Rowkin ASCENT CHARGE User manual

ASCENT
CHARGE/CHARGE+
TRUE WIRELESS HEADPHONES
USER MANUAL

(Included with purchase ofAscent Charge+)
IN-THE-BOX
2 BLUETOOTH EARBUDS
DUAL-FUNCTION
PORTABLE CHARGING CASE
QI WIRELESS CHARGER
3 SIZES OF EARTIPS:
SMALL, MEDIUM, LARGE
USB-C CHARGING CABLE + USB ADAPTER

Built-in-Mic &
LED Indicator
Touch Control
Surface
FEATURES
WIRELESS QI CHARGER
ROWKIN APP
Capacitive touch
Noise cancelling
Quality sound
IPX5 water-resistant technology
Charges earbuds
USB-C port for charging your mobile device
Premium metal finish
Durable carrying strap
Qi-compatible
LEFT & RIGHT BLUETOOTH EARBUDS
DUAL-FUNCTION
PORTABLE CHARGING CASE
The 5W single coil Qi charger
allows you to charge your
Ascent Charge and other
compatible mobile devices.
Download the Rowkin Mobile App on
your phone to access “Find My Earbuds”
feature and sound customization. Rowkin
(Included with purchase ofAscent Charge+)

To charge your earbuds place both earbuds in the charging
case. When earbuds are charging, the red LED will blink.
Once they are fully charged, the LED will turn o.
Plug the USB-C cable into the port
on the bottom of the case and then
connect to power.
Lightly shake charging case to check battery levels.
Each LED indicates 25% charge level.
The charging case also acts as a power bank for your other
devices. Simply plug the USB-C cable into the port on the bottom
of the case and then connect the other end to your device.
To charge the charging case, place
charging case directly on top of Qi
wireless charger.
BATTERY LEVEL INDICATOR LED
OR
CHARGE DEVICE

To use the Qi charger, plug the charging pad into a power source
using the included USB cable. The LED light should turn on.
To charge the Ascent charging case, place charging case directly
on top of Qi wireless charging pad. Charge pad LED light will
slowly blink as device charges.
For optimal performance, your device should be placed in the
proper location on the pad. Refer to diagram below.
Do not place other objects on Qi charging pad.
The 5W single coil Qi charger charges your Rowkin Ascent
products and other Qi-compatible devices.
(Included with purchase ofAscent Charge+) QI CHARGER

SYNC + PAIR
FOR SUBSEQUENT USE
TRUE WIRELESS NEEDS BLUETOOTH.
1
2
3
4
5
6
These earbuds will automatically sync to each other.
Remove earbuds from case and
place next to each other on a flat
surface. Be sure to place them
so the LED lights are visible.
Earbuds turn on automatically
when they are removed from the
case. You will hear “Power On”
from both earbuds.
A red LED light will be lit followed
by blinking white LED lights,
(takes approximately 5 seconds.)
Once the earbuds are synced to
each other, the Right earbud will
flash red and white to indicate it
has entered pairing mode.
Go to Bluetooth settings on your
device and select “Rowkin Ascent”.
Once the LED stops flashing red
and white on the Right earbud,
you are connected and ready to
experience true wireless sound.
POWER ON
Take earbuds out of the case or
press and hold the earbud surface
until you hear “Power On”
(approx. 3 seconds)
POWER OFF
Place earbuds back in the case
or press and hold the button
until you hear “Power O"
(approx. 5 seconds)
LR

CONTROLS
ANSWER CALL
TAP AND HOLD
FOR 3 SECONDS
END CALL
TAP AND HOLD
FOR 3 SECONDS
REJECT CALL
TRIPLE TAP
MUTE MIC
DOUBLE TAP
LEFT EARBUD
NEXT TRACK
DOUBLE TAP
PREVIOUS TRACK
TRIPLE TAP
RIGHT EARBUD
PLAY/PAUSE
DOUBLE TAP
SIRI/GOOGLE
TRIPLE TAP
SECOND CALL
END FIRST CALL
THEN TAP AND HOLD
FOR 3 SECONDS
PLACE ON HOLD
TAP AND HOLD
FOR 5 SECONDS
EITHER EARBUD

If you experience any malfunction with the earbuds, follow these
instructions to reset your device.
RESET
1 2
34
Place both earbuds into the
charging case and make
sure they are charging.
Press and hold touch
surface of either earbud.
Hold until earbud light blinks
white twice. (approximately
10 seconds)
Follow the initial setup
instructions to reconnect
the earbuds to your device.
FACTORY RESET
OTHER IMPORTANT NOTES
Do not place earbuds logo-side down on a surface, as this can wear
down touch capabilities.

