Royal garden SVPUPGZB106 User manual

Assembly Instructions
Pop-Up Canopy
Questions, problems, or missing parts?
Before returning to the store, call Customer Service.
1-866-988-3300
8 a.m. - 5 p.m., PST Monday - Friday
Model No. SVPUPGZB106
Retain this manual for future use.

SVPUPGZB106
Contents
Safety Instructions
Cleaning & Maintenance
Taking Down the Canopy
3
4
8
Assembly 5
Parts List 4
Spare Parts 10
Drain Holes 11
Warranty 12
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.

CAUTION
Take care not to pinch your fingers in the
frame during set up and take down.
CAUTION
Never set up or continue to use in any rain, wind,
or storm conditions, especially lightning storms.
Damage can occur to the tent and put you and
others in potential danger.
CAUTION
Avoid setting up the tent on steep inclines.
CAUTION
Do not use this tent for permanent shelter. It is
designed for temporary use only.
CAUTION
Never leave tent unattended.
Safety Instructions
WARNING: To reduce risk of injury: Before any use, be sure everyone using this unit reads and
understands all safety instructions and information contained in this manual. Save these instructions
and review frequently.
WARNING: Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock,
fire, and/or serious injury.
WARNING: Never modify the product or
any part of it. Damage or personal injury could
result.
WARNING: To reduce the risk of injury,
read the instruction manual.
If you have any questions or comments about
this or any product, call free at:
1-866-988-3300
WARNING: Dress Properly KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT
FABRIC. This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in
continuous contact with any flame source. The application of any foreign substance to the tent fabric
may render the flame resistant properties ineffective.
Avoid Dangerous Environment Don’t use canopy in damp or wet locations.
Don’t Use In Rain
Children Keep Away Keep children a safe distance from assembly area.
Must Be Staked The frame must be staked or properly weighted down at all times.
Use Caution Use extreme caution, even in light wind conditions!
Never Leave Unattended Never leave your shelter unattended! Wind and rain can cause damage to frame
and or possibly result in serious injury to you or others.
Do Not Leave Open Your Craftsman Canopy is a temporary pop-up shleter, we do not recommend leaving
the canopy open for an extended period of time.
Store Indoors When not in use, canopies should be stored indoors in dry, and high or locked-up place out of
reach of children.
Keep Away From Fire Keep all flame and heat sources well away from the fabric top. DO NOT build fires
within the shelter.
SVPUPGZB106

Cleaning and Maintenance
• Hand wash the canopy using only mild soap and water. Never use harsh detergents,
abrasives, or bleach.
• Do not machine wash.
• Never fold or store the canopy when it is wet or damp. Allow it to dry completely to
avoid mildew.
Parts List
A
Frame - 1
B
Canopy - 1
C
Carry Bag - 1
D
Guy Line - 4
E
Stakes - 8
SVPUPGZB106

Assembly
STEP 1
STEP 2
Opening the Canopy Frame (Fig. A)
Attaching the Canopy
With a person on each end, lift and partially pull the canopy apart.
Position the canopy on the center of the frame and hook the four corners of the canopy to the
four hooks on the center structure of the frame.
Fig. A
Fig. B
SVPUPGZB106

STEP 3
STEP 4
Locking the Frame (Fig. C, D)
Adjusting the Canopy Height (Fig. E)
Assembly (continued)
From under the canopy, place one hand on the upper frame and use the other hand to push the
central hub straight up until it clicks into the central pole. Finish attaching the canopy inside the
canopy frame using the Velcro loops.
Press the red button on each leg and raise or lower to adjust the canopy height.
Fig. C Fig. D
Fig. E
SVPUPGZB106

STEP 5
STEP 6
Attaching Guy Lines to Canopy (Fig. F)
Securing Canopy in Place
Assembly (continued)
Measure out from each leg to a proper distance and secure four stakes to the ground. Tie the
pre-attached ropes to the stakes in the ground. Ensure the rope has the proper tension by
adjusting the plastic adjusters on the ropes. Do not attach the ropes to the drain holes.
Fig. F
Fig. G Drain holes
SVPUPGZB106

STEP 7
STEP 8
Removing the Stakes and Shortening the Legs (Fig. H)
Collapsing the Canopy (Fig. I, J)
Taking Down the Canopy
From under the canopy, place one hand on the upper frame and use the other hand to push the
central hub straight up until it clicks into the central pole. Finish attaching the canopy inside the
canopy frame using the Velcro loops.
From under the canopy, place one hand on the upper frame and use the other hand to push the
central hub straight up until it clicks into the central pole. Finish attaching the canopy inside the
canopy frame using the Velcro loops.
Fig. H
Fig. I Fig. J
SVPUPGZB106

