ROWAN ELECTRIC APPLIANCE 5375 User manual

Remote Tower Fan
Model No.: 5375
Thank you for purchasing this product! Please read this manual carefully before operating
this product. If you have any questions about the product, such as missing parts, product
damage, product assembly and operation etc., please contact us via Amazon Message or
customer service phone: [phone]
Instruction Manual

Part 1 IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should
always be obeyed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING: To reduce the risk of fire, electric shock, or
personal injuries:
1. This fan is for household use only.
2. Before first use, check whether your voltage corresponds to the
product nameplate requirements.
3. For safety reasons, please check the status of the power cord and
plug before use.
4. When not in use, be sure to turn off the fan and unplug it from the
power socket.
5. Be careful when using this equipment near children.
6. Do not run the power cord under carpets, and do not cover the
cord with throw rugs. Do not put cord under furniture or appliances.
Arrange cord away from traffic areas so that people will not be
tripped over by it.
7. Do not operate any fan with the damaged cord or plug. Discard
the fan or return it to an authorized service facility for examination
and repair.
8. If the fan’s power supply cord is damaged, it must be replaced by
the manufacturer or its service agent to avoid potential safety
hazards.
9. Use the fan in well-ventilated areas. Place the fan at least 8 inches
from any walls to ensure the proper air flow during use. The fan
cannot be located directly under or close to the curtain.
10. Do not obstruct the airflow with any objects or place anything in
the opening of the fan.
11. Do not use the fan in areas where curtains may be sucked in.
12. Only place the fan on a hard, flat, dry floor.
13.Do not use the product in extreme temperatures, humidity, or

dusty environments.
14.Do not put heavy objects on the fan.
15. Do not place the fan below the power outlet that will suck the
cord inside to cause damage.
16.When the fan is oscillating, do not touch the fan manually to avoid
damage.
17. Be sure to turn off the power supply before unplugging the power
cord from the power outlet to avoid short circuit, fire, or electric
shock.
18. Do not twist or pull the power cord out.
19. In order to avoid the danger of electric shock, do not unplug the
fan when your hands are wet.
20. Children under 8 years old should not operate the fan.
21. This appliance is not suitable for people (including children) with
reduced physical/sensory/mental abilities or people who lack
experience and knowledge. Unless the above-mentioned people are
supervised or instructed by a person who is responsible for their
safety.
22. Children should be supervised to ensure that they do not play
with the appliance.
23. Ensure that the fan is switched off and unplugged from the power
supply before removing the guard.
24. To reduce the risk of fire or electric shock, do not use this fan with
any solid-state speed control device.
25. Please unplug or disconnect the appliance from the power
supply before the repair work is carried out.
26. This product has overload protection (fuse). A blown fuse
indicates an overload or short circuit. If the fuse is blown, unplug the
product from the socket. Replace the fuse (select the appropriate
fuse rating according to the product label) by following the user
maintenance instructions and check the product. If the replacement
fuse is blown, there may be a short circuit, and the product should be
discarded or returned to an authorized service facility for
examination/repair.

Warning:
This appliance has a polarized plug (one blade is wider than the
other). In order to reduce the risk of electric shock, the plug can only
be inserted into the electrical outlet/receptacle one way. If the plug
cannot be fully inserted into the power outlet, reverse the plug. If it is
still not suitable, please contact a qualified electrician. Do not
attempt to destroy this safety function alone.
To Change the fuse
The following should ONLY be conducted by qualified
professionals:
1. Grasp the plug and remove it from the electric receptacle.
Do not unplug by pulling on the cord.
2. As shown in the figure below, slide the fuse access cover
on the top of the plug towards the blade and open the fuse
cover.
3. Remove the fuse carefully. Push the fuse from the other
side or turn the fuse holder upside down to remove fuse.
4. Fire risk. Replace the fuse only with a 5-amp 125-volt fuse.
5. Close the fuse cover by sliding the fuse access cover on
the top of the plug away from the blades.
6. Fire risk. Do not replace the polarized plug as it has a
safety device that should not be removed.
Discard product if its polarized plug is damaged.
SAVE THESE INSTRUCTIONS
Part 2 Brief introduction

This tower fan is equipped with multiple functions, such as 8 speeds,3
modes, 360 degree oscillation, 24H timer, remote control and ionizer.
With the above functions, our tower fan can provide you a cool, healthy
and luxurious lifestyle.
Part 3 Specification
MODEL NO
RATED
POWER
CLASS
5375
120V, 60Hz
50W
II
Part 4 Structure and parts
Part 5 Installing
Parts list
Description
Quantity
Description
Quantity
Remote
control
1
Instruction
manual
1
Base
2
Screws(1)
(ST4*12mm)
2
Screws(2)
（ST4*16mm）
4
1-------------Control panel
2-------------Head
3-------------LED screen
4-------------Air outlet
5-------------Base A
6-------------Base B

