RSA Lighting QCT-2075BK User manual

35º (0º to 35º tilt) locking
angle adjustment
Ball
Detent Retainers
Steel Safety
Cable
4.00" 
Dia.
3.00" 
Dia.
Type: Project:
RSA LIGHTING 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2004 RSA Lighting All Rights Reserved • Specifications subject to change without notice. QC17
4” Adjustable Truncated Cone Trimless Fixture
w/ Internal Non-Glare Reflector
New Construction Housing - 4.75” Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
13.25"
8.22"
4.63"
7.25"
MDL
For 277 volt transformer add “277” to end of item #.
Item # Description Finish Voltage / Wattage
QCT-2075WH / QCT-900
QCT-2075BK / QCT-900
QCT-2075S / QCT-900
QCT-2075SS / QCT-900
QCT-2075PM / QCT-900
Quiet Ceiling Series Adjustable Truncated Cone Trimless
Fixture with New Construction Housing w/ Magnetic
Transformer
White
Black
Silver
Stainless Steel
Primer
12V / 75W Max.
Hanger Bars extend from
14.00” to 25.25” max.
Housing adjusts in
plaster frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
Butterfly Brackets
for commercial
installations
DESCRIPTION:
Recessed trim with internal 15otruncated
cone reflector with non-glare finish. Trim
has 360orotational and 35o(0overtical to
35otilt) angle adjustability with angle
locking mechanism in trim. Exclusive
adjustable mud ring accommodates 1/2”,
5/8”, 3/4” & 1”ceilings.
ELECTRICAL:
120V input, 12V output. Junction box is
U.L. listed for through branch wiring.
Internal rotation
ring with locking
adjustment.
Provides 360º
rotation and
secures original
trim position after
relamping or
maintenance.
CONSTRUCTION:
Housing and plaster frame: 18 gauge CRS
Trim ring, j-box and hanger assemblies:
16 gauge CRS.
SYSTEM PROTECTION:
Thermal protection provided to guard
against overheating and misuse of insu-
lation over and around fixture. Vent holes
in housing provide cooler operation.
Magnetic
Transformer
Perforated flap for secure
drywall installation
Mud Ring adjusts in plaster
frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
Ceiling mudding compound
is applied right to the edge
of the fixture.
Mudding Compound
Lamp holder can accept
up to three (3) optical
accessories
Angle Indicators
c QCT-2075WH c QCT-2075BK
c QCT-2075S c QCT-2075SS
c QCT-2075PM
w/ QCT-900 Housing
