Rotronic RMS-GW-868 User manual

RMS Gateway
© 2016 ROTRONIC AG Bassersdorf Switzerland

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
Table of Contents
1Overview.................................................................................................................................................3
1.1 RMS System Overview ........................................................................................................................3
1.2 Device Overview..................................................................................................................................4
1.3 RMS Gateway......................................................................................................................................5
1.4 Power Supply.......................................................................................................................................5
1.5 RTCC (Real Time Clock Calendar)......................................................................................................6
1.6 Interval.................................................................................................................................................6
1.7 Indicator and Button.............................................................................................................................6
1.8 Interface...............................................................................................................................................6
1.9 Software Compatibility .........................................................................................................................6
2Dimensions ............................................................................................................................................7
3Installation..............................................................................................................................................8
3.1 Drilling Template Wall Bracket...........................................................................................................13
4Electrical Connections........................................................................................................................14
5Operation..............................................................................................................................................15
5.1 Default Configuration .........................................................................................................................15
5.2 Configuration with RMS-CONFIG ......................................................................................................16
5.3 General Manipulations.......................................................................................................................17
5.4Integration in the RMS-WEB Software...............................................................................................18
5.5 Function Overview .............................................................................................................................20
6Firmware Update..................................................................................................................................21
7Technical Specifications.....................................................................................................................22
8Accessories .........................................................................................................................................24
9Additional Documents.........................................................................................................................25
10 Document Version...............................................................................................................................26
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 2 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
Scope:
This manual is valid for the RMS gateways from firmware version V1.x. The low-order digit of the firmware
version stands for minor changes, e.g. correction of errors that do not influence the main functionality of the
device.
1 Overview
1.1 RMS System Overview
The Rotronic Monitoring System (RMS) is a network comprising various devices and the RMS server software.
The software is theheart of the system. It collects allmeasured data of the devices and saves it in the database.
The individual devices work as input modules (data loggers) and as output modules (displays, analog outputs,
switched outputs). The user can view the system data at any time on a PC, laptop or smart phone.
Figure 1: Schematic diagram of the RMS with the server software and database at the heart
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 3 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
1.2 Device Overview
All devices can be configured as wanted as modules of the system. The following table shows all basic types of
the RMS devices. Almost all modules1have the following options:
•Interface: Ethernet / Wireless
•Housing: Wall housing / DIN top hat rail housing
Display Module
The display module can show any values from the
RMS network. Humidity, temperature and switch
states can be configured per software.
Standard Logger
Records the measured data of the digital HygroClip
HCD or other RMS probes. Stored in the ring
memory, the data are then sent to the server
software.
Output Module
Provides two analog voltage or current outputs or is
also available as variant with two solid-state relays in
order, for example, to switch alarm lamps.
Input Module
Records voltage or current signals from analog
devices such as particle counters, flow transmitters
or CO2 probes. For example:
•HF5 transmitter (humidity & temperature)
•AF1 transmitter (air flow)
•CO2 transmitter (CO2)
•PF4 transmitter (differential pressure)
Temperature Logger
The loggers can be equipped with various
temperature sensors (NTC, Pt100, Pt1000 or K-
element). This offers the highest flexibility in use.
Mini Logger
A temperature logger with integrated or remote NTC
sensor. Instead of a temperature sensor, it is also
available with a switch input in order, for example, to
monitor door contacts.
Gateway
The gateway is the connecting element between
Ethernet and wireless network and forwards the data
flow from the loggers to the data centre.
1Except for the Mini Logger
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 4 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
1.3 RMS Gateway
The gateway is the interface between the wire data logger and the web software. The gateway can manage up
to 60 data loggers simultaneously, collecting all wireless logger data and passing them on to theserver software.
When several gateways are used in the same network, they are configured redundantly. If one gateway should
fail, the data are automatically sent to the server software via another gateway.
The gateway provides the following basic functions:
oCollection of all measured data from the wireless data loggers
oTransfer of the recorded data to the RMS software
oFirmware update
1.4 Power Supply
The gateway has the following two power supply variants:
•24 V (< 50 mA) via terminals (V+ / V-)
•Power over Ethernet (PoE), per standard IEEE 802.3af, Class 1
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 5 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
1.5 RTCC (Real Time Clock Calendar)
The device has a real time clock calendar. The time is synchronized continuously when connected to the server.
1.6 Interval
The interval for data transfer is exactly the same as that of the connected data loggers. At every interval the
gateway receives the latest measured values from the data loggers and sends them to the server software.
1.7 Indicator and Button
The device has a button and multicolour LED for use and indication of the operating state. The button is used
to start the device or switch it off in battery mode. The LED indicates the device status and whether it was
possible in the current measurement interval to carry out a valid measurement and send the data to the
monitoring system.
LED Status Indicator for LAN Devices
Status
LED Function
Meaning
Connected
Flashes green
Status OK
Flashes red
2 times: no connection to server
Not connected
Flashes orange
Device waiting for integration into the software
1.8 Interface
The gateway is operated completely via the LAN interface and does not have an additional service connector.
1.9 Software Compatibility
The gateway is designed for use with the RMS server software (local installation or Rotronic Cloud). The
gateway can alternatively also be operated with the RMS configuration software (standalone software).
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 6 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
2 Dimensions
The data logger and the gateway of the RMS are all integrated in the same wall housing. All dimensions are
shown in Figure 2.
Figure 2: Dimensions of the wall housing
Figure 3: Mounting bracket with dimensions for drill holes
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 7 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
3 Installation
There is a difference between mechanical installation of the wall housing and the DIN top hat rail housing. This
manual only describes installation of the wall housing. Installation of the DIN top hat rail housing requires no
special handling. All terminal markings are identical to those of the wall housing.
The following instructions describe installation of the data logger step by step.
1
Press a blunt object (e.g.
screwdriver in the AC1321
mounting kit) lightly into the
hole opening on the top
side of the housing. The
flap springs open.
2 Press the cover to the back
and take off from the basic
unit.
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 8 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
3
The cover has two
suspension openings and
two additional prepared
fastening possibilities2.
4
Make a round opening in
the large rubber seal (use
the mounting cone in
AC1321), pass the cable
through it and fit the rubber
plug in the cover.
2Only the mounting points provided should be used for mounting.
© 2016 ROTRONIC AG Bassersdorf Switzerland Page 9 of 26

RMS-GW-868 Gateway
E-M-RMS-GW-868-V1_0.docx Instruction Manual
5
Plug the cable into the
device3. For secure
fastening and to ensure a
reliable data link, make
sure it clicks in audibly.
6 If necessary:
Connect the device to a
power supply.
3The connected cable may not exceed a length of 30 m at most. Disruptions can occur in operation if a longer
cable is used!