PROBLEM PROBABLE CAUSE SOLUTION
Sound breaks up or fades
in and out
Headset is too far away
from the source device;
Interference between the
headset and the source
device; The human body
may interfere and weaken
signal in some conditions.
Keep source device close
and in direct view of the
headset. Do not cover with
your hands or arms.
The other party on the call
can’t hear my voice
Environment is too noisy;
Headset is covered during
the call, for example, by
hair or hands.
Remove anything covering
the headset; Speak louder
and call in a quiet
environment.
My earbud doesn’t power
on when removed from
the case.
The earbuds were not
connected firmly in the
case while charging.
Make sure the earbud
indicator is flashing while in
the case to confirm charging.
Earbuds can be powered on
manually by pressing the
button for 3 sec.
TROUBLESHOOTING + SPECS
Dimensions:
Earbud: 0.61”(D) x 0.93”(L) (15.5x23.5mm)
Portable charging case:
1.28”(D) x 1.71”(H) x 4.45(L)
(32.6x43.4x113.1mm)
Weight:
Earbud: Earbud: 0.23 oz (6.4g) each
Portable charging case: 4.39 oz (124.4g)
Battery type:
Rechargeable lithium-ion polymer battery
Battery input:
Earbud: 5V / 35mA
Portable charging case: 5V / 1A
To earbuds: 5V / 120mA
USB Output: 5V/1A
Battery output:
Battery capacity:
Earbud: 55mAh
Portable charging case: 1900mAh
Charging time:
Earbud: ≤70 minutes
Portable charging case: ≤120 minutes
Standby time (power on): about 70 hours
Standby time (power o): about 120 days
Bluetooth profiles:
Music/talk time: up to 3.5 hours
Frequency response: 20Hz-20kHz
Bluetooth version: 5.0
HFP, HSP, AVRCP, A2DP, and SPP
Audio enhancements:
Noise reduction and echo cancellation
TROUBLESHOOTING
SPECIFICATIONS
For the best Bluetooth connection, keep source device in
direct view of the earbuds. The human body may
interfere and weaken signal in some conditions.

SAFETY INFORMATION / STATEMENTS
SAFETY INFORMATION
STATEMENTS
Use Responsibly
Do not use earphones when it is unsafe to do so: while operating a vehicle,
crossing the street, or during any activity or in an environment where your full
attention to your surroundings is required.
It is dangerous to drive while wearing the earphones and in many places illegal
because it decreases your changes of hearing life-saving sounds outside of
your vehicle, such as another car’s horn and emergency vehicle sirens. Please
avoid wearing our earphones while driving.
Listen Responsibly
To avoid hearing damage, make sure that the volume on your music player is
turned down before connecting your earphones . After placing the earphones
in your ear, gradually turn up the volume until you reach a comfortable
listening level. Noise levels are measured in decibels (dB); exposure to any
noise at or above 85 dB can cause gradual hearing loss. Monitor your use;
hearing loss is function of loudness versus time. The louder it is, the less time
you can be exposed to it. To prevent possible hearing damage, do not listen at
high volume levels for long periods.
FCC and IC Compliance Statement
This device complies with Part 15 of the FCC rules and industry Canada
license-exempt RSS standards. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference; and (2) this
deice must accept any interference received, including interference that may
cause undesired operation.
EU Compliance Statement
Rowkin hereby declares that this wireless device is in compliance with the
essential requirements and other relevant provisions of the R&TTE Directive.
Caution Statement
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
WARNING: Do not expose this product to liquid or excessive heat.
Disposal Information
The symbol indicates that this product and/or battery should not be disposed
of with household waste. When you decide to dispose or this product and/or
is battery, do so in accordance with local environment laws and guidelines.

SUPPORT
CUSTOMER SUPPORT
If you experience any problems with your Rowkin product(s)
please review our FAQs or contact our support team at
WARRANTY
Your Products are warranted against defects in materials and
workmanship for a period of 1 year from the date of original
retail purchase (if purchased at a retailer) or 1 year from the date
of shipment (if purchased on rowkin.com) (“Warranty Period”)
when used in accordance with the applicable usage
documentation. If a defect arises during the Warranty Period,
Rowkin will, at its option, (1) repair the aected Product at no
charge using new parts or parts that are equivalent to new in
performance and reliability, (2) exchange the aected Product
with a functionally equivalent Product that is new or formed
from new and/or previously used parts that are equivalent to
new in performance and reliability or, with your consent, a
Product that is at least functionally equivalent to the Product it
replaces; or (3) refund the original purchase price for the
aected Product . This warranty excludes normal depletion of
consumable parts unless failure has occurred due to a defect in
materials or workmanship, and damage resulting from abuse,
accident, modifications, unauthorized repairs, or other causes
that are not defects in materials and workmanship. No other
person is authorized to modify this limited warranty.
THANK YOU
Thank you for supporting Rowkin. If you enjoy our product(s)
please share the love on social media with the hashtags
#Rowkin and #RowkInspired
@rowkininc
www.rowkin.com/support
Follow the Rowkin community at
www.rowkin.com/warranty
