RSA Lighting MINI ACCURUS RECESSED TRIM ACM5004 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Recessed Trim
Fixed position showerlight. 3.9” o.d. trim
face with 1.7” aperture. Includes bullet
plunger retainers for smooth snap-in
action during installation and removal of
trim for relamping. Helps guard against
plaster cracking.
B ...Lamp
For use with 12V MR16 lamp 50W max .
Lamp not included.
C ...Socket
Posi-Grip bi-pin socket for firm,
mechanical lamp connection. (Included
with Mini Accurus Housing sold
separately)
D...Lens
Solite™ soft focus lens with silicone
gasket included. Can hold up to one (1)
optical accessory total.
E ...Finish
Trim face is powder coated in white,
black, industrial silver, stainless
steel or primer finish for painting in
existing ceiling color. All other internal
components are flat black.
F....Safety
Steel safety cable provided. Attaches
to tab inside housing to prevent falling
during maintenance or as a result of
accidental dislodging of the trim.
G...Gasketed
Trim is assembled with 1/16” closed cell
silicone foam gasket for shower location
installations.
NOTE: Not intended for saunas or steam
rooms.
MINI
ACCURUS
RECESSED
TRIM
ACM5004
3.9” O.D.
1.7” Aperture
Round Fixed
Wet Location
Showerlight
FOR 12V MR16 50W max.
Compatible Housings:
ACM500
ACM502IC
ACM504RM
ORDERING INFORMATION
Fixture
ACM5004=
3.9” Recessed Fixed Position
Round Showerlight Trim
1.7” Aperture
3.9” small aperture fixed position round recessed showerlight trim. For
use with 12V MR16 lamp 50W max. Use with Mini Accurus housings
(ACM500, ACM502IC, ACM504RM).
For use in downlighting applications where small aperture recessed
ceiling fixtures are desired to illuminate shower locations.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Finish
WH =White
BK =Black
S =Industrial Silver
SS =Stainless Steel (painted)
PM =Primer
ACM5004
A
G
B
D
C
F
3.90” dia.
1.70"
dia.
rev 072706