STEP 9
STEP 10
Folding the Frame (Fig. K, L)
Packing the Canopy in the Storage Bag (Fig. M)
Lift one corner of the frame until all legs are raised off the ground except for the 1 leg on the
opposite corner. Push inward until the frame is fully closed.
With the canopy feet facing the rollers, slide th ewheeled storage bag over the closed canopy
frame. Close the zipper on the wheeled storage bag.
Taking Down the Canopy (cont)
Fig. K Fig. L
Fig. M
SVPUPGZB106

Spare Parts
To inquire about replacement parts, please call 1-866-988-3300.
A
B
Top Cap
C
Slider
D
Ceiling Assembly
E
Eave Assembly
F
Leg Assembly
G
Leg Extend
H
Bolt Kit
I
Canopy
J
Wheeled Storage Bag
SVPUPGZB106

Drain Holes
The design team in order to improve the product experience with your canopy, has
implemented two drain holes with grommets in the top of the canopy on all four sides of the
canopy top located by the outer frame.
The design change was made to help alleviate water “ponding” on the top fabric of the
instant canopy during inclement weather due to heavy rain wind. This change will allow water
to drain efficiently from the top fabric of the instant canopy.
Please keep in mind, these drain holes are not intended for the guide ropes to be attached in
this location, please use your guide ropes in the intended areas per the instruction manual.
SVPUPGZB106

Warranty
Outdoor Furniture
IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
PLEASE DO NOT RETURN TO THE RETAILER/STORE
from where you purchased the product.
Please call our Toll-Free Customer Service Hotline at:
1-866-988-3300
To expedite any future warranty claims, please retain the instruction sheet, warranty card and
receipt for future use.
Cleaning and Maintenance
• Hand wash the canopy using only mild soap and water. Never use harsh detergents,
abrasives, or bleach.
• Do not machine wash.
• Never fold or store the canopy when it is wet or damp. Allow it to dry completely to
avoid mildew.
SVPUPGZB106

Warranty
Outdoor Furniture
1-YEAR LIMITED WARRANTY PROGRAM
For a period of one (1) year after date of purchase, the Manufacturer will either repair or replace defective
components in accordance with this Limited Warranty. This warranty is between the Manufacturer and the
original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing
original date of purchase and location of purchase. Replacements under this warranty revert back to the
date of original purchase for future warranty.
warranty applies in normal residential use only and is not intended for commercial use. The Manufacturer
can make substitutions as required of materials, components, and sub-components of comparable value
and utility. This warranty is limited to product repair or replacement (to be determined solely by the
Manufacturer). Warranty return is limited to only the single affected component.
This limited warranty covers only manufacturing defects and does not cover normal wear and tear, damage
due to acts of nature (such as, but not limited to freezing or high winds), abuse or misuse, including
chemical damage from suntan oil or other chemicals, exposure to extreme heat or cold, abrasion or
excessive weight. This product is intended to be used in standard installations only. This warranty is void
if the product is not used for its intended purpose. The Manufacturer disclaims liability for any aspect of
installation and any inconvenience caused by a defective part of a component.
Certain items are not covered by this warranty. These include, but are not limited to the following:
1. Components subjected to abuse, including abuse intended to simulate failure.
2. Damages caused by retailer, shipper or installation crew (such as scratches, dents, tears, chips, etc.).
3. Any part which merely exhibits normal wear yet functions essentially as new, including chips, scratches or
stretching of materials and stitching.
4. Tears, punctures, scratches or any damage caused by improper installation or use.
5. Damage to frames/welds resulting from improper assembly or exposure to water and/or sub-freezing
temperatures is not covered. General frame rusting is not covered.
6. Fading and/or discoloration of fabrics/cushions/straps/wicker resulting from exposure to the elements,
7. Umbrella bases are not covered under any circumstances.
To make a claim, call the toll-free number below. Please have available a copy of the original sales receipt
along with a brief description of the problem. Please also provide your email address and daytime telephone
or cell phone number. All items may be charged actual freight costs plus $15 for handling. Repairs or
replacement will be made at the Manufacturer’s option. Sales and use taxes, plus shipping and handling
charges are the responsibility of the consumer.
THIS IS THE ENTIRE EXCLUSIVE EXPRESS LIMITED LIABILITY. THE MANUFACTURER NEITHER MAKES
THOSE OF RETAILING DEALERS. THIS EXCLUSIVE REMEDY IS LIMITED TO RECEIPT OF A CREDIT IN
CONNECTION WITH THE REPAIR OR REPLACEMENT OF ANY PRODUCT OR COMPONENT DEEMED
TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER
ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED
ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED
OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED.