1. Take out the two bases from the gift box. Forming the base A and B
into one unit. (Shown in pic.1) Then fasten base A and base B with 2 pcs
screws(1). (Shown in pic.2)
2. Connect fan body to the base with 4 pcs of screws(2). (Shown in the
below figure)

Part 6 Function
Control panel Remote control
1. Power button
2. Oscillation button
3. Wind speed and timer add button
4. Wind speed and timer minus button
5. Timer button
6. Fan mode button

7. Light go out button
8. Ionizer button
1. ON/OFF
Press button on the control panel or press button on the
remote control to turn the fan ON/OFF. Press it once, the fan will start
operating. Press it again to stop the fan.
2. Mode
The model has three modes: Normal/ Natural/ Sleeping. When you turn
on the fan, the default mode is Normal wind mode, the LED screen will
indicate normal wind mode.
Normal wind mode:
The Normal light indicator will be switched ON when selected this
mode is selected.
Natural wind mode:
The Natural light indicator will be ON when this mode is selected.
The fan will run like real natural wind, alternating between high wind and
low wind.
Sleep wind mode:
The Sleep light indicator will be ON when this mode is selected. The
fan will run in the current natural wind mode, and reduce 1 natural wind
level every half an hour. Keep natural wind speed level 1 until it turns off.
3. Oscillation
Press “Oscillation” button to start oscillation function. The oscillation
degrees are optional: 60, 90,120, and 360 degrees.
4. Ionizer
Press “Ionizer” button to start ionizer.
The ionizer light indicator will be ON when selecting this function

5. Timer
Press “Timer” button, then press“+”or “-”to choose the duration of
time. The timer is 24 hours at most. To cancel the set timer, press the
“Timer” button again and press“-”button to set it as 00 Hr.
6、Wind Speed
Press “+”or “-”button to choose the wind speed ranging from 1-8.
7、Light
Press and hold“Mode”button for 3 seconds on the control panel or
press button on the remote controller, the light on the screen will go
out. If you want to turn on the light on the screen, press any button
except the power button.
Part 7 Maintenance and Storage
1. Always remove the plug from the socket-outlet and allow the fan to
stop before cleaning it.
2. Clean the external surfaces of the fan with a soft damp cloth (not
dripping wet cloth).
WARNING:
Do not immerse the fan into the water.
Do not use any cleaning chemicals such as detergents and
abrasives. Do not allow the interior to get wet as this could cause
dangerous problems.
3. When the unit is not in use, make sure that it is unplugged from the
wall socket. To store the fan, you may pack it in the original carton and
store it in a cool and dry place.
4. In case of malfunction or doubt, do not try to repair the fan yourself,
otherwise it may result in a fire hazard or electric shock.

Part 8 After sales service
This appliance has a warranty of 1 year from the date of purchase,
considering the following notes:
1. Guarantee is only valid showing the invoice or purchase ticket.
2. Damage caused during transportation, negligence, incorrect insta-
llation or installation, and external influences such as atmosphere or
electric rays, floods, humidity, etc. are not covered by the guarantee.
3. This warranty will void when it is discovered that they have been
subjected to repairs, alterations or interventions by any unauthorized
persons.

Thank you for purchasing this product! If you have any questions about the product,
such as missing parts, damaged products, product assembling, and operation, please
contact us via Amazon Message or customer service number: 213-4467172 or
661-4358826.
IMPORTANT
Please call our customer service department for any consulting:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
DATED PROOF OF PURCHASE IS REQUIRED FOR WARRANTY SERVICE.
AVIS
Veuillez appeler le service à la clientèle pour toutes questions au:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
PREUVE D’ACHAT ORIGINALE REQUISE POUR SERVICE DE GARANTIE.
IMPORTANTE
Sólo hay que llamar nuestro departamento de servicio
al cliente en caso de tener preguntas o inquietudes:
213-4467172
661-4358826
(8:30am - 5:30pm P.S.T.)
SE REQUIERE PRUEBA DE COMPRA CON FECHA PARA SERVICIO BAJO
GARANTÍA.
Address: ROWAN ELECTRIC APPLIANCE LLC
28407 Ascent Way, Santa Clarita, CA 91350
Phone: [phone] or 661-4358826
