Rousseau 3351 User manual

OWNER’S MANUAL
Lifetime
Warranty…Always
Super-size Folding Router Table
Model 3351
IMPORTANT
Read and understand all safety guidelines and instructions
carefully before operating.

Thank you for purchasing a Rousseau 3351 Router Table
Rousseau folding / portable router tables meet the needs of the mobile,
professional contractor as well as the space starved woodcrafter. Featuring our
pro-style top, the Rousseau Deluxe Router Base Plate, precision machined
router fence and folding leg set. Our robust design handles your heaviest jobs,
yet each table quickly folds to provide for compact storage and easy transport.
Accessorize your table with a Rousseau Power Switch, Rousseau Dual
Pressure Feather Boards, and the Rousseau Router Lift System.
Warranty
This product has a life time warranty to the original purchaser that applies to
defect in materials and workmanship only. We will repair or replace the product
or part(s) at our discretion. This warranty does not apply to product failure of
defects due to direct or indirect mis-use, abuse, negligence, accidents,
alterations, repairs or lack of maintenance. The item must e shipped prepaid to
our Clarkston, WA location. If items must be returned for warranty service, call
to receive a Returned Goods Authorization (RGA) number and further
instruction.
Safety Guidelines
This section contains important safety information concerning a hazard that
may cause serious injury or death, and/or damage to stand or equipment if
used improperly. Please read the following instructions very carefully.
Always follow the safety recommendations and guidelines provided by the
manufacture of your tools. When in doubt refer to your owner’s manual.
Always set stand on level ground or floor surface, making sure all legs are in
contact with the ground or floor. Failure to do so could result in travel,
movement or the collapse of the table causing injury to the operator or to the
equipment.
Always keep hands clear of pinch points and moving router bits. Failure to do
so could result in serious injury of loss of fingers
Never remove existing guards of safety equipment from power tools. Operation
without guards could result in loss of fingers, severe injury or death.

Set Up and Adjustments
Remove your router table from the box while leaving the table upside down on
its shipping protection, unfold the legs and secure them in the locked position.
Set table upright on a flat surface and turn the adjustable foot in or out until all
four legs make secure contact with the floor.
Please refer to the base plate manual for instructions on mounting your router.
After the router is mounted to your base plate simply drop it in the opening and
level to the top of the table using the nylon thumb screws provided and then
install corner snuggers.
Please refer to your Router fence manual for fence assembly instructions.
Mount the assembled fence to the table using the provided T-track nut and
knob fig. #1. Mount the fence to the tracks either side of the router base plate
fig. #2.
You will find the fence becomes secure with minimum torque on the knobs.
Figure #1 Figure #2
Model 3351 Parts List
Part # Description Quantity
3309 Leg set 2
3357 N Table Top 1
2700 05 Rubber foot 3
2700 03 Leg hinge 4
???? Adjustable foot 1
3301 55 T-Track Nut 2
KB01A Knob 2
???? 1/4-20 X 1 1/4 Bolt 2
See Router or Base Plate manuals for their parts list.

ROUSSEAU ROUTER TABLE ACCESSORIES
Power Switch Model 3506
Crash bar for a quick convenient and safe shut off.
INSERT RINGS W/SHOLDER
PIN MODEL 3509-1R
Replacement rings for the 3509
Router base Plate.
Feather Board
Single Pack Model 3301-5
Dual Pack Model 3301-10
Hold work securely and safely.
Aluminum Base Plate
Model 3509-AL Strong and flat with
a hard anodize surface.
T-Nut Kit Model 3501
For attaching accessories and
fixtures.
1392 Port Drive, Clarkston, WA 99403
800.635.3416 • 509.758.3954 • Fax [phone]
Email: [e-mail] • www.rousseauco.com
