
onments. If exposed to a liquid, remove power safely (at the breaker) and
send your equipment to be serviced by a qualified technician.

MIP 1664 –Startup Manual
Page 4 (8)
Revision History
Date
Version
Description
Author
11/6/2012
1.1
Updated format
CL

MIP 1664 –Startup Manual
Page 5 (8)
Table of Contents
1.1 Introduction............................................................................................................................ 6
1.2 Package Contents................................................................................................................. 6
1.3 Installation ............................................................................................................................. 6
1.4 Rear and Side Panel Connections........................................................................................ 6
1.5 MIP 1664 Startup .................................................................................................................. 7
1.6 Additional Documentation ..................................................................................................... 7
1.7 Maintenance.......................................................................................................................... 7

MIP 1664 –Startup Manual
Page 6 (8)
1.1 Introduction
Thank you for purchasing your Sencore MIP 1664. This unit is a powerful tool that can be used
to stream hundreds of IP services for any number of different uses.
This guide is meant to provide a quick overview of how to install, setup, and maintain the MIP
1664 MPEG/IP Streamer. Because the MIP 1664 can be configured in many ways, the included
instructions may not exactly match the unit being set up.
1.2 Package Contents
The following is a list of the items that are included with the MIP 1664 unit:
1. Startup Manual
2. Backup Software CD
3. AC Power Cord
4. Rackmount Rails
If any of these items were omitted from the packaging of you unit, please call
1-800-SENCORE to obtain a replacement.
1.3 Installation
The MIP 1664 rackmount chassis is a 1RU enclosure that is designed to be mounted in a
standard 19” equipment rack. The unit is shipped with the mounting hardware necessary to
safely secure the chassis in the rack. This includes rackmount ears and screws for the front
along with rails to support the sides. The user is advised to always use the included rails for
mounting.
The MIP 1664 is designed for front-to-back ventilation. Care must be taken to ensure that this
ventilation is not impeded in any way.
1.4 Rear and Side Panel Connections
All of the external connections for the MIP 1664 are located on the rear of the unit. These
connections include standard computer I/O (Monitor, USB, parallel, serial, audio, and LAN ports)
and the MIP 1664 IP output connections. The power connection is also located on the rear of the
unit.
Power Connection
Using the proper power connections is vital to the safe operation of the unit. Only use the
supplied 3-prong power connectors or those with equal specifications. NEVER tamper with or
remove the 3rd –prong grounding pin on any cord. This could cause damage to the unit,
personnel, or property.
The MIP 1664 is intended for use on either 120V or 240V systems. The power supply will
automatically detect the voltage to which it is connected. There is one power supply and one AC
power cord. To connect AC power, perform the following:
1. Locate the proper AC power cord.
2. Plug the female end of the power cord (end with no prongs) into the back of the unit.
3. Plug the male end of the power cord into a protected outlet.

MIP 1664 –Startup Manual
Page 7 (8)
IP Streamer Connections
The output connections for the analyzer are located on the rear of the MIP 1664. Depending on
the options ordered, these may include one or two IP/SFP outputs.
1.5 MIP 1664 Startup
After completing all of connections, turn on the power of the MIP 1664 using the power button.
The system, which is based on a Windows Server 2008, will login automatically. If the system
does not login automatically, login to Windows using the default parameters below:
Username: administrator
Password: mpeg101
Icons necessary to access the functionality of the MIP 1664 will be located both on the desktop
and in the start menu.
1.6 Additional Documentation
Detailed product manuals and additional information for all of the MIP 1664 functions can be
found in electronic form located in the Manuals folder on the desktop. If this folder has been
removed for any reason, the same folder is located in the start menu under the MIP 1664
heading.
1.7 Maintenance
The MIP 1664 is a maintenance-free piece of equipment. There are no user serviceable parts on
the inside of the unit.

Sencore Inc.
3200 Sencore Drive
Sioux Falls, SD 57107 USA
www.sencore.com
Copyright ©2012 Sencore Inc. 1.605.978.4600
